Wolf R364C User manual

36" Gas Ranges
Wol has per ected the orm, unction and
sheer durability o our gas ranges. Wol
gas ranges o er standard eatures such
as an in rared oven broiler, convection
baking, dual brass sur ace burners and
our signature large red control knobs.
Optional in rared charbroiler and in rared
griddle give you the reedom to customize
your gas range. Wol gas ranges are avail-
able in natural or LP gas.
FEATURES
•Stainless steel exterior finish.
•Optional infrared charbroiler and infrared
griddle configurations.
•Distinctive red control knobs with chrome
bezels—black knobs optional.
•Dual brass burners with automatic
reignition at all settings.
•Porcelain-coated cast iron grates.
•Large-capacity convection oven with
infrared broiler and three adjustable
oven racks.
•Spring/damper door hinge system.
•Stainless steel drip tray.
•Adjustable stainless steel legs in front and
rear casters.
•Full side panels and skirt.
Model 366
Model 364C
Model 364G
SURFACE FEATURES
Model R366 R364C R364G
Surface Burners
16,000 Btu high / 500 Btu simmer 644
Infrared Charbroiler – 16,000 Btu •
Infrared Griddle – 18,000 Btu •
Model numbers are for natural gas ranges, add (-LP) to t e model number for LP gas.
ACCESSORIES
•Stainless steel risers in 5" and 10",
or 20" riser with shelf.
•Stainless steel island trim.
•Black control knobs.
•Porcelain-coated, cast iron wok grate.
•Porcelain-coated, cast iron two-burner
S-grates.
•Oven rack.
•Full-extension ball bearing rack.
•Hardwood cutting board
(griddle model only).
•Griddle cleaning kit.
Accessories are available t roug your aut orized
Wolf dealer. For local dealer information, visit t e
find a s owroom section of our website,
wolfappliance.com.
Dual brass burner.Infrared griddle.
Model R364C s own.
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

36" (914)
36" (914)
37" (940)
HEIGHT TO
COOKING
SURFACE
21/2"
(64)
241/2"(622)
251/4"(641)
LEGS AND CASTERS ALLOW
1" (25) HEIGHT ADJUSTMENT
433/8"(1102)
463/4"
(1187)
10"
RISER
563/4"
(1441)
20"
RISER
271/4"(692)
91/4"
(235)
283/8"(721)
413/4"
(1060)
5"
RISER
INSTALLATION NOTES
•A riser is required for installations
against a combustible surface.
•A Wolf pro wall, chimney, island ventila-
tion hood or hood liner is recommended.
Unit dimensions may vary by ±1/8".
361/4"(921)
OPENING WIDTH
30" (762) TO 36" (914)
TO BOTTOM OF
VENTILATION HOOD**
*Minimum clearance from rough opening to combustible materials up to 18" (457) above countertop.
**36" (914) minimum clearance, 44" (1118) for charbroiler, from countertop to combustible materials without ventilation hood.
NOTE: For island installations, 12" (305) minimum clearance from back of range to combustible rear wall above countertop.
6" (152) TO
COMBUSTIBLE*
6" (152) TO
COMBUSTIBLE*
18" (457) min
36" (914)
FLOOR TO
COUNTERTOP
12"
(305)
10" (254)
12"
(305)
5"
(127)
G
2" (51)
37" (940)
TO COOKING
SURFACE
13" (330)
max
3"
(76)
LOCATION OF GAS AND
ELECTRICAL EXTENDS
ON FLOOR
SIDE
CABINET
E
73/4"(197)
53/4"
(146)
SPECIFICATIONS
Exterior Finish Stainless Steel
Overall Width 36"
Overall Height (to cooking surface) 37"
Overall Depth 283/8"
Oven Interior Capacity 5.5 cu ft
Oven Interior
Dimensions 30" W x 185/8" H x 17" D
Opening Width 361/4"
Opening Height (to countertop) 36"
Opening Depth 24"
Electrical equirements 110/120 V AC
50/60 Hz, 15 amp circuit
Shipping Weight 445–470 lbs
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
36" Gas Ranges
Dimensions in parent eses are in
millimeters unless ot erwise specified.
©Wolf Appliance, Inc. all rig ts reserved. Features and specifications are subject to c ange at any time wit out notice. 1/10
