USER MANUAL
iGS130 GPS CYCLING COMPUTER
www.igpsport.com
WUHAN QIWU TECHNOLOGY CO., LTD

CONTENTS
1. STANDARD PACKAGE INCLUDES.................................................................... 1
2. BUTTONS................................................................................................................. 1
3. STATUS ICONS....................................................................................................... 2
4. INSTALLATION OF BIKE MOUNT....................................................................3
5. ACQUIRING SATELLITE SIGNALS AND TIME SETTING...........................3
6. SMART BACKLIGHT..............................................................................................4
7. BATTERY................................................................................................................... 4
8. SETTING METRIC AND IMPERIAL UNITS (SETTING MODE E1)....................5
9.SETTING TIME ZONE (SETTING MODE E2)......................................................... 6
10.UPLOAD FILES TO COMPUTER AND WEBSITE....................................... 8
11.FACTORY RESET................................................................................................. 9
12.SPECIFICATIONS..............................................................................................10
13.ABBREVIATION................................................................................................ 11
14.Use help.............................................................................................................. 11
15.CONTACT US.....................................................................................................12
16.Declaration........................................................................................................ 12

iGS130 USER MANUAL
- 1 -
1. STANDARD PACKAGE INCLUDES
iGS130 x1
Micro USB Cable x1
User Manual x1
Standard Bike Mount x1
Bike Mount Pad x1
O-Ring Band x2
2. BUTTONS
Power on
Select for 1 seconds
Power off
Hold for more than 2 seconds
Record/Pause
Select to Record/Pause

iGS130 USER MANUAL
- 2 -
Data save
Data will be saved automatically after shutdown
Forced shutdown
or Reset
Hold for more than 8 seconds
Switch display
Select to switch data pages
Enter Setting Mode
Hold for more than 2 seconds to enter the setting
mode.
Exit Setting Mode
Hold for more than 2 seconds to exit the setting
mode.
3. STATUS ICONS
Full battery
Mid-capacity battery
Low battery
Out of battery and will shut off automatically soon
Recording
Pause
GPS not fixed

iGS130 USER MANUAL
- 3 -
GPS fixed
4. INSTALLATION OF BIKE MOUNT
1. Standard bike mount installation
2. Out front bike mount installation (Optional accessory)
5. ACQUIRING SATELLITE SIGNALS AND TIME SETTING
Please make sure iGS130 is outdoor and under a clear view of the sky.
Usually it may take 5 to 120 seconds to locate satellite signals.
Remain stationary when acquiring satellite signals.

iGS130 USER MANUAL
- 4 -
The time and date will be calibrated automatically after locate satellite
signals.
Note: Please set the time zone correctly.
6. SMART BACKLIGHT
iGS130 will automatically calculate the sunrise and sunset time based on the
GPS position.
Backlight turns on before sunset and turns off after sunrise automatically.
When backlight is off, select any button to turn on backlight for 15 seconds.
7. BATTERY
Warning: Keep iGS130 far away from the fire.
Battery type
Rechargeable, built-in lithium-ion battery
Battery life
About 22 hours, typical usage
Operating temperature range
From -10 ºto 50 ºC (14 ºto 122 ºF)
Charging temperature range
From 0 ºto 45 ºC (32 ºto 113 ºF)
Input
DC5V, 500mA
Charging time
2 Hours
Note：
1) Please use DC 5V power adapter for charging.
2) As the temperature drops, the battery life will decrease.
3) iGS130 supports charging during use.

iGS130 USER MANUAL
- 5 -
4) Do not overstretch the USB plug for keeping waterproof and dustproof.
8. SETTING METRIC AND IMPERIAL UNITS (SETTING MODE E1)
Default unit: metric (kilometer)
Steps:
1) Hold more than 2 seconds to enter the setting mode.
2) Select to enter E1 mode when E1 is flashing.
3) Select to switch metric (kilometer) and imperial (mile) unit.

iGS130 USER MANUAL
- 6 -
4) Select to save and exit.
Note:
The setting will be automatically saved if no operation in 10 seconds.
9. SETTING TIME ZONE (SETTING MODE E2)
Default time zone: UTC/GMT+0:00.
Time zone range: -12:00～13:00
Steps:
1) Hold more than 2 seconds to enter the setting mode.

iGS130 USER MANUAL
- 7 -
2) Select to scroll setting mode from E1 to E2.
3) Select to enter E2 mode when E2 is flashing.

iGS130 USER MANUAL
- 8 -
4) Select to change digits of hour and minute, select to
change value.
5) Hold more than 2 seconds to exit the setting mode and save
setting.
Note:
The setting will be automatically saved if no operation in 10 seconds.
10. UPLOAD FILES TO COMPUTER AND WEBSITE
1) Power off iGS130.
