Wolf CHALLENGER XL Series User manual

P.O. Box 696 ■Louisville, KY 40201 ■Toll-free: 1-800-814-2028 ■Local: 502-778-2791 ■Quote & Order Fax: [phone]
a division of ITW Food Equipment Group LLC
RESTAURANT RANGES
F-37373 (03/09)
Item # C.S.I. Section 11420
Model C60SS-6GB
shown with optional casters
SPECIFICATIONS
60” wide gas restaurant range, Wolf Model No. C60SS-6GB.
Fully MIG welded aluminized steel frame for added durability.
Stainless steel front, sides, backriser, highshelf and 6” adjustable
legs. Extra deep crumb tray with welded corners. Six 30,000
BTU/hr cast burners with lift-off burner heads. Energy saving
ashtube open burner ignition system (one pilot for every two
burners) shrouded for reliability. 24” wide manual fry top-broiler,
40,000 BTU/hr. Heavy duty cast grates, easy lift-off 12” x 12 1/2”
in the front and 12” x 14 1/2” in the back to better accommodate
stock pots or large pans. Grates have a built in aeration bowl
for greater efciency. Burner knobs are cool to the touch, high
temperature material. Two ovens: 35,000 BTU/hr standard bakers
depth ovens with porcelain oven bottom and door panel, measures
26 1/2”d x 26 3/8”w x 14”h. Oven thermostat adjusts from 250°F
to 500°F with a low setting. Each ovens is supplied with two racks,
two rack guide sets, and four rack positions.Oven doors are heavy
duty with an integrated door hinge/spring mechanism requiring no
adjustment. 1” rear gas connection and pressure regulator. Total
input 290,000 BTU/hr.
Exterior Dimensions:
34 3/4”d x 60”w x 58”h on 6” adjustable legs
C60SS-6GB 2 Standard Ovens
C60CC-6GB 2 Convection Ovens
C60SC-6GB 1 Standard Oven / 1 Convection Oven
C60SB-6GB 1 Standard Oven / Storage Base
C60CB-6GB 1 Convection Oven / Storage Base
STANDARD FEATURES
Fully MIG welded frame■
Stainless steel front, sides, backriser, lift-off high shelf■
6” Stainless steel adjustable legs■
30,000 BTU/hr open top burners with lift-off heads■
24” manual fry top-broiler. 4” wide front grease trough■
Shrouded ash tube pilot system (one pilot per two burners)■
Heavy duty cast grates, easy lift-off 12” x 12 1/2” in front and■
12” x 14 1/2” in the rear
Extra deep pull out crumb tray with welded corners■
35,000 BTU/hr baker’s depth standard oven cavity measures■
26 1/2”d x 26 3/8”w x 14”h
Oven thermostat adjusts from 250°F to 500°F■
Two oven racks and four rack positions for each oven■
35,000 BTU/hr Snorkler convection oven in place of std.■
oven 26”d x 26 1/8”w x 13 7/8”h (115v - 1 phase blower
motor 4 amp, 6’ cord and plug), includes three oven racks
One year limited parts and labor warranty■
OPTIONAL FEATURES (Factory Installed)
6” stainless steel stub back
Reinforced high shelf for mounting salamander broiler
Hot top section in lieu of one open burner
ACCESSORIES (Packaged & Sold Separately)
Extra oven rack
Extra rack guides (set of two)
Casters (set of six)
Flanged feet (set of six)
Reinforced high shelf for mounting salamander broiler
This appliance is manufactured for commercial
use only and is not intended for home use.
CHALLENGER XL
™SERIES – 60” GAS RESTAURANT RANGE
6 BURNERS / 24" FRY TOP-BROILER

P.O. Box 696 ■Louisville, KY 40201 ■Toll-free: 1-800-814-2028 ■Local: 502-778-2791 ■Quote & Order Fax: [phone]
a division of ITW Food Equipment Group LLC
RESTAURANT RANGES
F-37373 (03/09)
CHALLENGER XL
™SERIES – 60” GAS RESTAURANT RANGE
6 BURNERS / 24" FRY TOP-BROILER
INSTALLATION INSTRUCTIONS
Clearances5. Rear Sides
Combustible 6” 10”
Standard Oven Non-combustible 0” 0”
Convection Oven Non-combustible Min. 4” 0”
For proper combustion, install equipment on adjustable6.
legs or casters provided with unit.
For proper combustion, install equipment on adjustable7.
legs or casters provided with unit.
NOTE: In line with its policy to continually improve its product,
Wolf Range Company reserves the right to change materials
and specications without notice.
Specify type of gas when ordering.
Specify altitude when above 2,000 feet.
A pressure regulator sized for this unit is included. Natural1.
gas 5.0” W.C., propane gas 10.0” W.C.
Gas line connecting to range must be 1” or larger. If2.
exible connectors are used, the inside diameter must
be 1” or larger.
An adequate ventilation system is required for commercial3.
cooking equipment. Information may be obtained by
writing to the National Fire Protection Association, 1
Batterymarch Park, Quincy, MA 02269, www.NFPA.org.
When writing, refer to NFPA No. 96.
These units are manufactured for installation in4.
accordance with ANSZ223.1A (latest edition), National
Fuel Gas Code. Copies may be obtained from The
American Gas Association, 400 N Capitol St. NW,
Washington, DC 20001, www.AGA.org.
TOP
CONFIGURATION MODEL
NUMBER DESCRIPTION
TOTAL INPUT
BTU / HR
SHIPPING WEIGHT
LBS / KG
C60SS-6GB 6 Burners / 24” Fry Top-Broiler / 2 Standard Ovens 290,000 1025 / 465
C60CC-6GB 6 Burners / 24” Fry Top-Broiler / 2 Convection Ovens 290,000 1145 / 519
C60SC-6GB 6 Burners / 24” Fry Top-Broiler / 1 Std. Oven / 1 Conv. Oven 290,000 1085 / 492
C60SB-6GB 6 Burners / 24” Fry Top-Broiler / 1 Std. Oven / Storage Base 255,000 1020 / 508
C60CB-6GB 6 Burners / 24” Fry Top-Broiler / 1 Conv. Oven / 1 Storage Base 255,000 1055 / 579
