INSTALLATION INSTRUCTIONS
490 SERIES
MICRO LINK™ INFRARED RECEIVERS
These small IR receivers have been designed primarily for mounting in panels, doors, cabinets, etc. for
control of A/V equipment behind closed doors. They may be mounted in walls, ceilings, wall speakers, etc.
- anywhere an inconspicuous appearance is desired. Their high sensitivity allows placement behind
speaker grilles and still receive IR commands up to 20 feet away. If longer range is necessary, a 1/2-inch
hole must be drilled in the grille to allow unobstructed entry of the IR signal. The model versions covered
by these instructions are as follows:
490-00 Standard version, with brass bezel and 7 ft. three-conductor ribbon cable.
490W-00 Same as the 490-00 except with white bezel.
490DW-00 J-box version of the 490W-00. Includes a Decora™ insert for single gang mounting.
DECORA IS A REGISTERED TRADEMARK OF LEVITON.
490-30 Quick connect version of the 490-00. 7-foot cable with 3.5 mm stereo mini plug for
direct plug-in to Xantech Connecting Blocks, such as the CB12, CB20, 789-44,
791-44, etc.
490W-30 Same as 490-30 except with white bezel.
Each version in the 490 series has the same features and specifications as follows:
FEATURES
• Very small size, only 2 inches deep.
• Works in normal 3-wire mode or 2-wire phantom power mode.
• Phantom mode requires 792-10 power module.
• System testing talk-back LED.
• Includes 3-terminal block for easy extension of 7 ft. ribbon cable.
• 20 units may be powered by one 781RG power supply.
• RF Grid included for EMI interference reduction.
• SUN490 Sunscreen filters available separately. Order these to help with sunlight and stray IR problems.
They fit easily under the bezel.
SPECIFICATIONS
• Infrared modulation frequency bandwidth: 30 - 100 kHz.
• Reception range: > up to 30 feet, depending on local conditions.
• Nominal reception angle: 55 degrees off axis for 50% range reduction.
• Cable requirements: 3-conductor. Use 24 gauge up to 200', 22 gauge up to 600', 20 gauge up to 2000',
18 gauge up to 5000' -- unshielded OK).
• Maximum transmission length: One mile using 18 gauge wire.
• Maximum current output: 100 mA.
• Dimensions: 1/2" diameter x 2" deep.
• Power requirements: 12 volts DC @ 10 mA.


2490 Series
INSTALLATION
Model 490-00 Series. These units are intended to be wired to the input terminals of Xantech Connecting
Blocks or other devices, using the supplied 3-terminal block in the remote room location. A 3-conductor
cable (refer to specifications above), is run to the main room. Connections are then made to a Xantech
connecting block, power supply and emitters as shown in the following illustration of a typical basic system:
While it is possible to make wired connections without the connecting block, it is not recommended. The
connecting block reduces installation time, helps to eliminate errors, allows easy troubleshooting and
permits easy system upgrades later, if needed.
Input connections must be made as illustrated. To extend the emitter wires to a more distant location, you
may splice in 2-conductor wire, in the wire gauges mentioned under "Specifications", as needed.
Model 490-30 Series. These units, equipped with a 7-foot cable and 3.5 mm stereo mini plug, are plugged
directly into the "IR RCVR" or "AUX" jack on Xantech Connecting Blocks, such as the CB12, CB20, 789-
44, 791-44, etc. The 490-30 should be used in installations where the connecting block is within reach of
the 7-foot cable -- such as when installing the 490-30 on a cabinet where the controlled equipment is behind
closed doors.
A typical system, with a 490-30, 781RG Power Supply and 282M Emitters plugged into a 791-44 Amplified
Connecting Block, is shown in the following diagram:
Mounting: Drill a 1/2" hole in any flat surface, such as a cabinet panel. Pass the lead and the body of the
490 through the hole and secure from the rear with the nut (supplied).
Affix the Mini-Emitters, such as the 282, 284, 283 and 286 series, to the IR sensor windows of the controlled
equipment in accord with the instructions that come with them.
490-00 Series
IR Receivers
Red (or white)
Stripe
To 120 V AC
(Unswitched)
781RG
Power Supply
789-44
Connecting Block
283M Blink-IR™
283M Blink-IR™
REMOTE ROOM MAIN ROOM
Hand Held
Remote
3-Terminal Block (supplied)
0.469"
1 7/8"
3-Conductor
Inter-room Cable
(unshielded OK)
OUT
+12V
GND
7' Ribbon Cable
Satellite Receiver
AV Receiver
VCR
283M Blink-IR™
Mouse Emitter
12VDC
+12 VDC
GND
STATUS
IR IN
EMITTERS
IR
RCVR
789-44
CONNECTING BLOCK
®
490-30 Series
IR Receivers
To 120 V AC
(Unswitched)
781RG
Power Supply
791-44
Amplified
Connecting Block
283M
Blink-IR™
283M Blink-IR™
0.469"
1 7/8"
7 Foot 3-Conductor
Cable with Quick
Connect Mini Plug
Hand Held
Remote
Controlled Equipment
(mounted behind
closed cabinet doors)
490-30
(mounted on or
near cabinet in an
inconspicuous
location).
283M Blink-IR™
283M Blink-IR™
VCR
AV Receiver
Cassette DecK
283M Blink-IR™
Mouse Emitter
Satellite Receiver
CD Changer
+12 VDC
GND
EMITTERS
12 VDC
HIGH
IR
OUT
STATUS
IR IN
IR
RCVR
791- 44 AMPLIFIED CONNECTING BLOCK
®


IR Receivers & Modems
3
3-13-00
490 Series
490-30 Cable Connections
490-30's may also be used where the 7-foot lead is not long enough. In this case, simply cut off the mini
plug, strip the leads and connect them to a 3-terminal block in the same way as you would for the 490-00.
For correct color identification of wires, refer to the following tables and diagrams:
Phantom Power Connections
Some existing installations may have only 2 wires (such as coax) going to a remote room. The 490, when
used with a 792-10 Power Module, may be connected for 2-wire phantom power operation as follows:
Additional 490's may be wired in parallel at the 3-terminal block, up to a maximum of three. More than this
may cause unreliable results.
CAUTION: With any of these systems, be sure the 781 power supply is plugged into an un-switched AC
outlet. This maintains the 490 system in "stand-by" operation so that power-on commands can be sent to
the controlled equipment.
3-Terminal
Block
OUT
+12V
GND
WHITE
3-Conductor
Wire to
Controlled
Equipment
490-30
7-Foot 3-Conductor Cable
with Mini Plug removed
See Tables for
Wire Color
Table 1 - Black Insulators (older units)
CABLE LEADS CIRCUIT ITEM
RED
WHITE
BLACK
GROUND
OUTPUT
+ 12 V
PLUG
RING
TIP
SLEEVE
CABLE LEADS CIRCUIT ITEM
BLACK
WHITE
RED
GROUND
OUTPUT
+ 12 V
PLUG
RING
TIP
SLEEVE
Table 2 - Red Insulators (newer units)
Tip
Ring
Sleeve Insulators
Mini Plug
(3-Conductor)
792-10
POWER MODULE
+12V
OUT
IN
GND
+12V
OUT
XANTECH CORPORATION
SYLMAR CA • MADE IN USA
1 (ON)
0 (OFF)
1 2 3 4 5 6 7 8 910
ON
12345678910
792-10
Power Module
(In Phantom
High Current mode)
490-00 Series
IR Receivers
Red (or white)
Stripe
3-Terminal Block (supplied)
2-Conductor
Inter-room Cable
(usually coax)
OUT
+12V
GND
7' Ribbon Cable
To 282M or
283M Emitters
on controlled
equipment
Use wire jumper
between screws as
shown
REMOTE ROOM
SIGNAL
GROUND
EMITTERS
790
CONNECTING BLOCK XANTECH CORPORATION SYLMAR CA • MADE IN U.S.A.
IN / OUT
IN / OUT
781RG
Power Supply
790-00
Connecting Block
MAIN ROOM
