XENX P3-1060 User manual

P3-1060 Graphics Tablet
User Manual

Table of Contents
Product overview
Packaging content
Setup your graphics tablet on Windows OS
Setup your graphics tablet on Mac OS
Setup your graphics tablet on Android OS
Xenx Driver settings
Replace the pen nib
Specifications
Warranty terms and conditions
1
2
3
4
5
6
7
8
9
1. Mapping settings
2. Shortcut buttons settings
3. Pen settings
4. Advanced settings
5. Device and application
6. Manage Xenx Driver settings file

Product overview1P3-1060
XENX P3-1060 is an ideal graphics tablet for digital art, painting, photo editing and graphic design.
Besides, it is a great tool for document annotation, pen input for online classes and meetings as well as
electronic signature application.
10 x 6.22 inches drawing area
Our battery-free pen is enhanced by a highly precise pressure sensor which ultilizes 8192 level of pressure
sensitivity. Two customizable side buttons allow you to put your favourable shortcuts on it
With Xenx Tablet Driver installed, you can customize the 10 on-tablet buttons to your favourite shortcuts.
These shortcuts can be conÞgured and saved per application
Xenx P3-1060 captures 266 sets of pen coordinates and pressure data per second
Xenx Tablet is compatible with Mac OS 10.12 or later, Windows 7 64-bit or later, Android 6.0 or later. You
can also enjoy driver free pen experience with Windows 10 and Android 6.0 or later
Size
Battery-free Pen
10 Customizable Shortcut Keys
High Performance
Compatibility

Shortcut Keys
Led indicator
7\SH-C connector
$QWLVOLSUXEEHUIRRW
5HSODFHDEOHSHQQLE
6KRUWFXWNH\V
6HULDOQXPEHU

Packaging content2P3-1060
Battery-free Pen
Pen Nib*10 OTG Adapter Setup Guide
USB Cable
P3-1060
Nib Removal Tool

Setup your graphics tablet on Windows OS3P3-1060
Starting from Windows 10, Microsoft®has introduced Windows Ink to enhance experience on pen
applications. Thanks to this great feature, Xenx P3-1060 can simply plug and play for pen pressure
enabled applications, no additional driver is needed.
If you would like to receive extra tablet features such as customizing shortcut keys and screen mapping,
you have to install our Xenx Driver software to open up the full set of tablet functions.
Download the Xenx Driver software from our ofÞcial website www.xenx-tech.com/download
Click the to start downloading the Þle
Download
Unzip the Þle and run the installation Þle by double click it
Follow the instructions to complete the installation. Restart your computer if prompted
Now you can connect your P3-1060 tablet to your computer with the USB type-C cable
You can always open the Xenx Driver by clicking the Xenx icon in system tray
Step 5 Step 6
USB
Type-C
The ofÞcial Xenx Driver installer may sometimes be blocked by anti-virus program. If you encounter this
problem, please temporary disable the anti-virus software to allow the Xenx Driver installation
Always download the Xenx Driver from our ofÞcial website www.xenx-tech.com
Xenx Driver only supports Windows 7 or later.
If you have other graphics tablet driver installed, please uninstall it before installing the Xenx Driver
software
Note
Winsows OS
Winsows OS Xenx Driver
1
2
3
4
5
6

Setup your graphics tablet on Mac OS4P3-1060
Xenx graphics tablet supports Mac OS 10.12 or later. Please follow the below instructions to install
Xenx Driver software on your Mac computer.
Download the Xenx Driver software from our ofÞcial website www.xenx-tech.com/download
Click the and select the version of CPU of your Mac computer
CPU
Download
Unzip the Þle and run the installation Þle by double click it
Follow the instructions to complete the installation. Restart your computer if prompted
Now you can connect your P3-1060 tablet to your computer with the USB type-C cable
Step 5
USB
Type-C
If you see the below warning after installing the Xenx Driver software, please update the system
preferences with the following steps:
Open ÒSystem PreferencesÓ -> ÒSecurity and PrivacyÓ
Look for “XenxTabletShadow” and allow it
Note
Winsows OS
M1
1
2
3
4
5

Setup your graphics tablet on Android OS5P3-1060
Xenx graphics tablet supports plug and play on Android OS 6 or later. Default orientation of the
drawing area is in landscape mode. When using Xenx tablet an Android phone, you may Þnd ratio
distortion.
To switch the Xenx tablet to match the phone aspect ratio, please follow the steps below:
Xenx graphics tablets only support Android OS 6.0 or later. For some Android devices, the USB OTG
function is disabled by default. Please check with your Android device manufacturer for setting up the
OTG function
Please note that the shortcut keys on tablet and pen are not supported in Android devices
Only USB Type-C OTG adapter is provided with Xenx graphics tablet
Note
Connect XENX tablet to your Android phone with Type-C OTG adaptor
Launch your drawing or writing app
Press and hold both the top and bottom buttons at the same time for 5 seconds
XENX tablet will switch to portrait mode to Þt your phone orientation
To switch back to landscape mode for your PC or Mac, press and hold the two buttons again for
5 seconds
1
2
3
4
5
Step 1
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
Step 3
Step 4
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10

Xenx Driver settings6P3-1060
There are 6 sections on Xenx Driver software:
Mapping Buttons Pen
Advance Device Application

  
  
 



Mapping settings6.1 P3-1060
With mapping function, you can customize how the graphics tablet drawing area maps to your
monitor(s). Besides, you can deÞne the left-handed or right-handed orientations of the tablet.
By default, the full tablet drawing area will map to your entire display(s)
Right hand mode - shortcut keys are located at the left side of the tablet
Right hand mode
Left hand mode - shortcut keys are located at the left side of the tablet
Tablet orientation
Screen mapping
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
Right hand mode
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10
Left hand mode
K1
K2
K7
K3
K8
K6
K4
K9
K5
K10

Allow you to deÞne the tablet active area to Þt your drawing experience.
You can deÞne the display area to be mapped with the tablet.
Screen frame
Tablet frame
All Ð if you have multiple monitors, this option will map the tablet to all monitors as a whole
All Ð using the whole active area
By monitor Ð quickly map one of the monitors with the tablet
Partial Ð you can customize the active area by dragging the 8 control points or enter the absolute
coordinates
Partial Ð user can deÞne the portion of monitor(s) to map with the tablet

Shortcut buttons settings6.2 P3-1060
You can customize the on-tablet shortcut button functions via the buttons settings section. There
are three options for each button:
When you choose Hotkey option, it will pop up a window to let you enter the combination of keys.
Hotkey setup
The preset value - We have pre-deÞned a set of shortcut keys to work with Adobe®Photoshop®.
Run Application Ð this option allows you to open an application by clicking the button
Hotkey Ð You can customize any combination of keyboard keys to match the shortcut of speciÞc application
Brush Move Eraser Eyedropper Hand
Brush settings Brush size - Brush size + Zoom out Zoom in
    
    

Pen settings6.3 P3-1060
Under this section, you can customize your pen pressure and side buttons settings.
There are three pen modes you can choose from:
There are two pen modes you can choose from:
Windows OS
Mac OS
By default, Xenx tablet is set to Windows Ink mode in order to take advantages of the built-inpen features
of Microsoft®Windows. If you found the pen pressure is not functioning on older applications, please
switch pen settings to Absolute mode
By default, Xenx tablet is set to absolute mode on Mac OS. In this mode, the coordinates of the pen
location will be absolutely mapped on the screen area. The cursor jumps to the corresponding point on
your screen when you place your pen on the tablet
Windows Ink
Absolute
Absolute
Relative
In this mode, the coordinates of the pen location will be absolutely mapped on the screen area. The cursor
jumps to the corresponding point on your screen when you place your pen on the tablet
This is also known as mouse mode where the behavior of the pen will work like a traditional mouse device.
The cursor will stay at the point you lift the pen and it will continue at that point when you put the pen back
on the tablet. This mode is useful when you want to replace your mouse with pen device for daily operation

You can setup the feeling of pen tip with this slider. You can check the pressure sensitivity with the
“Current pressure” indicator by pressing the pen tip at any empty space inside the driver window.
The harder pen tip means you need to press the pen harder to achieve maximum pen pressure.
You can also customize the pen pressure sensitivity by clicking the ÒUser deÞneÓ button. It will then
open the force vs pressure output graph and you can drag the coordinate point to adjust the behavior.
Pen tip sensitivity
This is also known as mouse mode where the behavior of the pen will work like a traditional mouse device.
The cursor will stay at the point you lift the pen and it will continue at that point when you put the pen back
on the tablet. This mode is useful when you want to replace your mouse with pen device for daily operation
Relative

There are two side buttons on Xenx pen and you can customize the functions to enhance your work
efÞciency.
Pen side button settings
By default, both buttons on pen are set to be eraser function on Windows OS
Disable the pen button
Simulate the right click of a mouse
Simulate the middle click of a mouse
Toggle pen tip function between pen stroke and eraser
Allow user to customize any keys combination to work with different applications
Default
None
Right Click
Middle Click
Pen / Eraser
Hotkey

Advanced settings6.4 P3-1060
In advanced settings page, there are three extra functions:
This mode is dedicated for OSU! gaming. If you enable this mode, it takes away the pen stroke smoothing
algorithm in return for the enhancement to overall response of the pen
OSU mode
Pen tip
Open Xenx Driver when plug in tablet
You can disable the pen tip if you want to pen for cursor moving only so that you can rest the pen on the tablet
surface all the time
if you do not want the Xenx Driver open up every time you connect the tablet, please uncheck this option

Device and application6.5 P3-1060
If you have multiple Xenx devices, Xenx driver will create different proÞles for each device. Click
the device icon to view the settings of this proÞle
You can also set different settings proÞle for different software applications. By default, settings will
be applied to all applications. It will be useful to have application speciÞc settings especially for the
shortcut key deÞnitions.
To create an application speciÞed setting proÞle:
Device list
Application List
Frist, select the target device from the device list
In the application list, click the + button
Select the target application you want to create a setting proÞle

For Windows OS, you have to locate the application .exe Þle for this setting. If you are not sure the
destination folder, you can Þrst create a shortcut of the application to your Desktop. When choosing
the target application, you can simply select the shortcut in Desktop folder.
To remove an application speciÞed setting proÞle:
Note
Frist, select the target device from the device list
In the application list, select the target application and click the - button

Manage Xenx Driver settings file6.6 P3-1060
At the bottom section of Xenx Driver, there are four regular buttons:
You can get the driver and Þrmware version information
About
Export
Import
Reset
Backup/export your settings Þle to your computer storage
Restore/import your settings Þle
Clear all customized settings to default values

Replace the pen nib7P3-1060
Extra pen nibs and nib removal tool are included in the package.
Pull out the nib with the nib removal tool
Gently push the replacement nib into the pen until it stops
1
2
over-tighten the pen nib may results in bad pressure sensitivity
Note
