Wouxun KG-S86B User manual

ank you for purchasing the Wouxun KG-S86B portable business radio.
Your feedback makes our products better. Please share your thoughts.
[e-mail]
www.buytwowayradios.com

2
Contents
Safety Information������������������������������������������������������������������������������������8
FCC Licensing Information.........................................................................11
Getting Started��������������������������������������������������������������������������������������� 12
Feature Summary..........................................................................................12
What’s Included ...........................................................................................13
Front Panel Guide ........................................................................................14
Right / Left Side Guide ...............................................................................15
Display Guide...............................................................................................16
Dust and Water Protection...........................................................................17
Installing and Removing the Battery ............................................................18
Charging the Battery ....................................................................................18
Antenna Information....................................................................................20
Installing the Belt Clip .................................................................................21
Operation����������������������������������������������������������������������������������������������� 22

3
Introducing the KG-S86B............................................................................22
Power On/O and Adjusting Volume ..........................................................22
Your First Transmit.......................................................................................23
Channels and Privacy Codes.........................................................................24
Channel Scan................................................................................................25
Priority Channel Scan ..................................................................................26
Compander...................................................................................................27
Programmable Key Functions .....................................................................27
Menu Functions ������������������������������������������������������������������������������������� 32
[01: SQUELCH] Squelch............................................................................32
[02: TX-POWER] Output Power................................................................32
[03: CH-DISP] Channel Display Mode......................................................32
[04: BACK-LT] Active Backlight ................................................................33
[05: BAT-SAVE] Battery Saver....................................................................33

4
[06: RX-CTCSS] Receive CTCSS Tone .....................................................34
[07: RX-DCS] Receive DCS Code..............................................................34
[08: TX-CTCSS] Transmit CTCSS Tone ...................................................34
[09: TX-DCS] Transmit DCS Code............................................................35
[10: SCANMODE] Scan Mode ..................................................................35
[11: SCAN-QT] Tone Scanning Compatibility Check ...............................36
[12: SCAN-ADD] Scan Add / Delete.........................................................36
[13: PRI-SCAN] Priority Scan ....................................................................36
[14: PRI-CH] Priority Channel ...................................................................37
[15: TONESCAN] CTCSS/DCS Scanning ...............................................37
[16: TONESAVE] CTCSS/DCS Tone Save Options.................................38
[17: VOX] Voice Activated Transmit............................................................38
[18: VOX-DLY ] VOX Delay .......................................................................39
[19: TOT] Transmit Overtime Timer ..........................................................39

5
[20: TOA] Transmit Overtime Alarm ..........................................................39
[21: ROGER] Roger Beep ...........................................................................40
[22: BEEP] Button Beeps.............................................................................40
[23: VOICE] Voice Guide............................................................................41
[24: BUSYLOCK] Busy Channel Lockout..................................................41
[25: COMPAND] Voice Compander ..........................................................41
[26: CALL-ID] Caller ID............................................................................42
[27: CH-NAME] Channel Name................................................................42
[28: CH-ADD] Add Memory Channel.......................................................43
[29: CH-DEL] Delete Memory Channel....................................................43
[30: SP-MUTE] Speaker Mute ...................................................................43
[31: SIDETONE] Sidetone Setting ............................................................44
[32: ALERT] Tone Alert..............................................................................44
[33: ID-EDIT] Edit Radio ID.....................................................................45

6
[34: ID-DLY] ID-Delay..............................................................................45
[35: PTT-ID] Radio ID Setting ..................................................................46
[36: RING] Ring Time ................................................................................46
[37: STARTUP] Power On Message ...........................................................47
[38: ST-MSG] Custom Power On Message ................................................47
[39: TIMER] Stopwatch Timer ...................................................................48
[40: RPT-TONE] Squelch Tone..................................................................48
[41: AUTOLOCK] Auto Lock ...................................................................48
[42: LOCKMODE] Lock Mode.................................................................49
[43: PF1-SHRT] Side Key PF1 Short Press Assignment............................49
[44: PF1-LONG] Side Key PF1 Long Press Assignment ...........................50
[45: PF2-SHRT] Side Key PF2 Short Press Assignment............................50
[46: PF2-LONG] Side Key PF2 Long Press Assignment ...........................50
[47: TOP-SHRT] Top Key Short Press Assignment...................................51

7
[48: TOP-LONG] Top Key Long Press Assignment ..................................51
[49: VOLTAGE] Voltage .............................................................................52
[50: RESET] Factory Reset..........................................................................52
Advanced Operation ������������������������������������������������������������������������������� 53
DTMF Encoding .........................................................................................53
Setting Non-Standard CTCSS or DCS.......................................................56
Troubleshooting ������������������������������������������������������������������������������������� 59
Technical Information ���������������������������������������������������������������������������� 61
Specications ................................................................................................61
Standard CTCSS and DCS Tones ...............................................................63
Default Frequencies ......................................................................................65
Available Frequencies....................................................................................66
Optional Accessories������������������������������������������������������������������������������� 68
Limited Warranty ����������������������������������������������������������������������������������� 69

8
Safety InformationSafety Information
e KG-S86B is an electrical apparatus, as well as a generator of RF (Radio Frequency)
energy, and you should exercise all safety precautions as are appropriate for this type of
device.
Please read the suggestions and warnings below before using the transceiver.
⚠ Keep the transceiver and accessories out of the reach of children.
⚠ Do not disassemble the transceiver.
⚠ Only use the supplied battery pack and charger or genuine Wouxun branded
replacements purchased from an authorized dealer. Using improper batteries and
charging accessories can damage the transceiver.
⚠ e supplied antenna is tuned for the frequencies supported by this transceiver.
Using an aftermarket antenna can damage the transceiver.
⚠ Do not leave the transceiver exposed to direct sunlight or in overheated areas for an
extended period of time.
⚠ Keep the transceiver away from dusty or humid areas.

9
Safety InformationSafety Information
⚠ e transceiver should be cleaned with mild detergents and a soft brush or cloth.
Avoid cleaning with aggressive chemicals.
⚠ NEVER transmit without a properly connected antenna.
⚠ If an abnormal odor or smoke is detected from the transceiver, power it o immedi-
ately, then remove the battery pack. Contact your dealer for further assistance.
⚠ Only the carry accessories supplied with this radio (such as the belt clip) should be
used. Use of other accessories may exceed RF exposure guidelines.
Notice
▪ ese tips are important for safe operation of your KG-S86B
radio and its accessories. If the transceiver does not function
normally, please get in touch with your dealer immediately.
▪ If you use components or accessories not produced by the
Wouxun Company, Wouxun will not guarantee the safety and
usability of the transceiver.

10
Safety Information
Caution
Please read this manual before using the radio, as it includes important instructions for
the safe handling, use and operation of your radio.
FCC Compliance
is device complies with Part 15 of the FCC Rules. Operation is subject to the follow-
ing two conditions:
(1) is device may not cause harmful interference, and
(2) is device must accept any interference received, including interference that may
cause undesired operation.
WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR
RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC
RULES AND US FEDERAL LAW.

11
Safety InformationSafety Information
Radio Operation and EME Exposure
Use only an antenna designed for use with this radio and its operating frequencies. Un-
authorized modications or attachments may damage the radio and violate FCC rules.
DO NOT hold the antenna while the radio is in use.
DO NOT attempt to use the radio with a damaged antenna.
FCC Licensing Information
e Wouxun KG-S86B is FCC Part 90 type accepted for use on the business band.
e KG-S86B operates on UHF business frequencies according to the Federal Com-
munications Commission (FCC) Rules in the United States. As such, a business radio
license is required to transmit on these frequencies. To obtain an FCC license for the
your business, go to the FCC’s web site and complete the online application. For assis-
tance with the FCC licensing process, visit https://www.buytwowayradios.com/services/
radio-licensing.html.

12
Getting StartedGetting Started
Feature Summary
▪ Up to 400 Custom Channels
▪ 99 Business Frequencies
▪ Up to 2 Watts Output Power
▪ 16 Pre-Programmed Channels (for
out-of-the-box compatibility)
▪ 50 CTCSS Tones / 105 DCS Codes
▪ LCD Display
▪ Display Channel Name, Number, or
Frequency
▪ Caller ID Display
▪ IP65 Waterproof
▪ USB-C Charging Port
▪ High/Low Power Selectable
▪ Standard and Non-Std CTCSS/DCS
▪ Channel Scan
▪ Priority Channel Scanning
▪ Superheterodyne Receiver
▪ Companding
▪ Monitor Function
▪ DTMF Support
▪ VOX
Narrowband Compliant
▪ English Voice Guide
▪ Built-in Flashlight
▪ 2 Congurable Side Keys
▪ Congurable Top Key
▪ Alarm and SOS Functions
▪ PC Programmable

13
Getting StartedGetting Started
What’s Included
Carefully unpack the contents of the box and be sure that you have the items in the list
below. If any items are missing or damaged, please contact your dealer.
Transceiver High gain antenna Lithium-ion batterypack Intelligent charger
Beltclip Handstrap User’s manual

14
Getting Started
Front Panel Guide
Channel Knob
Volume Knob
RX/TX LED (Green/Red)
Microphone
Exit/Cancel
Antenna
Flashlight
Display
Speaker
Up Key
Menu/Enter
Down Key
4 Key Keypad
Top Key

15
Getting StartedGetting Started
Right / Left Side Guide
Earphone Jack
Transmit/PTT Key
PF2
Short Press: FLASHLIGHT
Long Press: MONITOR
PF1
Short Press: BACKLIGHT
Long Press: SCAN
Note: Defaults are shown for PF1 / PF2.
These buttons can be assigned different
functions in the menu.
USB Charging Port

16
Getting Started
Display Guide
Narrowband Indicator
Battery Save
VOX
CTCSS/DCS
DT/QT
Current Channel
TX Power
Keypad Lockout
Battery Voltage
Channel Number
Signal Strength Indicator

17
Getting StartedGetting Started
Dust and Water Protection
e KG-S86B is waterproof to IP65 standards. It is dust resistant and rated to with-
stand any ingress of solid objects. It can withstand direct jets of water projected by
a nozzle (6.3 mm) against the enclosure for a limited period. is radio is dust and
waterproof only while the battery is properly installed and locked in place with no
gaps and all ports are completely sealed with their port covers� Use of a headset or
other accessory will negate the dust and waterproong features of this radio� Do not
attempt to operate this radio if it has been submerged in water.
▪ e radio charger is NOT dust or waterproof.
▪ Charge the radio only under dry conditions.
▪ DO NOT charge the radio when it is wet.
▪ DO NOT expose the radio and charger to wet environments when charging.

18
Getting Started
Installing and Removing the Battery
e lithium-ion battery pack included with the radio is not fully charged out of the box.
It is recommended to charge it before using the radio for the rst time.
Installing the Battery
Slide the battery pack up along the back of the radio until it stops. en push the bot-
tom of the battery towards the radio until it clicks into place.
Removing the Battery
Pull the release latch toward the three battery contacts. While holding the release latch
in place, press down on the top end of the battery pack and slide the battery pack down
and o the radio.
Charging the Battery
e KG-S86B features two charging options for the battery pack. It can be charged
using the included desktop charger or the built-in USB-C port on the side of the radio.

19
Getting StartedGetting Started
Charging with the Desktop Charger
e KG-S86B includes an intelligent desktop charger. It can charge the battery pack
with or without the radio attached.
1. Insert the AC plug into an available 100~240v outlet. e LED light on the charger
base will ash red for 2-3 seconds. is indicates the charger is in standby mode.
2. Insert the battery or radio with the battery attached into the charger. e LED light
on the charger will turn red to indicate the battery is charging.
3. When the LED light on the charger turns green, charging is complete.
Note
▪ When a completely drained battery is rst inserted into the charger, the charger
will switch to trickle charge mode and the LED will ash red continuously.
▪ After 10-20 minutes the charger will switch to normal charging mode and the
light will turn solid red. e LED will turn green when charging is complete.

20
Getting Started
Charging with the USB-C Port
e KG-S86B can charge the battery from the USB-C charging port on the side of
the radio using an optional USB-C cable (not included). e battery pack can be fully
charged with a USB cable connected to a USB to AC adapter plugged into an AC
outlet or a to a USB port in a vehicle, power bank or computer.
When the radio is connected to a power source through the USB-C charging port with
a battery attached, the LED at the bottom of the port will light up red to indicate the
battery is charging. e LED will turn green when charging is complete.
In addition to the charging option, the radio can be powered directly via the USB-C
port while charging the battery pack.
Antenna Information
e KG-S86B includes an antenna with an SMA female connector that is tuned for
the frequency range of your radio. Aftermarket antennas may be used, provided they are
tuned for this frequency range.
