MODEL: WKGHD2 Half-Size Double Section Gas Convection Oven
Approved by ______________________
Date: _____________________________
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
Model WKGHD2
Design Certified by the American Gas Association
Listed by the National Sanitation Foundation
DOUBLE SECTION FULL FEATURED
HALF-SIZE GAS CONVECTION OVEN
BASIC MODEL:
WKGHD2 Double section half-size gas convection oven
KEY FEATURES:
➤Stainless steel front, sides and top.
➤Stainless steel doors with window (field reversible).
➤163⁄4" adjustable stainless steel legs.
➤25,000 BTU/hr. power burner per section, 50,000
BTU/hr. total input.
➤Electronic spark igniters.
➤1⁄2H.P. single speed fan motors.
➤Solid state temperature controls adjusts from 200°to
500°F.
➤60 minute timers with audible alarm.
➤Oven cool switch for rapid cool down.
➤Porcelain enamel on steel oven interiors.
➤Five nickel plated oven racks with nine rack positions
per section.
➤Rear body enclosure panel.
➤Gas pressure regulator and manual shut-off valve.
➤One year limited parts and labor warranty.
OPTIONAL FEATURES:
➤➤163⁄4" adjustable stainless steel legs with casters.
DESCRIPTION:
Double section half-size gas convection oven, Wolf Model
No. WKGHD2. Stainless steel front, sides and top. Field
reversible stainless steel doors with window. 165⁄8" adjust-
able stainless steel legs. Non-sag insulation applied to the
top, rear, sides, bottom and door. Porcelain enamel on steel
oven interiors measure 151⁄4"w x 21"d x 20"h. Five nickel
plated oven racks per section measure 143⁄8" x 207⁄8". Nine
position nickel plated rack guides with positive rack stops
per section. 25,000 BTU/hr. power burners with electronic
spark igniters per section, 50,000 BTU/hr. total input. Single
speed 1⁄2H.P. oven blower motors. Side mounted controls.
Solid state temperature controls adjusts from 200°to 500°F.
60 minute timers with audible alarm. Oven cool switch for
rapid cool down. 115 volt, 60 Hz, 1 ph power supply required.
8 amps draw per section, 16 amps total draw.
Exterior dimensions: 30"w x 2719⁄32"d x 681⁄8"h on 163⁄4" legs.

NOTE: In line with its policy to continually improve its product, Wolf Range Company
reserves the right to change materials and specifications without notice.
This appliance is manufactured for commercial use only and is not intended for home use.
F-39012 (3/03)
Total BTU Approx.
DOUBLE OVEN Width Depth Height Per Oven Electrical Shp. Wt.
WKGHD2 30" 2719⁄32"68
1⁄8"50,000 115/60/1 560 lbs.
Model WKGHD2 Half-Size Double Section
Full Featured Gas Convection Oven
IMPORTANT
1. A gas pressure regulator sized for this unit is included. Natural gas 3.5" W.C., propane gas 10.0" W.C.
2. These units are manufactured for installation in accordance with ANSZ223.1 (latest edition), National
Fuel Gas Code. Copies may be obtained from American Gas Association, 400 N Capitol St. NW,
Washington, DC 20001, www.AGA.org.
3. This appliance must be installed with a 3" clearance at both sides and the rear adjacent to combustible
or noncombustible construction.
4. This appliance must be installed on legs or a leg stand.
