READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
2 PEOPLE ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
This products must be installed by a fully insured and licensed plumber only. Installaon of any our product by anyone other
than fully insured and licensed plumber shall void limited warranty. We recommends that such licensed plumber have experience
in the installaon of products.
Limited warranty is void on any commercial installaon
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-state in
accordance to your locaon. We are not resonsible for providing any compliance cerficaons.
Under no circumstances we are shall not be liable for any and all incidental damages sustained in connecon with this product
Neither manufacture, nor distributor, nor retailer is responsible for water damage or flood caused due to use of this product.
Under no circumstances We shall not be liable for any and all fees, cost of installaon/reinstallaon/removal, subsequent
damage or transportaon in case of the product defect
INSTALLATION AND CARE GUIDE
PREFERED
EDUCATION
PROVIDER
LISTED
TM
ICC
• 2015 Uniform Plumbing Code ( UPC )
• 2018 International Plumbing Code ( IPC )
• 2018 International Residential Code ( IRC )
• CSA B45.5 / IAPMO Z124-2017- Plastic Plumbing Fixtures
®
®
®
Compliance with the following codes & standard:
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help.[email protected]
1
SCC Accredited
CB-P/S
OCPS
Accrédité CCN
ANSI
ACCREDITED
ISO/IEC 17065
Product Certification Body
#1000
20114 REV. 2
MODERN ALCOVE BATHTUB
BTA1531R /B1531R BTA1532L /B1532L

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
2
TOOLS REQUIRED FOR INSTALLATION (NOT INCLUDED)
OTHER TOOLS MAY BE REQUIRED
SoCloth
or Blanket
Silicone Tape
Measure
Pencil/Marker Hammer
Safety Glass LevelKnife Caulk Gun Adjustable
Wrench
Channel
Lock Pliers
First ensure that the subfloor is level.
If needed, level subfloor with leveling compound or mortar over
the entire area of installation.
Cut subfloor to accommodate plumbing in compliance with local plumbing and building code.
Verify your bathtub for final dimensions.
30"
60"
20 1/4"
Position bathtub.Verify that the draining pipe location matches the actual location of the bathtub
drain.Remove the bathtub.
Hacksaw
Drill
30"
60"
20 1/4"
BTA1531R/
B1531R
BTA1532L/
B1532L
Framing Square

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
3
Tolerance on dimensions: ±1/2"
20 1/4"
1"
16"
13 1/4"
BTA1531R /B1531R
BTA1532L /B1532L
60"
41 1/2"
4" 7 1/2" 3 3/4" 3 1/4"
3/8"
30"
17 3/4"
10 1/2"
3"
3"
3 1/8"3 1/8"
20 1/4"
1"
16"
13 1/4"
60"
41 1/2" 4"
7 1/2"
3 3/4"
3 1/4"
3/8"
30"
17 3/4"
10 1/2"
3"
3"
3 1/8"3 1/8"

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
4
90
90°
1. Locate provided L-brackets and screws
2. Using a framing square to gauge the angle,
hold skirt at 90 degrees from top of tub
Framing Square
3. While held in place, install L-Bracket
(utilizing provided screws.) Attach the
flat side to the mounting block and
the angled side to reinforced skirt
!!! No pre-drilling required !!! 4. Install the other two L-brackets in
the same manner.
4 x 10mm

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
5
Must be tighten up to prevent water leakage
1
Use Teflon
Sealing Tape
2
3
Install flex drain

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
6
The bathtub can be leveled by adjusting the feet.
Check your adjustment with a level
The bathtub must be tested before installation is
completed. Fill the tub to the overflow and inspect
it for leaks. Tighten any loose connections.
Fasten bathtub to studs framing.
Shim if necessary
Lock the adjustment by tighten the hexagon nut.

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
7
Apply silicone sealant to seal the joints between the bathtub rim and the finished wall.
Stud.
Cement board.
Tile adhesive.
Tile.
Bathtub
3 to 4 mm gap.
Silicone.
Shim if necessary.
Reference for Correct Tile Flange Installation . Use drawing below as a reference guide for rough-in measurements.

R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
R
WOODBRIDGE
Care and Cleaning
Retain these installaon instrucons for future reference!
IMPORTANT!
DO NOT USE: Abrasive cleaners such as: acid, ammonia, bleach, and simmilar solutions. Use of such solutions may cause
corrosion, finish peeling, and/or dull the surface.
DO NOT USE: Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the surface.
8
• Most dirt will wash offwith mild soap and warm water.
• For tough spots, use liquid dish washing soap or non-chlorine bleach.
• Do not use abrasive material such steel wool or scouring pads to clean the acrylic surface.
• Always test the cleaning soluon on a small area before using it on the enre surface.
• Do not allow cleaning to soak on the acrylic surface.
• Rinse thoroughly with water immediately and wipe dry with socloth.
• Use liquid polish compound such as Gel-Gloss Kitchen and Bath Polish(TM) to keep the original shine of acrylic surface.
• Light scratches can be removed with polishing compound for automobiles.
• For deeper scratches use wet sandpaper (1500 grit or higher). Always add water when sanding and lightly sand the area larger
than the scratch in a circular moon to remove the scratches. Repeat unl the scratch is removed. Use socloth and small
amount of polishing compound to restore shine. Repeat as needed unl surface shine is restored.
Repair and Maintenance
Please don't hesitate to contact us if you have any quesons or concerns.
Customer Service Phone: [phone]. (Monday - Friday 9 AM - 5 PM Pacific Time)
Or Email: help.[email protected]
The bathtub must be installed and used as described in this manual
Use cauon when entering or exing the bathtub
Do not permit children or persons with infirmies to use the bathtub without supervision of an adult
People using any medicaons or having adverse medical history must consult a physician prior to use of the bathtub
to avoid potenal hyperthermia and possible drowning
Water temperature over 100ºF may cause hyperthermia and/or other health problems. Check water temperature
and adjust it for your personal comfort
Never use bathtub while intoxicated, aer taking meals or any alcoholic beverages. Consuming alcoholic beverages
before or during bathing will cause drowsiness and may result in hyperthermia, loss of consciousness, or even
drowning
If you are pregnant or you feel that you are may be pregnant, consult your doctor before using the bathtub
Never use any electrical devices such as hair dryer, lamp, telephone, tv, radio, or others within 5 feet of the bathtub
Do not overfill the bathtub before enetering. Entering the bathtub when filled will cause overflow and slippery
condions. Use extreme cauon when entering and exing
IMPORTANT SAFETY RULES
ATTENTION! ALWAYS FOLLOW THESE PRECAUTIONS WHEN USING A BATHTUB
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Warning
Thank you for using WoodBridge products!
