MODEL: WKED2 Electric Convection Oven
Approved by ______________________
Date: _____________________________
NSF listed. UL listed. UL listed to Canadian safety standards.
DOUBLE SECTION FULL FEATURED
ELECTRIC CONVECTION OVEN
BASIC MODEL:
WKED2 Double section electric convection oven
KEY FEATURES:
XStainless steel front, sides, top and legs.
XIndependently operated stainless steel doors with double
pane windows.
X25 total KW.
X1/2H.P. two speed oven blower-motor.
XMoisture vent damper control.
XSide mounted solid state temperature controls adjust from
150° to 500°F.
X60 minute timers with audible alarm.
XOven cool switch for rapid cool down.
XPorcelain enamel on steel oven interiors.
XFive nickel plated oven racks with eleven rack positions per
section.
XOne year limited parts and labor warranty.
OPTIONAL FEATURES:
ZFive hour timer in place of 60 minute timer.
ZCasters.
Z480 volt, 60 Hz, 3 phase.
Z220/380 volt, 50 Hz, 1 phase, 3 wire.
Z220/380 volt, 50 Hz, 3 phase, 4 wire.
Z240/415 volt, 50 Hz, 3 phase, 4 wire.
ACCESSORIES:
ZExtra oven rack(s).
ZStainless steel drip pan.
DESCRIPTION:
Double section electric convection oven, Wolf Model No.
WKED2. Stainless steel front, sides, top and legs. Independently
operated stainless steel doors with double pane windows.
Non-sag insulation applied to the top, rear, sides, bottom and
doors. Porcelain enamel on steel oven interiors measure 29"w
x 221/8"d x 20"h. Two interior oven lights per section. Five nickel
plated oven racks per section measure 281/4" x 201/2". Eleven
position nickel plated rack guides with positive rack stops per
section. Each section heated by electric solid sheath elements
rated at 12.5 KW. Furnished with a two speed 1/2H.P. oven
blower-motor per section. Side mounted solid state temperature
controls adjust from 150° to 500°F. 60 minute timers with
audible alarm. Oven cool switch for rapid cool down. 208 or 240
volt, 60 Hz, 1 or 3 phase.
Exterior dimensions: 40"w x 421/4"d x 70"h on 8" legs. Depth
measurement includes door handles.
SPECIFY VOLTAGE AND PHASE WHEN ORDERING.

NOTE: In line with its policy to continually improve its product,Wolf Range Company
reserves the right to change materials and specifications without notice.
This appliance is manufactured for commercial use only and is not intended for home use.
F-39245 (03/08)
Model WKED2 Double Section Full Featured
Electric Convection Oven
NOMINAL AMPS PER LINE WIRE
TOTAL 3 PHASE LOAD 3 PHASE
MODEL CONN. KW PER PHASE 208 VOLT 240 VOLT 480 VOLT 1 PHASE
NO. KW X-Y Y-Z X-Z X Y Z X Y Z X Y Z 208V 240V
WKED2 25 88 9 706670665866283030120104
