X-tra Seal Smart Sensor ELITE User manual

SMART SENSOR ELITE
PROGRAMMING/DIAGNOSTIC TOOL
QUICK START GUIDE
BUTTON
FUNCTIONS
SELECT VEHICLE
From the MAIN MENU, select / , then using the directional arrows,
select the MAKE / , MODEL / and YEAR / of the vehicle.
ESC Key
Press to return to the previous menu.
ENTER Key
Press to validate or process function.
HOME Key
Takes you back to MAIN MENU.
POWER ON / OFF
Turns the tool on and off.
ARROW Keys
Use these keys to navigate
through displayed options.
SCAN SENSOR
After selecting the VEHICLE to be serviced, select / .
Select / , if only one sensor is going to be scanned or / ,
if all sensors are going to be scanned.
Position either side of the tool against the sidewall of the tire near the sensor.
Press to SCAN.
SCAN
SINGLE
MULTIPLE
VEHICLE
PROGRAM NEW SENSOR
After selecting the VEHICLE to be serviced, select / .
Choose how you want to program the Smart Sensor – IN CRADLE or WIRELESS.
PROGRAM
IF IN CRADLE
Place the Smart Sensor
in the cradle of the tool.
IF WIRELESS
Hold the Smart Sensor
against the side of the tool .
Note: to wirelessly program a
sensor, that is already installed in a
tire, first deflate the tire to less than
26 psi, otherwise the sensor can not
be programmed.
Press to PROGRAM.
IF SCAN TO COPY
Press to scan the original sensor.
Tool displays ID.
Press to SCAN NEXT or /
to COPY.
Select IN CRADLE or WIRELESS.
Place the Smart Sensor in the CRADLE
of the tool or hold it against the side
of the tool for WIRELESS.
Press to COPY.
Note: to wirelessly program a
sensor, that is already installed in a
tire, first deflate the tire to less than
26 psi, otherwise the sensor can
not be programmed.
COPY SENSOR
After selecting the VEHICLE to be serviced, select . Select , if the original sensor
can still be scanned or to manually enter the original sensor ID.
COPY
SCAN TO COPY
MANUALLY COPY
IF MANUALLY COPY
Use the to highlight characters
and press to select and COPY.
For help identifying the sensor ID, from the
MAIN MENU, select
/ , then the MAKE /,
MODEL / and YEAR / .
Select IN CRADLE or WIRELESS.
Place the Smart Sensor in the CRADLE
of the tool or hold it against the side
of the tool for WIRELESS.
Press to COPY.
INFORMATION
/ /
OEM
PROGRAM NEW SENSOR
After selecting the VEHICLE to be serviced, select / .
Choose how you want to program the Smart Sensor – IN CRADLE or WIRELESS.
RELEARN
After selecting the VEHICLE to be serviced, select / .
Select / to view the RELEARN PROCEDURE(S).
or select then the appropriate type of relearn
(there may only be one), and follow the instructions to
PERFORM the RELEARN.
PERFORM
RELEARN
PROCEDURE
RELEARN
OBD II OPTIONS
After selecting the VEHICLE to be serviced, select .
Note: If OBD II OPTIONS does not appear, then OBD II support
is not currently available for that vehicle.
Connect OBD II Cable or Bluetooth Module to vehicle and press .
Note: The Bluetooth OBD II Module must be paired
to the ELITE tool prior to first use.
To pair the Bluetooth OBD II Module,
select INFORMATION, then SETTINGS,
then OBD II PAIRING, and following
the onscreen instrucitons.
Note: If Bluetooth OBD II Modules beeps, then re-connect OBD II
by going back to and press .
Select to upload IDs to vehicle, to adjust the placard pressures or to read
IDs store in vehicle.
Press and follow the onscreen instructions.
OBD II OPTIONS
INFORMATION
/
SETTINGS
/ / OBD II PAIRING
OBD II OPTIONS
ADJUST PLACARD
UPLOAD IDs
READ IDs
OBD II OPTIONS
PERFORM
RELEARN
Backed by Industry Leading
TPMS Network
24/7 Support •
(877) 659-8767
(TPMS)
SETTINGS
Select / .
Using the to scrool through settings.
Press to select/change a setting.
SETTINGS
Smart Sensor ELITE User Guide
available at www.tpmsnetwork.com
Mobile App for Apple and Android Devices
Visit the App Store and search
TPMS Part Finder
UPDATING TOOL
From the MAIN MENU, select / .
Select TOOL or BLUETOOTH OBD II to update.
UPDATE
USB PORT
Visit www.tpmsnetwork.com, Create
an Account and/or Log In, and download
Smart Sensor Updater software.
Load Smart Sensor Updater on to
your Windows computer.
Connect tool or Bluetooth OBD II module
to computer via included USB Cable
and click .
WIFI
Connect to selected network.
Press to begin the UPDATE.
NOTE: BLUETOOTH OBD II must
be plugged in to vehicle to
update wirelessly.
