Woodward HighPROTEC MRU4 User manual

MRU4
HighPROTEC
Voltage / Frequency Protection
Device Manual DOK HB MRU4E

MRU4 Functional overview
Page 2 EN MRU4 10/09
Fault recorder
Event recorder
Disturbance
recorder
f, delta phi ,
V, VE, V1, V2
Measured and
calculated values
option standard
4
MRU4
74
TC
81
U/O
59N5927
47 60
FL 78 81R

Order Code
EN MRU4 10/09 Page 3

COMMENTS ON THE MANUAL.....................................................................................................................9
Information Concerning Lia ility and Warranty ................................................................................................9
IMPORTANT DEFINITIONS............................................................................................................10
Scope of Delivery ..........................................................................................................................................14
Storage..........................................................................................................................................................14
Important Information ....................................................................................................................................14
Sym ols.........................................................................................................................................................15
DEVICE...............................................................................................................................................19
Device Planning.............................................................................................................................................19
Device Planning Parameters of the Device....................................................................................................20
INSTALLATION AND CONNECTION ...............................................................................................................21
Three-Side-View............................................................................................................................................21
Installation Diagram.......................................................................................................................................22
Assem ly Groups...........................................................................................................................................23
Grounding .....................................................................................................................................24
Power Supply and Digital Inputs.....................................................................................................................25
Binary Output Relays, System Contact and IRIG ..........................................................................................27
Voltage Measuring Inputs ..............................................................................................................................29
PC Interface...................................................................................................................................................31
Assignment of the Zero Modem Cable.................................................................................................32
Communication Interfaces ............................................................................................................................33
Modbus® RTU / EC 60870-5-103 via Terminals..................................................................................33
Profibus DP / Modbus® RTU / EC 60870-5-103 via D-SUB-plug............................................................35
VOLTAGE TRANSFORMERS.......................................................................................................................36
Check of the Voltage Measuring Values.........................................................................................................36
Wiring Examples of the Voltage Transformers...............................................................................................37
NAVIGATION OPERATION ......................................................................................................................43
Basic Menu Control .......................................................................................................................................47
Smart view Key oard Commands..................................................................................................................48
SMART VIEW.......................................................................................................................................49
Installation of Smart View...............................................................................................................................49
Uninstalling Smart view..................................................................................................................................49
Switching the Language of the Graphical User Interface...............................................................................49
Setting up the Connection PC - Device..........................................................................................................50
Set-up a Connection via Ethernet - TCP/ P.............................................................................................50
Set-up a Connection via Serial nterface under Windows 2000................................................................51
Set up a Connection via Serial nterface under Windows XP....................................................................53
Set up a Connection via Serial nterface under Windows Vista.................................................................54
Connected to the Device and Calling up Websites at the same Time.........................................................56
Establishing the Connection via a USB-/RS232-Adapter..........................................................................56
Smart view Troubleshooting................................................................................................................57
Smart view persistent connection problems............................................................................................59
Loading of Device Data when using Smart view ...........................................................................................60
Restoring of Device Data when using Smart view..........................................................................................61
Backup and Documentation when using Smart view.....................................................................................62
Printing of Device Data When using Smart view (Setting List).....................................................................63
Saving Data as a txt-file via Smart view................................................................................................63
Offline Device Planning via Smart view..........................................................................................................64
MEASURING VALUES..............................................................................................................................65
Read out Measured Values............................................................................................................................65
Read out of Measured Values via Smart view .......................................................................................65
Standard Measured Values............................................................................................................................66
STATISTICS..........................................................................................................................................68
Read out Statistics.........................................................................................................................................68
Statistics to be Read-Out via Smart view...............................................................................................68
Statistics (Configuration)................................................................................................................................69
Statistics (Configuration) via Smart view................................................................................................69
Direct Commands..........................................................................................................................................70
Standard Statistic Values...............................................................................................................................70
Page 4 EN MRU4 10/09

Glo al Protection Parameters of the Statistics Module..................................................................................73
States of the Inputs of the Statistics Module..................................................................................................74
Signals of the Statistics Module.....................................................................................................................74
Counters of the Module Statistics..................................................................................................................74
ACKNOWLEDGMENTS..............................................................................................................................75
Manual Acknowledgment...............................................................................................................................77
Manual Acknowledgment via Smart view.............................................................................................77
External Acknowledgments............................................................................................................................78
External Acknowledge via Smart view..................................................................................................78
MANUAL RESETS .................................................................................................................................79
Manual Resets via Smart view.......................................................................................................................79
ASSIGNMENT LIST ................................................................................................................................80
STATUS DISPLAY ..................................................................................................................................93
Status Display via Smart View.......................................................................................................................93
MODULE: DIGITAL INPUTS (DIS)..............................................................................................................94
Digital Inputs (Standard)................................................................................................................................95
Glo al Protection Parameters of the Digital Inputs (Standards).....................................................................95
Digital Input Signals (Output States)..............................................................................................................98
BINARY OUTPUT RELAYS........................................................................................................................99
System Contact............................................................................................................................................101
Glo al Protection Parameters of the Binary Output Relays..........................................................................102
Binary Output Relay Input States.................................................................................................................114
Binary Output Relay Signals.........................................................................................................................119
LIGHT EMITTING DIODES (LEDS)..........................................................................................................120
The »System OK« LED ...............................................................................................................................123
Glo al Protection Parameters of the LED Module........................................................................................124
LED Module Input States.............................................................................................................................135
OPERATING PANEL (HMI)....................................................................................................................139
Special Parameters of the Panel..................................................................................................................139
Direct Commands of the Panel....................................................................................................................139
Glo al Protection Parameters of the Panel..................................................................................................139
MODULE: DISTURBANCE RECORDER .......................................................................................................140
Read Out Distur ance Records...................................................................................................................143
Disturbance Recorder to be Read Out by Smart view ...........................................................................144
Deleting Distur ance Records.....................................................................................................................145
Deleting Disturbance Records via Smart view ......................................................................................145
Direct Commands of the Distur ance Recorder Module .............................................................................146
Glo al Protection Parameters of the Distur ance Recorder Module............................................................146
Distur ance Recorder Module Input States..................................................................................................148
Distur ance Recorder Module Signals.........................................................................................................148
Special Parameters of the Distur ance Recorder........................................................................................149
MODULE: FAULT RECORDER .................................................................................................................150
Read Out the Fault Recorder.......................................................................................................................151
Read Out the Fault Recorder via Smart View .......................................................................................151
Direct Commands of the Fault Recorder Module ........................................................................................153
Glo al Protection Parameters of the Fault Recorder Module.......................................................................153
Fault Recorder Module Input States.............................................................................................................155
Fault Recorder Module Signals....................................................................................................................155
MODULE: EVENT RECORDER ................................................................................................................156
Read Out the Event Recorder......................................................................................................................157
Read Out the Event Recorder via Smart View.......................................................................................157
Direct Commands of the Event Recorder Module .......................................................................................159
Event Recorder Module Signals...................................................................................................................159
MODULE: SCADA............................................................................................................................160
Device Planning Parameters of the Serial Scada Interface..........................................................................160
Glo al Protection Parameters of the Serial Scada Interface........................................................................160
MODULE: MODBUS® (MODBUS)............................................................................................................161
Mod us® Protocol Configuration.................................................................................................................161
Modbus RTU.................................................................................................................................162
Modbus TCP.................................................................................................................................163
EN MRU4 10/09 Page 5

Direct Commands of the Mod us®..............................................................................................................164
Glo al Protection Parameters of the Mod us®............................................................................................164
Mod us® Module Signals (Output States)..................................................................................................167
Mod us® Module Values.............................................................................................................................168
MODULE: PROFIBUS............................................................................................................................170
Direct Commands of the Profi us................................................................................................................171
Glo al Protection Parameters of the Profi us..............................................................................................171
Module Inputs of the Profi us......................................................................................................................181
Profi us Module Signals (Output States).....................................................................................................184
Profi us Module Values...............................................................................................................................185
MODULE: IEC60870 5 103...............................................................................................................187
IEC60870-5-103 Protocol Configuration......................................................................................................187
Glo al Protection Parameters of the IEC60870-5-103.................................................................................189
IEC60870-5-103 Module Signals (Output States).......................................................................................191
IEC60870-5-103 Module Values..................................................................................................................192
PARAMETERS.....................................................................................................................................193
Parameter Definitions..................................................................................................................................193
Device Parameters..........................................................................................................................193
Field Parameters............................................................................................................................193
Protection Parameters......................................................................................................................193
Device Planning Parameters.............................................................................................................194
Direct Commands..........................................................................................................................194
State of the Module nputs...............................................................................................................194
Signals........................................................................................................................................194
Adaptive Parameter Sets..................................................................................................................195
Operational Modes (access authorization)...................................................................................................200
Operational Mode – »Display Only«...............................................................................................200
Operation Mode – »Parameter Setting and Planning«..........................................................................200
Password.....................................................................................................................................................201
Password Entry at the Panel.............................................................................................................201
Password Changes........................................................................................................................201
Password Forgotten .......................................................................................................................201
Changing of Parameters - Example.............................................................................................................202
Changing of Parameters when using the Smart View - Example.................................................................203
Protection Parameters ................................................................................................................................205
Setting Groups.............................................................................................................................................205
Setting Group Switch .....................................................................................................................205
Setting Group Switch via Smart View.................................................................................................206
Copying Setting Groups (Parameter Sets) via Smart View.......................................................................207
Comparing Setting Groups via Smart View.........................................................................................207
Comparing Parameter Files via Smart view.................................................................................................208
Converting Parameter Files via Smart view.................................................................................................208
FIELD PARAMETERS ............................................................................................................................209
BLOCKINGS.......................................................................................................................................212
Permanent Blocking.....................................................................................................................................212
Temporary Blocking.....................................................................................................................................212
To Activate or Deactivate the Tripping Command of a Protection Module....................................................215
Activate, Deactivate respectively Block Temporarily Protection Functions...................................................216
MODULE: PROTECTION (PROT)..............................................................................................................217
Direct Commands of the Protection Module.................................................................................................224
Glo al Protection Parameters of the Protection Module ..............................................................................224
Protection Module Input States....................................................................................................................226
Protection Module Signals (Output States)..................................................................................................226
Protection Module Values.............................................................................................................................227
MODULE: TRIP CONTROL (TRIPCONTROL)................................................................................................228
Direct Commands of the Trip Control Module..............................................................................................231
Glo al Protection Parameters of the Trip Control Module............................................................................231
Trip Control Module Input States..................................................................................................................234
Trip Control Module Signals (Outputs States)..............................................................................................235
Page 6 EN MRU4 10/09

Trip Control Module Values..........................................................................................................................235
V PROTECTION MODULE – VOLTAGE PROTECTION [27/59].........................................................................236
Device Planning Parameters of the Voltage Protection Module ..................................................................238
Glo al Protection Parameters of the Voltage Protection Module .................................................................238
Setting Group Parameters of the Voltage Protection Module ......................................................................239
Voltage Protection Module Input States.......................................................................................................243
Voltage Protection Module Signals (Output States)......................................................................................243
Commissioning: Overvoltage Protection [59]...............................................................................................244
Commissioning: Undervoltage Protection [27].............................................................................................245
VE PROTECTION MODULE – RESIDUAL VOLTAGE [59N].............................................................................246
Device Planning Parameters of the Residual Voltage Supervision Module..................................................248
Glo al Protection Parameters of the Residual Voltage Supervision Module................................................248
Setting Group Parameters of the Residual Voltage Supervision Module......................................................249
Residual Voltage Supervision Module Input States......................................................................................250
Residual Voltage Supervision Module Signals (Output States)....................................................................250
Commissioning: Residual Voltage Protection - Measured [59N]..................................................................251
Commissioning: Residual Voltage Protection - Calculated [59N].................................................................252
FPROTECTION MODULE – FREQUENCY [81O/U, 78, 81R]........................................................................253
Device Planning Parameters of the Frequency Protection Module..............................................................260
Glo al Protection Parameters of the Frequency Protection Module.............................................................260
Setting Group Parameters of the Frequency Protection Module..................................................................261
Frequency Protection Module Input States..................................................................................................264
Frequency Protection Module Signals (Output States).................................................................................264
Commissioning: Frequency Protection (Overfrequency) [ANSI 81O]...........................................................265
Commissioning: Frequency Protection (Underfrequency) [ANSI 81U].........................................................265
Commissioning: df/dt...................................................................................................................................266
Commissioning: f< and -df/dt.......................................................................................................................267
Commissioning: delta phi.............................................................................................................................268
V 012 PROTECTION MODULE ASYMMETRY [47]......................................................................................269
Device planning parameters of the asymmetry module ..............................................................................271
Glo al protection parameter of the asymmetry-module...............................................................................271
Parameter set parameters of the asymmetry module..................................................................................272
States of the inputs of the asymmetry module............................................................................................273
Signals of the asymmetry module (states of the outputs).............................................................................274
Commissioning: Asymmetry Protection........................................................................................................275
EXP PROTECTION MODULE – EXTERNAL PROTECTION................................................................................276
Device Planning Parameters of the Module External Protection..................................................................278
Glo al Protection Parameters of the Module External Protection.................................................................278
Setting Group Parameters of the Module External Protection......................................................................279
Module External Protection Input States......................................................................................................280
Module External Protection Signals (Output States)....................................................................................280
Commissioning: External Protection............................................................................................................281
TCS SUPERVISION MODULE – TRIP CIRCUIT SUPERVISION [74TC]..............................................................282
Device Planning Parameters of the Trip Circuit Supervision Module............................................................285
Glo al Protection Parameters of the Trip Circuit Supervision Module..........................................................285
Setting Group Parameters of the Trip Circuit Supervision Module...............................................................286
Trip Circuit Supervision Module Input States................................................................................................287
Trip Circuit Supervision Module Signals (Output States)..............................................................................287
Commissioning: Trip Circuit Supervision [74TC]..........................................................................................288
VTS SUPERVISION MODULE VOLTAGE TRANSFORMER SUPERVISION [60FL].................................................289
Device Planning Parameters of the Voltage Transformer Module ...............................................................291
Glo al Protection Parameters of the Voltage Transformer Supervision Module ..........................................291
Setting Group Parameters of the Voltage Transformer Module....................................................................292
Voltage Transformer Supervision Module Input States................................................................................293
Voltage Transformer Module Signals (Output States)..................................................................................293
Commissioning: Voltage Transformer Supervision (via DI) [60FL]...............................................................294
Commissioning: Voltage Transformer Failure [60FL]...................................................................................295
DEVICE PARAMETERS...........................................................................................................................296
Date and Time.............................................................................................................................................296
Synchronize Date and Time via Smart View.........................................................................................296
Version.........................................................................................................................................................296
EN MRU4 10/09 Page 7

Version via Smart view.................................................................................................................................296
TCP/IP Settings...........................................................................................................................................297
Direct Commands of the System Module.....................................................................................................298
Glo al Protection Parameters of the System...............................................................................................299
System Module Input States........................................................................................................................301
System Module Signals................................................................................................................................302
Special Values of the System Module..........................................................................................................303
COMMISSIONING .................................................................................................................................304
Commissioning/Protection Test ...................................................................................................................305
Putting out of Operation – Plug out the Relay..............................................................................................306
SERVICE...........................................................................................................................................307
General........................................................................................................................................................307
SELF SUPERVISION..............................................................................................................................308
Error messages / -codes..............................................................................................................................309
TECHNICAL DATA ...............................................................................................................................310
Climatic Environmental Conditions...............................................................................................................310
Degree of Protection EN 60529...................................................................................................................310
Routine Test.................................................................................................................................................310
Housing........................................................................................................................................................310
Voltage Supply.............................................................................................................................................311
Power Consumption.....................................................................................................................................311
Real time clock.............................................................................................................................................311
Display.........................................................................................................................................................311
Digital Inputs................................................................................................................................................312
Voltage and Residual Voltage Measurement................................................................................................313
Frequency Measurement ............................................................................................................................313
Binary Output Relays...................................................................................................................................313
Time Synchronization IRIG..........................................................................................................................314
Front Interface RS232..................................................................................................................................314
RS485..........................................................................................................................................................314
Boot phase...................................................................................................................................................314
STANDARDS.......................................................................................................................................315
Approvals.....................................................................................................................................................315
Design Standards........................................................................................................................................315
High Voltage Tests (IEC 60255-6) ...............................................................................................................315
EMC Immunity Tests....................................................................................................................................316
EMC Emission Tests....................................................................................................................................316
Environmental Tests.....................................................................................................................................317
Mechanical Tests.........................................................................................................................................318
TOLERANCES......................................................................................................................................319
Real Time Clock Tolerances........................................................................................................................319
Phase-to-earth and Residual Voltage Measurement................................................................................319
Frequency Measurement..................................................................................................................319
Protection Stages Tolerances......................................................................................................................320
99c1977de8af928602794036350f2d10
1ec234129e097c 4 d1d689072d4742d
RMS Handoff: 0
File: C:\p4_data\deliverMRU4\generated\MRU4_user_manual_uk.odt
This manual applies to devices (version):
Version 1.5.c
Build: 8210
Page 8 EN MRU4 10/09

Comments on the Manual
Comments on the Manual
This manual explains in general the tasks of device planning, parameter setting, installation, commissioning,
operation and maintenance of the HighPROTEC devices.
The manual serves as working asis for:
•Engineers in the protection field,
•commissioning engineers,
•people dealing with setting, testing and maintenance of protection and control devices,
•as well as trained personnel for electrical installations and power stations.
All functions concerning the type code will e defined. Should there e a description of any functions, parameters
or inputs/outputs which do not apply to the device in use, please ignore that information.
All details and references are explained to the est of our knowledge and are ased on our experience and
o servations.
This manual descri es the (optionally) full featured versions of the devices.
All technical information and data included in this manual reflect their state at the time this document was issued.
We reserve the right to carry out technical modifications in line with further development without changing this
manual and without previous notice. Hence no claim can e rought ased on the information and descriptions
this manual includes.
Text, graphic and formulae do not always apply to the actual delivery scope. The drawings and graphics are not
true to scale. We do not accept any lia ility for damage and operational failures caused y operating errors or
disregarding the directions of this manual.
No part of this manual is allowed to e reproduced or passed on to others in any form, unless Woodward SEG
GmbH & Co. KG have approved in writing.
This user manual is part of the delivery scope when purchasing the device. In case the device is passed on
(sold) to a third party, the manual has to e handed over as well.
Any repair work carried out on the device requires skilled and competent personnel who need to e well aware
especially of the local safety regulations and have the necessary experience for working on electronic protection
devices and power installations (provided y evidence).
Information Concerning Liability and Warranty
Woodward SEG does not accept any lia ility for damage resulting from conversions or changes carried out on
the device or planning (projecting) work, parameter setting or adjustment changes done y the customer.
The warranty expires after a device has een opened y others than Woodward SEG specialists.
Warranty and lia ility conditions stated in Woodward SEG’s General Terms and Conditions are not
supplemented y the a ove mentioned explanations.
EN MRU4 10/09 Page 9

IMPORTANT DEFINITIONS
IMPORTANT DEFINITIONS
The signal definitions shown elow serve the safety of life and lim as well as for the appropriate operating life of
the device.
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a hazardous
situation which, if not avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
CAUTION, without the safety alert symbol, is used to address practices not
related to personal injury.
Page 10 EN MRU4 10/09

IMPORTANT DEFINITIONS
FOLLOW INSTRUCTIONS
Read this entire manual and all other publications pertaining to the work to
be performed before installing, operating, or servicing this equipment.
Practice all plant and safety instructions and precautions. Failure to follow
instructions can cause personal injury and/or property damage.
PROPER USE
Any unauthorized modifications to or use of this equipment outside its
specified mechanical, electrical, or other operating limits may cause
personal injury and/or property damage, including damage to the
equipment. Any such unauthorized modifications: (1) constitute "misuse"
and/or "negligence" within the meaning of the product warranty thereby
excluding warranty coverage for any resulting damage, and (2) invalidate
product certifications or listings.
The programmable devices subject to this manual are designed for
protection and also control of power installations and operational devices.
The devices are further designed for installation in low voltage (LV)
compartments of medium voltage (MV) switchgear panels or in de
centralized protection panels. The programming and parameterization has
to meet all requirements of the protection concept (of the equipment that is
to be protected). You must ensure that the device will properly recognize
and manage (e.g. switch off the circuit breaker) on the basis of your
programming and parameterization all operational conditions (failures).
Before starting any operation and after any modification of the
programming (parameterization) test make a documentary proof that your
programming and parameterization meets the requirements of your
protection concept.
Typical applications for this product family/device line are for instance:
•Feeder protection
•Mains protection
•Machine protection
Any usage beyond these applications the devices are not designed for. The
manufacturer cannot be held liable for any resulting damage, the user alone
bears the risk for this. As to the appropriate use of the device: The
technical data and tolerances specified by Woodward SEG have to be met.
EN MRU4 10/09 Page 11

IMPORTANT DEFINITIONS
OUT OF DATE PUBLICATION
This publication may have been revised or updated since this copy was
produced. To verify that you have the latest revision, be sure to check the
Woodward SEG documentation website:
http://eps.woodward.com/download
The latest version of most publications is available at:
http://eps.woodward.com/download
If your publication is not there, please contact your customer service
representative to get the latest copy.
Page 12 EN MRU4 10/09

IMPORTANT DEFINITIONS
Electrostatic Discharge Awareness
All electronic equipment is electro static sensitive, some components more
than others. To protect these components from electro static damage, you
must take special precautions to minimize or eliminate electrostatic
discharges.
Follow these precautions when working with or near the control.
1. Before doing maintenance on the electronic control, discharge the
static electricity on your body to ground by touching and holding a
grounded metal object (pipes, cabinets, equipment, etc.).
2. Avoid the build up of static electricity on your body by not wearing
clothing made of synthetic materials. Wear cotton or cotton blend
materials as much as possible because these do not store static
electric charges as much as synthetics.
3. Keep plastic, vinyl, and Styrofoam materials (such as plastic or
Styrofoam cups, cup holders, cigarette packages, cellophane
wrappers, vinyl books or folders, plastic bottles, and plastic ash trays)
away from the control, the modules, and the work area as much as
possible.
4. Do not remove any printed circuit board (PCB) from the control cabinet
unless absolutely necessary. If you must remove the PCB from the
control cabinet, follow these precautions:
•Do not touch any part of the PCB except the edges.
•Do not touch the electrical conductors, the connectors, or the
components with conductive devices or with your hands.
•When replacing a PCB, keep the new PCB in the plastic
antistatic protective bag it comes in until you are ready to
install it. Immediately after removing the old PCB from the
control cabinet, place it in the antistatic protective bag.
To prevent damage to electronic components caused by improper
handling, read and observe the precautions in Woodward manual 82715,
Guide for Handling and Protection of Electronic Controls, Printed Circuit
Boards, and Modules.
Woodward SEG reserves the right to update any portion of this pu lication at any time. Information provided y
Woodward SEG is elieved to e correct and relia le. However, no responsi ility is assumed y Woodward SEG
unless otherwise expressly undertaken.
© Woodward SEG 2007 All Rights Reserved
EN MRU4 10/09 Page 13

IMPORTANT DEFINITIONS
Scope of Delivery
The delivery scope does not include the fastening material, ut includes all connection terminals, except
communication connectors. Please check the consignment for completeness on arrival (delivery note).
Please ascertain whether the type plate, connection diagram, type code and description of the device tally.
If you have any dou ts please contact our Service Department (contact address to e found on the reverse of
the manual).
Storage
The devices must not e stored outdoors. The storing facilities have to e sufficiently ventilated and must e dry
(see Technical Data).
Important Information
In line with the customer’s requirement the devices are combined in a
modular way (in compliance with the order code). The terminal assignment
of the device can be found on the top of the device (wiring diagram). In
addition to that it can be found within the appendix (wiring diagrams).
Page 14 EN MRU4 10/09

IMPORTANT DEFINITIONS
Symbols
EN MRU4 10/09 Page 15
inactive
active
IG.nondir Trip at
VE=0
1 2
Setting value:
<n am e > .
I
Device planning:
<name>
Signal:
IG
easured value s:
<name>.*int Alm L1
internal messag e
Functional descrip tion : If the setting
value "IG .Block at VE=0" is set to
"inactive" the o utput 1 is active a nd
outpu t 2 is inactive. If the s etting valu e
"IG .Block at VE=0" is set to "active" the
outpu t 2 is active and the output 1 is
ina ctive.
Prot.I dir fwd
AR.t-DP
0
t-DP
φ
"
φ
"=Elements with complex functions
"gray-box".
inactive
active
CB.Latched
Option/featu res to be realised in the future
Param eter of a odule-Input with a
SelectionLis t/D ropD ow n. An (1..n)
signal/output from the list or a pre-
define d value ca n be selected.
1..n, Assignm ent List
<n am e >
1..n, VeEnable
no assig nm e n t,1.. n
no assignm ent 1
<n am e >
1..n, Assignm ent List
Param eter of a odule-Input (with
spe cial values): An (1..n) output from the
list will be assigned to the input
"< nam e>.id entifier". If the param eter is
set to "ItemNull", an "active"-signal w ill be
given out.
Lim it value m onitoring w ith three
analogue input values. Com p ares 3
analogue va lu es with the s et lim it;
output value s are three different
binary values as a result of the
com parision . If th e analogue sig na l
exceeds the limit I/In the
correspond ing ou tput signal becomes
"1 ".
I/ In
IL1 IL2 IL3
<20%Vn
V
Lim it value m onitoring (Com p ared to
a fixed value). Com pares a valu e w ith
the fix ed set lim it; output va lue is
binary as a result o f the com parision.
If the signal exceeds the lim it the
correspo nd ing output signal becomes
"1".
Adaptive Parameter

IMPORTANT DEFINITIONS
Page 16 EN MRU4 10/09
And Or Negated input Negated output
>1
Band-pass (filter) IH1 Band-pass (filter) IH2 Quotient of analogue values
0t
<name>.t
1
CB.t-TripCmd
t
Analog values
&
S 1
R1 1
a
b
c
d
RS flip-flop a b c d 0 0 Unchanged
0 1 0 1 1 0 1 0 1 1 0 1
Time stage: A "1" at the
input starts the stage. If the
time <name>.t is expired the output becomes "1" too.
The time stage will be reset by "0" at the input. Thus the
output will be set to "0" at
the same time.
Time stage minimum pulse
width: The pulse width
<name>.t will be started if a "1" is feed to the input. By
starting <name>.t the output
becomes "1". If the time is expired, the output becomes
"0" independent from the
input signal.
IH1 IH2
IH2 IH1
=1
Exclusive-OR
Analogue values comparator
+ R
+ increment R Reset
Edge triggered counter

IMPORTANT DEFINITIONS
EN MRU4 10/09 Page 17
2
2
Input Signal
Output Signal
2
name.active
3
name.Blo TripCmd
4
name.active
5
IH2.Blo L1
6
IH2.Blo L2
7
IH2.Blo L3
8
IH2.Blo IG
9
name. Fault in projected direction
10
name. Fault in projected direction
11
CB.Trip CB
12
VTS.Alarm
14 15
name.TripCmd
1
Prot.available
Please Refer To Diagram: Blockings
Please Refer To Diagram: Blockings**
Please Refer To Diagram:
Pro t
Please Refer To Diagram: Trip blockings
Please Refer To Diagram: IH2
Please Refer To Diagram: IH2
Please Refer To Diagram: IH2
Please Refer To Diagram: IH2
Please Refer To Diagram: direction decision
phase overcurrent
Please Refer To Diagram: VTS
Please Refer To Diagram: CB
Please Refer To Diagram: direction decision
Earth fault
name.Alarm
Each alarm of a module (except from
supervision modules ut including CBF) will
lead to a general alarm (collective alarm).
Each trip of an active, trip authorized
protection module will lead to a general trip.
17
name.Trip L2
18
name.Trip L3
19
name.TripCmd
20
name.Trip L1
21
name.Trip L2
16
name.Trip L1
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
22
name.Trip L3
23
name.Trip
Each trip of an active, trip authorized protection module
will lead to a general trip.
Each trip of an active, trip authorized protection module
will lead to a general trip.
25
name.Alarm L2
26
name.Alarm L3
27
name.Alarm
28
name.Alarm L1
29
name.Alarm L2
24
name.Alarm L1
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
30
name.Alarm L3
31
name.Alarm
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
Each phase selective alarm of a module (I, IG, V, VE
depending on the device type) will lead to a phase
selective general alarm (collective alarm).
32
Prot.Blo TripCm d

IMPORTANT DEFINITIONS
Page 18 EN MRU4 10/09
34
CB.Pos ON
35
CB.Pos OFF
33
CB.Pos
Please Refer To Diagram: CB.CB Manager
Please Refer To Diagram: CB.CB Manager
Please Refer To Diagram: CB.CB Manager
36
CB.Pos Indeterm
37
CB.Pos Disturb
Please Refer To Diagram: CB.CB Manager
Please Refer To Diagram: CB.CB Manager

Device
Device
MRU4
Device Planning
Planning of a device means to reduce the functional range to a degree that suits the protection task to e
fulfilled, i.e. the device shows only those functions you really need. If you, for example, deactivate the voltage
protection function, all parameter ranches related to this function do not appear in the parameter tree any more.
All corresponding events, signals etc. will e deactivated too. By this the parameter trees ecome very
transparent. Planning also involves adjustment of all asic system data (frequency etc.).
But it has to be taken into account that by deactivating, for instance,
protective functions, you also change the functionality of the device. If you
cancel the directional feature of the overcurrent protections then the device
no longer trips in a directional way but merely in a non directional way.
The manufacturer does not accept liability for any personal or material
damage as a result of wrong planning.
A planning service is also offered by Woodward SEG.
Beware of inadvertent deactivating protective functions/modules
If you are deactivating modules within the device planning all parameters of
those modules will be set on default.
If you are activating one of these modules again all parameters of those
reactivated modules will be set on default.
EN MRU4 10/09 Page 19

Device
Device Planning Parameters of the Device
Parameter Description Options Default Menu path
Hardware Variant 1 Optional Hardware
Extension
»A« 8 digital inputs | 6
binary output relays
8 digital inputs | 6 binary
output relays
[M U4]
Hardware Variant 2 Optional Hardware
Extension
»0« Standard »0« Standard [M U4]
Housing Mounting form »A« Flush mounting,
»B« 19 inch mounting
(semi-flush)
Flush mounting [M U4]
Communication Communication »A« Without,
»B« Modbus TU, IEC
60870-5-103: S485 /
Terminals,
»C« Ethernet,
»D« Profibus-DP: Fibre
Optics,
»E« Profibus-DP:
S485 / D-SUB,
»F« Fiber Optic,
»G« S485 D-Sub
»A« Without [M U4]
Page 20 EN MRU4 10/09
