Wohler HDM-156-3G-RM User manual

HDM-156-3G-RM
15.6” Audio/Video Rack Monitor
User Guide
User Guide
Part Number 821811, Revision A

Page 2
© 2016 Wohler Technologies, Inc. All rights reserved.
This publication is protected by federal copyright law. No part of this publication may be copied or
distributed, stored in a retrieval system, or translated into any human or computer language in any
form or by any means electronic, mechanical, manual, magnetic, or otherwise, or disclosed to third
parties without the express written permission of Wohler Technologies.
Reproduction
Licensed users and authorized distributors of Wohler Technologies, Inc. products may copy this
document for use with Wohler Technologies., Inc. products provided that the copyright notice above
is included in all reproductions.
Customer Support
Wohler Technologies, Inc.
31055 Huntwood Avenue
Hayward, CA 94544 www.wohler.com
Phone: [phone]
FAX: [phone]
US Toll Free: 1-888-596-4537 (1-888-5-WOHLER)
Web: www.wohler.com Sales: [e-mail]
Support: [e-mail]
Disclaimers
Even though Wohler Technologies, Inc. has tested its equipment and software, and reviewed the
documentation, Wohler Technologies, Inc. makes no warranty or representation, either express or
implied, with respect to software, documentation, their quality, performance, merchantability, or
fitness for a particular purpose.
In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or
consequential damages resulting from any defect in the hardware, software, or its documentation,
even if advised of the possibility of such damages.
Some states do not allow the exclusion or limitation for incidental or consequential damages, so the
above exclusion or limitation may not apply to you.
Printing
This document looks best when printed on a color printer since some images may be indistinct when
printed on a black and white printer.
PDF
All text strings underlined in this shade of blue are hyperlinks within this document.
Other Technologies and Products
Google Chrome is a registered trademark of Alphabet Inc. Microsoft Windows and Internet Explorer
are registered trademarks of Microsoft Corporation. Evertz and MAGNUM are registered trademarks
of Evertz Microsystems Ltd.
Last Update
December 13, 2016

Page 3
TAB E OF CONTENTS
Contents
User Guide..........................................................................................1
TABLE OF ONTENTS............................................................................3
ontents .........................................................................................................3
HAPTER 1: Installation ........................................................................5
Introduction ....................................................................................................5
Overview...............................................................................................5
Features ...............................................................................................5
Safety.............................................................................................................5
Instructions ...........................................................................................5
Safety Symbols......................................................................................6
Mounting...............................................................................................6
Heat Dissipation.....................................................................................7
Sympathetic Vibration.............................................................................7
Mechanical ............................................................................................7
Electrical Interference.............................................................................7
Power ...................................................................................................7
ompliance .....................................................................................................8
F ......................................................................................................8
I ES-003 ..............................................................................................8
HAPTER 2: Local Operation ..................................................................9
Front Panel ......................................................................................................9
On-Screen Display Features.............................................................................10
Rear Panel.....................................................................................................12
Rear Panel onnectors ....................................................................................15
Using the Quick Menu and the OSD Menus ........................................................16
Quick Menu .........................................................................................16
OSD Menus .........................................................................................16
OSD Menus ...................................................................................................17
HAPTER 3: Technical Info ................................................................ 29
Supported Video Formats ................................................................................31
HAPTER 4: Using Network ontrol ...................................................... 32
Web Browser / ontrol Device .........................................................................32
First Time- IP Assignments..............................................................................32
Status Page...................................................................................................33
Adjust Page ...................................................................................................35
Video Display Page .........................................................................................35
Input Setup Page ...........................................................................................36

Page 4
Marker Page ..................................................................................................37
Audio Page ....................................................................................................38
Display Page..................................................................................................39
lose aption Page.........................................................................................39
onfig Page ...................................................................................................40
olor Temperature Page..................................................................................41
Function Key Page..........................................................................................41
IMD Page ......................................................................................................42
GPI Page .......................................................................................................43
System Page .................................................................................................44

Page 5
CHAPTER 1: Installation
Introduction
Overview
The HDM-156-3G-RM monitor sets a new standard in L D monitors for broadcast
and professional video applications. The HDM-156-3G-RM is a rack mount monitor
providing a 15.6”, 8-bit, 1920 x 1080 resolution, 16:9 format, anti-glare IPS L D
screen. All video formats are scaled to fit on the screen in the highest quality using
12-bit digital processing, precision scaling and gamma correction to produce the
best images possible.
Features
The HDM-156-3G-RM audio/video monitor is designed for confidence monitoring of
two 3G/HD/SD-SDI, one HDMI/DVI, one VBS composite analog video, and one Y/
and component input. Input signals are easily selected and displayed. Two to
sixteen audio channels may be selected for visual monitoring on bar graph style
level meters. On screen markers, waveform, vector, Picture in Picture (PiP) and
Picture by Picture (PbP) displays can be enabled on this full-featured monitor.
Focus Assist and Luma Zone modes can be engaged to assist with camera
adjustments. Stereo speakers provide audio monitoring. A headphone jack and
stereo analog audio outputs are also provided for external audio monitoring.
Parameters are selected and adjusted using an On Screen Display (OSD) Menu. An
RJ45 connector serves as the interface to six general purpose inputs which can be
optioned to control a variety of monitor functions. Monitor settings can also be
made with a web browser over Ethernet using the integral web server.
Safety
Instructions
1. Read, keep, and follow all of these instructions; heed all warnings.
2. Do not use this equipment near water.
3. Use only a dry cloth to clean the equipment.
4. Do not block any ventilation openings.
5. Do not install near any heat source such as a radiator, heat register, amplifier, or
stove.
6. Do not attempt to plug the unit into a two-blade outlet (with only two prongs of
equal width).

Page 6
7. Protect the power cord from being walked on or pinched, particularly at plug
connection on the equipment and at the socket.
8. Use only the attachments/accessories specified by the manufacturer.
9. Unplug the equipment during lightning storms or when unused for long periods
of time.
10. Refer all servicing to qualified service personnel. Servicing will be required
under all of the following conditions:
a. The equipment has been damaged in any way, such as when the power-
supply cord or plug is damaged.
b. Liquid had been spilled or objects have fallen onto the equipment.
c. The equipment has been exposed to rain or moisture.
d. The equipment does not operate normally.
e. The equipment has been dropped.
Safety Symbols
Mounting
The HDM-173-3G-RM is designed to be mounted in 5RU of a standard 19" rack. It
may be tilted forward for easier viewing. Position either unit at ear/eye level for
best high frequency response and visual observation of the display screen. Please
adhere to the following clearances:
Table 1-1: Recommended learances
Clearance Surface
24” Front
3” Rear
2” Sides
1.75” Top and Bottom (if near other equipment)
0” Top and Bottom (if no other equipment)
The symbol to the left warns of electric shock hazard
inside the unit.
Disconnect the power cord before removing access panels when
installing upgrades. Only qualified service personnel are to operate
the equipment with covers removed, and are to exercise caution to
avoid personal injury.
Important:
By design, this monitor will only plug into a three
-
prong outlet for
your safety. If the plug does not fit into the outlet, contact an
electrician to replace the obsolete outlet.

Page 7
Heat Dissipation
The ambient temperature near the product should not exceed 40° elsius (104°
Fahrenheit). When rack mounting, adjacent devices can be rack mounted in
proximity to the unit if this temperature is not exceeded. Otherwise, allow a 1RU
(1.75”/44.45mm) space above and below the unit for air circulation.
Sympathetic Vibration
Sympathetic vibration from other equipment (cables, etc.) in the rack may be
serious enough to interfere with the unit’s sound quality. If you experience
sympathetic vibrations, use thin card stock, felt, foam, or weather-stripping
between the vibrating surfaces. Tie loose cables securely with cable ties.
Mechanical
The rack chassis is securely attached its mounting brackets. In addition, the chassis
is very shallow from front to back. This feature will reduce or eliminate rear bracing
requirements in many mobile/portable applications. It can be tilted downward for
viewing, if necessary. The weight of internal components is distributed fairly evenly
around the unit.
Electrical Interference
Be careful to avoid mismatched cable types and other similar causes of undesired
reflections in digital signal systems. If severe enough, such reflections can result in
corruption of the digital data stream. As with any audio equipment, maximum
immunity from electrical interference requires the use of shielded cable; however,
satisfactory results can sometimes be obtained without it. The internal circuitry
ground is connected to the chassis.
Power
The unit comes with an external power supply module which connects to an A
mains power source (40W, 100 to 240 VA , ±10%, 50/60Hz) through the IE
connector provided on the power supply.
When the mains plug or appliance coupler is used as the disconnect device, the
disconnect device should remain operable.
Important
:
To reduce noise, the monitor does not have any fans. As a
result, the heat generated by the audio amplifiers, power
supplies, and other components is vented by slots in the back
of
the unit. Therefore, as a safety precaution, you must allow
proper ventilation on these surfaces.

Page 8
Compliance
F
This equipment has been tested and found to comply with the limits for a lass A
digital device, pursuant to part 15 of the F Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at
their own expense.
I ES-003
This lass A digital apparatus complies with anadian I ES-003.
et appareil numérique de la classe A est conforme à la norme NMB-003 du
anada.

Page 9
CHAPTER 2: ocal Operation
The HDM-156-3G-RM front and rear panels are described in this chapter.
Front Panel
Figure 2–1: Front Panel Layout
1. Tally ights: This tri-color (red/green/amber) light is controlled through an RS-
485 interface or through the GPI connector on the rear panel. For more
information about the RJ45 connector, refer to the Rear Panel section of this
chapter. When first connected to power, the Tally Light glows amber until the
unit is ready for operation.
2. CD Screen: The L D screen displays the audio meters, Picture in Picture (PiP)
and Picture by Picture (PbP) screens, closed captioning, waveform/vector,
menus, and OSD features over the video.
3. Power: The Power button turns the L D screen to On or Standby mode. The
adjacent Power Indicator glows green to indicate On and red to indicate

Page
10
Standby.
4. Input: The Input button selects the video/audio input to be monitored from the
various connectors on the rear panel. The currently selected input source is
indicated when the Input button is pressed. Repeated presses change the input
source.
5. Function Keys: Press F1, F2, F3, F4, or F5 to activate the assigned function.
The default assignments are as listed in Table 2-1. The action of each Function
Key can be selected from a wide variety of actions in the Function Key Menu as
described in Table 2-14.
Table 2-1: Default Function Key Actions
Key Default Action
F1 Scan
F2 Native
F3 Aspect Win Select
F4 Win Select
F5 PBP
6. Menu: Press this button to display the OSD Menu. Refer to the OSD Menus
section of this chapter for operation and content of these menus.
7. Enter: When the OSD Menu is displayed, pressing this button accepts selections
in the menus and sub-menus. When the OSD Menu is not being displayed,
pressing this button displays the Quick Menu, which cycles through frequently
used volume and image controls. Refer to the Quick Menu section of this
chapter.
8. Down: When the OSD Menu is displayed, the Down button navigates down
through the menu and sub-menu selections and can be used to adjust the
settings. It also adjusts the items in the Quick Menu.
9. Up: When the OSD Menu is displayed, the Up button navigates down through
the menu and sub-menu selections and can be used to adjust the settings. It
also adjusts the items in the Quick Menu.
On-Screen Display Features
Functions and parameters can be selected and adjusted using the On Screen
Display (OSD) Menu. Refer to the OSD Menus section of this chapter.
Overlays can be added by the operator for Area & Safety Markers, Center
Marker, and to display names as IMD (In Monitor Display) for identification.
Video effects such as Monochrome, Blue Only, Focus Assist, H/V Delay and
other features can be used to assist setup. For convenience and quicker access,
these and other features can be assigned to the Function Keys.
Overscan, Underscan and Native modes control scaling and size of the video.
Audio level meter displays, for up to sixteen channels, can be displayed vertically

Page
11
or horizontally, positioned at various corners of the display. They can show VU, PPM
(PK) or both with assignable -20db to -18db reference levels.
Waveform (Y or Line) and/or Vectorscope can be shown on the left or right
bottom of the screen.
Closed Captions from VBS Line 21 ( EA-608) can be decoded and text is
displayed across the screen bottom. The ‘ ’ logo at screen top center indicates
captions are present in the SDI stream.
The de-embedded Timecode from the HD/SD-SDI source displays on the lower
part of the screen. hoose LT , VIT or D-VIT types in the Display Menu.
Figure 2-2: Display Features
1. Input Status: Displays the detected input and video parameters of the
signal: vertical active line count, (i)nterlaced or (p)rogressive, and
field/frame rate in Hz. This display is controlled be a setting in the Display
Menu. Refer to Table 2-9.
2. Area Marker: Used to mark an alternate aspect ratio area of the image. You
can set whether to display it, the brightness, and the matte mode in the
Marker Menu. Refer to Table 2-7.
3. Safety Marker: This is used to mark a percentage area, inside of the image,
safe for titles to be located. You can set whether to display it, as well as its
display mode, in the Marker Menu. Refer to Table 2-7.
4. Center marker: ross hairs are displayed in the center of the screen,
marking the center of the image. You can set whether to display them in the
Marker Menu. Refer to Table 2-7.
5. IMD: The IMD Menu provides settings to customize the IMD (In Monitor
Display) text area to show a static line of characters, numbers, and certain
symbols or to receive dynamic messages to be displayed. Refer to Table 2-
16.
6. Audio evel Meters: Levels for the audio channels are displayed on up to

Page
12
sixteen bar graph meters as left/right pairs. The meters can appear in
various selectable positions on the screen. Refer to Table 2-8.
7. Timecode: The de-embedded timecode from the HD/SD-SDI source displays
on the lower part of the screen. The timecode setting is located in the Display
Menu. Refer to Table 2-9.
8. Waveform/Vectorscope: This can be displayed only for SDI signals. The
waveform and vector of the input signal display are configurable in the
Display Menu. Refer to Table 2-9.
Rear Panel
Figure 2-3: HDM-156-3G Rear Panel Layout
Important
:
By design, the supplied A mains power cord will only plug into a
three-prong grounded outlet for your safety. If the plug does not fit
into the outlet, contact an electrician to replace the obsolete outlet.
The symbol to the left warns of electric shock hazard inside or outside
the unit. Disconnect the power cord before removing access panels.

Page
13
1. SDI 1 In: This input connector accepts 3G/HD/SD-SDI video signals. It is
compliant with SMPTE 424M, SMPTE 259M, SMPTE292M/ITU-R BT601. It can
be viewed using the SDI1 selection on the Input button menu.
2. SDI 1 Out: This connector provides a re-shaped and re-clocked duplicate of
the SDI 1 In signal. This connection is compliant with SMPTE 424M, SMPTE
259M, SMPTE292M/ITU-R BT601.
3. SDI 2 In: This is the second 3G/HD/SD-SDI video signal input. This
connection is compliant with SMPTE 424M, SMPTE 259M, SMPTE292M/ITU-R
BT601. It can be viewed using the SDI2 selection on the Input button menu.
4. SDI 2 Out: This connector provides a re-shaped and re-clocked duplicate of
the SDI 2 In signal. This connection is compliant with SMPTE 424M, SMPTE
259M, SMPTE292M/ITU-R BT601.
5. ine 1 In Video: This is the first input for an analog VBS video signal. It
can be viewed using the INE 1 selection on the Input button menu.
6. ine 1 Out Video: This is a pass through connection for the ine 1 In video
signal.
7. ine 2 In CVBS/Y: This is the second analog VBS video input signal or the
luminance (Y) signal of Y/ or YPbPr. This input combined with the other Line
In 2 input signals can be viewed using the INE 2 selection on the Input
button menu.
8. ine 2 Out CVBS/Y: This is a pass through connection for the ine 2 In
CVBS/Y video signal.
9. ine 2 In Pb/C: This is the chroma ( ) signal of Y/ or YPbPr. This input
combined with the other ine In 2 input signals can be viewed using the
INE 2 selection on the Input button menu.
10. ine 2 Out Pb/C: This is a pass through connection for the ine 2 In
Pb/C video signal.
11. ine In 2 Pr: This is red (Pr) component of YPbPr. This input combined with
the other Line In 2 input signals can be viewed using the INE 2 selection on
the Input button menu.
12. ine 2 Out Pr: This is a pass through connection for the ine 2 In Pr video
signal.
13. HDMI In: This input supports HDMI and DVI signals. It uses an HDMI Type-
A connector. It can be viewed using the HDMI selection on the Input button
menu.
14. Audio In 1: A pair of analog audio inputs related to the Line 1 video signal
is provided on R A jacks. They have a 47KΩ input impedance and will accept
Important:
The monitor and power adapter have been tested as a combined
apparatus to verify compliance with applicable safety and
electromagnetic compliance standards. Use of another power adapter
provided by the user may negate the compliance or not perform
properly
. Wohler Technologies cannot accept any responsibility for the
outcome in such cases.

Page
14
up to a 5dBu signal. These inputs are selected when the INE 1 selection
button is pressed.
15. Audio In 2: A pair of analog audio inputs related to the Line 2 video signal
is provided on R A jacks. They have a 47KΩ input impedance and will accept
up to a 5dBu signal. These inputs are selected when the INE 2 selection
button is pressed.
16. Headphones: A standard 1/8" stereo headphone jack is provided. The
speakers will mute when a headphone is inserted into this jack.
17. Audio Out: A pair of analog outputs is provided on R A jacks. They will
output the audio from the selected video source to be used with external
amplifiers and speakers if needed. They have a 500Ω output impedance and
will produce up to a 5dBu signal.
18. Power Connector: The supplied 100 to 240VA to 12VD power supply
plugs into this coax connector.
19. Power Switch: This switch removes all power from the product. Normally,
since this switch is on the rear panel, it is left in the 1 (On) position and the
front panel Power button is used to start and stop product operation.
20. Ethernet: The 10/100M Ethernet connector is used to connect with a
computer to modify the display settings remotely. AT5 network cables are
recommended for medium distances. AT6 twisted pair shielded cables are
recommended for longer distances.
21. GPI: This RJ45 jack controls the tally lights on the front panel. Refer to
Figure 2-5 below for the pinout and Table 2-2 for the terminal connections.
Either AT5 or AT6 cables may be used for this jack. The possible functions
for GPI contact closures are described in the GPI Menu shown in Table 2-15.
22. RS-485 In/Out: These RJ-45 jacks are used for dynamic Tally/IMD
controls. Two jacks are provided for in & out daisy chain arrangements. They
are wired identically. Refer to Figure 2-4 below for the pinout and to Table 2-
3 for terminal connections. These connections are also used for system
software upgrades. Either AT5 or AT6 cables may be used for these jacks.
23. Right and eft Speakers: The audio monitoring speakers are positioned
on the rear panel. The volume of the speakers is controlled using the Quick
Menu. Refer to the Quick Menu section of this chapter.
24. Carrying Handle: A carrying handle is provided so that the monitor can be
securely carried from location to location.

Page
15
Rear Panel Connectors
The following figure and tables detail the connections of the General Purpose Inputs
(GPI) and RS-485 connectors on the rear panel. The tables are also silkscreened on
the rear panel of the unit for your convenience.
Table 2-2: GPI Input onnections
To activate a GPI, connect its associated pin (1-6) to ground (8).
Figure 2-4: GPI Input & RS-485 I/O Pin-Out
Table 2-3: RS-485 I/O onnections
Pin RS-485 Terminal Name
1, 2 GND
3 Tx- (pair A)
4 Rx+ (pair B)
5 Rx- (pair B)
6 Tx+ (pair A)
7, 8 N
Pin GPI Terminal Name
1 GPI 1
2 GPI 2
3 GPI 3
4 GPI 4
5 GPI 5
6 GPI 6
7 N
8 GND

Page
16
Using the Quick Menu and the OSD Menus
In the following descriptions, refer to Figure 2-5 for the location of each control
button.
Figure 2-5: Screen ontrol Buttons
Quick Menu
The Quick Menu provides quick access to a few commonly used features, as listed
in Table 2-4. The Quick Menu appears as shown in Figure 2-6.
Figure 2-6: Quick Menu - Volume Setting
The following is a description of how to use the Quick Menu:
1. Press the Enter button to display the Quick Menu and the first item that can
be adjusted.
2. Use the Up and Down buttons to change the value for the item displayed.
3. Press the Enter button again to display the next adjustable item.
4. The Quick Menu will time out with no button presses. Alternatively, you may
press the Enter button repeatedly when finished until the menu disappears.
Table 2-4: Quick Menu
Parameters Default Value Domain Range
VOLUME 16 0 - 31
BRIGHTNESS 50 0 - 100
ONTRAST 50 0 - 100
HROMA 50 0 - 100
OSD Menus
The OSD Menus allow you to adjust a wide variety of control parameters for the
monitor. Refer to Table 2-5 through Table 2-17 for typical values and domain
ranges. The following is a description of how to use the OSD Menus:

Page
17
1. Press the Menu button to display the Main Menu.
2. Use the Up and Down buttons to navigate through the submenus.
3. Press the Enter button to enter the parameter selections in the chosen
submenu.
4. Use the Up or Down buttons to cycle through the submenu selections.
5. When the desired option is highlighted, press the Enter button to select it.
6. Use the Up or Down buttons to adjust the parameter value up or down,
make a selection, or turn a function on or off.
7. Press the Enter button to accept your parameter change -or- press the
Menu button to cancel your change.
8. Press the Menu button to back out of any submenu, and finally to remove
the OSD Menus from the screen.
OSD Menus
The following tables describe the information and settings available in the OSD
Menu system. Use the instructions in the previous section to navigate the menus.
Table 2-5: Status Menu Structure
Status
Parameters Default Value Domain Range Description
INPUT SDI-1
SDI-2, SDI-2, LINE
1 ( VBS), LINE 2
( VBS), LINE 2
(Y/ ), LINE 2
(YPBPR), HDMI
FORMAT NO SIGNAL
OLOR TEMP D65
D32, D93, D65,
D56, D50
S AN MODE NORMAL NORMAL, OVER,
UNDER
FAST MODE ON OFF, ON
MODEL HDM-156-3G
SERIAL NUMBER -
IP ADDRESS 192.168.1.86
OLOR VERSION 2015-9-16-1
Display only, for the value
of the parameter.

Page
18
Table 2-6: Input Menu Structure
Input
Parameters Default Value Domain Range Description
SDI 1 ON OFF, ON
SDI 2 ON OFF, ON
LINE 1 ON OFF, ON
LINE 2 VBS OFF,
VBS, LINE 2 (Y/ ),
LINE 2 (YPBPR)
HDMI ON OFF, ON
Enables or disables
the input choices
available in the
Input Select Menu
NTS SETUP 7.5 0: Japan
7.5: North America Select the NTS signal region.
NTS PHASE 0 -50 to 50
FO US ASSIST STANDARD OFF STANDARD
OLOR
OFF: Normal Video
STANDARD: An
image with
sharpened edges is
displayed.
OLOR: An image
with the color
selected in FO US
OLOR substituted
for the intensified
areas.
FO US LEVEL 49 0 to 100 Select the amount
of edge sharpening
in FO US ASSIST.
FO US OLOR GREEN
RED
BLUE
GREEN
When FO US
ASSIST: OLOR is
selected, this
selects which color
will substitute.
LUMA ZONE
HE K ON OFF, ON
OFF: Normal Video
ON: ompares the
signal luminance
with the LUMA
ZONE LEVEL
setting and fills the
higher luminance
areas with a zebra
pattern.
LUMA ZONE LEVEL 49 0 to 100
Set the luminance
comparison level
for the LUMA ZONE
HE K.
The Focus Assist feature is designed to help with camera focusing. The uma
Zone Check feature can help when setting the camera exposure.

Page
19
Table 2-7: Marker Menu Structure
Marker
Parameters Default Value Domain Range Description
MARKER
ENABLE OFF OFF, ON
Turn all markers on
or off.
AREA MARKER 15:9
If 16:9 aspect ratio:
OFF (close area marker),
4:3, 13:9, 14:9, 15:9,
1.85:1, 2.35:1
If 4:3 aspect ratio:
OFF (close area marker),
16:9
Set area marker size
according to the
aspect ratio.
ENTER
MARKER OFF OFF, ON Turn center marker display on or off.
SAFETY
MARKER OFF OFF, 80%, 85%, 88%, 90%, 93%, 95%
Set safety marker
size according to the
aspect ratio and scan
mode.
MARKER
LEVEL 1 1: 50%, 2: 75%, 3: 100% Set the luminance of all of the markers.
MARKER MAT OFF OFF, HALF (Background 50%)
BLA K
Set the transparency
of the area marker
mat.
ROSSHAT H ON OFF, ON
Figure 2-7: Marker Mat Effect

Page
20
Table 2-8: Audio Menu Structure
Audio
Parameters Default Value Domain Range Description
AUDIO SOUR E EXT
EXT: Analog Inputs
EBD: SDI & HDMI Inputs
UNDEF: No audio
Select the audio
source among the
available signals.
SPEAKER L AUD 1L
Select the input
channel for the
left speaker,
headphone, or
analog audio out.
SPEAKER R AUD 1R
OFF
For an AUD Source:
AUD 1L, AUD 1R, AUD
2L, AUD 2R
For an SDI EBD Source:
H1 to H16
For an HDMI EBD
Source: H1, H2
Select the input
channel for the
right speaker,
headphone, or
analog audio out.
AUDIO METER OFF ON or OFF Set whether to display the audio
meters.
METER SELE T H1-2
H1-2, G1, G2, G3, G4,
G1+G2, G1+G3, G1+G4,
G2+G3, G2+G4, G3+G4,
G1-G4
Select channels or
SDI groups to
display on the
meters.
METER
DIRE TION HORIZONTAL VERTI AL, HORIZONTAL
Select vertical or
horizontal meters.
METER POSITION TOP
If METER DIRE TION is
VERTI AL: BOTTOM
LEFT, BOTTOM RIGHT,
TOP RIGHT, TOP LEFT
If METER DIRE TION is
HORIZONTAL:
BOTTOM,
TOP
For vertical
meters, select
bottom left,
bottom right, top
right, or top left
position. For
horizontal meters,
select bottom or
top position.
METER DIS MODE MODE1
MODE1: meter only
MODE2: meter & c
hannel
numbers
MODE3: meter, channel
numbers, and dB value
Select the
appearance of the
meters.
REF LEVEL -20DB -18DB, -20DB
Set the meter
reference level
(green to yellow
transition).
OVER LEVEL -10DB -2DB, -4DB, -6DB, -
8DB,
-10DB
Set the meter over
level (yellow to red
transition)
