OWNER’S/
OPERATOR’S
MANUAL
MODEL NO.’s
ULF-355
ULF-346
VLF-7655
VLF-7646
SSPF-40
WHEN ORDERING
REPAIR PARTS, ALWAYS
GIVE THE FOLLOWING
INFORMATION:
1. PART NUMBER
2. PART DESCRIPTION
3. MODEL NUMBER
4. NAME OF ITEM
DECEMBER 2001
WS-TA004-OG
SAFETY PRECAUTIONS
MOST ACCIDENTS OCCUR BECAUSE OF NEGLECT OR CARELESSNESS.
AVOID NEEDLESS ACCIDENTS BY FOLLOWING ALL OF THE SAFETY PRECAUTIONS LISTED BELOW.
•Machinery should be operated only by those who are
responsible and are authorized to do so.
•Stop the engine, lower all equipment, lock the brakes,
and remove the ignition key before dismounting from the
tractor.
•Never stand between tractor and implement while tractor
is being backed to hitch.
•Loose fitting clothing should not be worn, to avoid catch-
ing on various parts.
•Detach implement in area where children normally do not
play.
•When performing adjustments or maintenance on an
implement, first lower it to the ground or block it securely
at a workable height.
•Only a qualified operator should be permitted on tractor
when in operation; no riders allowed.
•Make certain everyone is in the clear before starting
tractor or raising or lowering equipment.
•Operate the tractor and implement only while seated in
the driver’s seat.
• Reduce speed when transporting mounted implements
to avoid bouncing and momentary loss of steering
control.
•A heavy load can cause instability of the tractor. Use
extreme care during road travel. Slow down on turns and
watch out for bumps. Tractor may need front counter-
weights to counter-balance the weight of the implement.
•Reduce speed on hillsides or curves so there is no
danger of tipping.
•Avoid driving too close to the edge of ditches or creeks.
•Do not transport implement on public roads without
reflectors and slow moving vehicle emblem in daylight
and with approved warning lights at night and other
periods of poor visibility.
•Due to the width of some implements, use extra caution
on highways, farm roads, and when approaching gates.
•Always be sure the implement is in the proper position for
transport.
•Keep alert and watch the front as well as the rear when
working with the implement.
WORKSAVER, INC.
P.O. BOX 100 LITCHFIELD, IL 62056-0100 [phone]
WEB: http://www.worksaver.com E-MAIL: [e-mail]
UNIVERSAL LOADER FORK
and
SKID STEER PALLET FORK
Safety Instructions Assembly & Mounting
Tractor Preparation Maintenance
Operating Instructions Repair Parts
CAUTION
THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD
BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE
1. Select an area for assembly that is clean and free of any
debris which might cause persons working on the
assembly to trip.
2. Do not lift heavy parts or assemblies. Use crane, jack,
tackle, fork trucks or other mechanical devices.
3. Preview the assembly instructions in your operator’s
manual before proceeding further.
4. If the assembly instructions call for parts or assemblies to
be blocked up, use only blocking material that is in good
condition and is capable of handling the weight of the
assembly to be blocked. Also insure that the blocking
material is on a clean, dry surface.
5. Never put hands, or any part of body, under blocked up
assemblies if at all possible.
6. After completing assembly, thoroughly inspect the
machine to be sure that all nuts, bolts, hydraulic fittings
or any other fastened assemblies have been thoroughly
tightened.
7. Before operating the machine, thoroughly read the
operation section of your operator’s manual.
8. Before operating, read the maintenance section of your
operator’s manual to be sure that any parts requiring
lubrication, such as gearboxes, are full, to avoid any
possible damage.
9. Before operating equipment – If you have any
questions regarding the proper assembly or
operation, contact your dealer or representative.
OWNER’S/
OPERATOR’S
MANUAL
MODEL NO.’s
ULF-355
ULF-346
VLF-7655
VLF-7646
SSPF-40
CAUTION
For Safe Operation
Read Rules And
Instructions Carefully
SINO LEEINGLES, PIDAAYUDA
A AIGUIEN QUE SI LO LEA
PARA QUE LE TRADUZCA LAS
MEDIDAS DE SEGURIDAD.
MAKE EVERY DAY A
HOLIDAY FROM ACCIDENTS!
LOADER FORK
Please work, drive, play and live each day with care
and concern for your safety and that of your family
and fellow citizens.

1
20
TABLE
OF
CONTENTS
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SAFETY SIGNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PREPARATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . 14
OPERATING INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . 16
OWNER MAINTENANCE & LUBRICATION . . . . . . . . . . . . . 19
PARTS DRAWING/LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
TO THE OWNER:
Read this manual before using your Loader Fork. This manual is provided to give you the necessary operating
and maintenance instructions for keeping your Loader Fork in top operating condition. Please read this manual
thoroughly. Understand what each control is for and how to use it. Observe all safety signs on the machine and
noted throughout the manual for safe operation of implement. Keep this manual handy for ready reference.
Like all mechanical products, it will require cleaning and upkeep.
Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet stan-
dards required for safe and satisfactory operation. Record the model and serial number of your Loader Fork here:
Model:________________________________________ Serial Number:_______________________________
RETAIL CUSTOMER’S RESPONSIBILITY
It is the Retail Customer and/or Operator’s responsibility to read the Operator’s Manual, to operate, lubri-
cate, maintain, and store the product in accordance with all instructions and safety procedures. Failure
of the operator to read the Operator’s Manual is a misuse of this equipment.
It is the Retail Customer and/or Operator’s responsibility to inspect the product and to have any part(s)
repaired or replaced when continued operation would cause damage or excessive wear to other parts or
cause a safety hazard.
It is the Retail Customer’s responsibility to deliver the product to the authorized Worksaver Dealer, from
whom he purchased it, for service or replacement of defective parts which are covered by warranty.
Repairs to be submitted for warranty consideration must be made within forty-five (45) days of failure.
It is the Retail Customer’s responsibility for any cost incurred by the Dealer for traveling to or hauling
of the product for the purpose of performing a warranty obligation or inspection.
SINO LEEINGLES, PIDA AYUDA A
AIGUIEN QUE SI LO LEA PARA QUE
LE TRADUZCA LAS MEDIDAS DE
SEGURIDAD.
STATEMENT
OF POLICY
It is the policy of Worksaver,
Inc. to improve its products
where it is possible and practical
to do so. Worksaver, Inc.
reserves the right to make
changes or improvements in
design and construction at any
time, without incurring the obliga-
tion to make these changes on
previously manufactured units.
ULF-346, ULF-355,
VLF-7646, VLF-7655 & SSPF-40
PARTS DRAWING

19
2
LIMITED WARRANTY
Worksaver warrants to the original purchaser of any new Pallet Fork or Hay Fork (Models ULF-346/355, VLF-
7646/7655, and SSPF-40), that the equipment be free from defects in material and workmanship for a period
of six (6) months for non-commercial, state, and municipalities. Use sixty (60) days for commercial use from
date of retail sale.
Replacement or repair parts installed in the equipment covered by this warranty are warranted for sixty (60)
days from the date of purchase of such part or to the expiration of the applicable new equipment warranty
period, whichever occurs later.
Such parts shall be provided at no cost to the user during regular working hours. Worksaver reserves the right
to inspect any equipment or parts which are claimed to have been defective in material or workmanship.
DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES
Worksaver’s obligation under this warranty, to the extent allowed by law, is in lieu of all warranties, implied or
expressed, including implied warranties of merchantability and fitness for a particular purpose and any liability
for incidental and consequential damages with respect to the sale or use of the items warranted. Such
incidental and consequential damages shall include but not be limited to: transportation charges other than
normal freight charges; cost of installation other than cost approved by Worksaver; duty; taxes; charges for
normal service or adjustments; loss of crops or any other loss of income; rental of substitute equipment,
expenses due to loss, damage, detention or delay in the delivery of equipment or parts resulting from acts
beyond the control of Worksaver.
THIS WARRANTY SHALL NOT APPLY:
1. To vendor items which carry their own warranties, such as hydraulic cylinders, tires, and tubes.
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident.
3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge-
ment of Worksaver such use affects its performance, stability, or reliability.
4. If the unit has been altered or repaired outside of an authorized Worksaver dealership in a manner which,
in the sole judgement of Worksaver affects its performance, stability or reliability.
5. To normal maintenance service and normal replacement items such as gearbox lubricant, hydraulic fluid,
worn blades, or to normal deterioration of such things as belts and exterior finish, due to use or exposure.
6. To expendable or wear items such as teeth, chains, sprockets, belts, springs and other items that in the
company’s sole judgement is a wear item.
NO EMPLOYEE OR REPRESENTATIVE OF WORKSAVER IS AUTHORIZED TO CHANGE THIS WARRANTY IN
ANY WAY OR GRANTANY OTHER WARRANTY UNLESS SUCH CHANGE IS MADE IN WRITING AND SIGNED
BY WORKSAVER’S SERVICE MANAGER, POST OFFICE BOX 100, LITCHFIELD, ILLINOIS 62056-0100.
OWNER SERVICE
Check the pins at the ends of the loader arms. Make
sure they are locked in place with the linchpins.
Periodically check all bolts to make sure they are tight.
Check hydraulic hoses. Make sure they are not chafed
or pinched. Replace any damaged hose.
Check hydraulic hoses and fittings for leaks. Repair any
leaks immediately. Never use your hand to check for a
hydraulic leak when system is under pressure.
Periodically lubricate the swing arm pivot bushings.
Replace any worn or damaged parts immediately. Do
not use attachment with any damaged parts.
REPLACE SAFETY SIGNS
IF DAMAGED OR MISSING!
STORAGE
MAINTENANCE
• Never store equipment with fuel in the tank inside a
building where fumes may reach an open flame or
spark. Allow engine to cool before storing in an
enclosure.
• Do not run engine indoors – exhaust gasses contain
carbon monoxide, and odorless and deadly poison.
• At the end of the working season or when the Loader
Fork will not be used for a long period, it is good
practice to clean off any dirt or grease that may have
accumulated.
• Inspect the Loader Fork for loose, damaged or worn
parts and adjust or replace if needed.
• Sand areas where paint is chipped or worn and
repaint to prevent rust.
• Always store in a safe place away from children or
livestock.
W ARNING!
Always stop the tractor, set brake, shut off engine,
remove key, and lower loader to ground before
attempting to service. Never leave equipment unat-
tended with engine running.
W ARNING!
Do not work under a raised loader unless it is
securely blocked or held in position. Do not depend
on the hydraulic system to hold loader and attach-
ment in place.

3
18
To the Owner/Operator/Dealer
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera-
tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this
implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!!
Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
THIS SAFETY ALERT SYMBOL IDENTIFIES IMPORTANT
SAFETY WARNING MESSAGES. CAREFULLYREAD EACH
WARNING MESSAGE THAT FOLLOWS. FAILURE TO
UNDERSTAND AND OBEY A SAFETY WARNING, OR
RECOGNIZE A SAFETY HAZARD, COULD RESULT IN AN
INJURY OR DEATH TO YOU OR OTHERS AROUND YOU.
THE OPERATOR IS ULTIMATELY RESPONSIBLE FOR THE
SAFETY OF HIMSELF, AS WELL AS OTHERS, IN THE
OPERATING AREA OF THE TRACTOR AND ATTACHED
EQUIPMENT.
IMPORTANT SAFETY INFORMATION!
Working with unfamiliar equipment can lead to careless injuries. Read this manual, and the manual for your tractor,
skid steer, or forklift, before assembly or operating, to acquaint yourself with the machines. It is the implement owner’s
responsibility, if this machine is used by any person other than yourself, is loaned or rented, to make certain that the
operator, prior to operating:
1. Reads and understands the operator’s manuals.
2. Is instructed in safe and proper use.
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design. All operators of this equipment must read and understand this entire manual, paying
particular attention to safety and operating instructions, prior to using. If there is something in this manual you
do not understand, ask your supervisor, or your dealer, to explain it to you.
THIS SYMBOL MEANS
– ATTENTION!
– BECOME ALERT!
– YOUR SAFETY IS INVOLVED!
UNDERSTAND SIGNAL WORDS
Note the use of the signal words DANGER, WARNING
and CAUTION with the safety messages. The
appropriate signal word for each has been selected
using the following guidelines:
DANGER: Indicates an imminently hazardous situation
that, if not avoided, will result in death or serious injury.
This signal word is to be limited to the most extreme
situations typically for machine components which, for
functional purposes, cannot be guarded.
If you have questions not answered in this manual or require additional copies or the manual is damaged, please
contact your dealer or the manufacturer directly.
WARNING: Indicates a potentially hazardous sit-
uation that, if not avoided, could result in death
or serious injury, and includes hazards that are
exposed when guards are removed. It may also
be used to alert against unsafe practices.
CAUTION: Indicates a potentially hazardous sit-
uation that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
CAUTION!
When traveling on public roads, whether at night or
during the day, use accessory light and devices for
adequate warnings to operators of other vehicles.
Comply with all federal, state and local laws.
Carry load low.
Check visibility. If visibility is impaired, reduce speed or
consider other means of transport.
Allow for additional length of loader on tractor while
turning.
Select a safe ground travel speed when transporting
from one area to another. When traveling on roadways,
transport in such a way that faster moving vehicles may
pass you safely.
When traveling over rough or hilly terrain or when mak-
ing turns, slow down and use extra care.
Read all the safety warnings in the front of the
manual.
TRANSPORTING
OPERATING INSTRUCTIONS (continued)
OBEY ALL
SAFETY WARNINGS
UKeep children away from danger all day, every day.
UEquip tractors with roll-over protection (ROPS) and keep
all machinery guards in place.
UPlease work, drive, play, and live each day with care and
concern for your safety and that of your family and fellow
citizens.

17
4
SAFETY INSTRUCTIONS (continued)
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment.
Designers and manufacturers build in as many safety features as possible. However, every year many
accidents occur which could have been avoided by a few seconds of thought and a more careful approach to
handling equipment. You, the operator, can avoid many accidents by observing the following precautions in
this section. To avoid personal injury, study the following precautions and insist those working with you, or for
you, follow them.
In order to provide a better view, certain photographs or illustrations in this manual may show an assembly
with a safety shield removed. However, equipment should never be operated in this condition. Keep all shields
in place. If shield removal becomes necessary for repairs, replace the shield prior to use.
To prevent injury or death, use a tractor equipped with a Roll-Over Protective System (ROPS). Do not paint
over, remove or deface any safety signs or warning signs on your equipment. Observe all safety signs and
practice the instruction on them.
Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question -
DON’T TRY IT.
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety and
could affect the life of the equipment.
In addition to the design and configuration of this implement, including Safety Signs and Safety Equipment,
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also
to Safety Messages and Operation Instructions in each of the appropriate sections of the Tractor, Skid Steer,
and Implement Manuals. Pay close attention to the Safety Signs affixed to the Tractor, Skid Steer, and the
Implement.
Replace any CAUTION, WARNING, DANGER or instruction safety sign that is not readable or is missing.
Location of such safety signs is indicated in this booklet.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this
equipment. Consult your doctor about operating this machine while taking prescription medications.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator should be a
responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not allow per-
sons to operate or assemble this unit until they have read this manual and have developed a thorough
understanding of the safety precautions and of how it works.
EQUIPMENT SAFETY GUIDELINES
OPERATING INSTRUCTIONS (continued)
Improper use of loaders to handle round bales can
result in serious injury or death to the tractor/loader oper-
ator. This could be caused by the bale rolling back down
the loader into the operator’s station.
For optimum stability and visibility:
• Do not handle bales that exceed the bale weight
limitations of the loader.
• Carry the bale slowly and as low as possible to the
ground.
• When handling round bales on a slope, always
approach the bale with the tractor facing uphill.
• Never use the tractor/loader to stop a rolling bale.
• Only use a tractor equipped with a ROPS cab or roll-
over protective structure.
• Use particular care when working on inclines and hill-
sides.
When stacking bales, ALWAYS MAKE SURE BALES
ARE PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER –
FALLING BALES CAN ROLL OR TUMBLE.
CAUTION!
For operator safety, always keep bale in front of
tractor hood. NEVER position bale back over opera-
tor. ALWAYS BE CAREFUL!
CAUTION!
Be sure stabilizer spike is in place when handling
round bales with fork-type equipment. Without spike,
uncontrolled bale movement could occur.
When stacking bales, ALWAYS MAKE SURE BALES
ARE PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER
– FALLING BALES CAN ROLL OR TUMBLE.
HANDLE ROUND BALES SAFELY
SAFETY INSTRUCTIONS
Observe all instruction and safety decals on the Loader
Fork. These decals are shown for reference. Read them
carefully before using the Loader Fork. Replace any
decals that may be faded or damaged.
Make sure all operators have read the Owner’s Manual
and are familiar with the instructions and the safety rules
of operation.
OPERATE LOADER SAFELY
• Improper use of loader can cause serious injury or
death.
• Become familiar with controls.
• Be sure anyone operating the loader is aware of safe
operation and potential hazards. Read and observe
safety recommendations in loader manual.
• Operate loader from operator’s seat only. Remain at
controls until operating cycle is complete.
• Stop loader gradually when lowering or lifting loads.
• Use particular care when working on inclines and hill-
sides.
• Avoid holes, ditches, and obstructions which may
cause tractor/loader to tip.
• Allow for additional length of loader on tractor while
turning.
• Never allow anyone to walk or work under a raised
loader.
• Be sure that people, livestock, or pets are not stand-
ing near the machine while operating.
• Do not use the loader for a work platform.
• Do not lift or carry anyone on loader or in bucket or
attachment.
• Carry load low.
• Travel slowly over rough ground or when making
turns.
• Drive slowly through gates and doors.
• Avoid carrying loose or shiftable loads.
• Lower bucket or attachment to ground when loader is
unattended.

5
16
SAFETY INSTRUCTIONS (continued)
Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide
safe equipment can be wiped out by a single careless act of an operator.
Know your controls and how to stop tractor, engine, and loader quickly in an emergency. Read this manual
and the one provided with your tractor or skid steer.
In addition to the design and configuration of equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
It has been said, “The best safety device is an informed, careful operator.” We ask you to be that kind of an
operator. It is the operator’s responsibility to read and understandALL Safety and Operating instructions in the
manual and to follow these. Accidents can be avoided.
Train all new personnel and review instructions frequently with existing workers. A person who has not read
and understood all operating and safety instructions is not qualified to operate the machine.An untrained oper-
ator exposes himself and bystanders to possible serious injury or death.
Working with unfamiliar equipment can lead to careless injuries. Read this manual, and the manual for your
tractor, before assembly or operating, to acquaint yourself with the machines. It is the equipment owner’s
responsibility, if this machine is used by any person other than yourself, is loaned or rented, to make certain
that the operator, prior to operating:
1. Reads and understands the operator’s manuals.
2. Is instructed in safe and proper use.
SAFETY TRAINING
Do not allow children to operate this machine.
OPERATION
Be sure tractor or skid steer is properly counterbal-
anced with weights before attempting to lift any load.
Using the bucket tilt cylinders, adjust the angle of the
fork tines so they are parallel with the ground.
Adjust height of fork tines to enter the pallet to be
handled. Always keep the load or pallet as close to the
forklift main frame as possible.
Never exceed the lift capacity of the tractor/loader
or skid steer used with the forklift.
CAUTION!
The ULF-346, VLF-7646 and SSPF-40 Front Loader
Forks are NOT to be used for large round bales, as
this would create a hazardous condition.
CAUTION!
Avoid carrying loose or shiftable loads. Falling
items could cause injury.
CAUTION!
OPERATING INSTRUCTIONS
PRE-OPERATION CHECKLIST
(OWNER/OPERATOR RESPONSIBILITY)
____ Review and follow safety rules and safety signs on
pages 3 through 13.
____ Check that Loader Fork is properly and securely
attached to loader.
____ Check that all hardware is properly installed.
____ Check that no one enters the area of machine
operation. Always work at a safe distance from
roads, built-up areas, or populated places.
____ Know your controls and how to stop skid steer,
tractor, engine and PTO quickly in an emergency.
READ THIS MANUALAND THE ONE PROVIDED
WITH YOUR TRACTOR AND LOADER OR SKID
STEER.
____ To avoid accident or injury, do not allow anyone to
operate this equipment without proper instructions.
Any person who operates this equipment must be
instructed in and be capable of the safe operation
of the tractor, skid steer, implement and all
controls.
When working on side hills, DO NOT
RAISE LOADER TOO HIGH. Keep an
eye on terrain changes. Keep load low.
CAUTION!
Beware of lift clearance when raising loader to max-
imum height.
When stacking hay bales or loading vehicles, make
sure you are operating in an area AWAY FROM OVER-
HEAD WIRES.
DANGER!
Beware of low electrical wires when loader is
raised. Serious injury or death can result if contact is
made.
Do NOT carry round bales with short 46”
forks. Use only 55” long forks and stabi-
lizer spike to handle round bales.

15
6
SAFETY INSTRUCTIONS (continued)
Keep safety signs clean and legible at all times.
Replace safety signs that are missing or have become illegible.
Replaced parts that displayed a safety sign should also display the current sign.
Safety signs are available from your Distributor or Dealer Parts Department or the factory.
Be sure that the installation area is clean and dry.
Be sure temperature is above 50˚F (10˚C).
Decide on the exact position before you remove the backing paper.
Remove the smallest portion of the split backing paper.
Align the sign over the specified area and carefully press the small portion with the exposed sticky backing in
place.
Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign in place.
Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper.
Be certain the tractor or skid steer is in neutral or park position before starting engine.
Always shut off power unit and shift to “Park” or set brakes when leaving unit. Always lower bucket or
attachment to ground, relieve all hydraulic pressure. Remove key when leaving equipment unattended. Park
in level area.
Before operating equipment: if you have any questions regarding the proper assembly or operation, contact
your dealer or representative.
How to Install Safety Signs:
SAFETY SIGNS
STARTING AND STOPPING SAFETY
Remove the bucket from your front end loader. Check
your loader to make sure it is in good working order.
Check all frame mounting bolts to make sure they are
tight.
Loaders that attach to the tractor frame rails should
have a cross-tie installed for stability.
Refer to the “exploded view” of the Loader Fork on
page 20 of this manual.
Assemble the two lift brackets (Ref. #3) on the main
frame (Ref. #1) with the 5/8” x 3” I.D. U-bolts. Leave the
U-bolts loose.
NOTE: The lift channel brackets are supplied with 1”
diameter pins to fit your loader. If your loader requires
11/8” pins, it will be necessary for the hole diameter in the
channel brackets to be drilled out to 15/32” (1.156”) and
ask your dealer to order 11/8” diameter pins. The 11/8” pins
are part #830318. Be sure to indicate if two or four 11/8”
pins are required.
If your loader requires 11/4” diameter pins, please ask
your dealer to order adapter bushings (part #830319). Be
sure to indicate how many adapter bushings are
required.
If your tractor loader has a bucket QuickAttach feature,
check with your dealer on the availability of adapter
brackets for your brand and model loader.
Connect the above assembly to the loader arms using
the bottom hole in the channel and attach the upper con-
trol cylinder to the top hole in the lift channels. Center the
main frame (side to side) with your loader arms and
tighten the four (4) 5/8” x 3” U-Bolts.
The lower hole positions in the lift channels can be
used to obtain more angle movement. However, if the
frame becomes too parallel with the loader lift arms, the
loader may not have enough power (mechanical advan-
tage) to bring the frame back.
NOTE: The Ford Model 7109, 7209, 7210 and 7410
Loaders require special mounting brackets instead of the
standard lift channels supplied. Order #830330 for this
application.
NOTE: Generally, it is not recommended to have the tilt
cylinders located any closer than 10-12 inches to the
main loader lift arms. Check the spacing of mounting
pins on your loader bucket and use this as a guide.
If tilt cylinders are located too close to the loader arms,
they may go “over center” when fully extended. If this
happens, damage may occur to the cylinders and/or
mounting brackets.
NOTE: The Model VLF-7655 and VLF-7646 have
special quick-attach brackets on the frame. No lift
channel brackets are required.
INSTRUCTIONS (continued)
ASSEMBLY –
TRACTOR LOADERS
ASSEMBLY – SKID STEER AND
TRACTOR LOADERS
Remove the bucket from your skid steer unit and con-
nect the main frame of the pallet fork to the universal
quick-attach coupler.
Raise the loader and main frame slightly so that the
bottom of the main frame is about one or two inches off
the ground. Engage tractor parking brake and shut off
the engine.
Remove the forkshaft from the main frame by remov-
ing the lock bolt on end of the forkshaft and slide it out
until about 12” remain through one end of the frame.
Place one fork locking collar on the shaft and place the
fork tine into position and slide the forkshaft through
them. Place another lock collar on the forkshaft and slide
into the center support until the shaft extends about 8”
past the center support.
Place another fork locking collar and place second fork
tine into position and continue sliding the forkshaft until it
is all the way through the second fork.
Slide the last locking collar on the fork shaft and then
continue sliding the forkshaft until it is through the last
shaft support.
Rotate the forkshaft until the clip on the end lines up
with the hole in the end support bracket. Replace the lock
bolt and tighten.
Slide the fork tines into the desired position and tight-
en the lock collars on each side of each fork tine.
ADJUSTING TINE WIDTH
1. Block up the forklift frame.
2. Loosen lock bolts and slide forklift tines to desired set-
ting. Each tine must be the same distance from the
center of the forklift. Tighten lock bolts.
IMPORTANT: Keep forklift tines adjusted to maxi-
mum width for better load stability.
To help prevent personal injury, stand clear of frame
and loader. Keep feet away from underside of main
frame.
CAUTION!

7
14
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design.All operators of this equipment must read and understand this entire manual, paying
particular attention to safety and operating instructions, prior to using. If there is something in this manual you
do not understand, ask your supervisor, or your dealer, to explain it to you.
Be sure power unit is in good condition. Read all the safety precautions and make sure all operators are
familiar with the safety rules of operation.
Know your controls and how to stop the power unit and engine quickly in an emergency. READ THIS MANUAL
AND THE ONE PROVIDED WITH YOUR TRACTOR AND LOADER, SKID STEER OR FORKLIFT.
Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders fifty feet (50’) from
an operating power unit and attached equipment. Only properly trained people should operate this machine.
It is recommended the tractor be equipped with a Rollover Protection System (ROPS) and a seat belt that is
used. Always stop the tractor, skid steer, or forklift, set brake, shut off the engine, remove the ignition key, and
lower loader and attachment to the ground before dismounting. Never leave equipment unattended with the
engine running.
Please remember it is important that you read and heed the safety signs on the front loader attachment and
loader, and the safety rules set forth. Clean or replace all safety signs if they cannot be clearly read and under-
stood. They are there for your safety as well as the safety of others. The safe use of this machine is strictly
up to you, the operator.
The use of any loader attachment is NOT recommended on tractor with a tricycle wheel arrangement. Tricycle
type tractors are unstable for front loader use.
A heavy load can cause instability in driving a power unit. Make sure the front or rear of the power unit is
properly counter-balanced with weights. Always drive slowly – especially around turns. An unstable power unit
could steer badly and possibly tip over, causing injury or death.
When the use of hand tools is required to perform any part of assembly, installation, adjustment, maintaining,
repairing, removal, or moving the implement, be sure the tools used are designed and recommended by the
tool manufacturer for that specific task.
Personal protection equipment including safety glasses, safety shoes, and gloves are recommended during
assembly, installation, operation, adjustment, maintaining, repairing, removal, or moving the attachment.
Always use two people to handle heavy, unwieldy components during assembly, installation, removal, or
moving the loader attachment.
Never place any part of your body where it would be in danger if movement should occur during assembly,
installation, operation, maintaining, repairing, removal, or moving the implement.
Do not allow others to ride on the power unit with an operator. Riders are subject to injury such as being struck
by foreign objects or being thrown off. Riders obstruct the operator’s view resulting in unsafe operation. Never
allow anyone to ride on the implement!
INSTRUCTIONS
CAUTION!
Be sure your tractor and loader is in good condi-
tion. Read all the safety precautions and make sure
all tractor operators are familiar with the safety rules
of operation.
W ARNING!
A heavy load can cause instability in driving a
tractor. Make sure the rear of the tractor is properly
counterbalanced with weights or a bale. Always
drive slowly – especially around turns. An unstable
tractor could steer badly and possibly tip over,
causing injury or death.
The model ULF-355 with 55” tubular forks can handle
large round hay bales up to 3,000 lbs.
The model ULF-346 with 46” solid pallet forks can han-
dle loads up to 4,000 lbs. Load ratings are figured with
the load about 20” in front of the fork lift frame and even-
ly distributed between the two fork tines. NEVER put load
at the ends of the fork tines – the lift capacity at the ends
of the forks is only about 1/3of the total lift capacity.
WARRANTY DOES NOT COVER BENT FORKS.
NOTE: Loaders with only one hydraulic cylinder in the
center of the loader to tilt the bucket or attachment may
be used with the addition of an optional center bracket
(order bracket #830320).
Be sure tires and rims are in good condition. Inflate
tires to the proper recommended air pressure.
It is recommended that a ROPS (Roll-Over Protection
Structure) and a seat belt be installed on all tractors.
Contact your local dealer for a ROPS for your tractor.
The operator is responsible for the safe operation of
this equipment. The operator must be properly trained.
Operators should be familiar with the tractor, loader and
loader attachment, and all safety practices before start-
ing operation. Read the safety rules and safety signs on
pages 3-13.
TRACTOR AND LOADER/SKID
STEER REQUIREMENTS AND
PREPARATION
The required size of the tractor and front loader or skid
steer will be determined by the weight of the load to be
handled.
Always use a tractor and front loader or skid steer large
enough to safely handle the load.
The Universal Loader Fork attachment is designed to
fit most farm tractor double-cylinder front-end loaders.
Optional brackets are available to fit some popular quick
coupler front-end loaders.
The model SSPF-40 Skid Steer Pallet Fork is designed
for skid steer power units having the universal bucket
attach system (same as original Bobcat design). Skid
steer units must have rated lifting capacity greater than
or equal to the loads to be handled.
Both the Universal Loader Fork and the Skid Steer
Pallet Fork can handle loads up to 4000 pounds. Load
must be equally distributed on both fork tines.
NOTE: The 4000 pound load rating is figured with a load
center being 20 inches in front of the forklift frame.
The Models VLF-7655 and VLF-7646 are designed for
Versatile/Ford/New Holland Model 256, 276 and 9030 Bi-
Directional Tractors.
The Model TV-140 Bi-Directional Tractor requires spe-
cial bolt on brackets.
The Universal Loader Fork will also work on the rear of
tractors with a Category II 3 pt. hitch.
Make sure your tractor and loader are of sufficient size
to safely handle the loads you want to move.
Check your tractor and front loader or skid steer to
make sure they are in good working condition. Check all
frame mounting bolts to make sure they are tight.
Loaders that attach to the tractor frame rails should
have a cross-tie installed for stability.
Check the hydraulic system. Be sure the hydraulic oil
and filter have been serviced according to the manufac-
turer’s recommendations.
It is recommended that tractors and skid steers be
equipped with a roll-over protective structure
(ROPS) or cab.
CAUTION!
W ARNING!
The use of any loader attachment is NOT recom-
mended on tractors with a tricycle wheel arrange-
ment. Tricycle type tractors are unstable for front
loader use.

13
8
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY (continued)
For operator safety, always keep load in front of power unit. NEVER position load back over operator.ALWAYS
BE CAREFUL!
Beware of lift clearance when raising loader to maximum height.
Keep alert and watch the rear as well as the front when working with the loader.
Beware of low electrical wires when loader is raised. Serious injury or death can result if contact is made.
Before you operate any equipment, check over all pins, bolts and connections to be sure all are securely in
place. Replace any damaged or worn parts immediately.
Do not work under a raised loader unless it is securely blocked or held in position. Do not depend on the power
unit hydraulic system to hold the implement in place.
Operate the loader controls smoothly, avoiding jerky operation. Stop loader gradually when lowering or lifting
loads.
When handling material on a slope, always approach the material with the power unit facing uphill.
Only use a power unit equipped with a ROPS cab or rollover protective structure.
When stacking material, ALWAYS MAKE SURE MATERIAL IS PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER FALLING ITEMS CAN ROLL OR TUMBLE.
Do not handle loads that exceed the weight limitations of the loader.
Carry the loads slowly and as low as possible to the ground. Avoid excessive speed during operation.
SAFETY SIGNS
OBEY
SAFETY
RULES
NOTE:
If Safety Sign is
missing
or damaged,
replace
immediately.

9
12
SAFETY INSTRUCTIONS (continued)
When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance
for the power unit, loader, and load. Drive slowly.
Operate loader from operator’s seat only. Remain at controls until operating cycle is complete.
Use extreme care when working on inclines and hillsides.
Do not operate close to ditches, creeks or holes. Slow down when operating over rough ground.
Allow for additional length of loader and load on power unit while turning.
Keep load centered on attachment and loader. Unbalanced loads increase possibility of tipping or roll-over.
Never allow anyone to walk or work under a raised loader.
Be sure that people, livestock, or pets are not standing near the machine while operating.
Do not use loader for a work platform.
Do not lift or carry anyone on loader or in bucket or on attachment.
ALWAYS lower loader to the ground or block securely before performing any maintenance work.
Always keep power unit on solid footing when operating loader.
Observe Safety Recommendations in loader instruction manual.
Inspect the entire machine periodically as indicated in the Maintenance Section of this manual. Look for loose
fasteners, worn or broken parts, pinched hydraulic hoses, and leaky or loose fittings. Make sure all pins have
cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
OPERATIONAL SAFETY (continued)
SAFETY INSTRUCTIONS (continued)
After servicing, be sure all tools, parts and service equipment are removed.
Check to ensure all safety signs are installed and in good condition. (See safety sign section for location
drawing.)
Do not allow grease or oil to build up on any deck or platform.
Never replace hex bolts with less than grade five bolts unless otherwise specified, i.e. shear bolts. Refer to
bolt torque chart for head identification marking.
Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement
parts must be used to restore your equipment to original specifications. The manufacturer will not claim
responsibility for use of unapproved parts and/or accessories and other damages as a result of their use.
If equipment has been altered in any way from original design, the manufacturer does not accept any liability
for injury or warranty.
A fire extinguisher and first aid kit should be kept readily accessible while performing maintenance on this
equipment.
Following operation or when unhooking, stop the tractor, set the brakes, shut off the engine, relieve all
hydraulic pressure and remove the ignition keys.
Store the unit in an area away from human activity.
Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock
injury could result.
Do not permit children to play on or around the stored unit.
Make sure all parked machines are on a hard, level surface and engage all safety devices.
If blocking is used, make sure it is solid and secure before leaving area.
MAINTENANCE SAFETY (continued)
STORAGE SAFETY

11
10
SAFETY INSTRUCTIONS (continued)
Comply with state and local laws governing highway safety and movement of farm machinery on public roads.
The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use.
Local laws should be checked for all highway lighting and marking requirements.
When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the
day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Always be sure the implement is in the proper raised position for transport.
Reduce speed when transporting mounted implements to avoid bouncing and momentary loss of steering
control.
Plan your route to avoid heavy traffic.
Always install transport locks, pins or brackets before transporting.
Do not drink and drive!
Watch for traffic when operating near or crossing roadways.
Turn curves or go up or down hills only at a low speed and at a gradual steering angle. Make certain that at
least 20% of the tractor’s weight is on the front wheels to maintain safe steerage. Slow down on rough or
uneven surfaces, and loose gravel.
Use extreme care and maintain minimum ground speed when transporting on hillside, over rough ground and
when operating close to ditches or fences. Be careful when turning sharp corners.
Never allow riders on either power unit or implement. Falling off can kill.
Be a safe and courteous driver.Always yield to oncoming traffic in all situations, including narrow bridges, inter-
sections, etc.
Do not exceed 20 mph (32 kph). Reduce speed on rough roads and surfaces.
Always disengage PTO before driving the tractor to transport the implement from one place to another.
TRANSPORT SAFETY
SAFETY INSTRUCTIONS (continued)
Good maintenance is your responsibility. Poor maintenance is an invitation to trouble.
Follow good shop practices.
- Keep service area clean and dry.
- Be sure electrical outlets and tools are properly grounded.
- Use adequate light for the job at hand.
Make sure there is plenty of ventilation. Never operate the engine of the towing vehicle in a closed building.
The exhaust fumes may cause asphyxiation.
Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if
working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the
brakes, and remove the ignition keys.
Be certain all moving parts on attachments have come to a complete stop before attempting to perform
maintenance.
Never work under equipment unless it is blocked securely. Never depend on hydraulic system to keep imple-
ment in raised position.
Always use personal protection devices such as eye, hand and hearing protectors, when performing any
service or maintenance.
Keep all persons away from operator control area while performing adjustments, service, or maintenance.
Periodically tighten all bolts, nuts and screws and check that all cotter pins are properly installed to ensure unit
is in a safe condition.
When completing a maintenance or service function, make sure all safety shields and devices are installed
before placing unit in service.
Openings in the skin and minor cuts are susceptible to infection from hydraulic fluid. If injured by escaping
hydraulic fluid, see a doctor at once. Gangrene and death can result. Without immediate medical treatment,
serious infection and reactions can occur.
MAINTENANCE SAFETY

11
10
SAFETY INSTRUCTIONS (continued)
Comply with state and local laws governing highway safety and movement of farm machinery on public roads.
The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use.
Local laws should be checked for all highway lighting and marking requirements.
When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the
day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Always be sure the implement is in the proper raised position for transport.
Reduce speed when transporting mounted implements to avoid bouncing and momentary loss of steering
control.
Plan your route to avoid heavy traffic.
Always install transport locks, pins or brackets before transporting.
Do not drink and drive!
Watch for traffic when operating near or crossing roadways.
Turn curves or go up or down hills only at a low speed and at a gradual steering angle. Make certain that at
least 20% of the tractor’s weight is on the front wheels to maintain safe steerage. Slow down on rough or
uneven surfaces, and loose gravel.
Use extreme care and maintain minimum ground speed when transporting on hillside, over rough ground and
when operating close to ditches or fences. Be careful when turning sharp corners.
Never allow riders on either power unit or implement. Falling off can kill.
Be a safe and courteous driver.Always yield to oncoming traffic in all situations, including narrow bridges, inter-
sections, etc.
Do not exceed 20 mph (32 kph). Reduce speed on rough roads and surfaces.
Always disengage PTO before driving the tractor to transport the implement from one place to another.
TRANSPORT SAFETY
SAFETY INSTRUCTIONS (continued)
Good maintenance is your responsibility. Poor maintenance is an invitation to trouble.
Follow good shop practices.
- Keep service area clean and dry.
- Be sure electrical outlets and tools are properly grounded.
- Use adequate light for the job at hand.
Make sure there is plenty of ventilation. Never operate the engine of the towing vehicle in a closed building.
The exhaust fumes may cause asphyxiation.
Before working on this machine, drive to a level area, disengage the PTO, lower implement or loader (or if
working underneath, raise and block securely), shut off the engine, relieve all hydraulic pressure, set the
brakes, and remove the ignition keys.
Be certain all moving parts on attachments have come to a complete stop before attempting to perform
maintenance.
Never work under equipment unless it is blocked securely. Never depend on hydraulic system to keep imple-
ment in raised position.
Always use personal protection devices such as eye, hand and hearing protectors, when performing any
service or maintenance.
Keep all persons away from operator control area while performing adjustments, service, or maintenance.
Periodically tighten all bolts, nuts and screws and check that all cotter pins are properly installed to ensure unit
is in a safe condition.
When completing a maintenance or service function, make sure all safety shields and devices are installed
before placing unit in service.
Openings in the skin and minor cuts are susceptible to infection from hydraulic fluid. If injured by escaping
hydraulic fluid, see a doctor at once. Gangrene and death can result. Without immediate medical treatment,
serious infection and reactions can occur.
MAINTENANCE SAFETY

9
12
SAFETY INSTRUCTIONS (continued)
When maneuvering close to buildings or passing through narrow areas, be sure to allow sufficient clearance
for the power unit, loader, and load. Drive slowly.
Operate loader from operator’s seat only. Remain at controls until operating cycle is complete.
Use extreme care when working on inclines and hillsides.
Do not operate close to ditches, creeks or holes. Slow down when operating over rough ground.
Allow for additional length of loader and load on power unit while turning.
Keep load centered on attachment and loader. Unbalanced loads increase possibility of tipping or roll-over.
Never allow anyone to walk or work under a raised loader.
Be sure that people, livestock, or pets are not standing near the machine while operating.
Do not use loader for a work platform.
Do not lift or carry anyone on loader or in bucket or on attachment.
ALWAYS lower loader to the ground or block securely before performing any maintenance work.
Always keep power unit on solid footing when operating loader.
Observe Safety Recommendations in loader instruction manual.
Inspect the entire machine periodically as indicated in the Maintenance Section of this manual. Look for loose
fasteners, worn or broken parts, pinched hydraulic hoses, and leaky or loose fittings. Make sure all pins have
cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order.
OPERATIONAL SAFETY (continued)
SAFETY INSTRUCTIONS (continued)
After servicing, be sure all tools, parts and service equipment are removed.
Check to ensure all safety signs are installed and in good condition. (See safety sign section for location
drawing.)
Do not allow grease or oil to build up on any deck or platform.
Never replace hex bolts with less than grade five bolts unless otherwise specified, i.e. shear bolts. Refer to
bolt torque chart for head identification marking.
Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement
parts must be used to restore your equipment to original specifications. The manufacturer will not claim
responsibility for use of unapproved parts and/or accessories and other damages as a result of their use.
If equipment has been altered in any way from original design, the manufacturer does not accept any liability
for injury or warranty.
A fire extinguisher and first aid kit should be kept readily accessible while performing maintenance on this
equipment.
Following operation or when unhooking, stop the tractor, set the brakes, shut off the engine, relieve all
hydraulic pressure and remove the ignition keys.
Store the unit in an area away from human activity.
Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock
injury could result.
Do not permit children to play on or around the stored unit.
Make sure all parked machines are on a hard, level surface and engage all safety devices.
If blocking is used, make sure it is solid and secure before leaving area.
MAINTENANCE SAFETY (continued)
STORAGE SAFETY

13
8
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY (continued)
For operator safety, always keep load in front of power unit. NEVER position load back over operator.ALWAYS
BE CAREFUL!
Beware of lift clearance when raising loader to maximum height.
Keep alert and watch the rear as well as the front when working with the loader.
Beware of low electrical wires when loader is raised. Serious injury or death can result if contact is made.
Before you operate any equipment, check over all pins, bolts and connections to be sure all are securely in
place. Replace any damaged or worn parts immediately.
Do not work under a raised loader unless it is securely blocked or held in position. Do not depend on the power
unit hydraulic system to hold the implement in place.
Operate the loader controls smoothly, avoiding jerky operation. Stop loader gradually when lowering or lifting
loads.
When handling material on a slope, always approach the material with the power unit facing uphill.
Only use a power unit equipped with a ROPS cab or rollover protective structure.
When stacking material, ALWAYS MAKE SURE MATERIAL IS PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER FALLING ITEMS CAN ROLL OR TUMBLE.
Do not handle loads that exceed the weight limitations of the loader.
Carry the loads slowly and as low as possible to the ground. Avoid excessive speed during operation.
SAFETY SIGNS
OBEY
SAFETY
RULES
NOTE:
If Safety Sign is
missing
or damaged,
replace
immediately.

7
14
SAFETY INSTRUCTIONS (continued)
OPERATIONAL SAFETY
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design.All operators of this equipment must read and understand this entire manual, paying
particular attention to safety and operating instructions, prior to using. If there is something in this manual you
do not understand, ask your supervisor, or your dealer, to explain it to you.
Be sure power unit is in good condition. Read all the safety precautions and make sure all operators are
familiar with the safety rules of operation.
Know your controls and how to stop the power unit and engine quickly in an emergency. READ THIS MANUAL
AND THE ONE PROVIDED WITH YOUR TRACTOR AND LOADER, SKID STEER OR FORKLIFT.
Most accidents occur because of neglect or carelessness. Keep all helpers and bystanders fifty feet (50’) from
an operating power unit and attached equipment. Only properly trained people should operate this machine.
It is recommended the tractor be equipped with a Rollover Protection System (ROPS) and a seat belt that is
used. Always stop the tractor, skid steer, or forklift, set brake, shut off the engine, remove the ignition key, and
lower loader and attachment to the ground before dismounting. Never leave equipment unattended with the
engine running.
Please remember it is important that you read and heed the safety signs on the front loader attachment and
loader, and the safety rules set forth. Clean or replace all safety signs if they cannot be clearly read and under-
stood. They are there for your safety as well as the safety of others. The safe use of this machine is strictly
up to you, the operator.
The use of any loader attachment is NOT recommended on tractor with a tricycle wheel arrangement. Tricycle
type tractors are unstable for front loader use.
A heavy load can cause instability in driving a power unit. Make sure the front or rear of the power unit is
properly counter-balanced with weights. Always drive slowly – especially around turns. An unstable power unit
could steer badly and possibly tip over, causing injury or death.
When the use of hand tools is required to perform any part of assembly, installation, adjustment, maintaining,
repairing, removal, or moving the implement, be sure the tools used are designed and recommended by the
tool manufacturer for that specific task.
Personal protection equipment including safety glasses, safety shoes, and gloves are recommended during
assembly, installation, operation, adjustment, maintaining, repairing, removal, or moving the attachment.
Always use two people to handle heavy, unwieldy components during assembly, installation, removal, or
moving the loader attachment.
Never place any part of your body where it would be in danger if movement should occur during assembly,
installation, operation, maintaining, repairing, removal, or moving the implement.
Do not allow others to ride on the power unit with an operator. Riders are subject to injury such as being struck
by foreign objects or being thrown off. Riders obstruct the operator’s view resulting in unsafe operation. Never
allow anyone to ride on the implement!
INSTRUCTIONS
CAUTION!
Be sure your tractor and loader is in good condi-
tion. Read all the safety precautions and make sure
all tractor operators are familiar with the safety rules
of operation.
W ARNING!
A heavy load can cause instability in driving a
tractor. Make sure the rear of the tractor is properly
counterbalanced with weights or a bale. Always
drive slowly – especially around turns. An unstable
tractor could steer badly and possibly tip over,
causing injury or death.
The model ULF-355 with 55” tubular forks can handle
large round hay bales up to 3,000 lbs.
The model ULF-346 with 46” solid pallet forks can han-
dle loads up to 4,000 lbs. Load ratings are figured with
the load about 20” in front of the fork lift frame and even-
ly distributed between the two fork tines. NEVER put load
at the ends of the fork tines – the lift capacity at the ends
of the forks is only about 1/3of the total lift capacity.
WARRANTY DOES NOT COVER BENT FORKS.
NOTE: Loaders with only one hydraulic cylinder in the
center of the loader to tilt the bucket or attachment may
be used with the addition of an optional center bracket
(order bracket #830320).
Be sure tires and rims are in good condition. Inflate
tires to the proper recommended air pressure.
It is recommended that a ROPS (Roll-Over Protection
Structure) and a seat belt be installed on all tractors.
Contact your local dealer for a ROPS for your tractor.
The operator is responsible for the safe operation of
this equipment. The operator must be properly trained.
Operators should be familiar with the tractor, loader and
loader attachment, and all safety practices before start-
ing operation. Read the safety rules and safety signs on
pages 3-13.
TRACTOR AND LOADER/SKID
STEER REQUIREMENTS AND
PREPARATION
The required size of the tractor and front loader or skid
steer will be determined by the weight of the load to be
handled.
Always use a tractor and front loader or skid steer large
enough to safely handle the load.
The Universal Loader Fork attachment is designed to
fit most farm tractor double-cylinder front-end loaders.
Optional brackets are available to fit some popular quick
coupler front-end loaders.
The model SSPF-40 Skid Steer Pallet Fork is designed
for skid steer power units having the universal bucket
attach system (same as original Bobcat design). Skid
steer units must have rated lifting capacity greater than
or equal to the loads to be handled.
Both the Universal Loader Fork and the Skid Steer
Pallet Fork can handle loads up to 4000 pounds. Load
must be equally distributed on both fork tines.
NOTE: The 4000 pound load rating is figured with a load
center being 20 inches in front of the forklift frame.
The Models VLF-7655 and VLF-7646 are designed for
Versatile/Ford/New Holland Model 256, 276 and 9030 Bi-
Directional Tractors.
The Model TV-140 Bi-Directional Tractor requires spe-
cial bolt on brackets.
The Universal Loader Fork will also work on the rear of
tractors with a Category II 3 pt. hitch.
Make sure your tractor and loader are of sufficient size
to safely handle the loads you want to move.
Check your tractor and front loader or skid steer to
make sure they are in good working condition. Check all
frame mounting bolts to make sure they are tight.
Loaders that attach to the tractor frame rails should
have a cross-tie installed for stability.
Check the hydraulic system. Be sure the hydraulic oil
and filter have been serviced according to the manufac-
turer’s recommendations.
It is recommended that tractors and skid steers be
equipped with a roll-over protective structure
(ROPS) or cab.
CAUTION!
W ARNING!
The use of any loader attachment is NOT recom-
mended on tractors with a tricycle wheel arrange-
ment. Tricycle type tractors are unstable for front
loader use.

15
6
SAFETY INSTRUCTIONS (continued)
Keep safety signs clean and legible at all times.
Replace safety signs that are missing or have become illegible.
Replaced parts that displayed a safety sign should also display the current sign.
Safety signs are available from your Distributor or Dealer Parts Department or the factory.
Be sure that the installation area is clean and dry.
Be sure temperature is above 50˚F (10˚C).
Decide on the exact position before you remove the backing paper.
Remove the smallest portion of the split backing paper.
Align the sign over the specified area and carefully press the small portion with the exposed sticky backing in
place.
Slowly peel back the remaining paper and carefully smooth the remaining portion of the sign in place.
Small air pockets can be pierced with a pin and smoothed out using the piece of sign backing paper.
Be certain the tractor or skid steer is in neutral or park position before starting engine.
Always shut off power unit and shift to “Park” or set brakes when leaving unit. Always lower bucket or
attachment to ground, relieve all hydraulic pressure. Remove key when leaving equipment unattended. Park
in level area.
Before operating equipment: if you have any questions regarding the proper assembly or operation, contact
your dealer or representative.
How to Install Safety Signs:
SAFETY SIGNS
STARTING AND STOPPING SAFETY
Remove the bucket from your front end loader. Check
your loader to make sure it is in good working order.
Check all frame mounting bolts to make sure they are
tight.
Loaders that attach to the tractor frame rails should
have a cross-tie installed for stability.
Refer to the “exploded view” of the Loader Fork on
page 20 of this manual.
Assemble the two lift brackets (Ref. #3) on the main
frame (Ref. #1) with the 5/8” x 3” I.D. U-bolts. Leave the
U-bolts loose.
NOTE: The lift channel brackets are supplied with 1”
diameter pins to fit your loader. If your loader requires
11/8” pins, it will be necessary for the hole diameter in the
channel brackets to be drilled out to 15/32” (1.156”) and
ask your dealer to order 11/8” diameter pins. The 11/8” pins
are part #830318. Be sure to indicate if two or four 11/8”
pins are required.
If your loader requires 11/4” diameter pins, please ask
your dealer to order adapter bushings (part #830319). Be
sure to indicate how many adapter bushings are
required.
If your tractor loader has a bucket QuickAttach feature,
check with your dealer on the availability of adapter
brackets for your brand and model loader.
Connect the above assembly to the loader arms using
the bottom hole in the channel and attach the upper con-
trol cylinder to the top hole in the lift channels. Center the
main frame (side to side) with your loader arms and
tighten the four (4) 5/8” x 3” U-Bolts.
The lower hole positions in the lift channels can be
used to obtain more angle movement. However, if the
frame becomes too parallel with the loader lift arms, the
loader may not have enough power (mechanical advan-
tage) to bring the frame back.
NOTE: The Ford Model 7109, 7209, 7210 and 7410
Loaders require special mounting brackets instead of the
standard lift channels supplied. Order #830330 for this
application.
NOTE: Generally, it is not recommended to have the tilt
cylinders located any closer than 10-12 inches to the
main loader lift arms. Check the spacing of mounting
pins on your loader bucket and use this as a guide.
If tilt cylinders are located too close to the loader arms,
they may go “over center” when fully extended. If this
happens, damage may occur to the cylinders and/or
mounting brackets.
NOTE: The Model VLF-7655 and VLF-7646 have
special quick-attach brackets on the frame. No lift
channel brackets are required.
INSTRUCTIONS (continued)
ASSEMBLY –
TRACTOR LOADERS
ASSEMBLY – SKID STEER AND
TRACTOR LOADERS
Remove the bucket from your skid steer unit and con-
nect the main frame of the pallet fork to the universal
quick-attach coupler.
Raise the loader and main frame slightly so that the
bottom of the main frame is about one or two inches off
the ground. Engage tractor parking brake and shut off
the engine.
Remove the forkshaft from the main frame by remov-
ing the lock bolt on end of the forkshaft and slide it out
until about 12” remain through one end of the frame.
Place one fork locking collar on the shaft and place the
fork tine into position and slide the forkshaft through
them. Place another lock collar on the forkshaft and slide
into the center support until the shaft extends about 8”
past the center support.
Place another fork locking collar and place second fork
tine into position and continue sliding the forkshaft until it
is all the way through the second fork.
Slide the last locking collar on the fork shaft and then
continue sliding the forkshaft until it is through the last
shaft support.
Rotate the forkshaft until the clip on the end lines up
with the hole in the end support bracket. Replace the lock
bolt and tighten.
Slide the fork tines into the desired position and tight-
en the lock collars on each side of each fork tine.
ADJUSTING TINE WIDTH
1. Block up the forklift frame.
2. Loosen lock bolts and slide forklift tines to desired set-
ting. Each tine must be the same distance from the
center of the forklift. Tighten lock bolts.
IMPORTANT: Keep forklift tines adjusted to maxi-
mum width for better load stability.
To help prevent personal injury, stand clear of frame
and loader. Keep feet away from underside of main
frame.
CAUTION!

5
16
SAFETY INSTRUCTIONS (continued)
Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide
safe equipment can be wiped out by a single careless act of an operator.
Know your controls and how to stop tractor, engine, and loader quickly in an emergency. Read this manual
and the one provided with your tractor or skid steer.
In addition to the design and configuration of equipment, hazard control and accident prevention are
dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation,
transport, maintenance and storage of equipment.
It has been said, “The best safety device is an informed, careful operator.” We ask you to be that kind of an
operator. It is the operator’s responsibility to read and understandALL Safety and Operating instructions in the
manual and to follow these. Accidents can be avoided.
Train all new personnel and review instructions frequently with existing workers. A person who has not read
and understood all operating and safety instructions is not qualified to operate the machine.An untrained oper-
ator exposes himself and bystanders to possible serious injury or death.
Working with unfamiliar equipment can lead to careless injuries. Read this manual, and the manual for your
tractor, before assembly or operating, to acquaint yourself with the machines. It is the equipment owner’s
responsibility, if this machine is used by any person other than yourself, is loaned or rented, to make certain
that the operator, prior to operating:
1. Reads and understands the operator’s manuals.
2. Is instructed in safe and proper use.
SAFETY TRAINING
Do not allow children to operate this machine.
OPERATION
Be sure tractor or skid steer is properly counterbal-
anced with weights before attempting to lift any load.
Using the bucket tilt cylinders, adjust the angle of the
fork tines so they are parallel with the ground.
Adjust height of fork tines to enter the pallet to be
handled. Always keep the load or pallet as close to the
forklift main frame as possible.
Never exceed the lift capacity of the tractor/loader
or skid steer used with the forklift.
CAUTION!
The ULF-346, VLF-7646 and SSPF-40 Front Loader
Forks are NOT to be used for large round bales, as
this would create a hazardous condition.
CAUTION!
Avoid carrying loose or shiftable loads. Falling
items could cause injury.
CAUTION!
OPERATING INSTRUCTIONS
PRE-OPERATION CHECKLIST
(OWNER/OPERATOR RESPONSIBILITY)
____ Review and follow safety rules and safety signs on
pages 3 through 13.
____ Check that Loader Fork is properly and securely
attached to loader.
____ Check that all hardware is properly installed.
____ Check that no one enters the area of machine
operation. Always work at a safe distance from
roads, built-up areas, or populated places.
____ Know your controls and how to stop skid steer,
tractor, engine and PTO quickly in an emergency.
READ THIS MANUALAND THE ONE PROVIDED
WITH YOUR TRACTOR AND LOADER OR SKID
STEER.
____ To avoid accident or injury, do not allow anyone to
operate this equipment without proper instructions.
Any person who operates this equipment must be
instructed in and be capable of the safe operation
of the tractor, skid steer, implement and all
controls.
When working on side hills, DO NOT
RAISE LOADER TOO HIGH. Keep an
eye on terrain changes. Keep load low.
CAUTION!
Beware of lift clearance when raising loader to max-
imum height.
When stacking hay bales or loading vehicles, make
sure you are operating in an area AWAY FROM OVER-
HEAD WIRES.
DANGER!
Beware of low electrical wires when loader is
raised. Serious injury or death can result if contact is
made.
Do NOT carry round bales with short 46”
forks. Use only 55” long forks and stabi-
lizer spike to handle round bales.

17
4
SAFETY INSTRUCTIONS (continued)
Safety of the operator is one of the main concerns in designing and developing a new piece of equipment.
Designers and manufacturers build in as many safety features as possible. However, every year many
accidents occur which could have been avoided by a few seconds of thought and a more careful approach to
handling equipment. You, the operator, can avoid many accidents by observing the following precautions in
this section. To avoid personal injury, study the following precautions and insist those working with you, or for
you, follow them.
In order to provide a better view, certain photographs or illustrations in this manual may show an assembly
with a safety shield removed. However, equipment should never be operated in this condition. Keep all shields
in place. If shield removal becomes necessary for repairs, replace the shield prior to use.
To prevent injury or death, use a tractor equipped with a Roll-Over Protective System (ROPS). Do not paint
over, remove or deface any safety signs or warning signs on your equipment. Observe all safety signs and
practice the instruction on them.
Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question -
DON’T TRY IT.
Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety and
could affect the life of the equipment.
In addition to the design and configuration of this implement, including Safety Signs and Safety Equipment,
hazard control and accident prevention are dependent upon the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also
to Safety Messages and Operation Instructions in each of the appropriate sections of the Tractor, Skid Steer,
and Implement Manuals. Pay close attention to the Safety Signs affixed to the Tractor, Skid Steer, and the
Implement.
Replace any CAUTION, WARNING, DANGER or instruction safety sign that is not readable or is missing.
Location of such safety signs is indicated in this booklet.
Never use alcoholic beverages or drugs which can hinder alertness or coordination while operating this
equipment. Consult your doctor about operating this machine while taking prescription medications.
Review the safety instructions with all users annually.
This equipment is dangerous to children and persons unfamiliar with its operation. The operator should be a
responsible adult familiar with farm machinery and trained in this equipment’s operations. Do not allow per-
sons to operate or assemble this unit until they have read this manual and have developed a thorough
understanding of the safety precautions and of how it works.
EQUIPMENT SAFETY GUIDELINES
OPERATING INSTRUCTIONS (continued)
Improper use of loaders to handle round bales can
result in serious injury or death to the tractor/loader oper-
ator. This could be caused by the bale rolling back down
the loader into the operator’s station.
For optimum stability and visibility:
• Do not handle bales that exceed the bale weight
limitations of the loader.
• Carry the bale slowly and as low as possible to the
ground.
• When handling round bales on a slope, always
approach the bale with the tractor facing uphill.
• Never use the tractor/loader to stop a rolling bale.
• Only use a tractor equipped with a ROPS cab or roll-
over protective structure.
• Use particular care when working on inclines and hill-
sides.
When stacking bales, ALWAYS MAKE SURE BALES
ARE PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER –
FALLING BALES CAN ROLL OR TUMBLE.
CAUTION!
For operator safety, always keep bale in front of
tractor hood. NEVER position bale back over opera-
tor. ALWAYS BE CAREFUL!
CAUTION!
Be sure stabilizer spike is in place when handling
round bales with fork-type equipment. Without spike,
uncontrolled bale movement could occur.
When stacking bales, ALWAYS MAKE SURE BALES
ARE PLACED SO THE STACK IS STABLE.
Keep all bystanders at a safe distance. REMEMBER
– FALLING BALES CAN ROLL OR TUMBLE.
HANDLE ROUND BALES SAFELY
SAFETY INSTRUCTIONS
Observe all instruction and safety decals on the Loader
Fork. These decals are shown for reference. Read them
carefully before using the Loader Fork. Replace any
decals that may be faded or damaged.
Make sure all operators have read the Owner’s Manual
and are familiar with the instructions and the safety rules
of operation.
OPERATE LOADER SAFELY
• Improper use of loader can cause serious injury or
death.
• Become familiar with controls.
• Be sure anyone operating the loader is aware of safe
operation and potential hazards. Read and observe
safety recommendations in loader manual.
• Operate loader from operator’s seat only. Remain at
controls until operating cycle is complete.
• Stop loader gradually when lowering or lifting loads.
• Use particular care when working on inclines and hill-
sides.
• Avoid holes, ditches, and obstructions which may
cause tractor/loader to tip.
• Allow for additional length of loader on tractor while
turning.
• Never allow anyone to walk or work under a raised
loader.
• Be sure that people, livestock, or pets are not stand-
ing near the machine while operating.
• Do not use the loader for a work platform.
• Do not lift or carry anyone on loader or in bucket or
attachment.
• Carry load low.
• Travel slowly over rough ground or when making
turns.
• Drive slowly through gates and doors.
• Avoid carrying loose or shiftable loads.
• Lower bucket or attachment to ground when loader is
unattended.

3
18
To the Owner/Operator/Dealer
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera-
tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this
implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
BEFORE YOU START!!
Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
THIS SAFETY ALERT SYMBOL IDENTIFIES IMPORTANT
SAFETY WARNING MESSAGES. CAREFULLYREAD EACH
WARNING MESSAGE THAT FOLLOWS. FAILURE TO
UNDERSTAND AND OBEY A SAFETY WARNING, OR
RECOGNIZE A SAFETY HAZARD, COULD RESULT IN AN
INJURY OR DEATH TO YOU OR OTHERS AROUND YOU.
THE OPERATOR IS ULTIMATELY RESPONSIBLE FOR THE
SAFETY OF HIMSELF, AS WELL AS OTHERS, IN THE
OPERATING AREA OF THE TRACTOR AND ATTACHED
EQUIPMENT.
IMPORTANT SAFETY INFORMATION!
Working with unfamiliar equipment can lead to careless injuries. Read this manual, and the manual for your tractor,
skid steer, or forklift, before assembly or operating, to acquaint yourself with the machines. It is the implement owner’s
responsibility, if this machine is used by any person other than yourself, is loaned or rented, to make certain that the
operator, prior to operating:
1. Reads and understands the operator’s manuals.
2. Is instructed in safe and proper use.
The use of this equipment is subject to certain hazards which cannot be protected against by mechanical
means or product design. All operators of this equipment must read and understand this entire manual, paying
particular attention to safety and operating instructions, prior to using. If there is something in this manual you
do not understand, ask your supervisor, or your dealer, to explain it to you.
THIS SYMBOL MEANS
– ATTENTION!
– BECOME ALERT!
– YOUR SAFETY IS INVOLVED!
UNDERSTAND SIGNAL WORDS
Note the use of the signal words DANGER, WARNING
and CAUTION with the safety messages. The
appropriate signal word for each has been selected
using the following guidelines:
DANGER: Indicates an imminently hazardous situation
that, if not avoided, will result in death or serious injury.
This signal word is to be limited to the most extreme
situations typically for machine components which, for
functional purposes, cannot be guarded.
If you have questions not answered in this manual or require additional copies or the manual is damaged, please
contact your dealer or the manufacturer directly.
WARNING: Indicates a potentially hazardous sit-
uation that, if not avoided, could result in death
or serious injury, and includes hazards that are
exposed when guards are removed. It may also
be used to alert against unsafe practices.
CAUTION: Indicates a potentially hazardous sit-
uation that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
CAUTION!
When traveling on public roads, whether at night or
during the day, use accessory light and devices for
adequate warnings to operators of other vehicles.
Comply with all federal, state and local laws.
Carry load low.
Check visibility. If visibility is impaired, reduce speed or
consider other means of transport.
Allow for additional length of loader on tractor while
turning.
Select a safe ground travel speed when transporting
from one area to another. When traveling on roadways,
transport in such a way that faster moving vehicles may
pass you safely.
When traveling over rough or hilly terrain or when mak-
ing turns, slow down and use extra care.
Read all the safety warnings in the front of the
manual.
TRANSPORTING
OPERATING INSTRUCTIONS (continued)
OBEY ALL
SAFETY WARNINGS
UKeep children away from danger all day, every day.
UEquip tractors with roll-over protection (ROPS) and keep
all machinery guards in place.
UPlease work, drive, play, and live each day with care and
concern for your safety and that of your family and fellow
citizens.

19
2
LIMITED WARRANTY
Worksaver warrants to the original purchaser of any new Pallet Fork or Hay Fork (Models ULF-346/355, VLF-
7646/7655, and SSPF-40), that the equipment be free from defects in material and workmanship for a period
of six (6) months for non-commercial, state, and municipalities. Use sixty (60) days for commercial use from
date of retail sale.
Replacement or repair parts installed in the equipment covered by this warranty are warranted for sixty (60)
days from the date of purchase of such part or to the expiration of the applicable new equipment warranty
period, whichever occurs later.
Such parts shall be provided at no cost to the user during regular working hours. Worksaver reserves the right
to inspect any equipment or parts which are claimed to have been defective in material or workmanship.
DISCLAIMER OF IMPLIED WARRANTIES & CONSEQUENTIAL DAMAGES
Worksaver’s obligation under this warranty, to the extent allowed by law, is in lieu of all warranties, implied or
expressed, including implied warranties of merchantability and fitness for a particular purpose and any liability
for incidental and consequential damages with respect to the sale or use of the items warranted. Such
incidental and consequential damages shall include but not be limited to: transportation charges other than
normal freight charges; cost of installation other than cost approved by Worksaver; duty; taxes; charges for
normal service or adjustments; loss of crops or any other loss of income; rental of substitute equipment,
expenses due to loss, damage, detention or delay in the delivery of equipment or parts resulting from acts
beyond the control of Worksaver.
THIS WARRANTY SHALL NOT APPLY:
1. To vendor items which carry their own warranties, such as hydraulic cylinders, tires, and tubes.
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident.
3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge-
ment of Worksaver such use affects its performance, stability, or reliability.
4. If the unit has been altered or repaired outside of an authorized Worksaver dealership in a manner which,
in the sole judgement of Worksaver affects its performance, stability or reliability.
5. To normal maintenance service and normal replacement items such as gearbox lubricant, hydraulic fluid,
worn blades, or to normal deterioration of such things as belts and exterior finish, due to use or exposure.
6. To expendable or wear items such as teeth, chains, sprockets, belts, springs and other items that in the
company’s sole judgement is a wear item.
NO EMPLOYEE OR REPRESENTATIVE OF WORKSAVER IS AUTHORIZED TO CHANGE THIS WARRANTY IN
ANY WAY OR GRANTANY OTHER WARRANTY UNLESS SUCH CHANGE IS MADE IN WRITING AND SIGNED
BY WORKSAVER’S SERVICE MANAGER, POST OFFICE BOX 100, LITCHFIELD, ILLINOIS 62056-0100.
OWNER SERVICE
Check the pins at the ends of the loader arms. Make
sure they are locked in place with the linchpins.
Periodically check all bolts to make sure they are tight.
Check hydraulic hoses. Make sure they are not chafed
or pinched. Replace any damaged hose.
Check hydraulic hoses and fittings for leaks. Repair any
leaks immediately. Never use your hand to check for a
hydraulic leak when system is under pressure.
Periodically lubricate the swing arm pivot bushings.
Replace any worn or damaged parts immediately. Do
not use attachment with any damaged parts.
REPLACE SAFETY SIGNS
IF DAMAGED OR MISSING!
STORAGE
MAINTENANCE
• Never store equipment with fuel in the tank inside a
building where fumes may reach an open flame or
spark. Allow engine to cool before storing in an
enclosure.
• Do not run engine indoors – exhaust gasses contain
carbon monoxide, and odorless and deadly poison.
• At the end of the working season or when the Loader
Fork will not be used for a long period, it is good
practice to clean off any dirt or grease that may have
accumulated.
• Inspect the Loader Fork for loose, damaged or worn
parts and adjust or replace if needed.
• Sand areas where paint is chipped or worn and
repaint to prevent rust.
• Always store in a safe place away from children or
livestock.
W ARNING!
Always stop the tractor, set brake, shut off engine,
remove key, and lower loader to ground before
attempting to service. Never leave equipment unat-
tended with engine running.
W ARNING!
Do not work under a raised loader unless it is
securely blocked or held in position. Do not depend
on the hydraulic system to hold loader and attach-
ment in place.
