Xenotronix NTX7 Series User manual

B R A N D
Model NTX7 Series
Automatic Battery Charger
User’s Manual
Rev. 1.0
October 17, 2006
For Sales, Support and Service
phone: [phone]
fax: [phone]
website: www.xenotronix.com
email: [e-mail]
Xenotronix/TLI, Inc.
2541 Tracy Road
Toledo, Ohio 43619
Phone: [phone]
Fax: [phone]

Warranty
Seller warrants that its products ("Product(s)") will meet the specifications set forth in its catalog
from time to time, unless the Buyer is notified otherwise prior to delivery. Seller will, without
charge, repair or provide a replacement for any of the Products which prove to be defective in
materials or workmanship within one (1) year from the date of shipment ("Warranty Period").
If, within the Warranty Period, Buyer discovers a defect in materials or workmanship which
interferes with the operation of any Product, Buyer must promptly notify Seller, in writing, of such
defect. Seller's sole obligation to Buyer under this Warranty is to repair and correct any defect in
material or workmanship, or provide a replacement Product to Buyer. Seller's decision with
respect to the applicability of this Warranty to any defect shall be final and conclusive. Seller
reserves the right to require Buyer, at Buyer's sole cost and expense, to return any defective
Product, including any alterations made thereto, F.O.B. Seller's factory in Ohio.
Seller does not warrant against abrasion, corrosion or erosion. Seller shall not be liable to Buyer or
to any other person for work done or repairs made, to remedy any defect, by any person who is not
an authorized representative of Seller, unless Seller's written consent is first obtained by Buyer.
This Warranty does not apply to, and is rendered null and void by, any Product which, after
leaving Seller's manufacturing plant: (a) is repaired or altered without Seller's prior written
approval; (b) is the subject of improper storage, installation or operation; (c) is the subject of
intentional or negligent misuse, misapplication, neglect or accident; or (d) is not used, repaired or
altered in accordance with Seller's written instructions.
Seller expressly reserves the right to declare this Warranty null and void upon Buyer's failure to
make full and timely payments with respect to any Products purchased by Buyer from Seller, in
which event all of Seller's obligations, and Buyer's rights, under this Warranty, shall immediately
terminate. SELLER DISCLAIMS THE IMPLIED WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, AND ANY IMPLIED WARRANTIES
ARISING FROM COURSE OF PERFORMANCE, COURSE OF DEALING, OR USAGE OF
TRADE. SELLER SHALL NOT BE LIABLE TO BUYER OR ANY OTHER PARTY UNDER
THIS WARRANTY FOR DIRECT, SPECIAL, CONSEQUENTIAL, INDIRECT OR
INCIDENTAL DAMAGES OF ANY KIND.
Notice to the User
The information contained in this manual is believed to be correct. However,
Xenotronix/TLI, Inc. assumes no responsibility for any inaccuracies therein.
Information in this manual is subject to change without notice. No part of this manual may
be reproduced or transmitted in any form, electronic or mechanical, for any purpose, without
the express written permission of Xenotronix/TLI, Inc.
Copyright © 2006 Xenotronix/TLI, Inc. All rights reserved.

TABLE OF CONTENTS
Model NTX7 Automatic Battery Charger – User’s Manual
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Introduction . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Charging Notes and Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Maintenance Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Battery Charger Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

NTX7 User’s Manual
Xenotronix/TLI 1
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS - This manual contains important safety and operating
instructions for Model NTX7 Battery Chargers. Before using the battery charger, please
read all instructions and cautionary markings on the battery charger, the battery, and the
product using the battery.
CAUTION - To reduce the risk of electric shock:
oDo not expose unit to rain or moisture.
oDo not remove cover. There are no user serviceable parts inside. Refer service to
qualified service personnel.
oConnect the battery charger directly to a grounding receptacle. An adaptor
should not be used with this unit. This unit is equipped with a power plug having
an equipment grounding conductor (3-prong). The unit must be plugged into an
outlet that has been properly installed and grounded in accordance with all local
and national codes and ordinances.
oDisconnect charger from AC power and battery before attempting any
maintenance or cleaning. Turning off controls may not reduce this risk.
WARNING
oCharge only nickel-cadmium type rechargeable batteries. Attempting to charge
other types of batteries may result in personal injury and battery damage.
oThe enclosure (metal face) may become hot during the charge cycle - DO NOT
TOUCH!
DANGER - Never alter power plug blades or ground pin. If it will not fit the outlet, have
a proper outlet installed by an electrician. Improper connection will result in the risk of an
electric shock or fire.
Make sure cords are located so that they will not be stepped on, tripped over, or otherwise
subjected to damage or stress. Do not operate this unit with a damaged cord or plug -
replace them immediately. To reduce the risk of damage to electric plug, pull by unit
body rather than output cord when disconnecting unit.
Do not operate charger if it has received a sharp blow, been dropped, or otherwise
damaged in any way. Do not disassemble charger; incorrect reassembly will result in the
risk of an electric shock or fire. Refer service to qualified service personnel.
Allow space around unit and adequate air circulation to reduce internal heat buildup. Do
not block vents or operate in a small, enclosed space.

NTX7 User’s Manual
Xenotronix/TLI 2
INTRODUCTION
This unit is a two stage, constant current
battery charger for charging nickel-cadmium
type rechargeable batteries. The charge
termination is by a 14 hours timer at which
time it will switch from the charge current to a
low rate current. A 6 feet long output cable
with a barrel plug is provided. There are two
indicators on the front panel. The orange light
indicates that the charger is in the charging
mode. The green light indicates that the
battery is fully charged.
ASSEMBLY INSTRUCTIONS
Loosen the screws on the charger output terminal
strip. Identify the polarity of the terminal strip ant
the output connector; both the charger housing
and the output cable are marked with “+” & “-”
symbols. Insert the two spade terminals under the
terminal strip screws and tighten. To prevent
accidental shorting, cover the exposed terminals
with the molded press-on terminal cover.
If using loose wires, insert stripped ends under washers. A cable having a shield may be
grounded to the bottom hole using a number 6-32 x ¼” machine screw.
OPERATING INSTRUCTIONS
Before using this battery charger, make sure it is compatible with your battery. Refer to
the ratings on the battery charger, the specifications in this manual, and your battery
documentation. Charge only nickel-cadmium type
rechargeable batteries; attempting to charge other
types of batteries may result in battery damage. This
unit is provided with a polarized barrel plug
connector. Make sure your battery connector is
wired to match the output connector.
CAUTION: This unit is not reverse battery protected except by use of the polarized
connector. Make sure your battery connector is wired to match the charger connector or
damage to the battery and charger may result when power is applied. While in a reversed
condition the charger will indicate that it is in the charging mode. However, it may
actually be discharging the battery until either the battery or charger is damaged.

NTX7 User’s Manual
Xenotronix/TLI 3
CAUTION: This unit is not short circuit protected - it will deliver the full rated current
into a short. If the short is not removed, the charger may overheat and be damaged. While
in a shorted condition the charger will indicate that it is in the charging mode. If the
charging light is on while not connected to a battery then there is probably a short in the
output cable or connector. Remove the output cable and see if the charge light goes out
with the charger plugged back in. If the light stays on without an output cable connected
then there is a problem with the charger.
Plug the battery charger into a properly grounded (3-prong) wall outlet which supplies
the correct input power as marked on the unit. The indicators should be dark until a
battery is attached.
Attach the output connector to the battery connector. The charger should now be on and
charging the battery. The orange charging indicator should light. If the green ready
indicator lights instead then the battery voltage may be too high (too many cells). The
battery must be a 1.2 to 14.4 volts (1 to 12 cells) battery.
The orange charging light indicates that the charger is on and charging the battery. The
charger will deliver a constant current to the battery for 14 hours. After this time, the unit
will switch into the ready mode - the charging indicator will darken and the green ready
indicator will light. At this point the battery is fully charged. When the charger is in the
ready mode, a low rate constant current (1/4 that of the rated output current) is delivered
to the battery to keep it fully charged. Most nickel-cadmium batteries may be left
connected to the charger in the ready mode, for some time, without a danger of
overcharging. However, we recommend you refer to the battery manufacturer’s
documentation for the suitability of trickle charging your battery.
CHARGING NOTES AND TIPS
The batteries should be fully discharged before being put onto charge. This has two
benefits: the batteries will not be overcharged, although it is a fairly benign overcharge,
and they will be less likely to develop a “memory effect”.
The safe charging curve graph on the next page represents what size batteries, based on
voltage and capacity, can be properly charged using this charger. The charger is designed
to charge batteries at the C/10 charge rate (capacity ÷ 10). If your battery capacity is 2.8
Ah (2800 mAh) then the charger should be rated for 280 mA (2800 ÷10). Refer to your
battery documentation to see if the charger is appropriate to charge your battery.
Example: If your charger is rated for 400 mA then it will charge 4 Ah batteries between
4.8 to 13.2 volts (4 to 11 cells). It will charge a 14.4 volt (12 cells) battery as long as the
charger receives a full 115 volts ac input. If the input voltage is below 115 volts at that
charge voltage, the maximum current will begin to drop and the battery may not be fully
charged. Attempting to charge 4 Ah batteries between 1.2 to 3.6 volts (1 to 3 cells) may
cause the charger to overheat and possibly be damaged - the batteries should not be

NTX7 User’s Manual
Xenotronix/TLI 4
damaged. Batteries smaller than 4 Ah will be overcharged and batteries larger than 4 Ah
will be undercharged.
Xenotronix/TLI can make custom units, or modify our existing units, to exactly match
your charging needs. Call our sales department for technical information and pricing.
Following are some of the modifications we can perform:
oCustom match the charge current to your battery capacity
oAdjust the charge times for a faster or slower recharge
oProvide custom cables and connectors
oPrivate labeling
TROUBLESHOOTING
NO INDICATORS LIGHT - If the indicators are both dark when power is applied and
the charger is properly attached to a battery, check to see if the receptacle is controlled by
a light switch or power strip. It is normal for both indicators to be off with power applied
and no battery attached.
CHARGER ENTERS READY MODE TOO SOON - If the ready indicator lights when
you first attach the battery or in less than 13 hours then the battery is probably higher
than 14.4 volts (12 cells). The charger switches to ready mode if the voltage becomes too
high. It may reach this voltage during charge with batteries over 15.6 volts (13 cells).
BATTERY VOLTAGE (CELLS)
8.4 (7)
SAFE TO CHARGE
OVERHEAT IF OPERATED UNDER
2.4 (2)
BATTERY CAPACITY (mAh)
30002500200015001000500
1.2 (1)
5000450040003500
THE "SAFE TO CHARGE" ENVELOPE
3.6 (3)
4.8 (4)
CAUTION: CHARGER WILL
7.2 (6)
6.0 (5)
ENVELOPE
12.0 (10)
9.6 (8)
10.8 (9)
13.2 (11)
14.4 (12)
FULL CHARGE @ 115V~
UNDER CHARGE @ 105V~

NTX7 User’s Manual
Xenotronix/TLI 5
CHARGER WILL NOT SWITCH TO READY MODE – If, after 15 hours, the charger
has not yet switched to the ready mode, try to determine if there was a power interruption
or a loose connection, which may have reset the charger timer for another 14 hours.
CHARGING INDICATOR IS ON WITHOUT A BATTERY ATTACHED - This
indicates that the output cable or connector may be shorted. If the indicator remains off
with the output cable removed then you should replace the cable. Do not attempt to
charge a battery with a shorted output cable.
RATTLE - If you think you hear a rattle inside the charger it is probably only a loose
terminal strip screw. Once the output cable is attached and the screws are properly
tightened, the rattle should go away.
MAINTENANCE INSTRUCTIONS
CLEANING - Unplug the charger and disconnect the battery before attempting any
cleaning. If it becomes necessary to clean the enclosure, wipe the enclosure exterior with
a damp cloth. If necessary, use a mild detergent. Do not use an abrasive cleanser or spray
cleaners directly onto the charger. Do not immerse unit in water.
BATTERY CHARGER SPECIFICATIONS
General Conditions 25 °C (77 °F)
Operating temperature 0 to 40 °C (32 to 104 °F)
Storage temperature -40 to 80 °C (-40 to 176 °F)
Dimensions H 3.8" (9.65 cm) x W 2.8" (7.1 cm) x D 2.8" (7.1 cm)
Weight Less than 1.5 lbs (0.68 kg) with standard output cable
Power Requirements 120 VAC, 60 Hz, 0.2 A
Output Ratings:
Model NTX7 (all variants)
Charge Amps C/10 or 0.1C, where C = Battery Capacity
(50 to 500 mA, refer to marking label on unit)
Trickle Amps C/40 or 0.025C, where C = Battery Capacity
(Approximately 1/4 of rated output current)
Charge Timer 14 hours ± 1 hr.
Open Circuit Voltage Greater than 20 VDC
Battery Rechargeable nickel-cadmium, 1.2 to 14.4 Volts
(1 to 12 cells), 500 mAh to 5 Ah
Safety Agency Approval CSA NRTL/C
(USAandCanada)

NTX7 User’s Manual
Xenotronix/TLI 6
DIMENSIONS
READY
CAUTION:
CHARGING
