Workspace48 Modulus Twin Pole Double Span Table User manual

TOOLS REQUIRED: Powered screwdriver.
www.workspace48.com
Modulus Twin Pole
Double Span Table
Installation Guide

www.workspace48.com
COMPONENTS
1Die Cast Upper Wrist x6
2Top Rail x4
3Bottom Rail x2
4Feet Tube x6
5Large Foot x6
6150° Collar x4
7Cross Collar x2
8Bottom T Connector x2
9Cross Connector x1
10 T Tube x6
11 Collar Plug x4
12 T Tube & Collar Connector x6
13 Minus Gasket x2
14 150° Gasket x4
15 Foot Glide x6
16 Top Rail Caps x$
17 Steel Strap x3
18 Plastic Support x4
19 Table Top Bracket Plate x2
20 Table Top x2
SCREWS
21 M8x16mm x28
22 M10x110mm x6
23 M10x30mm x6
24 M8x25mm x6
25 M5x30mm Self Tapping x12
26 M5x20mm x47
22
15
13
14
26
4
23
24
25
18
9
12
10
8
2
26
3
19
6
1
17
7
5
11
21
26 16
Modulus Twin Pole Double Span Table
INSTALLATION GUIDE

www.workspace48.com
01
03 04
02
Slide the large foot, T tube connector and 2 cross collar plugs into the collar, place
the minus gasket on top, and fully tighten the 2 M8x16mm bolts into the collar.
(Repeat with all cross collars)
Slide the large foot and T tube connector into the collar, place the 150° gasket on
top, and fully tighten the 2 M8x16mm bolts into the collar. (Repeat with all 150°
collars)
Using 2 T tubes, connect the assembled centre feet to the bottom cross
connector, and fully tighten the 4 M8x16mm bolts.
Using 2 T tubes, connect the assembled corner feet to the bottom T connector,
and fully tighten the 4 M8x16mm bolts. (Repeat with all 150° feet)
Modulus Twin Pole Double Span Table
INSTALLATION GUIDE

www.workspace48.com
05
07 08
06
Place a feet tube on top of each collar, and the upper wrist assembly on top of
the feet tubes. Fully tighten the M10x30mm bolts through the upper wrists, and
M10x110mm bolt, spring washer and flat washer through the collars.
Screw all glides into the base of the large feet, leaving the glides one turn from
tight (then they can be adjusted easily if the floor is uneven).
Place all assembled leg sets together using the bottom rails, and fully tighten the
M8x16mm bolts to lock all legs together.
Place the steel strap onto the upper wrists, with the raised areas of the straps
slotting into the holes on the upper wrist, Fig C. Fully tighten the M8x25mm bolts.
(Repeat with all upper wrists and steel straps)
Fig C
Modulus Twin Pole Double Span Table
INSTALLATION GUIDE

www.workspace48.com
09
11 12
10
Tighten all small grub screws located on the bottom of each upper wrist.
Slide each top rail through the upper wrists, making sure they are located in the
centre of the frame.
Snap the plastic support brackets onto the centre of each top rail. The frame
assembly is now complete.
Place the top rail caps into the exposed holes on each end of the frame assembly.
Modulus Twin Pole Double Span Table
INSTALLATION GUIDE

www.workspace48.com
14
15
For multi piece work surfaces, use the table top bracket plates, and M5x20mm
screws to join together as one solid piece. This should be done with the work
surface sitting on the frame in its final position.
Fully tighten all M5x30mm screws through each upper wrist into the work surface.
Fully tighten all M5x20mm screws through each steel strap and plastic support into
the work surface.
13
Optional: For extra strength, the plastic support brackets can be screwed onto the
top rails.
