World Video Sales MicroImage Video Systems VDA206 User manual

Page 4
WARRANTY
MicroImage Video Systems warrants that each VDA206 is free from
defects due to faulty materials or improper workmanship for a period of
one ( ) year. MicroImage Video Systems further warrants that any part
which proves defective in materials or workmanship within one ( ) year,
will be replaced or repaired at no cost to the user. Labor to replace
defective parts will be done without charge, provided the equipment is
returned to MicroImage Video Systems prepaid, insured and properly
packaged. Prior return authorization must be obtained from MicroImage
Video Systems.
NOTE
This warranty covers the MicroImage VDA206 Video Distribution Amplifier
only.
CONDITIONS
This warranty is void if the warranted part has been altered or subjected
to abuse or misuse. Defective parts must be returned to MicroImage
Video Systems.
SOLE WARRANTY
This Warranty is in lieu of all other warranties expressed or implied
including, without limitation, any implied warranty or any implied
warranty of fitness for a particular purpose. MicroImage Video Systems
shall have the final right to determination as to the existence and cause of
any defect and its appropriate adjustment in accordance with the terms of
this warranty. In no event shall MicroImage Video Systems be liable for
any consequential or collateral damages.
RETURNS
All returns MUST have an RMA number. Please call, fax or email
for an RMA form. The RMA form will have the proper shipping
address for returns.
Phone [phone]
Fax [phone]
Email [e-mail]
S-Video 1x6
DISTRIBUTION AMPLIFIER
Operation Manua
Model VDA206
MicroImage Video Systems
division of World Video Sales Co., Inc
PO Box 33
Boyertown, PA 95 2
Phone [phone]
Fax [phone]
[e-mail]
www.mivs.com

Page 2
CONTENTS
SPECIFICATIONS....................................................................2
UNPACKING.............................................................................3
CONNECTIONS........................................................................3
Power ....................................................................................3
Video.....................................................................................3
IN CASE OF DIFFICULTY........................................................3
WARRANTY..............................................................................4
RETURNS.................................................................................4
Rev 0 09-30-1998, Reviewed 07-07-2015
SPECIFICATIONS
Input level .0 Vpp Composite, 75 Ω
Output level Same as respective inputs "2% into 75 Ω
Connectors
VDA206 4 pin mini-DIN female (std. S-Video conn.)
Bandwidth Greater than 30Mhz
Temperature
Operating 0E - 40E C (32E - 04E F)
Storage -40E - 60E C (-40E - 40E F)
Humidity
Operating 0% - 90% (non-condensing)
Storage 5% - 95% (non-condensing)
Power
Voltage 0 - 25VAC, 50/60Hz
(+ 2VDC & 230VAC available, contact factory)
Consumption 2W
Size 8.6" (W) x 6.7" (D) x 2.4" (H)
2 8.5 mm (W) x 70 mm (D) x 6 mm (H)
Weight lb, 5 oz.
Manufactured in USA by MicroImage Video Systems
Page 3
UNPACKING
The VDA206 package includes the following items:
VDA206 Video Distribution Amplifier
CAB05006 Power Cord
This operation manual
Please inspect all items carefully and report damaged or missing
items to your dealer or MicroImage Video Systems.
CONNECTIONS
ower
The VDA206 uses an industry standard, detachable 3 wire power
cord which is included with the unit. For medical applications, a
special low leakage cord (part # CAB0 006) is available. Connect
the cord to a suitable power source of 20VAC, 50-60Hz.
Video
Connect the video source (i.e. camera) to the IN connector on the
VDA unit. Connect the OUTPUT signals from the VDA unit to the
video displays as required. Each output can only have a single 75
ohm termination.
The VDA206 uses industry standard mini-DIN connectors for
S-Video.
IN CASE OF DIFFICULTY
If you are experiencing problems with any MicroImage product,
you can contact MicroImage Support using the following methods:
Phone [phone]
Fax [phone]
Email [e-mail]
Web www.mivs.com
