CHALLENGER XL™SERIES
36” GAS RESTAURANT RANGE
OPEN BURNERS / FRY TOPS
Item # __________________ C.S.I. Section 11420
SPECIFICATIONS
36” wide gas restaurant range, Wolf Model No. C36S-2FT24.
Fully MIG welded aluminized steel frame for added durability.
Stainless steel front, sides, backriser, highshelf and 6” adjustable
legs. Extra deep crumb tray with welded corners. Two 30,000
BTU/hr cast burners with lift-off burner heads. Energy saving
flashtube open burner ignition system (one pilot for every two
burners) shrouded for reliability. 7/8” thick x 24” wide manual
fry top, 40,000 BTU/hr. Heavy duty cast grates, easy lift-off 12”
x 12 1/2” in the front and 12” x 14 1/2” in the back to better
accommodate stock pots or large pans. Grates have a built in
aeration bowl for greater efficiency. Burner knobs are cool to
the touch, high temperature material. One oven: 35,000 BTU/hr
standard bakers depth ovens with porcelain oven bottom and door
panel, measures 26 1/2”d x 26 3/8”w x 14”h. Oven thermostat
adjusts from 250°F to 500°F with a low setting. Each oven is
supplied with two racks, two rack guide sets, and four rack
positions. Oven door is heavy duty with an integrated door hinge/
spring mechanism requiring no adjustment. 3/4” rear gas
connection and pressure regulator. Total input 135,000 BTU/hr.
Exterior Dimensions:
34 3/4”d x 36”w x 58”h on 6” adjustable legs
F-37368 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 QLouisville, KY 40201 QToll-free: 1-800-814-2028 QLocal: 502-778-2791 QQuote & Order Fax: [phone]
C36S-4FT12T❏C36C-4FT12 ❏C36B-4FT12
C36S-2FT24T❏C36C-2FT24 ❏C36B-2FT24
C36S-FT36T❏C36C-FT36 ❏C36B-FT36
STANDARD FEATURES
Fully MIG welded frame■
Stainless steel front, sides, backriser, lift-off high shelf■
6” Stainless steel adjustable legs■
30,000 BTU/hr open top burners with lift-off heads■
7/8” thick manual fry top. 4” wide front grease trough■
Shrouded flash tube pilot system (one pilot per■
two burners)
Heavy duty cast grates, easy lift-off 12” x 12 1/2” in■
front and 12” x 14 1/2” in the rear
Extra deep pull out crumb tray with welded corners■
35,000 BTU/hr baker’s depth standard oven cavity■
measures 26 1/2”d x 26 3/8”w x 14”h
Oven thermostat adjusts from 250°F to 500°F■
Two oven racks and four rack positions■
35,000 BTU/hr Snorkler convection oven in place of std.■
oven 26”d x 26 1/8”w x 13 7/8”h (115v - 1 phase blower
motor 4 amp, 6’ cord and plug), includes three oven racks
One year limited parts and labor warranty■
OPTIONAL FEATURES (Factory Installed)
6” stainless steel stub backT
Reinforced high shelf for mounting salamander broilerT
Hot top section in lieu of one open burnerT
Thermostatically controlled (snap-action) onT
24” and 36” only
ACCESSORIES (Packaged & Sold Separately)
Extra oven rackT
Extra rack guides (set of two)T
Casters (set of four)T
Flanged feet (set of four)T
Reinforced high shelf for mounting salamander broilerT
This appliance is manufactured for commercial
use only and is not intended for home use.
Model C36S-2FT24 shown with optional casters

CHALLENGER XL™SERIES
36” GAS RESTAURANT RANGE
OPEN BURNERS / FRY TOPS
F-37368 (07/08)
Vulcan & Wolf Range
a division of ITW Food Equipment Group LLC
P.O. Box 696 QLouisville, KY 40201 QToll-free: 1-800-814-2028 QLocal: 502-778-2791 QQuote & Order Fax: [phone]
A pressure regulator sized for this unit is included.1.
Natural gas 5.0” W.C., propane gas 10.0” W.C.
Gas line connecting to range must be 3/4” or larger. If2.
flexible connectors are used, the inside diameter must be
3/4” or larger.
An adequate ventilation system is required for commercial3.
cooking equipment. Information may be obtained by
writing to the National Fire Protection Association,
1 Batterymarch Park, Quincy, MA 02269, www.NFPA.org.
When writing, refer to NFPA No. 96.
These units are manufactured for installation in4.
accordance with ANSZ223.1A(latest edition), National
Fuel Gas Code. Copies may be obtained from The
American Gas Association, 400 N Capitol St. NW,
Washington, DC 20001, www.AGA.org.
Clearances5. Rear Sides
Combustible 6” 10”
Standard Oven Non-combustible 0” 0”
Convection Oven Non-combustible Min. 4” 0”
For proper combustion, install equipment on adjustable6.
legs or casters provided with unit.
For proper combustion, install equipment on adjustable7.
legs or casters provided with unit.
NOTE: In line with its policy to continually improve its product,
Wolf Range Company reserves the right to change materials
and specifications without notice.
Specify type of gas when ordering. Specify altitude when
above 2,000 feet.
INSTALLATION INSTRUCTIONS
TOP
CONFIGURATION MODEL NUMBER DESCRIPTION TOTAL INPUT BTU / HR SHIPPING WEIGHT LBS / KG
C36S-4FT12 4 Open Burners / 12” Fry Top /1 Standard Oven 175,000 560 / 254
C36C-4FT12 4 Open Burners / 12” Fry Top / 1 Convection Oven 175,000 620 / 281
C36B-4FT12 4 Open Burners / 12” Fry Top / Storage Base 140,000 530 / 240
C36S-2FT24 2 Open Burners / 24” Fry Top / 1 Standard Oven 135,000 570 / 259
C36C-2FT24 2 Open Burners / 24” Fry Top / 1 Convection Oven 135,000 630 / 286
C36B-2FT24 2 Open Burners / 24” Fry Top / Storage Base 100,000 540 / 245
C36S-FT36 36” Fry Top / 1 Standard Oven 95,000 610 / 277
C36C-FT36 36” Fry Top / 1 Convection Oven 95,000 660 / 299
C36B-FT36 36” Fry Top / Storage Base 60,000 580 / 263
Note: Add 7” to depth on
convection oven models.
