Xerox Wide Format 6030 User manual

Xerox 6030/6050 Wide Format
TWAIN
User Guide
701P41580
Version 1.5
May 2004

Xerox Corporation
Global Knowledge & Language Services
800 Phillips Road Bldg. 845-17S
Webster, NY 14580
Copyright © 2004 Xerox Corporation. All rights reserved.
Printed in the United States of America.
Copyright protection claimed includes all forms and matters of
copyrighted material and information now allowed by statutory
or judicial law or hereinafter granted, including without
limitation, material generated from the software programs that
are displayed on the screen such as styles, templates, icons,
screen displays, looks, etc.
Adobe® and the Adobe logo, InDesign®, Illustrator®,
PageMaker®, Photoshop®, Acrobat®, Distiller®, and the
Acrobat logo are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other
countries.
The Creo wordmark, Creo logo, and the names of Creo
products and services referred to this document are
trademarks of Creo, Inc.
Macintosh, Power Macintosh, and Mac are registered
trademarks of Apple Computer, Inc.
Microsoft® Windows NT® and Microsoft® Windows are
trademarks of Microsoft Corporation.
PANTONE® is a registered trademark of Pantone, Inc.
Sun Microsystems and Solaris are a trademarks, registered
trademarks, or service marks of Sun Microsystems, Inc. in the
U.S. and other countries.
SWOP® is a registered trademark of SWOP, Inc.
Quark and QuarkXPress are trademarks of Quark, Inc. and all
applicable affiliated companies, Reg. U.S. Pat. & Tm. Off. and
in many other countries.
Macromedia FreeHand® is a trademark of Macromedia, Inc.
This product includes software developed by the Apache
Software Foundation (http://www.apache.org).
This product includes software developed by the JDOM
Project (http://www.jdom.org).
This product includes software developed by the Jaxen
Project (http://www.jaxen.org).
XEROX®, The Document Company®, the digital X®, Xerox
6030/6050 Wide Format TWAIN are the trademarks of or
licensed to XEROX CORPORATION.

Preface
Welcome to 6030/6050 Wide Format TWAIN.
6030/6050 Wide Format TWAIN is TWAIN data source for 6030/6050 Wide Format
Copier/Printer.
This User Guide describes 6030/6050 Wide Format TWAIN operation and usage
cautions.
Read this guide prior to using 6030/6050 Wide Format TWAIN for most effective use
and maximum performance.

Manual Organization
Manual Organization
This guide has been prepared on the assumption that the user has understood the general
idea and operation of Scanner, Printer, and Microsoft Windows.
For operation guide for Scanner and Printer, refer to the following manuals.
Types of Manuals Contents
Xerox 6030/6050 Wide
Format Printer with Scan
System User Guide
Describes the operation methods and precautions regarding usage related to
the Xerox 6030/6050 Wide Format Printer with Scan System.
Xerox 6030/6050 Wide
Format Copier/Printer User
Guide
Describes the various setup procedures and precautions regarding usage
related to the copier.
Xerox 6030/6050 Wide
Format Printer User Guide
Describes the various setup procedures and precautions regarding usage
related to the printer.
DocuScan 1200w User
Guide
Describes the operation methods and precautions regarding usage related to
the DocuScan 1200w.

Using This Guide
Using This Guide
This guide describes how to scan a monochrome image by using DocuScan 1200w and
6030/6050 Wide Format Copier/Printer, and how to edit, save, and print the scanned
data.
About This Guide
This book has been prepared on the assumption that the user has used 6030/6050 Wide
Format Copier/Printer prior to reading this manual.
The detail specifications and functions of Scanner and Printer, refer to respective
manuals.
6030/6050 Wide Format TWAIN is compatible with Microsoft Windows 2000,
Microsoft Windows XP and Microsoft Windows 98 operating systems.
For basic operation of each Windows operating system, refer to Microsoft Windows
manual.
Table of Contents
This guide consists of the following chapters:
Chapter 1 Overview of 6030/6050 Wide Format TWAIN
Chapter 2. Preparation
Chapter 3. Functions
Chapter 4. Error messages

Using This Guide
Conventions
This guide uses the following symbols depending on the contents:
[XXXX] Indicates the topics, button names, and menu on operation
window.
1234 Bold letters indicates the messages displayed on Wide
Format TWAIN operation window.
<XXXX> Indicates the messages.
Indicates important information and must be read in detail.
Gives what to follow for the correct use of Wide Format
TWAIN.
=>p.10 <xxxx> Indicates page number and topic.

Table Of Contents
Table of Contents
Preface
Manual Organization
Using This Guide
Table of Contents
Chapter 1 Overview of 6030/6050 Wide Format TWAIN
1.1 About TWAIN Source..............................................................................................................2
1.2 Terms .............................................................................................................................................3
1.3 Precautions ...................................................................................................................................4
Chapter 2 Preparation
2.1 System Configuration................................................................................................................8
2.2 Installation....................................................................................................................................9
2.3 Uninstallation ............................................................................................................................17
Chapter 3 Functions
3.1 Available scanning function ...................................................................................................20
Chapter 4 Error and Warning messages
4.1 Error and Warning messages..................................................................................................30
Index ....................................................................................................................................... 34

Table Of Contents

Chapter 1
Overview of 6030/6050 Wide
Format TWAIN
Chapter 1
This chapter overviews and describes the functions of 6030/6050 Wide Format TWAIN.

2Chapter 1 Overview of 6030/6050 Wide Format TWAIN
1.1 About TWAIN Source
6030/6050 Wide Format TWAIN (hereafter referred to as Wide Format TWAIN)
provides image document scanning function by using 6030/6050 Wide Format Copier/
Printer and DocuScan 1200w with a host computer. The supported operating systems are
Microsoft Windows 2000, Microsoft Windows XP and Microsoft Windows 98.
Basic functions required for wide size image scanning are available by Windows user
interface operation.
Feature of Wide Format TWAIN
•Easy operation using TWAIN protocol, which is used as standard protocol for
image scanner
•Including automatic document size judgement, and automatic background
suppression

3
1.2 Terms
1.2 Terms
This section explains the terms used in this guide
Explanation of terms
Scan protocol:
Indicates the communication between image scanning application software and image
scanner.
TWAIN Source software:
Indicates standard image scanning protocol for image scanning application and image
scanner, developed by TWAIN Working Group.
Wide Format TWAIN uses this protocol for the communication with image scanning
application such as DocuWorks. For detail explanation of DocuWorks, refer to
DocuWorks user guide.

4Chapter 1 Overview of 6030/6050 Wide Format TWAIN
1.3 Precautions
This chapter explains the precautions for using Wide Format TWAIN.
Precautions and Restrictions for Scanner
To use Wide Format TWAIN, Scanner firmware version must be 1.0.0 or later version.
The firmware version can be confirmed by Wide Format TWAIN version information. If
the version is before 1.0.0, call for your Service Representative.
Precautions and Restrictions for Document Scanning
Available scanning size for Wide Format TWAIN is as follows. Read error or
unexpected results may occur if oversized document is scanned.
[1] Scan size
At 600 dpi:
Size series Size Paper size (Width x
Length) [mm] dot [dot]
ISO A A0 Portrait 841.0 x 1189.0 19866 x 28087
A1 Portrait 594.0 x 841.0 14031 x 19866
A2 Portrait 420.0 x 594.0 9921 x 14031
A3 Portrait 297.0 x 420.0 7016 x 9921
A4 Portrait 210.0 x 297.0 4961 x 7016
A1 Landscape 841.0 x 594.0 19866 x 14031
A2 Landscape 594.0 x 420.0 14031 x 9921
A3 Landscape 420.0 x 297.0 9921 x 7016
A4 Landscape 297.0x 210.0 7016 x 4961
SpecialA-1
(880mm)
Special A0 Portrait 841.0 x 1189.0 19866 x 28087
Special A1 Portrait 594.0 x 841.0 14031 x 19866
Special A2 Portrait 420.0 x 594.0 9921 x 14031
Special A3 Portrait 297.0 x 420.0 7016 x 9921
Special A4 Portrait 210.0 x 297.0 4961 x 7016
Special A1 Landscape 841.0 x 594.0 19866 x 14031
Special A2 Landscape 594.0 x 420.0 14031 x 9921
Special A3 Landscape 420.0 x 297.0 9921 x 7016
A4 Landscape 297.0x 210.0 7016 x 4961

5
1.3 Precautions
Special A-2
(870mm)
B1 Portrait 728.0 x 1030.0 17197 x 24331
B2 Portrait 515.0 x 728.0 12165 x 17197
B3 Portrait 364.0 x 515.0 8598 x 12165
B4 Portrait 257.0 x 364.0 6071 x 8598
B5 Portrait 182.0 x 257.0 4299 x 6071
B2 Landscape 728.0 x 515.0 17197 x 12165
B3 Landscape 515.0 x 364.0 12165 x 8598
B4 Landscape 364.0 x 257.0 8598 x 6071
B5 Landscape 257.0 x 182.0 6071 x 4299
ANSI ANSI/E Portrait 863.6 x 1117.6 20400 x 26400
ANSI/D Portrait 558.8 x 863.6 13200 x 20400
ANSI/C Portrait 431.8 x 558.8 10200 x 13200
ANSI/B Portrait 279.4 x 431.8 6600 x 10200
ANSI/A Portrait 215.9 x 279.4 5100 x 6600
ANSI/E Landscape 863.6 x 558.8 20400 x 13200
ANSI/D Landscape 558.8 x 431.8 13200 x 10200
ANSI/C Landscape 431.8 x 279.4 10200 x 6600
ANSI/B Landscape 279.4 x 215.9 6600 x 5100
ARCH ARCH/E Portrait 914.4 x 1219.2 21600 x 28800
ARCH/D Portrait 609.6 x 914.4 14400 x 21600
ARCH/C Portrait 457.2 x 609.6 10800 x 14400
ARCH/B Portrait 304.8 x 457.2 7200 x 10800
ARCH ARCH/A Portrait 228.6 x 304.8 5400 x 7200
ARCH/E Landscape 914.4 x 609.6 21600 x 14400
ARCH/D Landscape 609.6 x 457.2 14400 x 10800
ARCH/C Landscape 457.2 x 304.8 10800 x 7200
ARCH/B Landscape 304.8 x 228.6 7200 x 5400
Size series Size Paper size (Width x
Length) [mm] dot [dot]

6Chapter 1 Overview of 6030/6050 Wide Format TWAIN
Automatic document size judgement
Maximum document size
Maximum document size is determined by the memory size installed in scanner.
Judged
value ISO A Special A (880mm)
Special A
(870mm) ANSI ARCH
718mm or
over
841mm
(A0 Portrait/A1
Landscape)
880mm
(Sp.A0 Port./
Sp.A1 Land.)
880/870mm
(Sp. A0 Port. /
Sp.A1 Land.)
863.6mm
(34"x44"/
34"x22")
914.4mm
(36"x48"/
36"x24")
718 - 502mm 594mm
(A1 Portrait/
A2 Landscape)
625mm
(Sp.A1 Port./
Sp. A2 Land.)
620mm
(Sp. A1 Port. /
Sp.A2 Land.)
558.8mm
(22"x34"/
22"x17")
609.6mm
(24"x36"/
24"x18")
502 - 332mm 420mm
(2 PortraitA3
Landscape)
440mm
(Sp.A2 Port./
Sp. A3 Land.)
435mm
(Sp. A2 Port. /
Sp.A3 Land.)
431.8mm
(17"x22"/
17"x11")
457.2mm
(18"x24"/
18"x12")
332 - 242mm 297mm
(A3 Portrait/A4
Landscape)
312/297mm
(Sp. A3 Port. /
Sp.A4 Land.)
310/297mm
(Sp.A3 Port./
A4 Landscape)
279.4mm
(11"x17"/
11"x8.5")
304.8mm
(12"x18"/
12"x9")
242 - 137mm 210m
(A4 Portrait)
210mm
(A4 Portrait)
210mm
(A4 Portrait)
215.9mm
(8.5"x11")
28.6mm
(9"x12")
Document size is judged by the detected document width and specified size series.
Installed memory Maximum scan length
256MB 3,000mm
512MB 7,500mm
1GB 15,000mm
Depending on the scanning application software, document less than the above
maximum size may not be scanned. Refer to the corresponding scanning application
software manual for the maximum size.

Chapter 2
Preparation Chapter 2
This chapter describes the host computer and system configuration required for
scanning and printing using Wide Format TWAIN.

8Chapter 2 Preparation
2.1 System Configuration
Host Configuration
Wide Format TWAIN uses a computer with Windows 2000, Windows XP, or Windows
98 operating system installed. The following are the requirements for the host computer:
Requirements for a host computer
<Hardware>
CPU
Pentium III 450MHz or over
Memory
Mainly A0 size binary image256MB or over
Mainly Gray multi tone image:1GB or over
Hard disk
Mainly A0 size binary image: 500MB or over free space
Mainly Gray multi tone image: 1GB or over free space
SCSI board
Adaptec AHA-2940 Ultra (For Windows XP)
Adaptec ASC29160(For Windows 98, 2000)
<Software> (OS)
Windows 2000, Windows XP, Windows 98 operating system (English version only)
Connections
To scan image document, it is required to confirm if SCSI card is installed to a host
computer, and DocuScan 1200w and 6030/6050 Wide Format Copier/Printer are
connected correctly.
For the information about SCSI card and how to install SCSI card driver, follow the
instructions described on each SCSI card manual.

9
2.2 Installation
2.2 Installation
This chapter describes how to install Wide Format TWAIN software to a host computer.
Before installation
Please follow the instructions below for installation.
Product information
Wide Format TWAIN is an optional software for 6030/6050 Wide Format Copier/
Printer. Please confirm that the following items are contained when you open Wide
Format TWAIN package.
<License Agreeement(1)>
Read carefully before installation of software.
It describes about the license of Wide Format TWAIN software.
<CD for Setup>
The setup program for installing the program required to execute scanning application
and Wide Format TWAIN software for processing data between 6030/6050 Wide Format
Copier/Printer and host computer is located on a CD.
How to install
Use Setup program from the CD to install Wide Format TWAIN software to a host
computer.
•For software upgrade, prior to installing the latest version software
uninstall any previous version of the software. Wide Format TWAIN new
version setup program creates new a file and does not overwrite the
previous version file. Because of this, the new version software may be
installed incorrectly if the previous version has not been uninstalled.
•Wide Scanner TWAIN Source is a different product, and not the previous
version software. TWAIN Source and Wide Format TWAIN can be
installed in the same PC.
The program will be saved on the hard disk of the host computer, following the setup
program. Therefore, you do not need to confirm the contents of the floppy disk.
It is required to login as an administrator to install Wide Format TWAIN on Windows
2000. For Windows XP, it is required to login as an administrative user of a computer.

10 Chapter 2 Preparation
Start Setup program on the host computer (Windows 98, Windows 2000, Windows XP)
from the CD in either of the following methods.
1. Use [Add/Delete program] wizard of control panel.
2. Use [Run...] from Start menu.
3. Open Setup program file from CD by using Explorer.
Installation Procedure
The followings is the installation procedure using [Add/Remove Programs] wizard.
Start the host computer (Windows 98, Windows 2000, Windows XP).
1Open the Control panel and double-click (Windows XP single-click) on [Add/
Remove Programs].
[Add/Remove programs Property] will be displayed.
If you install the program in the method other than 1., select setup.exe and execute it.
If you are not accustomed to Windows file operation, it is recommended to use the
method 1.
This section explains the procedures using Windows 2000.
For the case of Windows 98, Windows XP, operations are the same as Windows 2000.

11
2.2 Installation
2Click on [Add New Programs] button.
[Install Program from Floppy Disk or CD-ROM] will be displayed.
3Insert Setup disk into the CD drive, and click on [Next].
The screen will be switched into [Run Installation Program]
Select the [Browse] button and select the CD drive and directory
that contains the Setup.exe.
This explanation is based on the assumption that the CD drive is D.

12 Chapter 2 Preparation
4Click [Finish] button.
Setup wizard will be displayed.
5Click [Next] button.
Setup program will be started, and [Choose Destination Location] screen will
be displayed.
Default installation folder will be automatically prepared by Setup program. To change
the folder, click [Browse] button and specify the location.
Installation procedure will be different if the procedure other than 1. has been selected.
