Wouxun KG-824B User manual

ank you for purchasing the Wouxun KG-824B portable business radio.
Your feedback makes our products better. Please share your thoughts.
[e-mail]
www.buytwowayradios.com

2
Contents
Safety Information������������������������������������������������������������������������������������5
FCC Licensing Information...........................................................................8
Getting Started�����������������������������������������������������������������������������������������9
Feature Summary............................................................................................9
What’s Included ...........................................................................................10
Front Panel Guide ........................................................................................11
Right / Left Side Guide ...............................................................................12
Dust and Water Protection...........................................................................13
Installing and Removing the Battery ............................................................14
Charging the Battery ....................................................................................15
Antenna Information....................................................................................16
Installing the Belt Clip .................................................................................17
Operation����������������������������������������������������������������������������������������������� 18
Introducing the KG-824B ............................................................................18

3
Power On/O and Adjusting Volume ..........................................................18
Your First Transmit.......................................................................................19
Channels and Privacy Codes.........................................................................20
Channel Scan................................................................................................21
Programmable Features ................................................................................22
Monitor Key Functions ................................................................................27
Programmable Key Functions .....................................................................28
Wireclone Function ....................................................................................29
Troubleshooting ������������������������������������������������������������������������������������� 30
Technical Information ���������������������������������������������������������������������������� 32
Specications ................................................................................................32
Standard CTCSS and DCS Tones ...............................................................33
Default Frequencies ......................................................................................35
Optional Accessories������������������������������������������������������������������������������� 36

4
Limited Warranty ����������������������������������������������������������������������������������� 37

5
Safety InformationSafety InformationSafety InformationSafety Information
e KG-824B is an electrical apparatus, as well as a generator of RF (Radio Frequency)
energy, and you should exercise all safety precautions as are appropriate for this type of
device.
Please read the suggestions and warnings below before using the transceiver.
⚠ Keep the transceiver and accessories out of the reach of children.
⚠ Do not disassemble the transceiver.
⚠ Only use the supplied battery pack and charger or genuine Wouxun branded
replacements purchased from an authorized dealer. Using improper batteries and
charging accessories can damage the transceiver.
⚠ e supplied antenna is tuned for the frequencies supported by this transceiver.
Using an aftermarket antenna can damage the transceiver.
⚠ Do not leave the transceiver exposed to direct sunlight or in overheated areas for an
extended period of time.
⚠ Keep the transceiver away from dusty or humid areas.

6
Safety Information
⚠ e transceiver should be cleaned with mild detergents and a soft brush or cloth.
Avoid cleaning with aggressive chemicals.
⚠ NEVER transmit without a properly connected antenna.
⚠ If an abnormal odor or smoke is detected from the transceiver, power it o immedi-
ately, then remove the battery pack. Contact your dealer for further assistance.
⚠ Only the carry accessories supplied with this radio (such as the belt clip) should be
used. Use of other accessories may exceed RF exposure guidelines.
Notice
▪ ese tips are important for safe operation of your KG-824B
radio and its accessories. If the transceiver does not function
normally, please get in touch with your dealer immediately.
▪ If you use components or accessories not produced by the
Wouxun Company, Wouxun will not guarantee the safety and
usability of the transceiver.

7
Safety InformationSafety Information
Caution
Please read this manual before using the radio, as it includes important instructions for
the safe handling, use and operation of your radio.
FCC Compliance
is device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions:
(1) is device may not cause harmful interference, and
(2) is device must accept any interference received, including interference that may
cause undesired operation.
WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR
RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC
RULES AND US FEDERAL LAW.

8
Safety Information
Radio Operation and EME Exposure
Use only an antenna designed for use with this radio and its operating frequencies. Un-
authorized modications or attachments may damage the radio and violate FCC rules.
DO NOT hold the antenna while the radio is in use.
DO NOT attempt to use the radio with a damaged antenna.
FCC Licensing Information
e Wouxun KG-824B is FCC Part 90 type accepted for use on the business band. e
KG-824B operates on UHF and VHF business frequencies according to the Federal
Communications Commission (FCC) Rules in the United States. As such, a business
radio license is required to transmit on these frequencies. To obtain an FCC license for
the your business, go to the FCC’s web site and complete the online application. For
assistance with the FCC licensing process, visit https://www.buytwowayradios.com/
services/radio-licensing.html.

9
Getting StartedGetting StartedGetting StartedGetting Started
Feature Summary
▪ Up to 128 Custom Channels
▪ Up to 5 Watts Output Power
▪ 16 Pre-Programmed Channels (for
out-of-the-box compatibility)
▪ 50 CTCSS Tones / 105 DCS Codes
▪ Dual Band UHF/VHF
▪ Superheterodyne Receiver
▪ IP55 Waterproof
▪ High/Low Power Selectable
▪ Repeater Capable
▪ Channel Scan
▪ Priority Scan
▪ Monitor Function
▪ VOX
▪ Narrowband Compliant
▪ English Voice Guide
▪ Low Voltage Prompt
▪ Transmit Overtime Prompt
▪ Built-in Flashlight
▪ Congurable Side Key
SOS Function
▪ Busy Channel Lockout
▪ Cloning Capable
▪ PC Programmable

10
Getting Started
What’s Included
Carefully unpack the contents of the box and be sure that you have the items in the list
below. If any items are missing or damaged, please contact your dealer.

11
Getting StartedGetting Started
Front Panel Guide
Channel Knob
On/Off/Volume Knob
TX LED (Red)
Antenna
RX LED (Green)
Flashlight
Microphone
Speaker

12
Getting Started
Right / Left Side Guide
Battery Latch
Monitor Key
Short Press: FLASHLIGHT
Long Press: MONITOR
PF1 (Scan)
Note: Default is shown for PF1.
This button can be assigned different
functions in the programming software.
Mic/Earphone Jacks
Battery Latch
Transmit/PTT Key

13
Getting StartedGetting Started
Dust and Water Protection
e KG-824B is water resistant to IP55 standards. It is dust resistant and rated to
withstand mild ingress of solid objects. It can withstand direct jets of water projected
by a nozzle (6.3 mm) against the enclosure for a limited period. is radio is dust and
water resistant only while the battery is properly installed and locked in place with
no gaps and all ports are completely sealed with their port covers� Use of a headset or
other accessory will negate the dust and water resistant features of this radio� Do not
attempt to operate this radio if it has been submerged in water.
▪ e radio charger is NOT dust or waterproof.
▪ Charge the radio only under dry conditions.
▪ DO NOT charge the radio when it is wet.
▪ DO NOT expose the radio and charger to wet environments when charging.

14
Getting Started
Installing and Removing the Battery
e lithium-ion battery pack included with the radio is not fully charged out of the box.
It is recommended to charge it before using the radio for the rst time.
Installing the Battery
To install the Lithium-ion battery pack:
1. Be sure the radio is o.
2. Slide the battery pack down the back of the radio until the three tabs on the bottom
of the battery slide into the slots at the bottom of the radio.
3. Push forward on the top of the battery until it is securely locked in place on both
sides.
Removing the Battery
To remove the battery pack:

15
Getting StartedGetting Started
1. With your thumb and forenger, slide down the latches on each side of the battery
near the top of the battery pack simultaneously
2. While holding down the latches, pull the battery pack away from the radio.
Charging the Battery
e KG-824B includes an intelligent desktop charger. It can charge the battery pack
with or without the radio attached.
1. Insert the AC plug into an available 100~240v outlet. e LED light on the charger
base will ash red for 2-3 seconds. is indicates the charger is in standby mode.
2. Insert the battery or radio with the battery attached into the charger. e LED light
on the charger will turn red to indicate the battery is charging.
3. When the LED light on the charger turns green, charging is complete.

16
Getting Started
Antenna Information
e KG-824B includes an antenna with an SMA female connector that is tuned for
the frequency range of your radio. Aftermarket antennas may be used, provided they are
tuned for this frequency range.
Warning: To avoid injury, DO NOT attempt to operate your radio if the antenna is
damaged or defective.
DO NOT attempt to operate your radio without an antenna connected to the radio.
Note
▪ When a completely drained battery is rst inserted into the charger, the charger
will switch to trickle charge mode and the LED will ash red continuously.
▪ After 10-20 minutes the charger will switch to normal charging mode and the
light will turn solid red. e LED will turn green when charging is complete.

17
Getting StartedGetting Started
Transmitting without an antenna or a correctly tuned antenna directly and properly
connected to the radio may damage the radio and void the warranty.
Installing the Belt Clip
e belt clip attaches to the back of the battery pack on the radio. To install the belt
clip, simply slide it down onto the back of the battery until it snaps in place. To remove
the belt clip, depress the lock release on the back of the belt clip, and while holding it
down, slide the belt clip up and away from the battery.

18
OperationOperation
Introducing the KG-824B
e KG-824B is a dual band UHF and VHF radio designed for businesses and organi-
zations that need a simple analog business radio without complicated preconguration.
Right out of the box, this radio is congured to allow you to transmit on 16 pre-loaded
UHF channels for instant compatibility with many other popular UHF business radios.
is radio can also be customized for your licensed frequency(ies) on the UHF and
VHF business bands. Your dealer can custom program your KG-824B with your busi-
ness frequencies and assign them to a total of 128 channels.
Read this chapter to learn the basics of using your new KG-824B radio, such as select-
ing a channel, transmitting and receiving, and scanning.
Power On/O and Adjusting Volume
Rotate the volume knob clockwise to power on the radio. To power o the radio, rotate
the volume knob counter-clockwise until a click is felt.
To adjust the volume, use the volume knob when the radio is powered on. Turning the
knob clockwise increases the volume, counter-clockwise decreases it.

19
OperationOperation
Your First Transmit
Selecting a Channel
When you power on your KG-824B for the rst time, the radio will emit a few short
tones and will be ready to transmit and receive on the current channel.Turn the Chan-
nel Knob to navigate through the available channels for your licensed frequency(ies).
Be sure the channel you choose is the same channel and frequency that everyone else in
your group is using.
Transmitting and Receiving
With a channel selected, the radio is actively “listening” for an incoming signal on that
channel. When a signal is detected, the transmission will be heard through the radio’s
speaker.
To transmit, rst be sure the channel is clear and then hold the radio a few inches from
your mouth. Hold down the PTT button on the side while talking and release the PTT
when nished.

20
Operation
For best performance and clarity of transmission, position the radio upright with the
front of the radio facing you, hold it several inches away from your mouth and speak
directly into the microphone during transmission.
Channels and Privacy Codes
Channels
e KG-824B is pre-congured with 16 default UHF business frequencies out of the
box, but can be custom programmed by your dealer with your own business frequen-
cies and save them to a maximum of 128 custom channels.is radio can transmit and
receive on business frequencies in the UHF and VHF band.
Privacy Codes
e KG-824B supports 50 CTCSS tones and 105 DCS codes, for a total of 155 pri-
vacy tones and codes. To successfully communicate between your stations or members
of your group, all the connecting radios must be using the same channel and privacy
(CTCSS or DCS) code.
