Xantrex XTR 850 Watt User manual

XTR 850 Watt Series
Programmable DC
Power Supply
(firmware version 1.09 and below)
Operating Manual
XTR 6-110
XTR 8-100
XTR 12-70
XTR 20-42
XTR 33-25
XTR 40-21
XTR 60-14
XTR 80-10.5
XTR 100-8.5
XTR 150-5.6
XTR 300-2.8
XTR 600-1.4
www.programmablepower.com

XTR 850 Watt Series
Programmable DC Power
Supply (firmware v1.09 and below)
Operating Manual

M370046-01 ii
About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with
products from small mobile units to utility-scale systems for wind, solar, batteries, fuel cells,
microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex
products include inverters, battery chargers, programmable power supplies, and variable speed drives
that convert, supply, control, clean, and distribute electrical power.
Trademarks
XTR 850 Watt Series Programmable DC Power Supply is a trademark of Xantrex International.
Xantrex is a registered trademark of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of their respective owners
and are used herein for identification purposes only.
Notice of Copyright
XTR 850 Watt Series Programmable DC Power Supply Operating Manual© March 2008 Xantrex
International. All rights reserved.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC.
(“XANTREX”)
(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF
ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER
DOCUMENTATION.
(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR
EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL,
WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH
INFORMATION WILL BE ENTIRELY AT THE USER’S RISK; AND
(C) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN
ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE
TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED XANTREX
CONTENT IS CONTAINED WITH THE ENGLISH LANGUAGE VERSION WHICH IS POSTED
AT WWW.PROGRAMMABLEPOWER.COM.
Date and Revision
March 2008 Revision D
Part Number
M370046-01

M370046-01 iii
Product Numbers (FGAs)
(firmware v1.09 and below)
Part Numbers for Rack Mount Kits
Contact Information
XTR6-110 XTR60-14
XTR8-100 XTR80-10.5
XTR12-70 XTR100-8.5
XTR20-42 XTR150-5.6
XTR33-25 XTR300-2.8
XTR40-21 XTR600-1.4
Rack Mount Kit Part Number
Dual XTR 850 Watt RM-D-XTR1
Single XTR 850 Watt RM-S-XTR1
Rack mount rails for
XTR Series
RM-XTR
Telephone: [phone] (toll free North America)
1 858 450 0085(direct)
Fax: [phone]
Email: [e-mail]
[e-mail]
Web: www.programmablepower.com

M370046-01 v
About This Manual (firmware v1.09 and below)
Purpose
The Operating Manual provides installation and operating information for
the XTR 850 Watt Series Programmable DC Power Supply.
Scope
The Manual provides safety information, features and specifications,
installation procedures, functional test procedures, and operating procedures
for both local (front panel) operation and remote operation.
The Manual does not provide information on the GPIB and Ethernet
(ENET) interface options. See the XTR 850 Watt GPIB and Ethernet
Interface Option Operating Manual (Part number M370046-06).
Audience
The Manual is intended for the user who is familiar with electronic power
supplies, Constant Voltage and Constant Current operating modes, and the
control of output power. The user should be familiar with practicing safe
techniques while making supply or pin connections.
Conventions Used
The following conventions are used in this guide.
WARNING
Warnings identify conditions or practices that could result in personal injury or
loss of life.
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
Important: Important notes provide information that is important for you to
know. They are not as serious as Warnings or Cautions.

About This Manual (firmware v1.09 and below)
vi M370046-01
Related Information
For related information on this product, see also:
•XTR 850 Watt GPIB and Ethernet Interface Option Operating
Manual (Part number M370046-06) provides information on the
GPIB and Ethernet interface option.
•XTR 850 Watt Series Programmable DC Power Supply: Quick
Reference Guide (Part number M370046-04) is included with your
power supply and provides an introduction to using the front panel
interface.
•Rack Mount Kit Options Installation Instructions (Part number
M370046-05) provides information on rack mounting a single or
dual XTR 850 Watt.
More information about Xantrex Technology Inc. as well as its products
and services is available at www.programmablepower.com.
Acronyms
Font Conventions
This Manual uses the following typographical conventions:
Acronym Definition
APG Analog Programming
AUX Auxiliary
ENET Ethernet
FGA Finished Goods Assembly
ISOL Isolated Analog Programming
OTP Over Temperature Protection
OVP Over Voltage Protection
PSU Power Supply Unit
TVS Transient Voltage Suppressor
UVP Under Voltage Protection
7 segment For display and readback information on the
output voltage and current displays.
Command body text Represents SCPI commands.

M370046-01 vii
Important Safety Instructions
Power Supply Safety Markings
WARNING: High energy and high voltage
Exercise caution when using a power supply. High energy levels can be stored at
the output voltage terminals on a power supply in normal operation. In addition,
potentially lethal voltages exist in the power circuit and on the output and sense
connectors of a power supply with a rated output greater than 40 V. F i l t e r
capacitors store potentially dangerous energy for some time after power is
removed.
WARNING: Fire hazard
Operate the power supply in an environment free of flammable gases or fumes.
To ensure that the power supply's safety features are not compromised, use the
power supply as specified in this Manual and do not substitute parts or make any
unauthorized modifications. If service is necessary, please return the power
supply to the Authorized Service Center. See “Warranty” on page WA – 1 .
WARNING: Limitations on use
The XTR 850 Watt Series Programmable DC Power Supply is not intended for
use in connection with life support systems or other medical equipment or
devices.
CAUTION: For use as a battery charger
When you are using a power supply for battery charging applications, it is
essential to provide an appropriately sized fuse or circuit breaker in series
between the power supply output and the battery.
Installation of a protector (fuse or DC circuit breaker), rated for about 115% of
the maximum current rating of the power supply and designed specifically to
interrupt the DC voltage of the battery, will provide adequate current protection.
Where several power supplies are in parallel, it is best to fuse each power supply
rather than use one fuse at the battery.
Alternating Current On (Supply)
Earth (Ground) Terminal Off (Supply)
Protective Conductor
Terminal
Caution (Check the Manual
for additional information.)

Safety
viii M370046-01
Standard Warnings
1. Before installing and using the XTR 850 Watt Series Programmable
DC Power Supply, read all instructions and cautionary markings on
the XTR and all appropriate sections of this Manual.
2. The XTR is for indoor use only. Do not expose the XTR to moisture.
To reduce risk of fire hazard, do not cover or obstruct the ventilation
openings. Be sure to install the XTR in a compartment which allows
air to reach the ventilation inlets on the front and rear of the unit to
prevent overheating. For more information, see “Ventilation” on
page 2–4.
3. To avoid a risk of fire and electric shock, make sure that the existing
wiring is in good condition and the wire is not undersized. Do not
operate the XTR with damaged or substandard wiring.
4. Do not operate the XTR if it has received a sharp blow, been dropped,
or otherwise damaged in any way. If the XTR is damaged, see
“Warranty and Product Information” on page WA –1 .
5. Do not disassemble the XTR. It contains no user-serviceable parts.
See the “Warranty and Product Information” on page WA – 1 for
instructions on obtaining service. Attempting to service the XTR
yourself may result in a risk of electrical shock or fire. Internal
capacitors remain charged after all power is disconnected.
6. To reduce the risk of electrical shock, disconnect AC power from the
XTR before attempting any maintenance or cleaning or working on
any circuits connected to the XTR. Turning off controls will not
reduce this risk.
WARNING: Keep these instructions
This chapter contains important safety and operating instructions. Read and keep
this Operating Manual for future reference.
