xenium CTX600 User manual

Discover Your Phone
Philips continuously strives to improve its
products.Therefore, Philips reserves the rights to
revise this user guide or withdraw it at any time
without prior notice. Philips provides this user
guide “as is” and does not accept, except as
required by applicable law, liability for any error,
omission or discrepancy between this user guide
and the product described. The device is meant
to be connected to GSM/GPRS networks.
How to ...
Alphanumeric
keypad
Microphone
262K colour
TFT LCD
Hang up and
on/off key
Left softkey
Right softkey
Pick up key
Back of phone:
Camera lens
Headset,
charger, and
data cable
Micro SD
card slot
Side volume
keys
Navigation
keys
Switch the
phone On/Off
Long press and release ) .
Enter your
PIN code
Enter your PIN code using the
keypad and press
, or L to
confirm.
Lock/unlock
the keypad
Long press
* .
Make a call Enter the phone number using
the keypad and press
( .
End a call Press
) .
Answer a call When the phone rings, press
( .

1
Activate/
deactivate
handsfree
mode
In idle mode, enter the phone
number using the keypad or
select a contact in the
phonebook.
During a call, press
R to
activate the handsfree mode.
When there is an incoming
call, Press
L Options, then
select Accept with handsfree and
press
, .
Mute a call When the phone rings, press
R .
Reject a call When the phone rings, press
) .
Adjust
conversation
volume
Press volume side keys to adjust
the volume during a call.
Adjust ringer
volume
When the phone is in idle
mode, press
, > Settings >
Sounds > Ring volume to adjust
the ring volume of an incoming
call.
Access all
calls list
Press ( in idle mode.
Access
Shortcuts
Press
+ in idle mode.
Access
Contacts
Press
- in idle mode.
Access Create
message
Press
< in idle mode.
Access My files Press
> or L in idle mode.
Access Main
Menu
Press
, in idle mode.
Access
Calendar
Press
R in idle mode.
Go to
previous
menu
Press
R Back when browsing
menu or in editing mode.
Quickly
return to idle
when
browsing
menus
Short press
) .

2
Softkeys
The left and right soft keys ( L and R ) are located
at the top of keypad area. Pressing the soft keys
allows you to select the option displayed on the
screen directly above them, including options
during a call. The functions of the soft keys change
according to the current context.
Operations of the headset
The following operations are applicable to headsets
with only one key.
When you enter a phone number in idle mode,
short press the headset key to dial the number. To
stop dialling, long press the headset key.
During a call, short press the headset key to record
or stop recording; long press to hang up the phone.
When there is an incoming call, press the headset
key to answer the call; long press to reject the call.
Main Menu
You can access the different features of your Xenium
X600 phone from the main menu. The following table
summarises the structure of the main menu, what the
icons represent and the page number on which you
can obtain more information regarding the menu
functions.
Press
, in idle mode to access the main menu and
press
+ , - , < or > to navigate through the icons and lists,
or press
0 - 9 keys, and * or # keys to access
Entertainment Browser Media player
page 24 page 25 page 28
Camera Messages My files
page 31 page 36 page 49
Business Contacts Profiles
page 53 page 59 page 62
Connectivity Calls Settings
page 65 page 67 page 71

3
the options and functions directly. You can also press
L to set the browse style as List or Grid.
When navigating through a list, the scrolling bar on
the right of the screen will indicate your current
position in the list. Press
, Select to access the
corresponding options of the selected item in the list.
Press
R Back to return to the previous menu.
Menu without SIM
If you do not have a SIM card, those menu items
whose functions that cannot work without a SIM
will be greyed out and not accessible.

4
Table of contents
1. Getting Started ........................................... 7
Inserting the SIM card ..................................... 7
Switching on the phone .................................. 9
Charging the battery ....................................... 9
Insert a micro SD Card ................................ 10
Setting hotkeys ............................................... 10
2. Calling ............................................................. 12
Switch on the phone ..................................... 12
Switch off the phone ..................................... 12
Make a call ....................................................... 12
Answer and end a call ................................... 12
Options during a call ..................................... 13
Mute or unmute a call ................................... 13
Adjust speaker/earpiece volume ................ 13
Call recording ................................................. 13
Make an international call ............................ 13
Make an emergency call ................................ 14
Make a second call (Network dependent) ..... 14
Make a Conference Call (Network
dependent) ....................................................... 14
Switch calls (Network dependent) ............ 15
Call Handsfree ................................................ 15
IP Dial ............................................................... 15
Answer a call ................................................... 15
Reject a call ..................................................... 15
Answer a second call (Network
dependent) ...................................................... 15
Contact Picture .............................................. 15
3. Text and number entry ...................... 17
Input method .................................................. 17
Entering texts and numbers ........................ 17
Entering symbols ............................................ 18
Shift case .......................................................... 18
Delete ............................................................... 18
T9® English input .......................................... 18
Basic text input ............................................... 19
Pinyin Input ...................................................... 20
Stroke input .................................................... 21
4. Entertainment ........................................... 24
Games ............................................................... 24
JAVA ................................................................. 24
5. Browser ........................................................ 25
WAP ................................................................. 25
Push Inbox ....................................................... 27

5
6. Media Player ............................................... 28
Music player .................................................... 29
7. Camera .......................................................... 31
Camera ............................................................. 28
Video recorder ............................................... 33
8. Messages ....................................................... 36
Create message .............................................. 36
Inbox ................................................................. 38
Sent ................................................................... 40
Outbox ............................................................. 41
Drafts ................................................................ 42
My favourites .................................................. 42
Spam box ......................................................... 43
SIM archive ...................................................... 43
Templates ........................................................ 44
E-mail ................................................................ 44
Advanced ......................................................... 45
Voice mail ........................................................ 46
Settings ............................................................. 47
9. My Files .......................................................... 49
Pictures ............................................................. 49
Sounds .............................................................. 50
Videos ............................................................... 51
Others .............................................................. 52
Memory status ................................................ 52
10. Business ...................................................... 53
Calendar ........................................................... 53
Alarm ................................................................ 54
Calculator ........................................................ 54
Voice recorder ............................................... 55
Secretary OTG ............................................... 55
Stopwatch ........................................................ 56
Countdown ..................................................... 56
Unit converter ................................................ 56
Firewall ............................................................. 56
Chinese festival (if available)......................... 57
Task.................................................................... 57
Lunar calendar (if available) .......................... 58
11. Contacts .................................................... 59
New contacts ................................................. 59
View contacts ................................................. 60
View group ...................................................... 60
Special numbers ............................................. 61
Advanced ......................................................... 61
12. Profiles ........................................................ 62
13. Connectivity ............................................ 65
Bluetooth ......................................................... 65
USB function ................................................... 66
14. Calls .............................................................. 67
View calls ......................................................... 67

6
Call options ..................................................... 67
Clear history ................................................... 70
15. Settings ........................................................ 71
General ............................................................. 71
Display .............................................................. 73
Sounds .............................................................. 73
Connectivity .................................................... 74
Icons & Symbols ............................................ 76
Precautions ....................................................... 78
Troubleshooting ............................................ 83
Philips Authentic Accessories .............. 85
Trademark Declaration ............................ 86
Specific Absorption Rate Information .... 87
Limited Warranty ........................................ 88
Declaration of conformity ...................... 91

Getting Started 7
1. Getting Started
Please read the safety instructions in the
"Precautions" section before use.
Before you start using your phone, you must insert
a valid SIM card supplied by your GSM operator or
retailer. The SIM card contains your subscription
information, your mobile telephone number, and a
small quantity of memory in which you can store
phone numbers and messages (for more
information, see “Contacts” on page 59).
You can also insert a memory card. This provides
you with expanded memory capability, which
allows you to store additional music, photo, and
video files separate from the phone's built-in
memory.
Inserting the SIM card
Remove the back cover
To insert the SIM card, you must first remove the
back cover. Press on the back cover with your
thumbs and slide the cover upwards. Then use your
free hand to lift up the back cover as shown below.
Remove the battery
Put your finger at the top of the battery and lift the
battery up from its slot.
You may lose all your personal settings if you
remove the battery when the phone is switched
on.

8 Getting Started
Insert the SIM card
Make sure that the clipped corner of the SIM card
is facing the correct direction (clipped corner at
upper left) and the metallic contacts are facing
downwards. Slide the SIM card into the card slot
until it stops. When you remove your SIM card the
first time, make sure that you smoothen the edges,
otherwise you may have difficulty sliding in the
card.
Replace the battery
With the metallic contacts facing downwards, press
the battery down into its slot until it locks into
place.
Replace the back cover
Replace the back cover by sliding it down into its
slots, until it stops.
When inserting the battery, be careful not to
damage the metallic connectors of the SIM
card slot.
Switching on the phone
To switch on the phone, long press and release the )
key. Enter the PIN code if required (the 4 to 8 digit
secret code of your SIM card). It is preconfigured and
provided to you by your network operator or retailer.

Getting Started 9
For more information on PIN code, see “Security” on
page 72.
If you enter an incorrect PIN code 3 times in
succession, your SIM card will be blocked. To
unblock it, you must obtain the PUK code from
your network operator.
Charging the battery
Your phone is powered by a rechargeable battery.
The new battery is partially charged. A sound alert will
be emitted to warn you when the battery level
becomes low.
We recommend that you do not remove the
battery when the phone is switched on as you
may lose all your personal settings as a result. If
you do remove it, the date and time settings are
only memorized for a short while. As such, you
need to reset the information after you have
installed the battery back again.
Once the battery and battery cover are installed,
you can charge the phone. Plug in the connector as
shown below. Then plug the other end into an AC
power socket.
The battery symbol indicates the state of charge.
During charging, the charge indicators will scroll; it
takes around 4 hours to fully charge the battery.
When all the scroll bars are steady, the battery is
fully charged. You can then disconnect the charger.
Depending on the network and condition of use,
talk time and stand-by time can go up to 16 hours*
and 1440 hours (2 months)* respectively.
*Depending on the network conditions, user
settings, method of use, etc the actual results
may differ.
Keeping the charger plugged to the mobile
phone when the battery is fully charged will not
damage the battery. The only way to turn off

10 Getting Started
the charger is to unplug it, so it is advisable to
use an easily accessible power socket.
If you do not intend to use your phone for
several days, we recommend that you remove
the battery.
You can use the phone while it is charging. If
the battery is completely flat, the battery icon
will only reappear after a few minutes of
charging.
Insert a micro SD card
1. Lift up the micro SD card cover on the left-
hand side of your phone as shown below. If
held properly, the card’s gold contacts will be
facing upwards.
2. Gently slip the card into the micro SD card slot
and press it down until the card locks into
place.
To remove the micro SD card, push down the
card into its slot and release it. The card will
spring out of the slot.
The maximum capacity of micro-SD that X600
can support is up to 2GB.
Setting hotkeys
You can configure the numeric keys 2 - 9 , + , - , < ,
> , L and R to access your favorite features. Once
they have been set, you can simply long press the
numeric key to access the corresponding features.
Majority of the hotkeys have been preset and
configured. To check the hotkey settings, go to Settings
> General > Shortcuts > keypad. To change the hotkey
setting, press the numeric key you wish to change
and Press
, Change, then select a feature to be

Getting Started 11
associated with the numeric key from the following
list:
Numeric keys 0 , 1 , # and * have been
preconfigured as the default keys to enter “+”,
access voice mailbox, activate Meeting profile
and unlock the keypad respectively, and cannot
be modified.
• Alarm • Bluetooth
• Calculator • Calendar
• View calls • Camera
• Contacts • Create message
• Firewall • Flight mode
•Games •Homepage
•Inbox •Languages
• Menu • Messages
• Meeting • Music
• My files • Profiles
•Ringtones •Shortcuts
• Tasks • Unit converter
•Flashdial •Voicerecorder
• Secretary OTG • Empty

12 Calling
2. Calling
This chapter describes the features and options
related to making and receiving calls.
Switch on the phone
Long press ) to switch on the phone.
You may set a security code (PIN code) on your
phone to protect it from unauthorised use. When
you have set a security code, you will be prompted
to enter the corresponding security code when you
switched on the phone.
1. Enter the PIN code. If you have entered the
wrong number, press
R Clear to clear it.
2. Press
, . The phone will validate the PIN code
and commence network registration.
3. Once a network name is displayed on the
screen, you are ready to make or answer a call.
If there is no network name on the screen, you
need to re-register.
If you enter a wrong PIN code 3 times in
succession, your SIM card will be blocked. To
unblock it, you must request the PUK code from
your operator. If you enter a wrong PUK code
10 times in succession, your SIM card will be
permanently blocked and cannot be used
anymore. If this happens, please contact your
network operator.
Switch off the phone
At all times, you can long press ) to switch off the
phone.
Make a call
You can make a call only when the network
name appears on the screen.
1. Enter the phone number.
2. Press
( to dial the number or press L Options
to enter options menu, then select Dial.
Answer and end a call
When receiving a call, the number of the caller may
be displayed, depending on whether or not the
person has chosen to display his or her ID. If the
corresponding name is displayed instead of the
number.
Answer the call: press
( or open the phone if the
Active flip option is On (see “General” on page 71).
End the call: press
) or close the phone.

Calling 13
Options during a call
During a call, you can press , to activate/cancel
Handsfree or press
L Options to carry out the
following operations:
-PutthecallonHold
-Mute/Unmute the call
-Record phone conversation (which includes 3
sub-options:
Record both , Record the opposite
party
and Record own )
- Make a New call
- End the current call
Mute or unmute a call
During a call, press L Options and select Mute or
Unmute . If you select Mute , the microphone will be
deactivated.
When you switch from one call to another, muting
will be cancelled.
Adjust speaker/earpiece volume
During a call, call on hold or call waiting, you can
press + / - side key to increase or decrease the
volume (if you are not browsing the call options
menu).
When the volume has been set, the call volume will
take effect immediately and the settings will be
applied to your subsequent calls.
Call recording
During a call, press L Options and select Record to
access the 3 recording options; namely,
Record both
(default), Record the opposite party and Record own
(applicable to two-party calls or multi-party calls).
When you start recording, a recording icon will
appear on the screen. When you end the call, the
recording will stop and saved automatically in AMR
format under
My files > Sounds .
There is no limit to the length of the recording;
the recording will stop only when you press
R key
to stop the recording, when there is insufficient
memory, or when the call has ended.
Make an international call
1. Long press 0 until "+"appears on the screen.
2. Enter the country code.
3. Enter the area code (normally without the 0 in
front), followed by the phone number.
4. Press
( to call directly.

14 Calling
Make an emergency call
You can make an emergency call anytime,
irrespective of whether the mobile phone has been
registered on the network.
1. In idle mode, enter the emergency call number
(specific number in the caller's country)
2. Press
( .
Note that an emergency call will not be stored
in the call record.
3. Alternatively, if there is no SIM card, pressing
R SOS can also bring you to the emergency
call screen, displaying the call number. Then
press
( or the OK softkey to directly make an
emergency call and the dial animation will be
displayed.
Make a second call (Network
dependent)
You can make a second call by putting the current
call on hold:
1. During a call with Party A, you can enter
Party's B number using the keypad.
2. Press
( to dial Party B's number. Party A will
be put on hold automatically.
Make a Conference Call (Network
dependent)
Your phone supports multi-party call of up to five
members. The screen will display Conference call
during the multi-party call.
When there is a call waiting while you are already
on the phone, you can carry out the following
operations to establish the multi-party call:
1. Press
( to answer the second call. The first
call will be put on hold automatically.
2. Select Conference Call from the call menu. The
two calls will be combined and a conference
call is established.
During the multi-party call, you can answer a new
incoming call or add a new member to the call by
dialing the new member (the ongoing multi-party
call will be put on hold automatically). Once the call
is established, select Establish conference call from
the call menu to add the new member to the multi-
party call (you can add up to five members).
If you wish to separate one member from the call,
you can select Split conference call during the multi-
party call. To disconnect a member from the call,
select End call in conference.

Calling 15
Switch calls (Network dependent)
When you have one active call and one call on hold,
you can press
L Options , then select Swap to switch
between the 2 calls.
Call Handsfree
During a call, press L Options and select Handsfree .
When the headset is plugged into the phone,
you cannot activate handsfree mode.
IP Dial
You may select IP dial. When you select IP dial
option, the mobile phone will automatically add the
IP special service number preset by you in front of
the phone number and then make IP dial. You can
also long press
( to activate IP dial.
When you have entered several IP special
service numbers, you will be prompted to verify
them to avoid adding them repeatedly.
Answer a call
Press ( to answer a call.
Reject a call
Press ) to reject a call.
Answer a second call (Network
dependent)
If you have activated Call waiting , you will be alerted
when there is a second incoming call. You can:
1. Press
( to answer the second call. The
current call will be put on hold automatically.
2. Press
) to reject the second call and continue
with your current call.
3. When there is one active call and one call on
hold, you can press
, Swap or L Options to
carry out the following operations:
If you press the numeric keys, the notepad
editor will opened under call waiting mode.
Contact Picture
This feature allows you to link a contact in your
phonebook to a photo you have taken using the
• Conference call • Handsfree • Mute
• Record • End all calls • End calls
• View contacts • Menu

16 Calling
Camera function, or a picture you have
downloaded via WAP or data cable. During a call, if
the other party's name card is linked to a picture,
the incoming call background will display the
corresponding picture. This feature is referred to
as Contact picture.
Contact picture is only available on the phone
memory. The photo size should not be larger
than 128 x 160 pixels.

Text and number entry 17
3. Text and number entry
Input method
Your mobile phone supports several input
methods, which include:
*During text editing, you can press
* to switch
input mode; the status bar on the screen will
display your current input mode.
represents Simplified Chinese Pinyin input mode;
represents Simplified Chinese stroke input
mode; represents Traditional Chinese stroke
input mode; 『en』represents T9 English input
mode; ϒ≡ abcϒ≈ represents English alphabets input
mode; 『123』represents numeric input mode. In
addition, you can press
# to input punctuations.
The text editor remembers the last input method
you have used before you exit the editing screen.
When you access the editor again, it will
automatically select the last input method you have
used.
Entering texts and numbers
You can input text in the editor using: T9 English
input, English alphabets, Pinyin, Simplified Chinese
Stroke or Traditional Chinese Stroke. In addition,
there are two input methods for you to enter
numbers and punctuations. The icon displayed on
the screen shows the current input method. You
can press
* to switch from one mode to another.
Long press to activate or deactivate T9. Short press
• T9 Pinyin: Enter chinese characters with T9
Pinyin;
• T9 Stroke: Enter Chinese characters with
T9 wubi and stroke components;
• T9 Traditional Chinese stroke: Enter
Traditional Chinese characters with Wubi
or stroke components;
• T9 English (T9eng/T9Eng): Enter English
text using T9 English;
• Multi-Tap (abc/Abc/ABC): Press the keys
that are marked with the corresponding
letter you wish to enter. Press once to get
the first letter on the key, press twice
quickly to get the second letter and so on
until the letter you want is displayed on the
screen.
• 123: Enter numbers
This phone supports T9 Simplified Chinese
association input method as well.

18 Text and number entry
# to enter punctuations or long press it to select
input language.
Entering symbols
In any input mode, press # to open/close symbols
input screen. If the symbols occupy more than one
screen, press
+ / - to scroll up/down the pages. Press
, to confirm the symbol input.
Shift case
Press * to shift case in the English input editor.
Delete
When there are contents in the input row, press
R Clear to delete the rightmost character or
symbol. The candidate area will be updated
accordingly until the input row is cleared. Long
press
R Clear to clear the input row.
When the input row is empty, press
R Clear will
delete the character on the left of the cursor in the
text area. Long press
R Clear to clear the contents
in the text area.
T9®English input
What is it?
T9®predictive Text Input is an intelligent editing
mode for messages, which includes a
comprehensive dictionary. It allows you to quickly
enter text. You need to press only once on the key
corresponding to each letter needed to spell a
word: keystrokes input are analysed and the word
suggested by T9®is displayed at the pop-up
window. If there are more than 3 candidates, a
scroll bar is shown, press
+ or - to browse the list
and choose from those proposed by the T9® built-
in dictionary (see example below). After you have
input the word, press
, or L to confirm.
How to use it?
Alphabets and symbols represented by each key
are as follows:
0 to 9 To input letters.
+ or - To browse the last or next candidate
word.
L OK To confirm the letter or word.

Text and number entry 19
Example: How to enter the word "Home"
1. Press 4 6°6 3 , the screen displays the
first word on the list:
Good .
2. Press
- to browse and select Home .
3. Press
L OK to confirm Home .
Basic text input
If you wish to use basic text input mode, press *
to select "ABC" basic text input. This method
requires multiple key presses to reach the desired
character: the letter "h"is the second letter on the
4 key, so you must press 4 twice to enter "h".
Using this mode requires you to press a key as
many times as is equal to the order of the letter.
To enter the word «Home» in basic text input
mode, you should therefore key
4 , 4 ( G H I ) 6 ,
6 , 6 ( MN O), 6 (M NO ), 3 , 3 ( D E F ).
Letters, numbers and symbols are located on each
key as follows:
R Clear
Short press to clear a letter, long press
to clear all entries.
*
Shift case, select input mode. Long
press to turn on/off T9 feature.
#
Short press to activate/deactivate
punctuation mode, long press to select
input language.
Key Letters and numbers
1 Space 1 @ _ # = < > ( ) & £ $ ¥
2
a b c 2 à ä å æ ç
3
d e f 3 é è D F
4
g h i 4 G ì
5
j k l 5 L
6
m n o 6 ñ ò ö ø
7
p q r s 7 b P Q S
8
t u v 8 ü ù
9
w x y z 9 W X Y
0
Input space
*
Switch text input mode
#
Input symbol
