WiT E100F User manual

Bluetooth 4.0 Energy Meter Socket
Model: E100/ E100F/ E100U/ E100C
USER MANUAL
INTRODUCTION
Thank you for purchasing our product Bluetooth
Energy Meter Socket E100. It supports iPhone 4S/ 5
and new generation iPad. We strongly recommend to
read this User Manual before you operate the
product.
E100 is a Bluetooth 4.0 Energy Meter Socket which
can seamlessly control and monitor your energy
usage of the electric appliance connected. With the
App provided, user can monitor the energy usage
and control at desired condition. User can program
the socket to turn on/ o at desired time schedule.
1 3
4 5 6 7
ENGLISH
ABOUT WiTenergy
Ratings:
E100/ E100F : 230 VAC, max 16A 3680W
E100U : 220-240 VAC, max 13A 3120W
E100C : 230 VAC, max 10A 2300W
Wireless Standard : Bluetooth 4.0
Frequency Range : 2400 – 2480 MHz
Operation Range : up to 30 meters
Environmental conditions:
Altitude: up to 2000m,
Maximum operating ambient temperature: 5°C to 35°C
Maximum relative humidity: 90%
Number of operating cycle : 3000
Circuit disconnection : Micro-disconnection
Proof tracking index PTI : 175
Pollution degree 2
- Unplug the appliance before cleaning.
- The receiver shall remain readily operable. The socket-outlet shall be
installed near the appliance and shall be easily accessible.
- If the equipment is used in a manner not specied by the
manufacturer, the protection provided by the equipment may be
impaired.
- The power meter shall be used only in area with installation category II
(CAT II) according to IEC664, in which the transient voltages do not
exceed 2500V. The mains supply for residential areas generally belongs
to this category.
SPECIFICATIONS
SAFETY INSTRUCTIONS
COUNTDOWN TIMER
OVERLOAD WARNING
GETTING STARTED
BOX CONTENTS
Your WiTenergy will contain:
1) WiTenergy main unit
2) This user manual
3) Quick start guide
2
1
2
LED INDICATOR
LED Colour Status
No LED on Output OFF and idle
Blue LED on Output ON and idle
Red LED blink Overload warning
REMOTE CONTROL
User can turn the output of smart socket to ON/ OFF
with the App.
To obtain better performance, user must ensure that
the smart socket is located within the coverage of
Bluetooth signal with your smartphone or tablet. The
receiving distance will be aected by obstacles and
building materials. It is recommended to place the
smart socket away from TV set, computer, wireless
router or any radio frequency apparatus.
To save energy cost, user need an energy monitor to
tell you how much energy is consuming by your
electrical appliance.
This smart socket has built-in non-volatile memory
which can record the energy consumption of the
electrical appliances. With the tari rate setting, the
energy cost can be calculated automatically. User can
analysis the energy consumption of their appliance
with graphical view.
This smart socket can set an overload warning with
the App. When the connected appliance exceed the
overload settings (Wattage or Current), the device
will give an overload alert by ashing Red LED or
beep sound or cut the power to the appliance. The
alert method can be set by the App via smartphone
or tablet.
SCHEDULE TIMER
This smart socket can be programmed with timer by
the App which can turn the appliance ON/ O at
desired time. The benets of setting the schedule
timer with the App is more convenient and easier
with the intuitive user interface.
To ensure safe operation of the equipment and eliminate the
danger of serious injury due to short-circuits, the following safety
precautions must be observed.
1) Do not connect after each other
2) Use indoor only.
3) Keep children and pets away.
4) Inspect periodically.
5) The unauthorized rebuilding and/or modifying of the device is
not permitted.
6) If you are not sure about the operation, safety or the connection
of the device, contact an expert.
7) Opening the equipment, service and repair work must only be
carried out by a trained person who is familiar with the relevant
regulations.
8) To avoid any hazard or misuse, please use this product only as
described in user manual.
9) Do not operate this product in wet or damp conditions, to avoid
electric shock.
10) Comply with the warning labels and other information on the
equipment.
11) Do not subject the equipment to direct sunlight or extreme
temperatures, humidity or dampness.
12) Do not subject the equipment to shocks or strong vibrations.
13) Do not operate the equipment near strong magnetic elds
(motors , transformers etc.)
14) Do not store the smart socket in a place of explosive,
inammable substances.
15) Do not modify the equipment in any way
16) The guarantee become invalid in the event of damage
resulting from non-observance or improper use of the operation
manual.
User can set a countdown timer to turn the appliance
ON/ OFF with the App. When the countdown timer
elapsed, the output of the smart socket will be turned
OFF.
This smart socket has equipped with LED indicator to
indicate the device status (see below).
MANUAL ON/ OFF
User can turn the output of
smart socket to ON/ OFF
manually by pressing the
On/ O button on the
device. The status of the
output will be shown in the
App on your smartphone or
tablet automatically.
Any unused smart socket and batteries must be disposed of according
to the local EPA regulations at the end of their service life.
Plug the WiTenergy into mains supply
WITHOUT any appliance connected. To
conrm the unit is working. Press the Manual
On/ O button and the LED indicator (Blue
colour) will blink with the key press.
Download and install the App WiTenergy
from App Store.
Follow the instructions of the App to pair the
device with your smartphone or tablet.
iPhone and iPad are the registered trademarks of Apple Inc.
ENERGY MONITORING
Pairing key during BT setup
Manual On/ O
LED indicator
WiTenergy
3
