WIZARD DRUM TOOL CO.
Wizard®
DRUM DEHEADER
OPERATING and SERVICE MANUAL
Electric, Air and Automatic Air
Models F, G & J
Serial No. _________________
Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D

TABLE OF CONTENTS
ii
MODEL DESIGNATION AND FEATURES ................................................................................................................................................. 1
GENERAL WARNINGS AND PRECAUTIONS ........................................................................................................................................... 3
SECTION 1 - GENERAL INFORMATION ................................................................................................................................................... 4
DESCRIPTION ....................................................................................................................................................................................... 4
MODEL DESCRIPTIONS (See Illustrations on Page 1) ........................................................................................................................ 4
STANDARD POWER SOURCE ............................................................................................................................................................. 4
Electric .............................................................................................................................................................................................. 4
Air ..................................................................................................................................................................................................... 4
SUPPORT TOWER ................................................................................................................................................................................ 5
WIZARD COVER LIFTER (Model F Only) ............................................................................................................................................. 5
WIZARD DEKINKER .............................................................................................................................................................................. 5
BUNG WRENCH .................................................................................................................................................................................... 5
SECTION 2 - HOW TO USE YOUR WIZARD ............................................................................................................................................. 6
BEFORE PLACING THE WIZARD ON A DRUM ................................................................................................................................... 6
PLACING THE WIZARD ON A DRUM ................................................................................................................................................... 6
STARTING THE UNIT ............................................................................................................................................................................ 6
CUTTING THE DRUM ............................................................................................................................................................................ 7
Non-Automatic Units ......................................................................................................................................................................... 7
Automatic Units ................................................................................................................................................................................. 7
SECTION 3 - REMOVING DRUM LIDS ....................................................................................................................................................... 8
CUTTING TECHNIQUE (Models F and G Only) .................................................................................................................................... 8
SECTION 4 - CUTTER WHEEL POSITIONING .......................................................................................................................................... 9
LOCATION OF CUTTING POSITION .................................................................................................................................................... 9
HEIGHT OF CUT ADJUSTMENT .......................................................................................................................................................... 9
DEPTH OF CUT ADJUSTMENT ............................................................................................................................................................ 9
Non-Automatic Units ......................................................................................................................................................................... 9
Automatic Units ................................................................................................................................................................................. 9
SECTION 5 - PROPER USE AND CARE .................................................................................................................................................. 10
SECTION 6 -- FACTORY SERVICING ...................................................................................................................................................... 10
SHIPPING INSTRUCTIONS ................................................................................................................................................................ 10
SECTION 7 -- GENERAL MAINTENANCE AND REPAIR ....................................................................................................................... 11
MAINTENANCE FOR INDUSTRIAL UNITS ......................................................................................................................................... 11
FIELD SERVICING ............................................................................................................................................................................... 11
RETAINING RINGS .............................................................................................................................................................................. 11
SWIVEL CONNECTOR REMOVAL ..................................................................................................................................................... 11
DRIVE CHAIN REMOVAL .................................................................................................................................................................... 11
HEAD REMOVAL AND REPLACEMENT ............................................................................................................................................ 12
LUBRICATION ..................................................................................................................................................................................... 12
Electric Motors ................................................................................................................................................................................ 12
Gear Reducers ............................................................................................................................................................................... 12
SECTION 8 -- CUTTER WHEEL AND DRIVE ROLLER ADJUSTMENT AND MAINTENANCE ............................................................. 12
CUTTER WHEEL OR DRIVE ROLLER REMOVAL AND REPLACEMENT FROM FRONT SHAFT .................................................. 12
CUTTER WHEEL OR DRIVE ROLLER REMOVAL AND REPLACEMENT FROM REAR SHAFT. .................................................... 12
SECTION 9 -- SHAFT ASSEMBLIES ........................................................................................................................................................ 13
FRONT SHAFT REMOVAL AND REPLACEMENT ............................................................................................................................. 13
REAR SHAFT REMOVAL AND REPLACEMENT ................................................................................................................................ 13
SECTION 10 -- TROUBLESHOOTING PROCEDURES ........................................................................................................................... 15
ELECTRIC MODELS ............................................................................................................................................................................ 15
Unit does not run (may also give off sparks) .................................................................................................................................. 15
Unit stalls or does not start ............................................................................................................................................................. 15
Unit does not cut drums .................................................................................................................................................................. 15
Unit is unstable – wobbles while traveling around drum ................................................................................................................. 15

TABLE OF CONTENTS
iii
Top drum head cannot be removed (Model F) ............................................................................................................................... 15
Unit does not run or cut .................................................................................................................................................................. 15
AIR MODELS ....................................................................................................................................................................................... 16
Unit does not run ............................................................................................................................................................................ 16
Unit runs too slow ........................................................................................................................................................................... 16
Unit does not cut drums (Manual models) ...................................................................................................................................... 16
Unit does not cut drums (Automatic models) .................................................................................................................................. 16
Top drum head cannot be removed (Model F) ............................................................................................................................... 16
Unit does not run or cut .................................................................................................................................................................. 16
SECTION 11 – PARTS LISTS ................................................................................................................................................................... 17
ALL THREE UNITS .............................................................................................................................................................................. 17
SECTION 12 -- GLOSSARY ...................................................................................................................................................................... 21

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
1
Model Designation and Features
Standard Duty WIZARD Drum Openers come in three basic models (F, G and J). Each model opens a drum in one of three ways:
1) (OC) cutting around the outside diameter of the chime (the flat or round rim that fastens the lid to the drum).
2) (IC) cutting around the inside diameter of the chime.
3) (OS) cutting around the drum shell below the chime.
All models operate on either air or electricity. Air driven models F, G and J are also available with an air driven regulator to
automatically maintain cutter wheel force through an integral air cylinder. The following table shows the eleven currently available
variations of the four standard duty basic model groups:
Model
Power Source
Auto.
Type
Color
Comments
No.
Air
Elec.
Air
Of Cut
FS
X
NO
OC
White
USDA approved for Food industry applications.
FA
X
NO
OC
White
Same as FS. Recommended for washdown areas
RFA
X
YES
OC
White
Same as FS but with cutting pressure automatically
maintained.
GS
X
NO
IC
Yellow
For general purpose use. Reuse or scrap drum.
GA
X
NO
IC
Yellow
Same as GS.
RGA
X
YES
IC
Yellow
Same as GS but with cutting pressure automatically
maintained.
JS
X
NO
OS
Blue
Scrap drum.
JA
X
NO
OS
Blue
Same as JS.
RJA
X
YES
OS
Blue
Same as JS but with cutting pressure automatically
maintained.
Model FA
Model RGA
Model JA
Model GS

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
2
SERIAL NUMBERS: Always specify model and serial number (located on housing nameplate) in correspondence and parts requests. This identification
is the key to many engineering details applying to your deheader.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
3
GENERAL WARNINGS AND PRECAUTIONS
ATTENTION
This section must be read thoroughly before operating any equipment
supplied by WIZARD Drum Tool Co. Failure to do so may result in damage
to equipment and/or severe injury to personnel.
• When using the unit, make sure you are wearing all personal safety equipment such as gloves, safety glasses, and
steel toe boots.
1. To avoid serious injury or death from electrical shock, make certain the unit is properly
grounded.
2. Do not operate any of the electrical units in wet areas.
3. Always use the correct voltage supply as indicated on the unit motor nameplate.
4. Do not use power cord if damaged or frayed.
1. Flip switch to “OFF” position.
2. In the event of a temporary power loss, there is the potential that the unit may be
restarted automatically if the power switch is left in the “ON” position!
3. Keep all body parts away from the cutter wheel and roller whenever the power is on!
4. If the unit stalls due to blockage between the cutter wheel and the roller, always turn the
unit off before attempting to dislodge any debris!
5. The chime of a cut drum may be sharp! Caution should be used when attempting to
remove the lid from the drum. It is recommended that leather work gloves be worn when
handling cut chimes.
6. Disconnect the power supply (electrical or air) before performing any maintenance on the
unit!
7. Do not operate unit on flooring that is not level. The drum may tip over during operation.
The following applies to units purchased for use in non-explosive environments:
1. Do not use any of the units to remove the lids off drums which may contain explosive
materials.
2. THE UNITS ARE NOT TO BE OPERATED IN EXPLOSIVE ENVIRONMENTS!
3. Extreme care must be taken so that the unit is not operated in any manner to potentially
ignite the drum contents and/or any explosive material.
ELECTRICAL
HAZARD
MECHANICAL
HAZARD
EXPLOSIVE
HAZARD

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
4
SECTION 1 - GENERAL INFORMATION
DESCRIPTION
The WIZARD drum openers are portable, self-propelled and
designed to cut the tops and/or bottoms of standard, 30-55
gallon (208 liters) steel drums up to 16 gauge.
All models are available with either an electric or air motor.
Models F, G and J are available with an automatic air powered
cutting feature.
WIZARD designs all its drum deheaders for long life, maximum
reliability and simplified maintenance. Modular construction
permits easy disassembly and adjustment, making parts
accessible for repair or replacement with a spare.
MODEL DESCRIPTIONS (See Illustrations on Page 1)
Model F opener (white) includes USDA-compliant parts and an
USDA-approved cutting method that cuts on the OUTSIDE of
the drum chime. Designed specifically for food industry aseptic
drums, no part of the Model F touches the drum contents. The
outside cut also prevents dirt, paint chips or other debris from
falling into the drum and contaminating its contents when
opening the drum. The drum deheader’s patented, continuous
cutting operation and round cutter wheel leave a completely
smooth edge, free of slivers or burrs. The drum lid remains
secure to protect the drum contents until it is removed with a
cover lifter.
The Model G opener (yellow) cuts on the INSIDE of the drum
chime and leaves a smooth burr-free edge for safe handling.
This versatile model is considered a general purpose opener
because opened drums can either be used for utility containers
or sold for scrap. This model has a small, 1-1/2" diameter
cutter wheel that travels between the chime and bung fittings
as it cuts. It is designed to open standard, 30-55 gallon
industrial drums of up to 16-gauge steel with either flat or
round chimes.
CAUTION
(For model J) Since the lid becomes completely separated from the
drum when cut, the unit has the potential to fall off the drum. Use
caution!
Model J opener (blue) cuts the drum shell BELOW the chime.
This model was designed for drum disposal because it
removes the entire drum head. Removing both top and bottom
heads of a drum makes it easy to flatten or crush the drum,
store it and later sell it for scrap.
STANDARD POWER SOURCE
WARNING
To avoid serious injury or death from electric shock, make sure the
unit is properly grounded and do not use the electric model in wet
areas.
Electric
Totally enclosed, fan cooled, permanently lubricated helical
gear/needle bearing gear motor. Furnished standard with 1/3
HP, 110 volt single phase, 60 Hz, electric drive and swivel
connectors matching standard single grounding plugs.
Deheaders are also available in 220VAC 50/60Hz
configurations. Satisfactory operation requires a 14ga or larger
3 prong plug properly grounded to earth ground.
Air
Variable speed, vane-type air motor and speed reducer.
Develops approximately 1/2 HP at 40 psig (275 kPa) (with 25
cfm (0.71 m3/min) free air. Best performance is generally
achieved with 80-100 PSIG air. Furnished with quick-
disconnect coupling for 1/4 inch MINIMUM diameter air line.
For long air hose runs we recommend larger 3/8 or 1/2 inch
diameter hoses.
Also, for proper operation and maximum service life you MUST
place pneumatic oil in the air line feeding into the motor.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
5
SUPPORT TOWER
We recommend using a
WIZARD Tower to suspend
your WIZARD Drum Opener.
The tower keeps the opener
at working height and also
prevents the opener from
being dropped or from falling
off a wobbly drum.
WIZARD COVER LIFTER (Model F Only)
After the WIZARD cuts the chime the lid is ready to be lifted
vertically off the drum
with a WIZARD Cover
Lifter. The cover lifter
will remove a properly
cut lid quickly and
easily. Drum lids may
be reused to cover
drum.
WIZARD DEKINKER
Easily straightens bent or dented
chimes so your WIZARD Drum
Openers can operate with
maximum efficiency. Reseals
leaking drums caused by bent
chimes.
BUNG WRENCH
All-plug universal wrench
easily, safely opens all known
styles of American and foreign-
made bungs and fittings.
Ductile iron and non-ferrous
style are available.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
6
SECTION 2 - HOW TO USE
YOUR WIZARD
BEFORE PLACING THE WIZARD
ON A DRUM
1. See Figure 1. Remove the plugs
from the bung fittings with a WIZARD
WRENCH (1 and 2).
2. Hammer down the bungs so they
do not block or interfere with either the drive roller or cutter
wheel. Note: For Model G with 1-1/2" diameter cutter wheel,
only hammer bungs less than 1-1/2" from the drum chime.
3. Straighten any bent chime using a WIZARD Dekinker or
hammer them into original contour (3).
4. Make sure the cutter wheel is in the retracted position, away
from the drive roller to allow chime clearance.
Non-Automatic Units: Turn the adjusting screw handle about
six turns counterclockwise.
Automatic Units: Turn on supply air to the drum opener and
push/pull the plunger button of the air valve.
PLACING THE WIZARD
ON A DRUM
1. See Figure 2. Place the
WIZARD on the drum so the
chime rollers ride on the top
of the chime. If using an
automatic air unit, push/pull
the plunger button of the air
valve to engage the cutter
wheel and skip step 3 below.
Dropping the Wizard on the
chime may damage the cutter
wheel.
2. Check the unit for proper
cutter height position.
The cutter height
position is factory set;
however, you may need
to make some minor
adjustments. Please
refer to section (4)
before continuing.
3. Refer to Figure 1. Turn
the adjusting screw handle (4) clockwise until the cutter
wheel just touches the chime (3). The cutter wheel must
not bite into metal at this point. Excess pressure prevents
the electric or air motor (5) from reaching operating speed
which may overload motor. The Warranty does not cover
motor damage caused by overload.
STARTING THE UNIT
Many operators place the electric cord or air line over their left
shoulder to keep it clear of the WIZARD. This also prevents the
cord or line from wrapping itself around the drum as the opener
rotates around the drum. Both the electric socket and the air
line connector swivel 360o to prevent the line/cord from
twisting during rotation.
Electric models have a toggle switch on the side of the handle.
Air driven models have a ball valve located on the air line and
an air regulator to adjust the rate of travel.
WARNING
DO NOT FOLLOW THE WIZARD AROUND THE DRUM.
Stand in one place and keep the cord or line out of the
WIZARD's path. Let the WIZARD make one complete
revolution and check for interference from bungs or chime.
Figure 1
Figure 2
Handle Assy.
Drive Unit
(Electric
or Air)
Motor
Bracket
Guide Rollers
Housing
Body
Front Shaft
Adj.
Screw
Assy.
Rear Shaft
CAUTION

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
7
CUTTING THE DRUM
Non-Automatic Units
1. Without stopping the drive unit, use HAND ACTION ONLY
to turn the adjusting screw handle about 1/4 turn clockwise.
DO NOT USE pipe, rod, or any other leveraging device to raise
cutting force. Excessive cutting force may damage the housing
body.
2. If you stop the unit for any reason, turn the adjusting screw
handle 1/4 turn counterclockwise before you restart. This
prevents overloading the drive unit.
3. After each revolution of the WIZARD around the drum, turn
the adjusting screw handle another 1/4 turn clockwise. This
gradually raises pressure on the cutter wheel so it can cut
through the drum or outer chime layer of metal. As the metal
splits, it makes a popping or cracking sound. Usually only 2 to
5 revolutions are enough to cut through the metal.
4. After you finish cutting the drum or its chime, turn the
adjusting screw handle six turns counterclockwise to retract the
cutter wheel. Tilt the WIZARD toward the center of the drum lid
and lift the WIZARD off the drum.
Automatic Units
1. Apply air to the opener and push/pull the plunger button of
the air valve. With the cutter wheel engaged, the cutting action
is automatic as the WIZARD travels around the drum. As the
metal splits, it makes a popping or cracking sound. Usually
only 2 to 5 revolutions are enough to cut through the metal.
2. After you finish cutting the drum or its chime, push/pull the
plunger button of the air valve to disengage the cutter wheel.
Tilt the WIZARD toward the center of the drum lid and lift the
WIZARD off the drum.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
8
SECTION 3 - REMOVING DRUM LIDS
Model F - The WIZARD Cover Lifter will remove a properly cut
lid quickly and easily.
Model G - A soft hit with a long-handled mallet on the top of
the drum lid will usually dislodge it and, depending on where it
is hit, will either fall to the bottom of the drum or tip sideways
so it can easily be removed. Drum lids are sharp so care
should be taken.
Model J - After the drum shell is cut the top is free to be lifted
off the drum.
CUTTING TECHNIQUE (Models F and G Only)
The correct way to open a drum is to cut cleanly through only
the single outer metal layer of the chime. If the cut is too
shallow, it is difficult to remove the head. If the cut is too deep,
the cutter wheel life is shortened. With some practice, judging
optimum cutting depth is easily done.
Figure 3A Model F
Figure 3B Model G

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
9
SECTION 4 - CUTTER WHEEL POSITIONING
Accurate positioning of the cutter wheel on the drum chime is
critical to getting the best performance from your WIZARD
Drum Opener. Read Section 4 carefully and check periodically
for proper cutter wheel positioning.
LOCATION OF CUTTING POSITION
Model F - Figure 3A. The cutter wheel shoulder must contact
the bottom edge of chime when the cutter knife edge just
meets the chime. However, the shoulder must actually touch
the chime. The knife edge of the cutter wheel should be from
1/8" to 5/32" (3.1 to 3.9 mm) below the top of the chime.
Model G - Figure 3B. The drive roller flange should just clear
the underside of the chime. The cutter wheel should be
approximately 1/8" (3.1 mm) or more above the drum lid.
Figure 3C Model J
Model J - Figure 3C. The cutter knife edge should contact the
drum only far enough under the chime to clear it.
HEIGHT OF CUT ADJUSTMENT
The chime roller settings control the height of the cut. Because
of the variety of drums, you must sometimes change this
factory set adjustment. The procedure is the same for all
models. Refer to Figures 3A through 3C above, and set the
height of the cut as follows:
1. Place the drum opener on the chime as described in
Section 2.
2. Using two 9/16" open or box end wrenches, loosen the
chime roller screw while holding the adjustment screw
(Figure 4).
3. The chime roller axle (shaft) is eccentric to the outside
diameter (Figure 4). Turn the adjustment screw while holding
the chime roller screw to raise or lower the cutting position.
4. Hold the adjustment screw and tighten the chime roller
screw.
5. Repeat steps 2 through 4 on the second chime roller to
level the opener on the drum.
NOTE
To be sure that the drum opener is sitting level on the drum, check
that the bottom edge of the housing body is parallel with the top
edge of the drum chime.
6. Engage the cutter wheel either by turning the manual
adjusting screw handle (non-automatic units) or by applying air
to the drum opener and pressing the top button on the air valve
(automatic units). Observe the cutter wheel position and
compare it to the appropriate figures.
7. Retract the cutter wheel and repeat the procedure until the
cutter wheel position is correct.
NOTE
All of the Part numbers in the following sections refer to the three
exploded views and parts lists in Section 11.
DEPTH OF CUT ADJUSTMENT
Since the cutter wheel wears during normal use, you must
occasionally change the factory setting for depth of cut.
Non-Automatic Units
1. Loosen the nuts on the adjusting screw handle and back
them away from the housing body.
2. Make an experimental cut to determine the cutting depth
needed to penetrate ONE layer and stop the machine at this
setting.
3. Turn the nuts back against the housing body and tighten
them together.
Automatic Units
1. Remove the lower linkage guard.
2. Loosen the set screw in the pressure rod boss on the front
of the housing body.
Figure 4

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
10
3. Turn the pressure rod guide (3111) into the housing body.
4. Make an experimental cut to determine the cutting depth
needed to penetrate ONE layer and stop the machine at this
setting.
5. Turn the pressure rod guide out of the housing body until it
contacts the flat of the pressure rod (3112).
6. Tighten the set screw.
7. Replace the lower linkage guard before operating the unit.
SECTION 5 - PROPER USE AND CARE
With proper use and care your WIZARD Drum Opener will give
you long and dependable service.
1. Lubricate the unit properly. Refer to Section 7.
2. Do not drop your drum opener. If unit falls and damage is
excessive or unit fails to operate, call for factory assistance.
3. Be certain your electrical connections and air line hookups
leading to the drum opener are correct and safe.
4. DO NOT use any kind of levering tool on the manual
adjusting screw handle. Excessive force may damage your
drum opener.
5. Occasionally wire-brush the drive roller serration’s.
6. All of the components of the front and rear shaft are drawn
together using a self-locking nut which contains a nylon
threaded insert. When properly tightened, all axial play should
be removed from each shaft and some drag should be felt in
the bearing when rotating the shaft. Check periodically that the
front and rear shafts are tight and refer to Section 9 for proper
shaft maintenance if they are not. If the shaft tightness requires
repeated attention, the self-locking nut is worn and should be
replaced.
SECTION 6 -- FACTORY SERVICING
Send units requiring major service to the factory. WIZARD will
make a repair estimate and perform the repair only after your
authorization is given.
NOTE: Please Contact Factory for Return Authorization before
Returning Unit.
SHIPPING INSTRUCTIONS
When returning openers to the factory:
1. Get return authorization number from factory.
2. Clean all exterior and accessible parts.
3. Fasten an identification tag to your machine. The tag should
show your company name and shipping address, and the
model and serial number of your unit.
Ship PREPAID to:
WIZARD Drum Tool Company
400 Pilot Court
Waukesha, WI 53188
COD shipments are not accepted.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
11
SECTION 7 -- GENERAL MAINTENANCE AND
REPAIR
WIZARD designs all its drum openers for long life, maximum
reliability and simplified maintenance. Modular construction
permits easy disassembly and adjustment, making parts easily
accessible for repair or replacement with a spare.
MAINTENANCE FOR INDUSTRIAL UNITS
Daily checks should be:
• Make sure all nuts and bolts are securely fastened
• Check cutter wheels for any chips and/or wear
• Check drive roller for wear
• Check proper alignment of chime rollers
• Make sure there is no binding of any gears or
bearings
• Make sure drive roller is free of debris
Bi-monthly checks:
• Take nameplate off to make sure there is enough
grease on gears
• Check air lines for cracking and pinching
• Check electrical lines for cracking and pinching
• Check T-handle for wear or thread damage
WARNING
Always use personnel safety equipment (PSE) when using this
machinery.
The grease we prefer is food grade grease. It is safer for the
environment.
FIELD SERVICING
Light servicing and maintenance is possible with ordinary hand
tools. Replacement parts are available from factory stock. Use
and experience will determine which parts to keep on hand for
routine maintenance, such as cutter wheels or shaft
assemblies. Call a certified Wizard technician for all questions.
Study the exploded view drawings in Section 11 and note
relative positions of the parts before disassembly.
NOTE
Disconnect any electrical or air pressure supply from the drum
opener before attempting to conduct any maintenance or repair
RETAINING RINGS
The pivot pin (3070) and one end of the rear shafts (3510 and
3512) have snap rings. You can easily remove these with snap
ring pliers.
SWIVEL CONNECTOR REMOVAL
To remove the swivel from your WIZARD Opener, follow these
simple steps:
1. Unplug the opener from the power outlet.
2. Remove the four 1/8" socket head cap screws (2144)
holding the two handle halves together.
NOTE
It is not necessary to remove the entire handle.
3. Remove the two hex head cap screws (2106) holding the
handle to the housing body from the handle half that is
opposite from the power cord. Second half of handle remains
attached to housing body. (DO NOT DISTURB THE DRIVE
CHAIN.)
4. Disconnect motor leads from power switch and from one
swivel connector lead.
5. Disconnect remaining swivel connector lead from power
switch and remove swivel connector.
6. To install new swivel, refer to wiring instructions included
with replacement swivel.
DRIVE CHAIN REMOVAL
Remove the drive chain (3190) by following these simple
steps:
1. Remove the handle by removing the four hex head cap
screws (2106) holding it to the housing body.
2. Open the chain at the connecting link, being careful not to
lose the spring clip, and install new chain.
Or as an alternative:
1. Remove lower two nuts and cap screws from motor bracket
and loosen or back off the top two nuts and cap screws about
halfway to allow motor to tilt to a 30-45 degree angle. With
motor tilted, chain becomes slack and can easily be removed
from sprockets.
2. Install new replacement chain on smaller motor sprocket
first and then on larger driven sprocket.
NOTE
If chain is too loose, remove slack by inserting flat washers or
shims between the motor feet and bracket.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
12
HEAD REMOVAL AND REPLACEMENT
For convenience and easy handling during maintenance
operations, you may want to separate the head assembly from
the drive unit and handle assembly.
1. Remove the handle assembly by removing the four hex
head cap screws holding it to the housing body.
2. Remove the four cap screws holding the motor to the motor
bracket.
3. Remove the four cap screws holding the motor bracket to
the housing body.
4. Disengage the larger sprocket (3180) from the chain.
NOTE
During head assembly, make sure to put the chain back on the
sprocket before installing the motor bracket. Install the lower
screws first when attaching the bracket.
LUBRICATION
Periodically lubricate your WIZARD as follows:
1. Remove one side plate from the housing body.
2. Apply a generous amount of light grease to the shaft gears.
Use Loctite Food Grade Grease NLGI #2, or equivalent,
on all Model G and J openers. Use a food grade grease or
equivalent on all Model F openers.
3. Grease pack bearings any time shaft is disassembled.
Repack at any time if grease becomes dry or caked.
Electric Motors
The gear motor gets a lifetime lubrication at the factory with
permanent, heavy fluid gear oil, so it should not be necessary
to lubricate the gear motor.
Gear Reducers
Check the gearbox grease annually. If unit requires additional
grease, use EP-O or equivalent. For proper operation and
maximum service life, you MUST oil your inlet air line ports
SECTION 8 -- CUTTER WHEEL AND DRIVE ROLLER
ADJUSTMENT AND MAINTENANCE
All machine tool cutting edges become dull through regular
use. Although the WIZARD cutter wheel is made from high-
grade hardened tool steel, it will eventually lose its edge after a
lot of cutting. If the WIZARD needs more than 7 or 8
revolutions to dehead a drum, the cutter wheel may be dull. If
the cutter wheel or drive roller becomes badly worn or chipped
replace them as follows:
CUTTER WHEEL OR DRIVE ROLLER REMOVAL AND
REPLACEMENT FROM FRONT SHAFT
1. Make sure cutter wheel or drive roller is in the retracted
position. Remove T-handle.
2. Loosen set screws on gears. They have to be lowered to
remove assembly.
3. Remove one snap ring holding the pivot pin (3070) in place.
Remove the pin from the housing body.
3. Drop the front shaft carrier assembly downward and remove
it from the housing body.
4. Remove the cotter pin and then the slotted hex nut from the
front shaft.
5. Remove the set screw from the gear.
6. Remove the woodruff key from the shaft and disassemble
the carrier assembly. The drive roller or cutter wheel may be
difficult to remove because of the tight fit.
7. Install the new drive roller or cutter wheel on the top end of
the shaft. Reassemble the carrier assembly, doing each step in
reverse order of disassembly.
8. Install the front shaft carrier assembly in the housing body.
Insert the pivot pin and attach the snap ring.
CUTTER WHEEL OR DRIVE ROLLER REMOVAL AND
REPLACEMENT FROM REAR SHAFT.
1. Remove one side plate from the housing to expose the
shaft gears (3100). Block the gears to prevent the shaft (3510
or 3512) from turning.
2. Remove the lock & jam nuts holding the cutter wheel or
drive roller in place. Remove the cutter wheel or drive roller
from the shaft.
3. Inspect woodruff key and replace if worn.
4. Install the new cutter wheel or drive roller on the shaft and
secure it with the lock & jam nuts. Tighten until all vertical play
disappears and there is a slight drag on the bearings.
5. Free the gears and install the side plate.
6. Make sure gears align and tighten set screws.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
13
SECTION 9 -- SHAFT ASSEMBLIES
FRONT SHAFT REMOVAL AND REPLACEMENT
1. Remove the front shaft carrier assembly and its drive roller
or cutter wheel as described in Section 8.
2. Remove slotted hex nut & cotter pin and loosen the set
screw holding the shaft gear (3100). Remove the shaft (3499)
from the assembly, drawing the shaft downward and through
the gear.
NOTE
The bearing cups (outer races) are press-fitted and almost never
need replacing.
3. Replace any worn parts and assemble the shaft as follows:
NOTE
If you remove the bearing cups and there is no press equipment
for installation, use a soft hammer to tap the cups into position.
When resetting the cups, insert a support in the gear cavity to
prevent its deformation under pressure. (See Figure 5.)
4. Install the drive roller or cutter wheel with its woodruff key
(3130) on the bottom of the shaft.
5. Slide the shaft through the lower bearing (3090), gear
(3100) and upper bearing (3090). Be sure the gear's woodruff
key is in place, but do not tighten the gear setscrew at this
point.
6. Install the top slotted hex nut & cotter pin. Tighten until all
end play disappears and there is a slight drag on the bearings.
7. Install the front carrier assembly in the housing body. Install
the pivot pin (3070) and its snap rings (3120).
8. Align the shaft gears (3100) and tighten the set screw.
REAR SHAFT REMOVAL AND REPLACEMENT
1. Remove the four hex head cap screws (2106) holding the
handle to the housing body. Remove the handle, but do not
disconnect the motor leads or air line.
2. Remove one side plate from the housing body and block
the shaft gears (3100).
3. Unscrew the lock & jam nuts from the lower end of the rear
shaft. Remove the cutter wheel or drive roller and its key from
the shaft.
NOTE
The cone of the lower bearing is now free to drop out.
4. Remove the lower bearing cone (3090A).
NOTE
The bearing cups (outer races) are press-fitted and almost never
need replacing.
5. Remove the snap ring (3120) from the upper end of the
shaft and remove the sprocket (3180) and its key (3130) from
the rear shaft (3510).
6. Remove the spacer (3110) from the shaft on Models FS, FA
and RFA and loosen the set screw on the shaft gear (3100).
7. Draw the shaft downward through the upper bearing and
shaft gear, out of the housing body.
NOTE
The top bearing cone and shaft gear are now free for removal.
8. Replace worn or broken parts. If the bearing cups need
replacement, see NOTE and Figure 5 at left. Assemble the
rear shaft as follows:
9. Install the snap ring (3120) on the rear shaft.
10. Insert the top woodruff key (3130) in the shaft and install
the sprocket gear (3180) on it. Gently tap the sprocket into
position using a soft mallet.
11. Install the spacer (3110) on the shaft.
12. Install the bearing (3090) on the shaft.
13. Install the second woodruff key (3130) on the shaft.
14. Position the shaft gear (3100) in the gear cavity.
Figure 5

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
14
15. Insert the shaft through the top bearing cup into the gear
housing, through the shaft gear (3100), and through the bottom
bearing cup. Install the shaft gear over its key (3130), tapping
lightly with a soft mallet to seat it.
16. Install the lower bearing (3090).
17. Install the cutter wheel or drive roller and the last woodruff
key (3130) on the shaft.
18. Install and tighten the bottom lock & jam nuts. Tighten until
all end play disappears and there is a slight drag on the
bearings.
19. Align the shaft gears (3100) and tighten the set screws.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
15
SECTION 10 -- TROUBLESHOOTING PROCEDURES
ELECTRIC MODELS
Problem
Possible Cause
Remedy (see note below)
Unit does not run (may also give off sparks)
Faulty power connection.
Check replace line cord.
Swivel connector broken.
Replace swivel connector.
Power switch broken.
Replace toggle switch.
Loose electrical connection.
Check wiring inside handle.
Unit stalls or does not start
Excessive pressure on cutter wheel (manual
units only).
Back off adjusting screw handle (manual models
only).
Unit does not cut drums
Cutter wheel dull or chipped.
Reset position of locknuts on adjusting screw
handle to obtain more cutting depth.
Replace cutter wheel
Cutter wheel does not penetrate deep enough to
get through layer of metal.
Reset position of locknuts on adjusting screw
handle to obtain more cutting depth.
Not enough cutting passes around drum.
Increase the number of cutting passes.
Adjusting screw handle bottoms out (manual
units only).
Adjust locknuts for greater travel on adjusting
handle (manual units only).
Not enough pressure (force) on cutter wheel.
Tighten adjusting screw handle.
Unit is unstable – wobbles while traveling
around drum
Chime rollers out of alignment.
Adjust chime rollers until unit is level.
Drum chime kinked.
Straighten chime using WIZARD Dekinker.
Drum shell dented.
Guide unit past dented area.
Top drum head cannot be removed (Model F)
Outer metal chime layer not cut completely
through.
Tighten cutter wheel adjusting screw (manual
units only. Increase the number of cutting
passes.
Cut location too low.
Cut above center of chime.
Cutter wheel not penetrating metal.
Replace dull or chipped cutter wheel.
Improper pry tool used to remove lid.
Use WIZARD cover lifter.
Unit does not run or cut
Defective motor.
Replace motor.
Gears in body housing not meshing.
Adjusting screw out too far – adjust.
Woodruf key sheared or missing.
Check all shaft parts for Woodruf keys.
Cutter wheel/drive roller hits bung.
Hammer down bungs for clearance.
Drive roller worn or dirty.
Replace or clean drive roller serrations with a
wire brush.
NOTE: Please Contact Factory or Hydro-Thermal Technician for Return Authorization before Returning Unit.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
16
Troubleshooting (cont.)
AIR MODELS
Problem
Possible Cause
Remedy (see note below)
Unit does not run
Insufficient air pressure.
Check air supply, compressor and/or regulator.
Clogged air lines.
Check air connections.
Air motor frozen or jammed.
Reverse air line to free vanes. Check air line
lubricator for oil.
Faulty throttle/sleeve valve
Replace valve.
Unit runs too slow
Air pressure too low
Increase air pressure.
Excessive pressure on cutter wheel (manual
models only).
Back off adjusting screw handle (manual models
only).
Unit does not cut drums (Manual models)
Cutter wheel dull or chipped.
Replace cutter wheel.
Cutter wheel does not penetrate deep enough to
get through layer of metal.
Reset position of locknuts on adjusting screw
handle to obtain more cutting depth.
Not enough cutting passes around the drum.
Increase the number of cutting passes.
Adjusting screw handle bottoms out.
Adjust locknuts for greater travel on adjusting
handle.
Insufficient pressure (force) on cutter wheel.
Tighten adjusting screw handle.
Unit does not cut drums (Automatic models)
Not enough cutting passes around the drum.
Increase the number of cutting passes.
Air pressure too low
Increase air pressure.
Insufficient pressure rod travel to obtain
necessary cutter wheel force.
Reset pressure rod guide screw for greater
pressure rod travel.
Loss of air pressure in cylinder.
Replace seals and O-rings in cylinder.
Unit is unstable – wobbles while traveling
around drum
Chime rollers out of alignment.
Adjust chime rollers until unit is level.
Drum chime kinked.
Straighten chime using WIZARD Dekinker.
Unit running too fast.
Reduce air motor pressure.
Drum shell dented.
Guide unit past dented area.
Top drum head cannot be removed (Model F)
Outer metal chime layer not cut completely
through.
Tighten cutter wheel adjusting screw (manual
units only. Increase the number of cutting
passes.
Cut location too low.
Cut above center of chime.
Cutter wheel not penetrating metal.
Replace dull or chipped cutter wheel.
Improper pry tool used to remove lid.
Use WIZARD cover lifter.
Unit does not run or cut
Defective air motor.
Replace air motor.
Gears in body housing not meshing.
Adjusting screw out too far – adjust.
Woodruf key sheared or missing.
Check all shaft parts for Woodruf keys.
Cutter wheel/drive roller hits bung.
Hammer down bungs for clearance.
Drive roller worn or dirty.
Replace or clean drive roller serrations with a
wire brush.
NOTE: Contact Factory for Repair Authorization before Returning Unit.

Wizard Drum Opener Operating and Service Manual; Version 2.0, Rev D
17
SECTION 11 – PARTS LISTS
ALL THREE UNITS
PART NO.
DESCRIPTION
QTY
1117-5
STUD THREADED
1
1358
ROUND 2.00" DIA.
1
1386
ROUND 1.00" DIA.
5
1780
ROUND 2.00" DIA.
3
1786
ROUND 2.00" DIA.
3
11340
ORING #2-016 EPDM
1
1807
ROUND 2.25" DIA
1
1840
ROUND .749" , G&P
10
1876
ROUND .75" DIA.
0
2144
SCREW CAP SOC
4
2222
SCREW SELF TAP
1
3043
COVER
1
3046
SHAFT
1
3047
SHELL, SWIVEL, 3
1
3053
INSERT THREADED
8
3054
INSERT THREADED
1
3058
BRACKET ROLLER
2
3062
INSERT 0.625" OD X
1
3090B
BEARING CUP
2
3091
BEARING BALL
1
3201
HANDLE FOR
1
3203
ROD THREADED
1
3270
TEMINAL ELEC
1
3291
PLUG ELECTRICAL,
1
3293
NUT WIRE 73B
2
3835
RING NEUTRAL,
1
3838
RING HOT,
1
3840
RING GROUND,
1
5313
NUT HEX JAM
3
5608
WASHER LOCK
1
6604
WIRE WHITE (FOR
1
6605
WIRE BLACK (FOR
1
6606
WIRE GREEN (FOR
1
6620
BRUSH WIRE
1
6621
BRUSH WIRE HOT
1
6622
BRUSH WIRE
1
6630
TUBING .50" DIA.
1
C0011
CASTING BODY
1
C0014
CASTING CARRIER
1
C0016
CASTING HANDLE,
1
11684
VALVE, BALL, 0.25"
1
11685
AIR PRESSURE
1
11686
GUARD LINKAGE
1
11687
GUARD LINKAGE
1
12111
RETAINING RING
1
2104
SCREW CAP HX HD
3
2106
SCREW CAP HX HD
8
