The leading choice of broadcasters worldwide, Wohler’s re-imagined AMP2-16V could be the last
audio monitor you will ever need. The open architecture design, superb quality, upgradeability and
ease-of-use is why broadcasters consistently choose the AMP2-16V for their most demanding
applications.
Since we invented the in-rack audio monitor, we have not stopped improving it—and the world’s
best selling and most powerful monitor now offers an even broader set of critical audio
management tools. Monitor and analyze all of your audio and video feeds from one compact,
convenient and easy to use workstation. It’s the best we’ve ever designed and built.
Features/Benefits
• Monitor, mix, and route embedded AVB, SDI, AES, analog , and TOSLINk audio sources
• 16-channels of simultaneous, multi-format audio monitoring, metering and management
• Upgradable architecture gives you not only what you need now, but also what you need later
add additional module cards/features as requirements change
• New AVB input card. Mix, level adjust and monitor two 8-channel AVB streams. AVB
channels can be re-embedded into an SDI stream, AES, and analog outputs
• Dual high resolution LCD screens with auto-detecting 3G/HD/SD-SDI video
• Display application specific audio, video, or metadata information on either screen
• Loudness monitoring with alarms
• Fully customizable level meters including scale, color, range, thresholds and more
• 32 presets allow complete reconfiguration of the entire unit with one button press
• 16 Hot Keys enable one touch access to solos, mutes, channel trims, presets, or Dolby
Zooms at the touch of a single button
• “SuperPair” feature offers additional channel pair (17, 18) monitor two intercom
or auxilary device channels
• Menu lockout function prevents unwanted system changes
• Save and copy system presets to other units via Ethernet or Serial connection to PC
• Redundant power supplies for secure transmission chain operation (optional)
16-CHANNEL AUDIO/VIDEO PROCESSING MONITOR
Modular 16-channel
audio/video workstation
with a complete suite of
tools for analyzing and
managing audio quality,
level and loudness,
metadata, and more
3G
AES
AHD
LUFS
I
I
I
I
I
I
SDI
LKFS
I
I
I
I
I
I
info@wohler.com ww w.wohler.com +1 888 5 WOHLER
VIDEO AUDIO CAPTIONING FILE-BASED SOLUTIONS
Order Part Numbers
AMP2-16V-M: 8130-0200 (16-Channel dual input, 3G/HD/SD-SDI, audio/video monitor)
AMP2-E16V-M: 8130-0300 (16-Channel dual input, 3G/HD/SD-SDI, audio/video monitor, Dolby D & E,)
New! Loudness Monitoring
Enhancements Released
« Loudness (LKFS or LUFS)
within window, Maximum
True Peak, Maximum Loudness
Program Loudness, and LRA
« Compatible with all worldwide
Loudness standards
« Color-Coded Alarm Indications
« Start, Pause, Reset, and Stop
controls for manual monitoring
« Pause and Reset control
for continuous monitoring
« Enable/Disable Alarms
with adjustable tolerance
