WLANthermo Mini User manual

Quick Start Guide
www.wlanthermo.com

2 Index
3 Hardware
3 Front
3 Back
4 First Steps
4 1. First Start
5 2. WLAN connection
7 3. Display Menu
8 4. Channels
11 5. Pitmaster
15 GUI
16 Credits
Index:
2

Hardware:
Front:
Back:
Channels: 0 – 1 – 2 – 3
4 – 5 – 6 – 7
Fan/Relay – Servo – Fan/Relay
Micro USB (5V-Input) – USB (WLAN-Stick)
Ports:
Ports:
3

First Steps:
1. First Start:
Make sure that the WLAN-Stick is connected and connect the
Power(5V/≥2A) to the WLANThermo Mini.
It will boot into the Home-Menu. There is a problem with the
hardware if you do not see the Home-Menu after 10 sec.
Settings
Channels Pitmaster
Shutdown
4

2. WLAN conection:
Press the cogwheel symbol » to get to the Settings
now the WIFi symbol »
By pressing on Connect » it starts searching for available wi net-
works. Select a network and key in the passphrase.
If the connection is sucsessfull a IP-adress will apear next to
“wlan0”. This IP is needed to reach the GUI with your browser –
further information on page 15. 5

3. Display Menü:
That symbol will bring you back to the previous screen »
With the cogwheel symbol » screen symbol » you canchange the
brighness and the timespann when the dispay should swich in
standby mode
ONLY the display is in stanby!! The thermometer stays up and
running. By pressing the display it will switsch on instandly.
6

4. Channels:
To get to the Channel page press the thermometer symbol » now
you see the 8 channels (numbered 0-7) and, if aktiv, the pitmaster.
It shows the actual-/target temperature and the actuator’s perfor-
mance from 0%-100%
If an alarm is set off a speaker symbol » appears in the left upper
corner and there is a acustic signal – the channel turns
red if the set temperature is exceed and blue if it falls below.
To cancle the acustic signal just press on the speaker symbol » it
will apear struck through. In case of another alarm there will be
again a acustic signal. The alarm will activate it self if all channels
are in the set termerature range again.
7

By presssing on a Channal » it is possible to set the min/max
temperature of the channel and select the type of probe you are
using. The meat symbol » allows you to select a variety of tem-
peratures for different meats.
Using the jack symbol » you can select the probe you are using.
Without a changeing the resistors in the hardware only the listed
probes can be used.
Tip: the original Maverick probe has a to long jack so it must not
be pluged all the way in. That would create a short and a nonsens
temperature reading.
8

5. Pitmaster:
With the Pitmaster it is possible to controll the temerature of a
grill or BBQ smokers using a fan or servo motor. Using a electrical
heatsource, SSR (SolideStateRelay) and a standard catering tray a
DIY Sous-Vide bath can be build.
Further information at: www.wlanthermo.com
To set up the pitmaster press on the cruise control icon »
Channel
Pitmaster
Setup
Servo/Fan/
Relay
Target
Temperature
9

With the thermometer symbol » the target temperature can be
set. Validate your entry with Enter »
The jack symbol » let you select the channal which should be
used as the reference measurement for the temperatur control.
Just press on the channel you want do select.
10

To select the device used to controll your grill press on the sym-
bol » with the fan/SSR/servo motor. It appears green if aktivated.
You can chose the following:
Servomotor - Fan - PWM Fan
Relay - SSR (Solid State Relay)
More information wich devices you can use and how to use them:
www.wlanthermo.com
11

• Pitmaster on/off : activates/deactivates the pitmasters.
• PID on/off: switches between closed-loop control and con
trol curve
• Lid-monitoring : the thermometer dedects when the lid
is open and stops the pitmaster as long as the lid is not
closed again.
• Invert Controll : changes the direction of a servo motor, if a
fan is connected it will stand still at 100% and runns at full
speed at 0% and if using a relay the the NO or NC can be
switched.
Pitmaster
on/off
Lid-
monitoring
PID on/off
Invert
Controll
12

GUI (graphical user interface):
That is the homescreen:
All active channels are listed here
To change the settigs you have to log in:
The user is allways „wlanthermo“, the password is the one chosen
while installing the software. The default password is „raspberry“.
13

This is the main menu
It contains:
Saves the current Logle, creates a new one and starts the plot.
The plot-grak will only be saved if it is activated as a new Logle
is created.
activates/deactivates the plot-grak.
opens a page with the saved Logles, you can downoad them
from this page
opens the settings
opens the WiFi settings
14

opens a page with generall informationen about the WLANTher-
mo. Updates can be installed here when avalable.
Both symbols will bring you back to the homescreen
With that symbol you can shutdown and reboot the system.
It is recomended to safey shutdown the WLANThermo instad of
just cutting the power!
“ Speichern ” saves the changes and you go back to the
homescreen. “ Zurück ” bings you bach to the homescreen without
saving.
15

Concept, Hardware & Backend © 2013-2016
Armin Thinnes
Web-Frontend © 2013-2016
Florian Riedl
Watchdog, Pitmaster © 2013-2015
Joe16
Display, Pitmaster © 2015-2016
Bjoern
Grak © 2013
Michael Spanel
PCB Design & Layout © 2013-2015
Grillprophet
Display Design & PCB Mini © 2015-2016
Alexander Schäfer
Quick Start Guide © 2016
Michael Puswald
www.wlanthermo.com
