Work Smart WS-MH-LFTB2-101 User manual

Instruction Manual
Lift Table
WS-MH-LFTB2-101 - WS-MH-LFTB2-104 - WS-MH-LFTB2-106
Note: Owner/Operator must read and understand this instruction manual
before using the lift table.

1
Contents
1
WARNING
2
2
CAUTION
2
3
NAME OF PARTS
3
4
HOW TO ASSEMBLE
3
5
DAILY INSPECTION
6
6
OPERATING LIFTTABLE
6. LIFTTABLE
7
7
SPECIFICATIONS
8
8
SERVICE INSTRUCTION
8
9
HYDRAULIC CIRCULT
9
10
SPARE PARTS LIST
10
11
TROUBLES SHOOTING
16

2
BEFORE OPERATING THE LIFT TABLE, READ THIS MANUAL CAREFULLY AND
UNDERSTAND COMPLETELY. KEEP THIS MANUAL ON FILE FOR FUTURE REFERENCE. IF
THIS IS LOST, PLEASE CONTACT YOUR LOCAL SUPPLIER FOR A NEW COPY. ALSO, IF
THE WARNING/CAUTION DECAL ON THE UNIT IS LOST, PLEASE CONTACT YOUR LOCAL
SUPPLIER FOR A NEW DECAL.
NOTE: On this manual, WARNING means the danger which can lead to death or serious injury.
CAUTION means the danger which can lead to slight injury or property damage.
1. WARNING
1. DO NOT put foot or hand in scissors mechanism.
2. DO NOT allow other person to stand in front of or behind lift table when it is moving.
3. DO NOT move lift table when table is in raised position. Load could fall down.
4. DO NOT enter under table.
5. DO NOT overload lift table.
6. DO NOT put foot in front of rolling wheels. Injury could result.
7. WATCH difference and hardness of floor level when moving lift table. Load could fall down.
8. DO NOTuse lift table on slope orinclined surface, lift table may become uncontrollable and create danger.
9. DO NOT lift people. People could fall down and suffer severe injury.
2. CAUTION
1. Read this operation manual carefully and understand completely operating lift table. Improper operation
could create danger.
2. This lift table is a movable lifter designed to lift or lower rated load on table. DO NOT use lift table for other
purpose than its intended use.
3. DO NOT allow person to operate lift table who does not understand its operation.
4. DO NOT lower table too fast. Load could fall down and create danger.
5. KEEP watching the condition of load. Stop operating lift table if load becomes unstable.
6. Brake lift table when sliding loads are off table.
7. DO NOT side or end load. Load must be distributed on at least 80%of table area.
8. DO NOT use lift table with unstable, unbalanced loosely stacked load.
9. Practice maintenance work according to service instructions.
10. DO NOT modify lift table without manufacturer’s written consent.
11. REMOVE load from table and use safety stopper to prevent table from lowering when servicing lift table.
12. This lift table is not designed to be water resistant. Use lift table under dry condition.

3
3. NAME OF PARTS
WS-MH-LFTB2-101 WS-MH-LFTB2-104 WS-MH-LFTB2-106
4. How to Assemble
Ensure that the “Lift Table” is sufficently secured before beginning to assemble.
A spanner tool and caliper are required when assembling the lift table. Clamping tools, such as monkey
wrenches can also be used..
Locate these parts for assembly Correctly assembled
4.1 Secure the handle on the chassis using two bolts as well as the flat washers and spring washer

4
4.2 Foot pedal assembly
1) Place the foot pedal into the chassis pipe 2) Tighten the bolts
4.3. Lift the platform and place two support bars that will secure and hold the chassis steady.
4.4. To attach the release handle:
4.4.1 Connect the chain to the bottom of the pump.
.
a) Remove the cotter pins from the axle

5
b) Secure the chain into the pump block using cotter pins and the axle.
4.4.2 Securing the chain into the chassis groove:
Using two washers, put the bolt into the the middle of thread groove and then tighten the nut.
4.4.3 Clip the chain on the handle.
4.4.4. Once assembled, the lift table will activate, lift and lower easily when the lift handle is released. If the
table will not lower, please adjust using steps a) or b)
a) Loosen the up and down nuts, pull the release wire up for a snug fit, and then tighten the nuts until the
table lowers smoothly.
a) b) Loosen the up and down nuts, Pull the release wire down, and then tighten the nuts until the table

6
lowers smoothly.
.
5. DAILY INSPECTION
Daily inspection is effective to prevent a malfunction or fault with the lift table. Check the following points before
operating the lift table.
CAUTION
DO NOT use the lift table if a malfunction or fault is found.
(1) Check the lift table for scratches, bending or cracks.
(2) Check if there is any cylinder oil leakage..
(3) Check the vertical creep of the table.
(4) Check that the wheel moves smoothly
(5) Check that the brake functions correctly.
(6) Ensure all bolt and nuts are securely tightened.
6. OPERATING LIFTTABLE

7
6-1. How to use the brake.
CAUTION
Ensure that the brake for the lift table is set when it is not in use to prevent sudden movement.
The brake is located on the right side of the swivel caster.
(1) To set the brake, press the brake pedal.
(2) To release the brake, lift up the brake pedal.
6-2. Lifting the table
WARNING
1. DO NOT overload the lift table; ensure the load is within its rated capacity.
2. All loads must be distributed evenly on at least 80% of the table area. DO NOT set loads to the side
or ends of the lift table surface.
Press the lifting pedal several times until the table reaches the desired position.
The table does not elevate once it has reached the highest possible position even if the lifting pedal is
continually pressed.
The table lowers slightly after reaching the highest position.
NOTE:
The hydraulic cylinder is designed to hold the table.As is the nature of the hydraulic system, the table lowers
very slowly over an extended period of time, Please note the table will not stay at the same position
indefinitely.
6-3. Lowering table
WARNING
Keep your feet and hands clear of the scissors mechanism.
Pull the lowering lever up and table lowers.
7. Specifications

8
Model
Capaci
ty
(lbs)
Table
(inch)
Table Height
(inch)
Stroke
L×W×H
(inch)
Pedal to top.
(approx.times)
Wheel
(inch
Weight
(lbs)
WS-MH-L
FTB2-101
440
17.7*257.
5
10.4—29.7
490
34.3×17.1×38.6
≤25
4
96.8
WS-MH-L
FTB2-104
1760
36.2×
20.5
17.4—39.4
558
46.1×20.5×44.5
≤70
5.9
250.8
WS-MH-L
FTB2-106
770
36.2×
20.5
17.1—59.1
1065
46.1×20.5×44.5
≤70
5.9
275
8. Service instruction
8-1. Change hydraulic oil every 12 months.
8-2. Lubricate each point described below every month:
Lubricating Points
(1) Fitting of cylinder……Oil
(2) Roller friction surface……Grease
(3) Link Pin ……Oil
(4) Pedal fitting point……Oil
(5) Link center pin……Oil
(6) Joint……Grease
(7) Grease nipple……Grease
(8) Hydraulic circuit

9
9. Hydraulic Circuit

10
10. LIFT TABLE SPARE PARTS LIST

11
LIFT TABLE SPARE PARTS LIST WS-MH-LFTB2-101
NO.
DESCRIPTION
NO.
DESCRIPTION
NO.
DESCRIPTION
1.
Table pair
33.
Spring
65.
Split pin 3×30
2.
Guide roller
34.
Spring
66.
Bushing
3.
Link pair
35.
Pump bass
67.
Pedal pivot pin
4.
Snap ring 12
36.
Mesh
68.
Hex. Nut M6
5.
Link pin
37.
Washer φ9×φ5
69.
Spring washer 6
6.
Safety pin
38.
Discharge spring
70.
Washer 6
7.
Hex socket screw bolt M8×20
39.
O-ring D14×2.4
71.
Hex. bolt M6×40
8.
Washer 8
40.
Plug
72.
Seal ring
9.
Frame pair
41.
O-ring d10.6×2.65
73.
Elbow
10.
Front wheel
42.
Discharge lever bushing
74.
Oil retum hose
11
Spring washer 8
43.
O-ring d4×1.8
75.
Check ring
12.
Nut M8
44.
Discharge lever
76.
Rubber bushing
13.
Piston rod
45.
Discharge lever
77.
Pedal pair
14.
Dust seal D33×d25×5
46.
Hex socket screw bolt M6×16
78.
Pedal rubber
15.
O-ring d25×2.65
47.
Washer 6
79.
Hex bolt M8×16
16.
Back up ring
48.
Bushing
80.
Cylinder pivot pin
17.
Cylinder pair
49.
Steel ball φ5
81.
Grease fitting
18.
Spring seat
50.
Spring seat assembly
82.
Piston head pin
19.
Relief spring
51.
Regulating pressure spring
83.
Joint
20.
O-ring 22×2.4
52.
Regulating pressure nut
84.
Hex. Bolt M12×25
21.
Joint
53.
O-ring d7.1×1.8
85.
Spring washer 12
22.
Adjust casing seat
54.
Screw
86.
Washer
23.
Adjust casing
55.
Plug
87.
Handle
24.
Spring seat
56.
O-ring d10×2.65
88.
Cover type nut M6
25.
Spring
57.
Seal ring 14
89.
Screw M6×30
26.
Conical valve
58.
High pressure hose
90.
Control link
27.
Check valve casing
59.
Joint
91.
Spring pin 5×14

12
28.
O-ring d6.9×1.8
60.
Rear wheel
92.
Rod
29.
Steel ball φ7
61.
Pedal holder
93.
Connecting rod
30.
O-ring d20×2.65
62.
Retaining ring for axle 10
94.
Chain
31.
Y-ring 28×20×5
63.
Pressure roller
32.
Pump plunger
64.
Pressure roller pin

13

14
LIFT TABLE SPARE PARTS LIST WS-MH-LFTB2-104
NO.
DESCRIPTION
NO.
DESCRIPTION
NO.
DESCRIPTION
1.
Seal cover d30×D42×7
38.
O-ring d18×2.65
75.
Spring
2.
Cylinder cover
39.
Pump plunger
76.
Retainer 10
3.
O-ring d63×2.65
40.
Y-ring
77.
Pin axle
4.
O-ring d30×3.55
41.
Pump body for plunger
78.
Link
5.
Piston Rod
42.
O-ring D28×3.1
79.
Wheel
6.
Spacing casing
43.
Pump body
80.
Nut M10
7.
Guidering δ1.5×15
44.
O-ring d10.6×2.65
81.
Spring washer 10
8.
O-ring D20×2.4
45.
Spring
82.
Washer 10
9.
Seal ring d34×D40×4.5
46.
Reflux rod
83.
Hex soch screw M10×25
10.
Retainer for piston rod
47.
O-ring d4×1.8
84.
Wheel
11.
Spacing retainer 18
48.
Guide casing
85.
axle
12.
Piston
49.
Protect casing
86.
Retainer 20
13.
Cylinder
50.
Lever
87.
Chassis
14.
Washer for cylinder
51.
Lever bushing
88.
Bolt M6×8
15.
Reservior
52.
Washer 6
89.
Table
16.
O-ring d10×2.65
53.
Spring washer 6
90.
Roller for table
17.
Filler screw
54.
Hex soch screw M6×16
91.
Split pin 3.2×26
18.
Washer for reservior
55.
Tube for steel wire
92.
Nut M16
19.
Steel ball 5
56.
Steel wire
93.
Washing
20.
Spring base
57.
Nut M8
94.
Bushing
21.
Regulating pressure spring
58.
Washer 8
95.
Spring pin 8×30
22.
Regulating pressure screw
59.
Screw M6×30
96.
Screw bolt M10×40
23.
O-ring d7.1×1.8
60.
Spring pin
97.
Safety rod
24.
End cover
61.
Control link
98.
Nut M10
25.
O-ring d15×2.65
62.
Handle
99.
External scissors lever
26
Regulating slide-valve
63.
Cover type nut M6
100.
Bushing
27
Regulating speed spring
64.
Spacing casing
101.
Roller for chassis
28.
Regulating speed spring casing
65.
Spring washer 12
102.
Internal scissors lever
29.
Regulating speed slide-casing
66.
Hex screw M12×30
103.
Pin axle for chassis
30.
Steel ball 7
67.
Split pin 2×15
104
Hex screw M8×16
31.
O-ring d6.9×1.8
68.
Pin
105
Spring washer 8
32
Check valve casing
69.
U- fork
106.
Pin axle for scissons
33
Conical valve
70.
Nut M6
107.
Pin axle for table
34
Spring
71.
Bolt
108.
Bushing
35.
O-ring d10×1.8
72.
Pedal bent pipe
109.
Bolt M8×12
36.
Check valve screw
73.
Hex soch screw M8×20
110.
Oil cup
37.
Seal cover d18×D25×4.5
74.
Shake link

15

16
LIFT TABLE SPARE PARTS LIST WS-MH-LFTB2-106
NO.
DESCRIPTION
NO.
DESCRIPTION
NO.
DESCRIPTION
1.
Seal cover d30×D42×7
41.
Pump body for plunger
81
Washer 10
2.
Cylinder cover
42.
O-ring D28×3.1
82
Wheel
3.
O-ring d63×2.65
43.
Pump body
83.
Hex soch screw M10×25
4.
O-ring d30×3.55
44.
O-ring d10.6×2.65
84.
Wheel
5.
Piston Rod
45.
Spring
85.
Pin axle
6.
Spacing casing
46.
Reflux rod
86.
Retaining ring for axle 20
7.
Guideing δ1.5×15
47.
O-ring d4×1.8
87.
Chassis
8.
O-ring D20×2.4
48.
Guide casing
88.
Bolt M6×8
9.
Seal ring d34×D40×4.5
49.
Protect casing
89.
Pin axle for chassis
10.
Retainer for piston rod
50.
Lever
90.
Bushing
11.
Spacing retainer 18
51.
Lever bushing
91.
Locking nut M14
12.
Piston
52.
Washer 6
92.
Washer 14
13.
Cylinder
53.
Spring washer 6
93.
Washer 16
14.
Washer for cylinder
54.
Hex soch screw M6×16
94.
Pin axle
15.
Reservior
55.
Tube for steel wire
95.
Bushing 1612
16.
O-ring d10×2.65
56.
Steel wire
96.
Bushing 1620
17.
Filler screw
57.
Nut M8
97.
Retaining ring for axle 16
18.
Washer for reservior
58.
Washer 8
98.
Pin axle
19.
Steel ball 5
59.
Screw M6×30
99.
Hex socket set screw M8×12
20.
Spring base
60.
Spring pin 5×14
100.
Oil cup
21.
Regulating pressure spring
61.
Control link
101.
External scissors lever for table
22.
Regulating pressure screw
62.
Handle
102.
Internal scissors lever for table
23.
O-ring d7.1×1.8
63.
Cover type nut M6
103.
Roller for table
24.
End cover
64.
Spacing casing
104.
Table
25.
O-ring d15×2.65
65.
Spring washer 12
105.
Spring pin 8×30
26
Regulating slide-valve
66.
Hex screw M12×30
106.
Screw bolt M10×40
27
Regulating speed spring
67.
Split pin 2×15
107.
Safety rod
28.
Regulating speed spring casing
68.
Pin
108.
Locking nut M10
29.
Regulating speed slide-casing
69.
U- fork
109.
External scissors lever for chassis
30.
Steel ball 7
70.
Nut M6
110.
Internal scissors lever for chassis
31.
O-ring d6.9×1.8
71.
Bolt
111.
Bushing
32
Check valve casing
72.
Pedal bent pipe
112.
Roller for chassis
33
Conical valve
73.
Hex soch screw M8×20
113.
Slotting nut M16×1.5
34
Spring
74.
Shake link
114.
Washing
35.
O-ring d10×1.8
75.
Spring
115.
Split pin 4×28
36.
Check valve screw
76.
Retainer 10
116.
Pin axle
37.
Seal cover d18×D25×4.5
77.
Pin axle
117.
Spring washer 8
38.
O-ring d18×2.65
78.
Link
118.
Hex screw M8×16
39.
Pump plunger
79
Nut M10
40.
Y-ring d10×D18×6
80
Spring washer 10

17
11. TROUBLES SHOOTING
NO
TROUBLE
CAUSE
ACTION
1
The table does not lift
to maximum height.
-Not enough hydraulic oil.
-Add more oil.
2
The table does not lift
up.
-Not enough hydraulic oil.
-The oil has impurities.
-Discharge valve is out of
adjustment.
-Pour in more filtered oil.
-Change the oil.
-Adjust the setting nut (See item 4.4.4
b). But pressure line adjusting the
opposite direction
3
The table does not
descend.
-A part has been broken or
been deformed resulting from
unbalanced load.
-The setting screw (58) is not in
the correct position.
-Repair or replace component.
-Adjust the setting nut (See item
4.4.4 b)
4
Leaks
-Seals worn out or damaged.
-Some parts may be cracked or
worn out.
-Replace seals with new ones.
-Check and replace with new ones.
5
The table descends
without being
lowered.
-Seals worn or damaged.
-Discharge valve is out of
adjustment.
-Replace with new ones.
-Adjust the setting nut (See item 4.4.4
b).
*NOTE: DO NOTATTEMPT TO REPAIR THE TABLE UNLESS YOU ARE TRAINEDAND AUTHORIZED TO
DO SO.
