X10 WS467 Installation manual

Black BlueBlack
(To Live
or lamp)
Black
(
To lamp,
or Live)
TheWS467WallDimmerModuleisdesignedtocontrolincandescentonlylights with a rating ofbetween40Wand
500W.Lightsratedbelow40Wmightflickeroroperateerratically.TheWS467replacesaswitchthatcontrolsand
indoororoutdoor ceiling light.Apush-buttonisprovided forlocalon/offcontrol.
WARNING:WallDimmerModules mustnot beused tocontrolappliances, orlow voltagelamps, or
fluorescentlamps.
InstallingtheWall Dimmer Module:
• Disconnectthepoweratthecircuitbreakerpanel.
• Removewallplate andunscrewtheexisting switchfromitsbox.
• RemovethetwowiresfromyouroldswitchandconnectthemtothetwowiresontheWS467usingthewirenuts
provided.Makesurenobarewhiskersofwireareprotruding,useinsulatingtapetocoverwirenuts if necessary.
• Screwtheswitchintoitswallbox(don’t replace the wall plate yet).
Settingupandoperating theWall Dimmer Module:
• Setthe House Code dial tothe same letter (A thruP) that you seton your X10 controller(s).
• SettheUnit Code dial to anunused code (1 - 16) whichcan be controlled from anyX10 controller.
• Setthepoweron-off slide switch (under the push button) to the ON (center) position. TurnthisswitchOFF(left)
whenchangingalightbulb.
• Replacethewallplate.
• Turnthe powerbackon at the circuit breaker panel.
• Pressthepushbuttontoturnthemoduleonand off.
• Youcan turn themoduleonandoffanddimandbrightenit remotely fromX10Controllers.
LIMITED1-YEARWARRANTYX10.com,adivisionofX10WirelessTechnology,Inc.(X10)warrantsX10
productstobefreefromdefectivematerialandworkmanshipforaperiodofone(1)yearfromtheoriginaldateof
purchaseatretail.X10agreestorepairorreplace,atit’ssolediscretion,adefectiveX10productifreturnedtoX10
withinthewarrantyperiodandwithproofofpurchase.
Ifserviceisrequiredunderthiswarranty:
Call1-800-442-5065,visitwww.x10.com,ore-mail[email protected].
X10.com, a division of X10 Wireless Technology, Inc. http://www.x10.com/support WS467-11/02
Wall Dimmer Set Up and Operating Instructions Model WS467
WS467
