BladeRunner®X2 EN
9
1. SWITCH WITH SAFETY KEY
2. STABILIZER BRACKET
3. BLADE STORAGE
4. MITER GAUGE
5. TABLE INSERT
6. GUARD KNOB
7. GUARD
8. VACUUM PORT
9. GUARD ARM
10. GUARD ARM CLAMP KNOB
11. RIP FENCE
12. FENCE SLOT
13. MITER SLOT
14. BLADE RELEASE
15. VACUUM ADAPTER (See Fig. K)
16. BOLT (See Fig. A1)
17. GUARD ARM ASSEMBLY KNOB (See Fig. A1)
18. BLADE (See Fig. B2)
19. BLADE HOLDER (See Fig. O)

BladeRunner®X2 EN
10
TECHNICAL DATA
Voltage 120V~60Hz
Amps 5.5A
No load speed 3000/min
Cutting capacity
Wood 1-1/2"
PVC pipe 1-1/4"
Aluminum 3/8"
Steel 1/8"
Ceramic 3/8"
Stroke Length 3/4"
Blade shank T shank
Blade length 4" or less
Table size 15-3/4"x17"
Protection class /ll
Weight 14.74 lbs
ACCESSORIES
Miter Gauge 1
Rip Fence 1
Blades:
Wood Cutting Blade 1
Aluminum Cutting Blade 1
Steel Cutting Blade 1
Ceramic Tile Cutting Blade 1
Scrolling Blade 1
Vacuum Adapter 1
Blade Grip 1
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
