Wolf DD45I User manual

Model DD45
45" Downdraft Ventilation System
The cooktop downdraft unit rises from
the countertop to whisk away odors and
smoke into the easy-to-clean, five-layer
mesh filter. The remote-mounted control
module and top cover have the classic
stainless steel finish. (I) models include an
internal blower. In-line and remote blower
options are available for (R) models.
Specifications
Overall Width 451/2"
Overall Height (above countertop) 91/16"
Overall Depth 23/8"
Duct Size (I) Models 31/4" x 10"
(R) Models 31/4" x 14"
Discharge Adjustable
Electrical Requirements 110/120 V AC
60 Hz, 15 amp dedicated circuit
Power Cord 21/2' cord with grounded plug
Accessories
Transitions in various sizes
Accessories are available through your Wolf dealer.
To obtain local dealer information, visit the Locator
section of our website, wolfappliance.com.
Product Notes
The downdraft control kit includes control
module, top cover, mounting brackets, DIN
connector and necessary hardware. The
control kit with classic stainless steel control
module and top cover is included.
IMPORTANT NOTE: Wolf downdraft ventila-
tion systems are recommended for use with
Wolf electric and gas cooktops and integrated
modules, excluding the unframed electric
cooktops and electric grill, steamer and fryer
modules. Model DD45 cannot be used with
Wolf dual fuel ranges, gas ranges, sealed
burner rangetops or gas rangetops.
Model Options DD45I DD45R
Includes 500 CFM Internal Blower
Requires In-Line or Remote Blower
Control Module and Top Cover Stainless Steel Finish Classic Classic
Shipping Weight (lbs) 85 85
Features
Remote mounted control module with
LED indicators
Three-speed blower control
Filter clean timer
Delay-off feature automatically turns unit
off, chimney remains up
Stainless steel filter cover with dishwasher
safe aluminum mesh filter
Blower Options – (R) Models
1100 CFM In-Line Blower
900, 1200 or 1500 CFM Remote Blower
(I) models include a 500 CFM internal blower. (R)
models require an in-line or remote blower. For
additional information on blowers, visit our website,
wolfappliance.com.
Model DD45 shown. Also shown are two Model CT15G/S
gas cooktops and Model IM15/S multi-function cooktop.
Control Module
Model DD45
