Workspace48 Agile Winder User manual

Winder 2 column installation guide

workspace48.com

Page 2
1 x Left & Right Leg Pair 1 x Cross Rail 1 x Drive Shaft
4 x Leveling Foot
1 x L&R Support Bar Pair
2 x Foot 2 x Leg Rail
1 x Winder 8 x M8x10 6 x ST5.0x23 2 x M8x10 2x Washer 2 x ST3.9x12
8 x M8x25
Winder 2 column installation guide



Page 3
4 x M8x10 2 x M8x10 2 x Washer
Step 1

Winder 2 column installation guide

Page 4
4 x M8x10
Step 2

Winder 2 column installation guide

Page 5
4 x Leveling Foot 8 x M8x25
Step 3

Winder 2 column installation guide

Page 6
Length
Worktop Length
1200mm 1125mm
1500mm 1425mm
1800mm 1725mm
2100mm 2025mm
Step 4

Winder 2 column installation guide

Page 7
1 x Drive Shaft
Step 5

Winder 2 column installation guide

Page 8
6 x ST5.0x23
Step 6

Winder 2 column installation guide

Page 9
1 x Winder 2 x ST3.9x12
FOR DEEP WORKTOPS REF PG-10 FOR POSITIONING DETAILS
1
2
3


Winder 2 column installation guide


Page 10
2 x ST.3.9x12
40mm
RELEASE GRUBSCREW
Step 7b

Winder 2 column installation guide

Page 11


Winder 2 column installation guide

Page 12

Changing crank handle from right to left operation
Step 1

Page 13

Changing crank handle from right to left operation
Step 2

Page 14
Step 1
Optional cable tray installation guide


Page 15
348
90.0°
348
90.0°
Step 2
Optional cable tray installation guide

DO NOT OVER TIGHTEN.

Page 16
Step 3
Optional cable tray installation guide


Page 17
Step 4
Optional cable tray installation guide


Page 18
Step 5
Optional cable tray installation guide


Page 19
Step 6
Optional cable tray installation guide


Page 20
1 x Power/Data Plate
Step 1
Optional cable tray - power/data plate installation guide

3 x Screw + Bolt
Complete Complete
Complete Complete
Complete Complete
Complete Complete
Complete Complete
Complete Complete
Complete Complete
