Worx WG773E User manual

WG773E
P06
P17
P30
P42
P54
P66
P78
P91
P103
P115
P127
CordlessLawnMower
Schnurloserrasenmäher
Tondeuseàgazonsansfil
Falciatriceperpratosenzafili
Cortacéspedsincables
Snoerlozegrasmaaier
Kosiarkadotrawyzzasilaniembateryjnym
Akkumulátorosfűnyíró
Maşinădecositiarbafărăcordon
Akumulátorovásekačkatrávy
Akumulátorovákosačkanatrávu
EN
D
F
I
ES
NL
PL
HU
RO
CZ
SK

Original instructions EN
Originalbetriebsanleitung D
Notice originale F
Istruzioni originali I
Manual original ES
Oorspronkelijke gebruiksaanwijzing NL
Instrukcja oryginalna PL
Eredeti használati utasítás HU
Instrucţiuni originale RO
Překlad CZ
Preklad SK

1
2
3
4
5
6
7
8
9
10
11

1
2
3
12
1
a
b
K-1
K-2
K-3
L-1
L-2
L-3
a
Front
Back
1
2
1
2
13
14
12
A B1 B2
B3 C1 C2
C3 C4 D1
D2 D3 E1
E2 F1 F2
G H I
J K L
M1 M2 N

1
2
3
12
1
a
b
K-1
K-2
K-3
L-1
L-2
L-3
a
Front
Back
1
2
1
2
13
14
12
A B1 B2
B3 C1 C2
C3 C4 D1
D2 D3 E1
E2 F1 F2
G H I
J K L
M1 M2 N

Cordless lawn mower EN
7
6
1. UPPER HANDLE
2. SWITCH LEVER
3. CABLE CLIP
4. GRASS BAG FILLING INDICATOR
5. GRASS COLLECTION BAG
6. SAFETY KEY
7. HANDLE KNOBS
8. LOWER HANDLE
9. SAFETY FLAP
10. BATTERY PACK*
11. MOTOR COVER
12. CHARGER* (See Fig. A)
13. BLADE BOLT (See Fig. M1)
14. BLADE (See Fig. M1)
* Not all the accessories illustrated or described are included in standard delivery.

Cordless lawn mower EN
7
6
TECHNICAL DATA
Type WG773E (7 --designation of machinery, representative of Battery powered
Lawn Mower)
Voltage 24V
Cutting diameter 33cm
Cutting height 20-60mm
Cutting height positions 3 positions
Grass collection capacity 30L
Battery type Lead acid
Battery model WA3216
Charging time 5-7hrs
Charger model WA3749
Charger rating Input: AC 110-240V, 50/60Hz
Machine weight 14kg
NOISE / VIBRATION INFORMATION
A weighted sound pressure LPA : 76dB(A) KPA: 3dB(A)
A weighted sound power LWA: 90dB(A)
Wear ear protection when sound pressure is over 80dB(A)
Typical weighted vibration 4.1m/s2K=1.5m/s2
ACCESSORIES
Battery pack (WA3216) 1
Charger (WA3749) 1
Grass collection bag 1
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.

Cordless lawn mower EN
9
8
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
Carefully read the instructions for the
safe operation of the machine.
Save all warnings and instructions for
future reference.
- This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
- Children should be supervised to ensure
that they do not play with the appliance.
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
SAFE OPERATION PRACTICES
TRAINING
a) Read the instructions carefully. Be familiar
with the controls and the proper use of the
equipment;
b) Never allow children or people unfamiliar
with these instructions to use the
lawnmower. Local regulations can restrict
the age of the operator;
c) Never mow while people, especially
children, or pets are nearby;
d) Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
PREPARATION
a) While mowing, always wear substantial
footwear and long trousers. Do not operate
the equipment when barefoot or wearing
open sandals;
b) Thoroughly inspect the area where the
equipment is to be used and remove
all objects which can be thrown by the
machine;
c) Before using, always visually inspect to
see that the blades, blade bolts and cutter
assembly are not worn or damaged.
Replace worn or damaged blades and
bolts in sets to preserve balance; Replace
damaged and unreadable labels.
d) On multi-bladed machines, take care as
rotating one blade can cause other blades
to rotate.
OPERATION
a) Mow only in daylight or in good artificial
light;
b) Avoid operating the equipment in wet
grass, where feasible;
c) Always be sure of your footing on slopes;
d) Walk, never run;
e) For wheeled rotary machines, mow across
the face of slopes, never up and down;
f) Exercise extreme caution when changing
direction on slopes;
g) Do not mow excessively steep slopes;
h) Use extreme caution when reversing or
pulling the lawnmower towards you;
i) Stop the blade(s) if the lawnmower has to
be tilted for transportation when crossing
surfaces other than grass, and when
transporting the lawnmower to and from
the area to be mowed;
j) Never operate the lawnmower with
defective guards, or without safety devices,
for example deflectors and/or grass
catchers, in place;
k) Switch on the motor carefully according to
instructions and with feet well away from
the blade(s);
l) Do not tilt the lawnmower when switching
on the motor, except if the lawnmower has
to be tilted for starting In this case, do not
tilt it more than absolutely necessary and
lift only the part which is away from the
operator;
m) Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all times;
n) Not to touch the blades before the
disabling device has been removed and the
blades have come to a complete stop;
o) Do not start the lawnmower when standing
in front of the discharge opening.
p) Do not transport the lawnmower while the

Cordless lawn mower EN
9
8
power source is running.
q) Stop the lawnmower, and remove the
disabling device. Make sure that all moving
parts have come to a complete stop.
– Whenever leaving the machine unattended,
– Before clearing a blockage,
– Before checking, cleaning or working on
the machine,
– After striking a foreign object. Inspect the
machine for damage and make repairs
before restarting and operating the
lawnmower
If the lawnmower starts to vibrate abnormally
(check immediately)
– Inspect for damage.
– Replace or repair any damaged parts.
– Check and tighten any loose parts.
MAINTENANCE AND STORAGE
a) Keep all nuts, bolts and screws tight to
be sure the equipment is in safe working
condition;
b) Check the grass catcher frequently for wear
or deterioration;
c) replace worn or damaged parts for safety.
Use only genuine replacement parts and
accessories.
d) Be careful during adjusting of the
lawnmower to prevent entrapment of the
fingers between moving blades and fixed
parts of the lawnmower.
e) Always allow the lawwnmower to cool
down before storing.
f) When servicing the blades be aware that,
even though the power source is switched
off, the blades can still be moved.
SAFETY WARNINGS FOR
BATTERY CHARGERS
WARNING! Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made
by children without supervision.
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR
BATTERY CHARGER
1. Before charging, read the instructions.
2. After charging, disconnect the battery
charger from the supply mains.Then
remove the chassis connection and then
the battery connection.
3. Do not charge a leaking battery.
4. Do not use chargers for works other than
those for which they are designed.
5. Before charging, ensure your charger is
matching the local AC supply.
6. For indoor use, or do not expose to rain.
7. The charging device must be protected
from moisture.
8. Do not use the charging device in the open.
9. Do not short out the contacts of battery or
charger.
10.Respect the polarity “+/-“ when charging.
11. Do not open the unit and keep out of the
reach of children.
12.Do not charge the batteries of other
manufactures or ill-suited models.
13.Ensure that the connection between the
battery charger and battery is correctly
positioned and is not obstructed by foreign
bodies.
14. Keep battery charger’s slots are free of
foreign objects and protect against dirt and
humidity. Store in a dry and frost-free place.
15.When charging batteries, ensure that the
battery charger is in a well-ventilated area
and away from inflammable materials.
Batteries can get hot during charging.
Do not overcharge any batteries. Ensure
that batteries and chargers are not left
unsupervised during charging.

Cordless lawn mower EN
11
10
16.Do not recharge non-rechargeable
batteries, as they can overheat and break.
17. Longer life and better performance can
be obtained if the battery pack is charged
when the air temperature is between 18°C
and 24°C. Do not charge the battery pack
in air temperatures below 4.5°C, or above
40.5°C.This is important as it can prevent
serious damage to the battery pack.
18.Charge only battery pack of the same
model provided by WORX and of models
recommended by WORX.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use,
keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
the liquid to come into contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts of
water and seek medical advice.
f) Seek medical advice immediately if a cell
or battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a
clean dry cloth if they become dirty.
i) Battery pack needs to be charged before
use. Always refer to this instruction and use
the correct charging procedure.
j) Do not maintain battery pack on charge
when not in use.
k) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
l) Battery pack gives its best performance
when it is operated at normal room
temperature (20°C ± 5°C).
m) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
n) Recharge only with the charger specified by
WORX. Do not use any charger other than
that specifically provided for use with the
equipment. A charger that is suitable for
one type of battery pack may create a risk of
fire when used with another battery pack.
o) Do not use any battery pack which is not
designed for use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for
future reference.
r) Remove the battery from the equipment
when not in use.
s) Dispose of properly.
ADDITIONAL SAFETY
RULES FOR LEAD ACID
BATTERY:
1. Working in the vicinity of a lead-acid
battery is dangerous. Battery pack
generates explosive gases during normal
battery operation. For this reason it is of the
utmost importance that each time before
using your charger, you read and follow the
instructions provided exactly.
2. Never smoke or allow an open spark or
flame in the vicinity of the battery.
3. Use charger for charging a lead-acid battery
pack only.
4. Never place the charger directly above
or below the battery pack being charged;
gases or fluids from the battery pack will
corrode and damage the charger. Locate
the charger as far away from the battery
pack as DC cables permit.
5. Do not operate charger in a closed-in area
or restrict ventilation in any way.

Cordless lawn mower EN
11
10
SYMBOLS
Only use the battery charger
indoors
Read instruction handbook before
operation this machine
Keep bystanders away.
Beware of sharp blades. Blades
continue to rotate after the motor
is switched off - Remove disabling
device before maintenance
Fuse
T 2 A time lag fuse with rated current of 2 A
The output plug is with positive
center pole and negative outer pole
Do not dispose of batteries. Return
exhausted batteries to your local
collection or recycling point.
Do not burn
Do not expose to rain or water
This product has been marked with a
symbol relating to removing electric
and electronic waste.This means that
this product shall not be discarded with
household waste but that it shall be returned
to a collection system which conforms to the
European Directive 2002/96/CE. It will then
be recycled or dismantled in order to reduce
the impact on the environment. Electric and
electronic equipment can be hazardous for
the environment and for human health since
they contain hazardous substances.
INTENDED USE
This product is intended for domestic
lawn mowing.
CHARGER SAFETY RULES
1. Plug charger directly into an electrical
outlet. DO NOT ABUSETHE CORD. Never
carry charger by cord. Do not disconnect
the charger from the outlet or mower by
pulling it by the cord.
2. CAUTION: To reduce the risk of fire,
electrical shock, or personal injury do
not attempt to use this charger with any
other product.
Likewise, do not attempt to charge the
battery with any other charger.
3. Do not service mower with charger or
safety key installed.
4. Do not operate a damaged charger. Replace
damaged cords or charger immediately at
an authorized WORX service center.
5. Always charge the mower in a dry area
protected from the weather. Do not expose
the mower or charger to rain. Do not
charge in wet locations. Do not charge
mower when temperature is above 104°F
(40°C) or below 41°F (5°C).
6. Keep the mower and charger away from
water, heat sources, (Such as radiators,
heaters, stoves...etc.) flames, or chemicals.
Be careful not to damage the charger cord,
by keeping cord away from sharp edges.
CHARGING PROCEDURE
1. Charging can be carried out only with the
battery REMOVED from the machine (See
A).
2. Insert the plug of the charger into the wall
receptacle, the Charging indicator light will
be green.
3. Plug the charger connector into the
receptacle on the battery, the light will
switch to be red indicating that you have
power and the battery is being charged.
4. The light will turn to be green when
charging is completed;

Cordless lawn mower EN
13
12
5. Always keep the battery connect with the
charger and the charger is powered on.
After the battery is fully charged, the green
light will turn on and the charger will stop
charging, but when the capacity is lower
than 90%, the charger will automatically
recharge to make sure the capacity stays
above 90%.
NOTE: if the battery is Defective, the red
light will Flash.
BATTERY CARE
The battery in your cordless lawnmower is a
24-volt sealed lead acid system.The mower
can be stored in any position without fear of
leakage.
• For optimal battery life and performance
the battery should be fully charged every 2
months during storage
• For optimal battery life and performance
the battery should be fully charged after
each use
• Store the battery in a cool dry location.
• The battery can be safely stored down to
14°F (-10°C).
• The battery does not need to be fully
discharged before recharging.
• Initially 2 to 3 charging cycles may
be required after purchase to achieve
maximum run time capacity.
ADDITIONAL BATTERIES can be obtained
from the Customer Helpline.
ASSEMBLY
IMPORTANT! Before you assemble
the lawn mower, check the accessories
according above information, make sure the
accessories are completed.
1. FITTING THE HANDLE
(See Fig. B1, B2, B3)
1) Remove the screws(x 2) on the both side
of deck. (See Fig. B1)
2) Insert the lower handle (8) into the holes on
the deck provided.
3) Secure with the screws provided.
(See Fig. B1)
4) Attach the upper handle (1) with the bolts
and Handle knobs (7) to the lower handle
(8). (See Fig. B2)
5) Screw on the two Handle knobs. Check that
the handle is FULLY secured.
NOTE: Ensure the bolts are fully inserted
through the handles before fitting the
handle knobs.
6) Attach the cable clips (3) provided, to the
upper and lower handle. Insert the cable
into the clips ensuring there is enough
cable slack. (See Fig. B3)
2. GRASS COLLECTION BAG ASSEMBLY
Connect the grass box handle to the box top
as shown in Fig C1-C4.
Step 1) Press the front of the handle briefly.
(See Fig. C2)
Step 2) Then push it forward. (See Fig. C2)
Step 3) Push down the back of the handle.
(See Fig. C2)
Step 4) Clip the plastic clips over the metal
frame. (See Fig. C3)
WARNING: Don’t fit the handle in
reversed direction. Fit the handle as
shown in Fig C1.
3. GRASS BAG FITTING
(See Fig D1, D2, D3)
1) Turn the mower off, wait until blade stops
and remove safety key (6).
2) Raise the safety flap (9) and hold it up,
ensure that the mulching insert has been
removed.
3) Pick up the grass bag by the handle, and
position grass bag on the lower hooks (a)
on the mower deck. (See Fig. D2)
4) Release the safety guard to lock the grass
bag into position. Ensure the grass bag is
installed securely. (See Fig. D3)
NOTE: Depress the grass bag slightly to
ensure that it is completely installed.
4. REMOVING/EMPTYING
Hold the grass bag, lift the safety flap (9) and
hold up. Remove grass bag (5).
WARNING! Always check the safety
flap can close the discharge outlet
tightly before using. Never lift the safety

Cordless lawn mower EN
13
12
flap (9) when the lawn mower is being used
without fitted grass bag.
5. FITTING/REMOVING BATTERY
(See Fig. E1, E2)
REMOVING BATTERY
Pull out the battery with the battery handle
directly. (See Fig. E1)
NOTE: Be careful not to drop the battery onto
your foot or on the ground when removing it.
FITTING BATTERY
Put the battery into the battery container;
make sure the battery is fitted correctly. (See
Fig. E2)
OPERATION
1. STARTING AND STOPPING
( See Fig. F1, F2)
WARNING! The blade continues
to rotate for a few seconds after the
machine is switched off. Allow the motor/blade
to stop rotating before switching “on” again.
Do not rapidly switch off and on.
STARTING
1) Insert safety key into the housing of the
switch box.
2) Slide the key to the right and hold in
position.
3) Pull the lever bar towards the handle and
the mower will start.
4) Release the safety key.
STOPPING
Release the switch lever.
2. GRASS BAG FILLING INDICATOR
( See Fig. G)
To remind you immediately to empty when
the grass bag is full, the mower provides
an indicator on the top of bag to show the
collection status. And you can follow as below:
Empty status: flap float (a)
Fully status: flap fall down (b)
3. REAR DISCHARGE (See Fig. H)
The mower provides a rear discharge function,
so that you can mower without bag collection.
The debris will be discharged from the rear
chute.
4. BATTERY STATUS LED’S (See Fig. I)
NOTE: The Status LED’s will indicate the
battery condition when the button on the
battery is pressed.
The LED’s constantly senses and displays the
battery condition as follows:
Press the button “POWERTEST”, the light
button is illuminated.
When the three green lights are illuminated,
the battery is in a highly charged condition.
When two lights ( ) are illuminated, the
battery is in a moderately charged condition.
When only one green light ( ) is illuminated,
the battery charge is depleted.
Before using your new mower for the first
time, it is recommended that the unit be
charged overnight to ensure that the battery is
fully charged.
IMPORTANT
When only one light is illuminated,
your battery is overly discharged, even
though the mower may still be capable
of cutting grass. Continuing to operate
your lawnmower with the battery in this
discharged condition may reduce the life
and performance of your battery.
5. ADJUSTING THE CUTTING HEIGHT
(See Fig. J)
WARNING! Before adjusting the
mower height, wait for the mower to
completely stop. Mower blades continue to
rotate after the machine is switched off and
a rotating blade can cause injury. Wait until
all machine components have completely
stopped before touching them.

Cordless lawn mower EN
15
14
Before your first cut, adjust the mower cutting
depth to the desired position.The lawnmower
can be set to 3 cutting heights between 20 mm
and 60 mm.
Grip one wheel and pull it out of the groove
and reposition it in the required height. ALL
other wheels should be positioned at the
same height.
6. MOWING TIPS
NOTE: Always inspect area where mower
is to be used and remove all stones,
sticks, wire, metal and other debris
which might be thrown by the rotating
blade.
1. Mow across the face of slopes, never up-
and-down. Exercise extreme caution when
changing direction on slopes. Do not mow
excessively steep slopes. Always maintain
good footing.
2. Release switch lever to turn mower “OFF”
when crossing any graveled area (stones
can be thrown by the blade).
3. Set mower at highest cutting height when
mowing in rough ground or in tall weeds.
Removing too much grass at one time can
cause circuit breaker to trip, which stops
mower.
4. If a grass bag is used during the fast
growing season, the grass may tend to
clog up at the discharge opening. Release
switch lever to turn mower “OFF” and
remove the safety key. Remove the grass
bag and shake the grass down to the back
end of the bag. Also clean out any grass
or debris which may be packed around the
discharge opening. Replace the grass bag.
5. If mower should start to vibrate
abnormally, release switch lever to turn
mower “OFF” and remove safety key.
Check immediately for cause. Vibration is a
warning of trouble. Do not operate mower
until a service check has been made.
6. ALWAYS RELEASE SWITCH LEVER TO
TURN MOWER “OFF” AND REMOVE
SAFETY KEY WHEN LEAVING IT
UNATTENDED EVEN FOR A SHORT
PERIOD OF TIME.
MAINTENANCE
WARNING: Stop the mower and
remove the safety key before
removing the grass bag.
NOTE: To ensure long and reliable service,
perform the following maintenance
procedures regularly. Check for obvious
defects such as a loose, dislodged or a
damaged blade, loose fittings, and worn
or damaged components. Check that the
covers and guards are all undamaged and
are correctly attached to mower. Carry out
any necessary maintenance or repairs before
operating mower. If the mower should
happen to fail despite regular maintenance,
please call our customer helpline for advice.
BLADE SHARPENING
KEEP BLADE SHARP FOR BEST MOWER
PERFORMANCE. A DULL BLADE DOES NOT
CUT GRASS CLEANLY.
WEAR PROPER EYE PROTECTION WHILE
REMOVING, SHARPENING, AND INSTALLING
BLADE. ENSURETHAT SAFETY KEY IS
REMOVED.
Sharpening the blade twice during a mowing
season is usually sufficient under normal
circumstances. Sand causes the blade to dull
quickly. If your lawn has sandy soil, more
frequent sharpening may be required.
REPLACE BENT OR DAMAGED BLADE
IMMEDIATELY.
WHEN SHARPENING THE BLADE:
1. Make sure blade remains balanced.
2. Sharpen blade at the original cutting angle.
3. Sharpen cutting edges on both ends of
blade, removing equal amounts of material
from both ends.
TO SHARPEN BLADE IN A VISE
(See Fig. K)
1. Be sure the switch lever is released, the
blade has stopped and the safety key
removed before removing the blade.
2. Remove blade from mower. See instructions
for removing and attaching blade.
3. Secure blade K-1 in a vise K-2.
4. Wear safety glasses and be careful not to
cut yourself.

Cordless lawn mower EN
15
14
5. Carefully file the cutting edges of the blade
with a fine tooth file K-3 or sharpening
stone.
6. Check balance of blade. See instructions for
blade balancing.
7. Replace blade on mower and tighten
securely. Refer to instructions below.
BLADE BALANCING (See Fig. L)
Check balance of blade by placing center hole
in blade L-1 over a nail or screwdriver shank
L-2, clamped horizontally in a vise L-3. If either
end of the blade rotates downward, file that
end. Blade is properly balanced when neither
end drops.
BLADE MAINTENANCE
(See Fig. M1, M2)
Renew your metal blade after 50 hours
mowing or 2 years, which ever is the sooner-
regardless of condition.
Follow these procedures to remove and
replace the blade.You will need garden gloves
(not provided) and a spanner wrench (not
provided) to remove the blade. Hold the blade
(14) and unscrew the blade bolt (13) counter-
clockwise using a spanner wrench, and then
remove blade.
To re-assemble, position the blade (14) with
the cutting edges towards the ground.Then
securely tighten the blade bolt (13).
STORAGE: (See Fig. N)
Stop the mower and always remove the
safety key. Clean the exterior of the machine
thoroughly using a soft brush and cloth. Do
not use water, solvents or polishes. Remove
all grass and debris, especially from the
ventilation slots.
Turn the machine on its side and clean the
blade area. If grass cuttings are compacted
in the blade area, remove with a wooden or
plastic implement.
Store the machine in a dry place. Do not place
other objects on top of the machine.
To aid storage, release the Handle knobs, and
rotate or fold the upper handle.
ENVIRONMENTAL
PROTECTION
This product has been marked with a
symbol relating to removing electric
and electronic waste.This means that
this product shall not be discarded with
household waste but that it shall be returned
to a collection system which conforms to the
European Directive 2012/19/EU. It will then
be recycled or dismantled in order to reduce
the impact on the environment. Electric and
electronic equipment can be hazardous for the
environment and for human health since they
contain hazardous substances.

Cordless lawn mower EN
17
16
DECLARATION OF
CONFORMITY
We,
POSITEC Germany GmbH
Konrad-Adenauer-Ufer 37
50668 Köln
Declare that the product
Description WORX Battery powered Lawn
Mower
Type WG773E (7 --designation of
machinery, representative of Battery
powered Lawn Mower)
Function Cutting grass
Complies with the following Directives,
2006/42/EC, 2004/108/EC, 2011/65/EU,
2000/14/EC amended by 2005/88/EC
2000/14/EC amended by 2005/88/EC:
- Conformity assessment procedure as per
Annex VI.
- Measured Sound Power Level 94dB(A)
- Declared Guaranteed Sound Power Level
96dB(A)
The notified body involved
Name: Intertek Testing & Certification
Ltd (notified body 0359)
Address: Davy Avenue, Knowlhill, Milton
Keynes, MK5 8NL
Standards conform to,
EN 60335-1 EN 60335-2-77
EN 62233 EN ISO 3744
EN 55014-1 EN 55014-2
The person authorized to compile the
technical file,
Name: Russell Nicholson
Address: Positec Power Tools (Europe)
Ltd,PO Box 152, Leeds, LS10 9DS, UK
Suzhou 2015/01/30
Allen Ding
Deputy Chief Engineer,Testing & Certification

17
Schnurloser rasenmäher D
17
16
1. GRIFFOBERTEIL
2. SCHALTBÜGEL
3. KABELKLEMMEN
4. GRASBEHÄLTERFÜLLSTANDANZEIGE
5. GRAS-SAMMELBEUTEL
6. SICHERHEITSSCHLÜSSEL
7. HALTEKNÄUFE
8. GRIFFUNTERTEIL
9. SICHERHEITSKLAPPE
10. AKKU *
11. MOTORABDECKUNG
12. LADEGERÄT * (Siehe A)
13. BLATTBOLZEN (Siehe M1)
14. SÄGEBLATT (Siehe M1)
* Abgebildetes oder beschriebenes Zubehör gehört teilweise nicht zum Lieferum-
fang

18
Schnurloser rasenmäher D
TECHNISCHE DATEN
Typ WG773E (7 - Bezeichnung der Maschinenteile, repräsentiert die
batteriebetriebenen Rasenmäher)
Nennspannung 24V
Schneidradius 33cm
Schnitthöhe 20-60mm
Schneidehöhen-Positionen 3
Grasfangkorb 30L
Batterietyp Säure-Blei
Akkumodell WA3216
Ladezeit 5-7 Stunden
Ladegerätmodell WA3749
Leistung des Ladegeräts Eingang: AC 110-240V, 50/60Hz
Gewicht 14Kg
LÄRMPEGEL UND VIBRATIONEN
Gewichteter Schalldruck LPA : 76dB(A) KPA: 3dB(A)
Gewichtete Schallleistung LWA: 90dB(A)
Tragen Sie bei einem Schalldruck über einen Gehörschutz 80dB(A)
Typischer gewichteter Vibrationswert 4.1m/s2K=1.5m/s2
ZUBEHÖRTEILE
Batterie-Paket(WA3216) 1
Aufladegerät(WA3749) 1
Gras-Sammelbeutel 1
Wir empfehlen Ihnen, sämtliche Zubehörteile beim selben Fachhändler zu beziehen, bei dem
Sie auch Ihr Elektrowerkzeug gekauft haben. Verwenden Sie nur hochwertige Zubehörteile von
namhaften Herstellern. Weitere Informationen finden Sie auf der Verpackung der Zubehörteile.
Auch Ihr Fachhändler berät Sie gerne.

19
Schnurloser rasenmäher D
ALLGEMEINE
SICHERHEITSHINWEISE
FÜR ELEKTROWERKZEUGE
WARNUNG Lesen Sie alle
Sicherheitshinweise und
Anweisungen. Versäumnisse bei der
Einhaltung der Sicherheitshinweise und
Anweisungen können elektrischen Schlag,
Brand und/oder schwere Verletzungen
verursachen.
Lesen Sie die Bedienungsanleitung
zum sicheren Betrieb des Gerätes
aufmerksam durch.
Bewahren Sie alle Sicherheitshinweise
und Anweisungen für die Zukunft auf.
- Dieses Gerät ist nicht dafür bestimmt,
durch Personen (einschließlich Kinder) mit
eingeschränkten physischen, sensorischen
oder geistigen Fähigkeiten oder mangels
Erfahrung und/oder mangels Wissen
benutzt zu werden, es sei denn, sie werden
durch eine für ihre Sicherheit zuständige
Person beaufsichtigt oder erhielten von ihr
Anweisungen, wie das Gerät zu benutzen
ist.
- Kinder sollten beaufsichtigt werden um
Sicherzustellen, dass sie nicht mit dem
Ladegerät spielen.
WICHTIG
VOR GEBRAUCH BITTE GENAU
DURCHLESEN
FÜR SPÄTERE BEZUGNAHME
AUFBEWAHREN
SICHERER BETRIEB
TRAINING
a) Die Anweisungen aufmerksam durchlesen.
Machen Sie sich mit den Bedienelementen
und dem vorschriftsmäßigen Gebrauch des
Rasenmähers vertraut.
b) Niemals Kindern oder mit diesen
Anweisungen nicht vertrauten Personen
erlauben, den Rasenmäher zu benutzen.
Nationale Vorschriften können das Alter
der Bedienperson möglicherweise
beschränken.
c) Niemals mähen, während sich Personen,
insbesondere Kinder, oderTiere in
unmittelbarer Nähe aufhalten.
d) Bedenken Sie, dass der Bediener oder
Benutzer bei Unfällen oder Gefährdungen
anderer Personen oder deren Eigentum die
Verantwortung trägt!
VORBEREITUNG
a) Tragen Sie beim Mähen stets festes
Schuhwerk und eine lange Hose. Den
Rasenmäher nicht barfuß oder mit offenen
Sandalen benutzen.
b) Inspizieren Sie die Gegend, in der die
Ausrüstung eingesetzt werden soll,
gründlich und entfernen Sie alle Objekte,
die durch die Maschine aufgeschleudert
werden könnten.
c) Vor der Benutzung immer durch
Augenschein prüfen, ob Messer,
Messerschrauben und Schneidbalken
abgenutzt oder beschädigt sind.
Abgenutzte Messer und Schrauben nur im
ganzen Satz auswechseln, um Unwuchten
zu vermeiden.Tauschen Sie beschädigte
und unleserliche Etiketten aus.
d) Achten Sie darauf, dass bei Geräten mit
mehreren Klingen ein Klingensatz durch
den anderen in Rotation versetzt werden
kann.
BETRIEB
a) Nur beiTageslicht oder gutem künstlichen
Licht mähen.
b) Nach Möglichkeit nicht in nassem Gras
arbeiten.
c) Auf schrägen Flächen stets auf sicherenTritt
achten.
d) Gehen Sie; rennen Sie niemals mit dem
Gerät;
e) Mähen Sie bei Rotormaschinen mit Rädern
Abhänge niemals auf hinaus oder hinab,
sondern immer seitlich am Hang entlang;
f) Beim Richtungswechsel an Abhängen
äußerst vorsichtig sein.
g) Keine besonders steilen Abhänge mähen.
h) Beim Rückwärtsgehen oder Ziehen des
Rasenmähers äußerst vorsichtig sein.
i) Die Messer müssen stehen, wenn der
Rasenmäher für denTransport gekippt
werden muss, wenn nicht mit Gras
bepflanzte Flächen überquert werden

20
Schnurloser rasenmäher D
und beimTransport vom und zu dem zu
mähenden Bereich.
j) Den Rasenmäher auf keinen Fall mit
defekten Schutzvorrichtungen oder
Schutzblechen, oder ohne ordnungsgemäß
montierte Sicherheitseinrichtungen
wie z. B. Prallbleche und/oder
Grasfangvorrichtung betreiben.
k) Den Motor wie in den Anweisungen
beschrieben starten und dabei darauf
achten, dass die Füße ausreichend weit von
den Messern entfernt sind.
l) Den Rasenmäher beim Starten des Motors
nicht kippen, es sei denn, es ist für das
Anlaufen erforderlich. In diesem Fall nur
so weit wie nötig und nur auf der Bediener
abgewandten Seite kippen.
m) Hände und Füße nicht in die Nähe
oder unter rotierendeTeile bringen. Bei
Rotormäher die Austragsöffnung unbedingt
freihalten.
n) Sie dürfen die Klingen nicht berühren,
bevor die Sperrvorrichtung entfernt
worden ist und die Klingen vollständig zum
Stillstand gekommen sind;
o) Starten Sie den Rasenmäher nicht, wenn
Sie vor der Auslassöffnung stehen.
p) Transportieren Sie den Rasenmäher nicht,
wenn die Stromquelle eingeschaltet ist.
q) Stoppen Sie den Rasenmäher
und entfernen Sie die
Deaktivierungsvorrichtung. Stellen Sie
sicher, dass die beweglichenTeile zum
vollständigen Stillstand gekommen sind.
– Sie die Maschine unbeaufsichtigt lassen,
– Sie ein Hindernis wegräumen,
– Sie die Maschine überprüfen, säubern oder
an der Maschine arbeiten,
– nach der Kollision mit einem Fremdkörper.
Den Rasenmäher auf Beschädigungen
untersuchen und wenn notwendig instand
setzen lassen
falls der Rasenmäher plötzlich
ungewöhnlich stark zu vibrieren beginnt
(sofort prüfen)
– Auf Schädenhininspizieren.
– BeschädigteTeile austauschen oder
reparieren.
– LoseTeile überprüfen und festziehen.
WARTUNG UND AUFBEWAHRUNG
a) Den Festsitz aller Schrauben, Muttern und
Bolzen sicherstellen, um zu gewährleisten,
dass sich der Rasenmäher in einem
betriebssicheren Zustand befindet;
b) Den Grasfangkorb regelmäßig auf
Abnutzung überprüfen;
c) Abgenutzte oder beschädigteTeile
sicherheitshalber auswechseln; Nur echte
Ersatz- und Zubehörteile benutzen.
d) Achten Sie bei der Einstellung des Gerätes
darauf, dass Ihre Finger nicht zwischen dem
beweglichen Messer und feststehenden
Teilen eingeklemmt werden.
e) Lassen Sie den Rasenmäher stets
auskühlen, bevor Sie ihn einlagern.
f) Beim Warten der Messer denken Sie daran,
dass sich die Klingen noch immer bewegen
lassen, auch wenn die Stromquelle schon
ausgeschaltet ist.
SICHERHEITSHINWEISE
FÜR LADEGERÄTE
WARNUNG: Lesen Sie alle
Sicherheitshinweise und
Anweisungen Eine Missachtung der
nachstehenden Hinweise kann einen
Stromschlag, Feuer und/oder Verletzungen
nach sich ziehen.
Heben Sie alle Warnhinweise und
Anweisungen für spätere Nutzung auf.
Dieses Gerät kann von Kindern ab 8
Jahren und Personen mit verringerten
physischen, sensorischen oder mentalen
Fähigkeiten bzw. Mangel an Erfahrung
oder Kenntnis verwendet werden,
wenn sie von einer Person beaufsichtigt
oderbezüglich des Gebrauchs des Gerätes
in einer sicheren Umgebung unterwiesen
werden und die damit verbundenen
Gefahren verstehen. Kinder sollten mit
dem Gerät nicht spielen und Reinigungs-
und Wartungsarbeiten nur unter Aufsicht
durchführen.
