Xentino C780 User manual

[Type text]
Xentino Technologies Corp.
www.xentino.com
Product Overview
C780 is an IEEE 802.11ac Wi-Fi standard high power Ceiling
Wireless Access Point with MTK chipset. It supports WAVE 2
MU-MIMO , combined with 1200Mbps Wi-Fi speed over 2.4GHz
(300Mbps) and 5GHz (900Mbps), make more than 80 end users
can access at the same time into it. It is an economic option
for hotel, school, restaurant or other enterprise places.
C780
11ac 1200Mbps Ceiling Wireless AP
Main Features
Comply with IEEE 802.11ac/b/g/n, dual band,
1200Mbps Data Rate, 11ac 2x2 MIMO Technology
2*10/1000Mbps Ethernet Ports to meet with different
customer’s request
Support active IEEE 802.3af 48V PoE standard
Support SSID broadcasting, Multi SSID up to 8 (4 SSID
in 2.4GHz, 4 SSID in 5GHz)
Support Gateway (PPPOE, static IP, dynamic IP),
Wireless AP, Repeater, WISP operation mode in FAT
AP
With function of build in firewall, IP filter, URL filter and
MAC filter
Comply with IEEE 802.3az standard, RF power
adjustment and frequency analyzer for better application
in different environment
Zero Configure and Cloud Management System
Support FIT/FAT AP together, work with Xentino WLAN Controller, zero configure in IP address, ESSID,
Channel, Password, upgrade firmware, backup and restore. Besides that, it support advertisement and
authentication functions like WeChat, Google, SMS, Facebook, Member Authentication.
Then the WLAN controller can access into Cloud Management System, easy to make administrator access
it, to do remote monitoring/management at any time and any place, make this AP and WLAN controller more
professional and cost saved in Wi-Fi Projects.

[Type text]
C780
11ac 1200Mbps Ceiling Wireless AP
Xentino Technologies Corp.
www.xentino.com
FIT/FAT Operation Mode
C780 supports FIT/FAT operation modes;
If FIT AP, work with AC controller, plug and play, central management by AC controller, mostly for
enterprise application.
If FAT AP, support AP, repeater, gateway, WISP operation mode, can be configured by GUI, suit
for home mostly.
Multiple Protection for Stable Performance
C780 with ABS fireproof material, white color, suite for various decoration styles. Besides that, PCB
board with watchdog design, can reboot automatically in case of failure. What’s more, it support
lightning protection and ESD protection, can install in various harsh environment.
Power over Ethernet
C780 has integrated IEEE802.3af Power over Ethernet (PoE), for easy installation and lower cost.
So it can be installed in areas where power outlets are not readily available, eliminating the mess of
altering existing

[Type text]
Hardware
Chipset
MT7621DAT+MT7615D
Standard
802.11ac/b/g/n, MIMO technology
Memory
128MB
Flash
SPI NOR 8MB
Interface
1 * 10/100/1000Mbps RJ45 WAN Port
1 * 10/100/1000Mbps RJ45 LAN Port
1 * Reset button, press 15 seconds to revert to default
setting
Antenna
Build in 5dBi 2.4GHz MIMO Antenna
Build in 4dBi 5.8GHz MIMO Antenna
Size
168mm * 168 mm * 32 mm
POE
48V 0.5A
DC
12V 1A
LED Indicator
Sys, 2.4G WIF, 5.8G WIFI, LAN, WAN
Max Power Consumption
< 10W
ESD
±6KV
RF Data
Frequency
2.4G:802.11b/g/n: 2400MHz~2484MHz
5GHz:802.11a/n/ac: 5150MHz ~5850MHz
Country code
FCC, IC, ETSI, MKK, MKK1, MKK2, MKK3, NCC, RUSSIAN,
CN
Modulation
OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM
DSSS = DBPSK, DQPSK, CCK
Throughput
1200Mbps
RF Power (2.4GHz)
<20dBm
RF Power (5GHz)
<23dBm
PPM
±20ppm
Max Users
128+
Specifications
C780
11ac 1200Mbps Ceiling Wireless AP
Xentino Technologies Corp.
www.xentino.com
Antenna Performance

[Type text]
Others
Package Contents
1200Mbps Dual Band wireless access point
Ethernet Cable
Quick Installation Guide
Setting Accessory
Environment
Operating Temperature: -20~45 ℃
Storage Temperature: -40~70 ℃
Storage Humidity: 5%~95% non-condensing
Management
Firmware GUI , Remote Management, WLAN Controller,
Cloud Management System
Firmware Features
Operation mode
Wireless AP: Plug and Play.
Gateway: Dynamic IP/Static IP/PPPoE
Wireless Functions
Multiple SSID functions: 2.4GHz: 4; 5.8GHz: 4
Support SSID hidden
Support SSID broadcast
Support 5G Prior for a faster Ethernet.
Wireless Security: OPEN, WPA, WPA2, WPA-PSK, WPA2-PSK
Support MAC filter
Support Wi-Fi time on/off to save energy
Support client isolation to improve the wireless stability
Support RF power adjustable, adjust the RF power based on
environment.
Short GI Enable and Disable
Support user quantity limited, Max 128 users to access each
band.
Networking Function
VLAN settings
Cloud access support in gateway mode
Device Management
Back-up the configuration
Restore the configuration
Reset to factory default
Reboot the device: including time reboot or reboot
immediately
Admin management password modify
Firmware upgrade
System log
Support firmware GUI web management, AC controller
management, remote management and cloud management
Protocols
IPv4
Xentino Technologies Corp.
www.xentino.com
Specifications
C780
11ac 1200Mbps Ceiling Wireless AP
