Wolf WKEHD2 User manual

Item #_____________ C.S.I. Section 11420
Wolf Range Company, LLC
19600 S. Alameda St., Compton, CA 90221-6291
P.O. Box 7050, Compton, CA 90240-7050
[phone] • FAX [phone] • (800) 366-WOLF
Customer Service [phone] • www.WOLFRANGE.com
R
F-39016 (3/03)
MODEL: WKEHD2 Half-Size Double Section Electric Convection Oven
Approved by ______________________
Date: _____________________________
SPECIFY VOLTAGE AND PHASE WHEN ORDERING
Model WKEHD2
Listed by Underwriters Laboratories, Inc.
Listed by the National Sanitation Foundation
DOUBLE SECTION FULL FEATURED
HALF-SIZE ELECTRIC CONVECTION OVEN
BASIC MODEL:
WKEHD2 Double section half-size electric convection oven
KEY FEATURES:
➤Stainless steel front, sides and top.
➤Stainless steel doors with window (field reversible).
➤163⁄4" adjustable stainless steel legs.
➤5.5 KW input per section, 11 KW total input
➤1⁄2H.P. two speed fan motors.
➤Solid state temperature controls adjust from 200°to
500°F.
➤60 minute timers with audible alarm.
➤Oven cool switch for rapid cool down.
➤Porcelain enamel on steel oven interiors.
➤Five nickel plated oven racks with nine rack positions
per section.
➤Rear body enclosure panel.
➤Standard power supply 208V or 240V/60/1 or 3 phase.
➤One year limited parts and labor warranty.
OPTIONAL FEATURES:
➤➤163⁄4" adjustable stainless steel legs with casters.
DESCRIPTION:
Double section half-size electric convection oven, Wolf Model
No. WKEHD2. Stainless steel front, sides and top. Field
reversible stainless steel doors with window. 165⁄8" adjust-
able stainless steel legs. Non-sag insulation applied to the
top, rear, sides, bottom and door. Porcelain enamel on steel
oven interiors measures 151⁄4"w x 21"d x 20"h. Five nickel
plated oven racks per section measure 143⁄8" x 207⁄8". Nine
position nickel plated rack guides with positive rack stops
per section. 5.5 KW input per section, 11 KW total input. Two
speed 1⁄2H.P. oven blower motors. Side mounted controls.
Solid state temperature controls adjust from 200°to 500°F.
60 minute timers with audible alarm. Oven cool switch for
rapid cool down. Requires 208/240 volt, 60 Hz, 1 or 3 phase
power supply. 11 KW total draw.
Exterior dimensions: 30"w x 2719⁄32"d x 681⁄8"h on 163⁄4" legs.

NOTE: In line with its policy to continually improve its product, Wolf Range Company
reserves the right to change materials and specifications without notice.
This appliance is manufactured for commercial use only and is not intended for home use.
F-39016 (3/03)
Model WKEHD2 Half-Size Double Section
Full Featured Electric Convection Oven
NOTE: This appliance may be installed with 1.0" clearance
at the rear and 0" clearance on both sides adjacent to
combustible construction.
Approx.
DOUBLE OVEN Width Depth Height Shp. Wt.
WKEHD2 30" 2719⁄32"68
1⁄8"520 lbs.
ELECTRICAL DATA
208, 240Volt - 3 PHASE LOADING NOMINAL AMPS PER LINE WIRE
MODEL TOTAL KW PER PHASE 3 PHASE 1 PHASE
KW 208V 240V 208V 240V
L1-L2 L2-L3 L1-L3 L1 L2 L3 L1 L2 L3
WKEHD2 11.0 5.0 0 6.0 46 20 24 40 18 22 52 46
