WTE MReX-PCB User manual

Christchurch, NZ
MReX-PCB User Guide V1.02
MReX-PCB
Mini Transmitter
User Guide
© WTE Limited, 2021 – Christchurch New Zealand Page 1 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Table of Contents
Introduction..........................................................................................................................................3
Electrical...............................................................................................................................................4
PCB Pinout...........................................................................................................................................5
Programming the M eX Module.........................................................................................................6
Inputs....................................................................................................................................................6
LEDs Outputs.......................................................................................................................................7
LED/Piezo esistor Configuration..................................................................................................8
Piezo connection............................................................................................................................10
Physical Dimensions..........................................................................................................................12
Disclaimer...........................................................................................................................................13
© WTE Limited, 2021 – Christchurch New Zealand Page 2 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Introduction
This user guide describes configuration and use of the WTE M eX-PCB. This PCB allows simple
integration into a system and incorporates the M eX-460 Module. For command use and detailed
operation, consult the M eX-460 User Manual. Not shown is the antenna connection. This may be
an SMA connector fitted to the red M eX-460 module (with antenna) or a 16cm wire (one quarter
the wavelength of the frequency of operation).
© WTE Limited, 2021 – Christchurch New Zealand Page 3 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Electrical
The following schematic shows how the M eX-460 module is routed to connection pads.
© WTE Limited, 2021 – Christchurch New Zealand Page 4 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
PCB Pinout
Pin # Description
1GND
2GND
3Contact Input 3 (Connection to input must
be volt free). Pull to GND to operate.
4Contact Input 2 (Connection to input must
be volt free). Pull to GND to operate.
5Contact Input 1 (Connection to input must
be volt free). Pull to GND to operate.
6Piezo. T is pin is electrically tied to pin 7
7Green LED – Cat ode (open drain output)
8Green LED + Anode (not connected if LED
is powered externally)
9Piezo. T is pin is electrically tied to pin 8
10 Contact Input 4 (Connection to input must
be volt free). Pull to GND to operate.
11 Contact Input 5 (Connection to input must
be volt free). Pull to GND to operate.
12 Programming VCC
13 GND
14 Serial TTL IN
15 Serial TTL OUT
16 Red LED – Cat ode (open drain output)
17 Red LED + Anode (not connected if LED is
powered externally)
© WTE Limited, 2021 – Christchurch New Zealand Page 5 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Programming the MReX Module
The Programming Header contains a 5V (VCC) pin which can be used to power the M eX Module
for loading configuration or uploading new firmware.
Do NOT apply vol age o his pin if ba eries are fi ed.
Note: Serial connection is 3.3V TTL. The M eX-P OG USB to serial adaptor can be provided
for serial interfacing.
Inputs
efer to the M eX Module manual (Input Hardware Connection) for example of connections
© WTE Limited, 2021 – Christchurch New Zealand Page 6 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
LEDs utputs
Connecting the LEDs using Open Drain (bypassing PCB resistors)
The LED outputs are open drain/collectors suitable for sinking a maximum of 50mA. The example
is being used to drive an LED from an external supply. Should the output be presented to potential
ESD conditions (such as any terminal screw or external connection), ESD devices should be fitted.
If the output is to be used to control a small relay, it is essential that a flyback diode is fitted across
the coil of the relay.
Only the Cathode connections of the LEDS are shown here. They are connected to an open drain
output. As shown in the simplified schematic above, it is the users responsibility to select a resistor
that suits the application, and then connect to a suitable power source that has a common GND.
© WTE Limited, 2021 – Christchurch New Zealand Page 7 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
LED/Piezo Resistor Configuration
The following resistor configuration information describes how to modify the M eX-PCB if LEDs
are to be used powered directly from the fitted AAA battery pack, or how to fit a piezo sounder (and
required components).
1 is used to limit current through the green LED/Piezo. Typical LED value resistor value from
220 to 470 . When a piezo sounder is fitted 1 = 47 .
2 is used by the piezo to improve audio response (1K typically). The resistor fitted should ideally
be selected to produced the greatest audio output.
3 is used to limit current through the ed LED. Typical LED value resistor value from 220 to
470 .
When the command * X_ENABLE=0 is sent to the M eX (disabling the receiver), the green LED
operation changes so that instead of flashing once a second, this output is modulated, so that when
connected to a piezo sounder, a beep will be heard prior to input activated transmissions.
© WTE Limited, 2021 – Christchurch New Zealand Page 8 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
© WTE Limited, 2021 – Christchurch New Zealand Page 9 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Piezo connection
The following images guide the connection of the piezo and required resistors.
© WTE Limited, 2021 – Christchurch New Zealand Page 10 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
© WTE Limited, 2021 – Christchurch New Zealand Page 11 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Physical Dimensions
Overall board dimensions
© WTE Limited, 2021 – Christchurch New Zealand Page 12 of 13

Christchurch, NZ
MReX-PCB User Guide V1.02
Disclaimer
THE ESPONSIBILITY LIES COMPLETELY ON THE USE TO ENSU E THAT THIS
DEVICE IS TESTED, TH OUGH METHODS THAT A E APP OP IATE, TO CONFI M
THAT ALL SYSTEM COMPONENTS (THAT THIS DEVICE AND PC SOFTWA E MAY BE
PA T OF) A E WO KING CO ECTLY.
This document has been prepared in good faith and produced to assist in the use of this product,
however WTE Limited reserves the right to modify, add or remove features without notice.
Please note that the maximum permitted transmit power level may vary from country to
country. It is the users responsibility to ensure local regulations are adhered to.
When product is supplied, it is the user who is responsible or payment o any customs ees/taxes
that are imposed on importation.
No User-Serviceable Components. There are no user-serviceable components within the product.
RoHS and WEEE Compliance
MReX is ully compliant with the European Commission’s RoHS (Restriction o Certain Hazardous
Substances in Electrical and Electronic Equipment) and WEEE (Waste Electrical and Electronic
Equipment) environmental directives.
Restriction o hazardous substances (RoHS)
The RoHS Directive prohibits the sale in the European Union o electronic equipment containing
these hazardous substances: lead, cadmium, mercury, hexavalent chromium, polybrominated
biphenyls (PBBs), and polybrominated diphenyl ethers (PBDEs).
End-o -li e recycling programme (WEEE)
The WEEE Directive concerns the recovery, reuse, and recycling o electronic and electrical
equipment. Under the Directive, used equipment must be marked, collected separately, and disposed
o properly.
© WTE Limited, 2021 – Christchurch New Zealand Page 13 of 13
