Wolf CTEIH42I User manual

Cooktop Low-Prof le Island Hood
Beh nd the contemporary l nes of the
new Wolf cooktop low-prof le hoods,
there’s a lot of hard-nosed funct onal
th nk ng. Br ll ant halogen l ght ng llum -
nates your cook ng surface. Powerful
mult -speed blowers wh sk away smoke
and odors. The low-prof le sland hood s
class c sta nless steel w th a black glass
front panel and s recommended for use
w th Wolf nduct on, electr c and gas
cooktops and ntegrated modules.
Model CTEIH42I
Overall Width 42"
500 CFM Internal Blower Included
Features
Heavy-duty stainless steel construction
with classic stainless steel finish.
Telescopic flue fits 8' to 9' ceilings.
Front-mounted electronic controls with
digital indicator and four-speed blower
control.
Sealed halogen lighting with three
settings.
Island hood can be used in a non-ducted
application using an accessory charcoal
recirculating filter.
Heat sentry feature automatically turns
unit on when heat is sensed and
automatically adjusts blower speed.
Delay-off mode automatically turns
unit off.
Stainless steel filter cover with dishwasher-
safe aluminum mesh filter.
Filter clean indicator lets you know when
the filter needs cleaning.
Transition with backdraft damper included.
Accessor es
Recirculating kit for non-ducted installations
Replacement charcoal filters
Accessories are available t roug your Wolf
dealer. To obtain local dealer information, visit t e
s owroom locator section of our website,
wolfappliance.com.
Model CTEIH42I s own.
Sealed Halogen Lighting
Model CTEIH42I
Cooktop Low-Profile Island Hood
Internal Blower
500 CFM internal blower
Island ood includes t e 500 CFM internal blower.
For blower recommendations, visit our website,
wolfappliance.com.
Electronic Controls

Installat on Notes
Island hood includes a 500 CFM internal
blower. For blower recommendations, visit our
website, wolfappliance.com.
Cooktop low-profile hoods are recommended
for use with Wolf induction, electric and gas
cooktops and integrated modules. For Wolf
ranges and rangetops, a pro ventilation hood
is recommended.
Complete installation specifications can be
found on our website, wolfappliance.com.
Unit dimensions may vary by ± 1/8".
8' TO 9'
(2.4 m – 2.7 m)
FLOOR TO
CEILING HEIGHT
24" TO 30"
(610 – 762)
TO
COUNTERTOP
42" (1067)
OVERALL WIDTH
281/4"(718)
TO
411/2"(1054)
OVERALL
HEIGHT
LOCATION OF
ELECTRICAL
ON CEILING
THROUGH TOP
OF HOOD
215/8"(549)
OVERALL DEPTH
Spec f cat ons
Exterior Finish Classic Stainless Steel
Overall Width 42"
Height (excluding chimney) 31/8"
Min Height (including chimney) 281/4"
Max Height (full extension) 411/2"
Overall Depth 215/8"
Bottom of Hood to Countertop 24" to 30"
Discharge ertical
Duct Size 6" Round
Electrical Requirements 110/120 AC
60 Hz, 15 amp dedicated circuit
Shipping Weight 92 lbs
Installat on Spec f cat ons
Overall D mens ons
Cooktop Low-Prof le Island Hood
Dimensions in parent eses are in
millimeters unless ot erwise specified.
227/8"
(581)
31/8"(79)
21/8"(54)
TO
151/2"(394)
107/8"
(276)
121/8"
(308)
281/4"(718)
TO
411/2"(1054)
OVERALL
HEIGHT
42" (1067)
OVERALL WIDTH
215/8"(549)
OVERALL DEPTH
