woodmizer LT10 Manual instruction

Wood-Mizer®Sawmill
Safety, Setup, Operation
& Maintenance Manual
LT10S3 E7,5S rev. A1.00
Safety is our #1 concern! Read and understand all
safety information and instructions before operating,
setting up or maintaining this machine.
December 2006
Form #794
!

Table of Contents Page-Section
2 doc052207 Table of Contents
SECTION 1 SAFETY 1-1
1.1 Safety Symbols.......................................................................................1-1
1.2 Blade Handling.......................................................................................................... 1-2
1.3 Sawmill Setup............................................................................................................ 1-2
1.4 Sawmill Operation..................................................................................................... 1-2
1.5 Sawmill Maintenance ................................................................................................ 1-4
1.6 Belt Sizes...................................................................................................................1-6
1.7 Blade Sizes ................................................................................................................ 1-6
1.8 Cutting Capacity........................................................................................................ 1-7
1.9 Engine/Motor Specifications ..................................................................................... 1-7
1.10 Sawdust Extractor Specifications...........................................................1-7
1.11 Overall Dimensions ................................................................................................... 1-9
1.12 Components............................................................................................................. 1-10
1.13 Electrical Information.............................................................................................. 1-11
SECTION 2 SAWMILL ASSEMBLY 2-1
2.1 Mounting Parts of LT10 Sawmills with Electric Motors .......................................... 2-1
2.2 Unpacking the Sawmill ............................................................................................. 2-6
2.3 Bed Frame Assembly ................................................................................................ 2-8
2.4 Saw Head Assembly................................................................................................ 2-15
SECTION 3 SETUP & OPERATION 3-1
3.1 Sawmill Setup............................................................................................................ 3-1
3.2 Replacing The Blade ................................................................................................. 3-9
3.3 Tensioning The Blade.............................................................................................. 3-10
3.4 Tracking The Blade ................................................................................................. 3-11
3.5 Loading, Turning, And Clamping Logs .................................................................. 3-13
3.6 Up/Down Operation ................................................................................................ 3-17
3.7 Blade Guide Arm Operation.................................................................................... 3-18
3.8 Blade Drive Operation............................................................................................. 3-19
3.9 Feed Operation ........................................................................................................ 3-21
3.10 Cutting The Log ...................................................................................................... 3-21
3.11 Edging......................................................................................................................3-23
3.12 Blade Height Scale .................................................................................................. 3-24
3.13 Water Lube Operation ............................................................................................. 3-26
3.14 Transporting the Sawmill ........................................................................................ 3-28
SECTION 4 MAINTENANCE 4-1
4.1 Wear Life................................................................................................................... 4-1
4.2 Sawdust Removal ...................................................................................................... 4-1
4.3 Carriage Track & Rollers .......................................................................................... 4-2
4.4 Vertical Mast Rails.................................................................................................... 4-2
4.5 Miscellaneous Lubrication ........................................................................................ 4-3
4.6 Blade Wheel Belts ..................................................................................................... 4-3
4.7 Up/Down System....................................................................................................... 4-4
4.8 Miscellaneous Maintenance ...................................................................................... 4-5

Table of Contents Page-Section
Table of Contents doc052207 3
SECTION 5 TROUBLESHOOTING GUIDE 5-1
5.1 Sawing Problems ....................................................................................................... 5-1
SECTION 6 SAWMILL ALIGNMENT 6-1
6.1 Pre-Alignment Procedures......................................................................................... 6-1
6.2 Preparing The Sawmill For Alignment ..................................................................... 6-1
6.3 Blade Installation and Alignment.............................................................................. 6-2
6.4 Blade Wheel Alignment ............................................................................................ 6-4
6.5 Blade Guide Arm Alignment..................................................................................... 6-9
6.6 Aligning The Blade Guides..................................................................................... 6-12
6.7 Blade Deflection...................................................................................................... 6-13
6.8 Blade Guide Vertical Tilt Adjustment..................................................................... 6-14
6.9 Blade Guide Flange Spacing ................................................................................... 6-16
6.10 Horizontal Tilt Adjustment...................................................................................... 6-17
6.11 Blade Height Scale Adjustment............................................................................... 6-18
6.12 Motor Drive Belt Adjustment.................................................................................. 6-20
6.13 Mast Side Bracket Adjustment................................................................................ 6-21
6.14 Safety Handle Linkage Adjustment......................................................................... 6-22

-i G24doc052207
Sawmill and Customer Identification
Each Wood-Mizer LT10 sawmill is identified with a revision and VIN numbers.
When you pick up your mill, you will receive a customer number. The VIN number,
revision, and your customer number expedite our service to you. Please write these
numbers below so you have quick, easy access to them.
REVISION AND VIN NUMBERS
Customer No. Type VIN No. Revision No.
LT10
Basic Sawmill I.D.
E7,5
Motor/Engine
A1.
Major “Revision” Code
00
Minor ”Revision”
Type
Revision Number
Code

Safety
Safety 15doc052207 1-1
1
SECTION 1 SAFETY
1.1 Safety Symbols
This symbol calls your attention to instructions concerning your personal safety. Be sure
to observe and follow these instructions.
The word DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death or serious
injury.
WARNING suggests a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION refers to potentially hazardous situations which,
if not avoided, may result in minor or moderate injury to
persons or equipment.
Warning stripes are placed on areas where a single decal
would be insufficient. To avoid serious injury, keep out of
the path of any equipment marked with warning stripes.
Read and observe all safety instructions before operating this equipment! Also read any
additional manufacturer’s manuals and observe any applicable safety instructions
including dangers, warnings, and cautions.
Always be sure that all safety decals are clean and readable. Replace all damaged safety
decals to prevent personal injury or damage to the equipment. Contact your local
distributor, or call your Customer Service Representative to order more decals.
IMPORTANT! It is always the owner's responsibility to comply with all applicable federal,
state and local laws, rules and regulations regarding the ownership, operation and towing
of your Wood-Mizer sawmill. All Wood-Mizer mill owners are encouraged to become
thoroughly familiar with these applicable laws and comply with them fully while using the
mill.
Always properly dispose of all sawing by-products, including sawdust and other debris,
coolant, oil, fuel, oil filters and fuel filters.
Safety instructions are listed in this section by the following operations:
Blade Handling,
Sawmill Setup
Sawmill Operation
Sawmill Maintenance

Safety
Blade Handling
1
1-2 15doc052207 Safety
1.2 Blade Handling
DANGER! Always disengage the blade and shut off the
sawmill engine before changing the blade. Failure to do so
will result in serious injury.
WARNING! Always wear gloves and eye protection when
handling bandsaw blades. Changing blades is safest when
done by one person! Keep all other persons away from
area when coiling, carrying or changing a blade. Failure to
do so may result in serious injury.
1.3 Sawmill Setup
WARNING! Do not set up the mill on ground with more than
a 10 degree incline. If setup on an incline is necessary, put
blocks under one side of the mill or dig out areas for the
legs to keep mill level. Setting up the mill on an incline
could cause it to tip over, resulting in serious personal
injury.
WARNING! Keep all persons out of the path of the saw
head while loading and unloading the sawmill. Failure to do
so may result in serious injury or death.
1.4 Sawmill Operation
DANGER! Make sure all guards and covers are in place
and secured before operating or towing the sawmill. Failure
to do so may result in serious injury.
DANGER! Be sure the blade housing is in place and
secured. Do not open the blade housing, when the blade is
engaged.
DANGER! Always keep hands away from moving bandsaw
blade. Failure to do so may result in serious injury.
DANGER! Keep all persons out of the path of moving
equipment and logs when operating sawmill or loading and
turning logs. Failure to do so may result in serious injury.
DANGER! Maintain a clean and clear path for all necessary
movement around the mill and lumber stacking areas.
Failure to do so may result in serious injury.
WARNING! Always be sure the blade is disengaged and all

Safety
Sawmill Operation
Safety 15doc052207 1-3
1
persons are out of the path of the blade before starting the
engine or motor. Failure to do so may result in serious
injury.
WARNING! Secure all loose clothing and jewelry before
operating the sawmill. Failure to do so will result in serious
injury or death.
WARNING! Always make sure log is clamped securely
before sawing. Failure to do so will result in serious injury or
death.
WARNING! Use ONLY water or alcohol solution with the
water lube accessory. Never use flammable fuels or liquids.
If these types of liquids are necessary to clean the blade,
remove it and clean with a rag. Failure to do so will result in
serious injury or death.
CAUTION! Be sure the log clamps are all the way down
before loading a log onto the bed. Failure to do so may
result in machine damage.
CAUTION! Before loading a log, be sure the cutting head is
moved far enough forward so the log does not hit it. Failure
to do so may result in machine damage.
CAUTION! Do not try to force the saw head beyond its
upper and lower travel limits. Damage to the up/down
system may result.
CAUTION! Be sure to stop the blade when returning the
carriage. This will not only prevent the blade from being
pulled off and ruined by a wood sliver, but also will increase
the life of the blade.
CAUTION! Remove the optional loading ramps before
sawing.

Safety
Sawmill Maintenance
1
1-4 15doc052207 Safety
1.5 Sawmill Maintenance
CAUTION! Reinstall the track wiper so that it lightly touches
the track bar. If the wiper presses too firmly against the bar,
it can cause the power feed to bind.
CAUTION! Never use grease on the mast rails as it will
collect sawdust.

Safety
Sawmill Maintenance
Safety 15doc052207 1-5
1
Pictograph decals used to warn the user about danger in the LT10:
FIG. 1-0
Carefully read operator’s manual before
handling the machine. Observe instructions
and safety rules when operating
Stay clear of hot surfaces
Do not open or remove safety shields while
engine is running
Do not open or remove safety shields while
engine is running
Close shields and guards prior to operating
the machine
PICTOGR

Safety
Belt Sizes
1
1-6 15doc052207 Safety
1.6 Belt Sizes
See Table 1-1. Belt sizes for the LT10 are shown.
1.7 Blade Sizes
See Table 1-2. Wood-Mizer TRU•SHARP™ offers three types of blades to provide
efficient sawing for all models of sawmills. The engine/motor size of your sawmill and the
type of wood you saw should determine which blade you choose for optimum
performance.
See The Blade Handbook for blade hook angle, tooth height, and tooth set
specifications.
Description Belt Size Wood-Mizer
Part #
Motor Drive Belt E7,5 B81 014819
Blade Pulley Belts B57 1
1 To insure proper blade tracking, use Goodyear, Dayco Super II, or Browning belts
only.
P04185
TABLE 0-0
Engine/Motor Size Recommended Blade For Sawing:
Softwood Hardwood Frozen or Hard-to-Cut
Wood
5 hp - 15hp B275IH1030
B275IH741030
B375IH929 B375IH929 1
1 TRU•SHARP™ “F” blades use a 9/29 profile (9° hook angle and 29° back angle) and are designed to cut frozen and/or
extremely dense, hard-to-cut wood.
Standard TRU•SHARP™ blades use a 10/30 profile.
16hp or more B376IH1030
B376IH741030
B275IH1030
B275IH741030
B376IH1030
B376IH741030 2
2 Customer may choose preferred blade.
B375IH929 1
Electric Motor B376IH1030
B376IH741030
B275IH1030
B275IH741030
B376IH1030
B376IH741030 2
B375IH929 1
TABLE 0-0

Safety
Cutting Capacity
Safety 15doc052207 1-7
1
1.8 Cutting Capacity
See Table 1-3. The log size capacities of the LT10 sawmills are listed below.
1.9 Engine/Motor Specifications
See Table 1-4. The power options available for the LT10 sawmill are listed below.
See Table 1-5. The noise levels of the Wood-Mizer sawmills are listed below.
1.10 Sawdust Extractor Specifications
See Table 1-6. The dust extractor specifications are given below.
Max. Diameter Max. Length 1
1 Each additional bed frame segment adds approximately 195
cm ( 6’ 5” ) to length capacity.
LT10 with three bed
sections
71 cm 5,4 m
LT10 with two bed
sections
71 cm 3,5 m
TABLE 0-0
Engine/Motor Type Manufacturer Model Number Specifications
5.5 kW Electric Motor Siemens, Germany 1LA7130-2AA60-2 3 x 400V, 50 Hz
TABLE 0-0
Idle Engaged
Sawmill Equipped With Electric
Motor
77,1 dB (A) 80,8 dB (A)
TABLE 0-0
Maximum Capacity 2300 m3/h
Collector Inlet Diameters (in
front of fan)
150 mm
Motor Power 3 kW
Number of Sacks for Waste 2 pcs
Total Capacity of Sacks 0.25 mp
Weight 110 kg
TABLE 0-0

Safety
Engine/Motor Specifications
1
1-8 15doc052207 Safety
Conveying Speed When 10m
Long Hose is Used
20 m/s
TABLE 0-0

Safety
Overall Dimensions
Safety 15doc052207 1-9
1
1.11 Overall Dimensions
See Figure 1-1. The overall dimensions of the LT10 sawmills are shown below.
FIG. 1-1
2234
2043
918
385
385
1950
6610
4660
1714
1823
1950

Safety
Components
1
1-10 15doc052207 Safety
1.12 Components
See Figure 1-2. The major components of the Wood-Mizer LT10 are shown below.
FIG. 1-2
Water Tank
Blade Tension
Handle
Up/Down Crank
Handle
Sawmill Frame
Clamp
Blade Guide Arm
Handle
Blade Drive
Motor
Electric Box

Safety
Electrical Information
Safety 15doc052207 1-11
1
1.13 Electrical Information
See Figure 1-3. The electrical symbol diagram of the LT10 equipped with the 5,5kW
electric motor is shown below
FIG. 1-3
5,5kW
2925 min-1
17 A
C1A
S1
S2
W1 W2

Safety
Electrical Information
1
1-12 15doc052207 Safety
See Figure 1-4. The electrical components are listed in the table below.
See Table 1-7. LT10 Site preparation
DANGER! It is recommended to use 30mA GFI (Ground
Fault Interrupter.
Symbol Mfg. Part No. Manufacturer Wood-Mizer
Part #
Description
GZ GZ1 M16 SCHNEIDER
ELECTRIC
090430 Motor Solenoid/Braker GZ1M16
F2 C60N C1 24395 SCHNEIDER
ELECTRIC
084454 Switch
QOT16E3 ABB 089801 Switch, ABB
TR 63 /A BREVE 094487 Transformer, TMM
1M LC1 D18 B7 SCHNEIDER
ELECTRIC
084306 Contactor
L1 M22 WHITE MOELLER 090448 Control Light
S1 XB4BS542 SCHNEIDER
ELECTRIC
086556 Switch, Emergency Stop
S2 M22 MOELLER 090452 Switch, Start-Stop
M1 1LA7130-2AA60-2 SIEMENS 095785 Blade Drive Motor
W1 AZ17-11ZRK SCHMERSAL 094232 Safety Switch
W2 EVN2000C HONEYWELL 089816 Limit Switch
TABLE 0-0
3-Phase V Switch, Fuse Recommended wire
section
400 VAC 16 A 1,5 mm2
to 15m length
TABLE 0-0

SAWMILL ASSEMBLY
Mounting Parts of LT10 Sawmills with Electric Motors
SAWMILL ASSEMBLY 15doc052207 2-1
2
SECTION 2 SAWMILL ASSEMBLY
2.1 Mounting Parts of LT10 Sawmills with Electric Motors
2.1.1 Parts specifications
Table 1:
Sawmill Frame Assembly 1
Fig. Wood-Mizer No. Description Qty.
097466-1 Plate, frame
supporting left
LT10-zinc
3
097465-1 Plate, frame
supporting right
LT10-zinc
3
097181-1 Bed rail LT10-zinc 9
097185-1 Plate, segments
connector
LT10-zinc.
6
097182-1 Square, frame
mount LT10-zinc
18
097464-1 Block, frame
contracting
LT10-zinc
12
097471-1 Side support, short
LT10
3
097469-1 Side support long
LT10
3
094513-1 Outrigger
Weldment, LT10
zinc-plated
12

SAWMILL ASSEMBLY
Parts specifications
2
2-2 15doc052207 SAWMILL ASSEMBLY
094530 Log Clamp 3
097369-1 Bed Extension,
LT10-zinc
2
097473-1 Stop, Saw Head
LT10-zinc
2
086035-1 Wedge Weldment,
Log Taper LT10 zinc
1
092567-1 Upper Sprocket
Cover, ptd.
1
Saw Head Assembly
086323 Plate, Left Track
Wiper
2
086322 Plate, Right Track
Wiper
2
093859 Operator’s Guard 1
086171-1 Side Bracket 2
086172-1 Lower Bracket 1
092378-1 Bracket, Roller
Guard Mount
Painted
1
Table 1:

SAWMILL ASSEMBLY
Specifications of Fasteners
SAWMILL ASSEMBLY 15doc052207 2-3
2
2.1.2 Specifications of Fasteners
092379-1 Guard, Blade Guide
Roller
1
086132-1 Power Cord Bracket 1
097567-1 Latch, Saw Head
LT10
1
094246-1 Sawdust Chute 1
097248-1 Mast Side
Bracket.LT10-ptd
1
1 Frame with 3-bed sections
Table 2:
Wood-Mizer No. Description Qty.
Sample designations of fasteners:
F81003-17 M10x35 Bolt 1
F81031-2 M6-8-B Nut 2
F81030-2 M5 Nut 2
F81000-7 M5x25 Bolt 2
F81053-11 Washer, 6.5 Special Flat Zinc 6
F81001-15 M6x16 Bolt 2
Table 1:
6,5
8
8,
4
20
13
M8 Nut M8x20 Bolt 8.4 Washer

SAWMILL ASSEMBLY
Specifications of Fasteners
2
2-4 15doc052207 SAWMILL ASSEMBLY
F81001-7 M6x12 Bolt 2
F81054-1 Flat Washer 8.4 264
F81032-2 M8 Nut 127
F81002-5 M8x25 Bolt 118
F81002-4 M8x20 Bolt 5
F81055-2 Washer, 10.2 Split Lock 2
F81003-11 M10x25 Bolt 4
F81003-1 M10x20 Bolt 2
F81055-1 Flat Washer 10.5 4
F81037-1 M20 Nut 28
F81032-1 M8 Nut 1
F81002-20 M8x16 Bolt 6
F81002-23 M8x100 Bolt 12
F81059-2 Washer, M20 FLAT ZINC 28
F81053-1 Washer, M6, FLAT,ZINC 2
095919 Cap, A 50x30, Black 2
097480 Pipe Cap 40x40x(3-4) 6
F81082-1 Clamp - Plastic Hose 2
Table 2:
