WorkCentre 7232/7242
Voluntary Product Accessibility Template (VPAT) Compliance Status
Compliant with minor exceptions
Learn more about Xerox and Section 508 at our website:
www.xerox.com/Section508
Contact Xerox for more information and to have a representative contact me
More about the WorkCentre 7232/7242
Summary Table – Voluntary Product Accessibility Template (VPAT)
Criteria Supporting Features Remarks and explanations
Section 1194.21
Software Applications and
Operating Systems Supports The WorkCentre 7232/7242 is compliant with Rule
1194.21.
Section 1194.22
Web-based internet
information and
applications
Not applicable General user functions can be accessed via the
standard user interface and client software
(assessed under Rule 1194.21.
Section 1194.23
Telecommunications
Products Not applicable The WorkCentre 7232/7242 is not a
telecommunications product.
Section 1194.24
Video and Multi-media
Products Not applicable The WorkCentre 7232/7242 is not a video or multi-
media product.
Section 1194.25
Self-Contained, Closed
Products Some limitations exist There is no alternative to the product touch screen.
Section 1194.26
Desktop and Portable
Computers Not applicable No computer is sold as part of the product.
Section 1194.31
Functional Performance
Criteria Some limitations exist There is no alternative to the product touch screen.
Section 1194.41
Information,
Documentation, and
Support
(Added by Xerox) This rule
covers accessibility of
documentation, training
and support for IT
products. Xerox includes
rule 41 in all its
assessments.
Supports The centralization of documentation, training, and support services for most Xerox products allows us
to achieve compliance across the corporation.
www.xerox.com/Section508 1 of 8
Last Revision: 10/03/07

www.xerox.com/Section508 2 of 8
Last Revision: 10/03/07
Section 1194.21 Software Applications and Operating Systems – Detail Back to top
Criteria Supporting Features Remarks and explanations
(a) When software is
designed to run on a
system that has a
keyboard, product
functions shall be
executable from a
keyboard where the
function itself or the result
of performing a function
can be discerned textually.
Supports All commands that can be described textually can
be executed from the keyboard.
(b) Applications shall not
disrupt or disable activated
features of other products
that are identified as
accessibility features,
where those features are
developed and
documented according to
industry standards.
Applications also shall not
disrupt or disable activated
features of any operating
system that are identified
as accessibility features
where the application
programming interface for
those accessibility
features has been
documented by the
manufacturer of the
operating system and is
available to the product
developer.
Supports
The product software does not override or disable
accessibility features of the host operating system
or other software possessing features that have
been developed and documented according to
industry standards.
(c) A well-defined on-
screen indication of the
current focus shall be
provided that moves
among interactive
interface elements as the
input focus changes. The
focus shall be
programmatically exposed
so that Assistive
Technology can track
focus and focus changes.
Supports
A well defined, on-screen indication of the current
focus is provided, and the focus is programmatically
exposed so that Assistive Technology can track
focus and focus changes.
(d) Sufficient information
about a user interface
element including the
identity, operation and
state of the element shall
be available to Assistive
Technology. When an
image represents a
program element, the
information conveyed by
Supports The program code makes the appropriate user
interface elements available to Assistive
Technology.

www.xerox.com/Section508 3 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
the image must also be
available in text.
(e) When bitmap images
are used to identify
controls, status indicators,
or other programmatic
elements, the meaning
assigned to those images
shall be consistent
throughout an application's
performance.
Supports Bitmap image meanings remain consistent
throughout the application.
(f) Textual information
shall be provided through
operating system functions
for displaying text. The
minimum information that
shall be made available is
text content, text input
caret location, and text
attributes.
Supports All textual information is provided through operating
system functions.
(g) Applications shall not
override user selected
contrast and color
selections and other
individual display
attributes.
Supports The product software does not override user-
selected contrast and color selections and other
individual display attributes.
(h) When animation is
displayed, the information
shall be displayable in at
least one non-animated
presentation mode at the
option of the user.
Supports Animation is used for control elements or relevant
text, and a non-animated option is available.
(i) Color coding shall not
be used as the only
means of conveying
information, indicating an
action, prompting a
response, or distinguishing
a visual element.
Supports The product software does not use color as the only
means of conveying information.
(j) When a product permits
a user to adjust color and
contrast settings, a variety
of color selections capable
of producing a range of
contrast levels shall be
provided.
Supports The application permits a user to adjust color and
contrast settings, and a variety of color selections
are provided to produce a range of contrast levels.
(k) Software shall not use
flashing or blinking text,
objects, or other elements
having a flash or blink
frequency greater than 2
Hz and lower than 55 Hz.
Supports The flash rate of any flashing elements does not fall
between 2 Hz and 55 Hz.
(l) When electronic forms
are used, the form shall
allow people using Supports Electronic forms allow people using Assistive
Technology to accurately complete and submit the

www.xerox.com/Section508 4 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
Assistive Technology to
access the information,
field elements, and
functionality required for
completion and
submission of the form,
including all directions and
cues.
forms.
Section 1194.25 Self-Contained, Closed Products – Detail Back to top
Criteria Supporting Features Remarks and explanations
(a) Self contained
products shall be usable
by people with disabilities
without requiring an end-
user to attach Assistive
Technology to the
product. Personal
headsets for private
listening are not Assistive
Technology.
Supports There is no specific Assistive Technology required;
however, the touch screen is not accessible.
(b) When a timed
response is required, the
user shall be alerted and
given sufficient time to
indicate more time is
required.
Supports A time-out alert feature is present and controllable.
(c) Where a product
utilizes touchscreens or
contact-sensitive controls,
an input method shall be
provided that complies
with §1194.23 (k) (1)
through (4).
Some limitations exist There is no alternative to the product touch screen.
(d) When biometric forms
of user identification or
control are used, an
alternative form of
identification or activation,
which does not require the
user to possess particular
biological characteristics,
shall also be provided.
Not applicable Biometric forms are not used.
(e) When products provide
auditory output, the audio
signal shall be provided at
a standard signal level
through an industry
standard connector that
will allow for private
listening. The product
must provide the ability to
interrupt, pause, and
Not applicable There is no auditory output.

www.xerox.com/Section508 5 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
restart the audio at
anytime.
(f) When products deliver
voice output in a public
area, incremental volume
control shall be provided
with output amplification
up to a level of at least 65
dB. Where the ambient
noise level of the
environment is above 45
dB, a volume gain of at
least 20 dB above the
ambient level shall be user
selectable. A function
shall be provided to
automatically reset the
volume to the default level
after every use.
Not applicable There is no voice output.
(g) Color coding shall not
be used as the only
means of conveying
information, indicating an
action, prompting a
response, or
distinguishing a visual
element.
Supports Color coding and additional means of unique
identification (e.g., text and symbols) are used.
(h) When a product
permits a user to adjust
color and contrast
settings, a range of color
selections capable of
producing a variety of
contrast levels shall be
provided.
Not applicable There are no color contrast settings.
(i) Products shall be
designed to avoid causing
the screen to flicker with a
frequency greater than 2
Hz and lower than 55 Hz.
Supports The flash rate of any flashing elements does not fall
between 2 Hz and 55 Hz.
(j) (1) Products which are
freestanding, non-
portable, and intended to
be used in one location
and which have operable
controls shall comply with
the following: The position
of any operable control
shall be determined with
respect to a vertical plane,
which is 48 inches in
length, centered on the
operable control, and at
the maximum protrusion of
the product within the 48
inch length on products
Supports All position measurements were performed against
the specified vertical plane.

www.xerox.com/Section508 6 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
which are freestanding,
non-portable, and
intended to be used in one
location and which have
operable controls.
(j)(2) Products which are
freestanding, non-
portable, and intended to
be used in one location
and which have operable
controls shall comply with
the following: Where any
operable control is 10
inches or less behind the
reference plane, the
height shall be 54 inches
maximum and 15 inches
minimum above the floor.
Supports All operable controls are within specification. The
document handler supports the rule as long as the
operator does not open to its fullest extent.
(j)(3) Products which are
freestanding, non-
portable, and intended to
be used in one location
and which have operable
controls shall comply with
the following: Where any
operable control is more
than 10 inches and not
more than 24 inches
behind the reference
plane, the height shall be
46 inches maximum and
15 inches minimum above
the floor.
Supports All operable controls are within specification. The
document handler supports the rule as long as the
operator does not open to its fullest extent.
(j)(4) Products which are
freestanding, non-
portable, and intended to
be used in one location
and which have operable
controls shall comply with
the following: Operable
controls shall not be more
than 24 inches behind the
reference plane.
Supports All operable controls are within specification. The
document handler supports the rule as long as the
operator does not open to its fullest extent.
Section 1194.31 Functional Performance Criteria – Detail Back to top
Criteria Supporting Features Remarks and explanations
(a) At least one mode of
operation and information
retrieval that does not
require user vision shall
be provided, or support for
Assistive Technology
used by people who are
blind or visually impaired
Some limitations exist There is no alternative to the product touch screen.

www.xerox.com/Section508 7 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
shall be provided.
(b) At least one mode of
operation and information
retrieval that does not
require visual acuity
greater than 20/70 shall
be provided in audio and
enlarged print output
working together or
independently, or support
for Assistive Technology
used by people who are
visually impaired shall be
provided.
Supports
All areas requiring visual user interaction with visual
acuity better than 20/70 support screen
enlargement and voice output or Assistive
Technology.
(c) At least one mode of
operation and information
retrieval that does not
require user hearing shall
be provided, or support for
Assistive Technology
used by people who are
deaf or hard of hearing
shall be provided
Supports No operations require user hearing.
(d) Where audio
information is important
for the use of a product, at
least one mode of
operation and information
retrieval shall be provided
in an enhanced auditory
fashion, or support for
assistive hearing devices
shall be provided.
Not applicable No audio information is required for use of the
product.
(e) At least one mode of
operation and information
retrieval that does not
require user speech shall
be provided, or support for
Assistive Technology
used by people with
disabilities shall be
provided.
Supports No operations require speech.
(f) At least one mode of
operation and information
retrieval that does not
require fine motor control
or simultaneous actions
and that is operable with
limited reach and strength
shall be provided.
Some limitations exist Fine motor skills are required to access the product
touch screen.
Section 1194.41 Information, Documentation and Support - Detail
(Xerox Addition to VPAT) Back to top

www.xerox.com/Section508 8 of 8
Last Revision: 10/03/07
Criteria Supporting Features Remarks and explanations
(a) Product support
documentation provided
to end-users shall be
made available in
alternate formats.
Supports Product support documentation is available in
alternate format.
(b) End-users shall have
access to a description of
the accessibility and
compatibility features of
products in alternate
formats or alternate
methods upon request, at
no additional charge.
Supports Accessibility and compatibility information is
available on www.xerox.com/section508/.
(c) Support services for
products shall
accommodate the
communication needs of
end-users with disabilities.
Supports Xerox provides support services that accommodate
the communication needs of end-users with
disabilities.
What is the Voluntary Product Accessibility Template (VPAT)?
The purpose of the Voluntary Product Accessibility Template is to assist Federal contracting officials in making
preliminary assessments regarding the availability of commercial Electronic and Information Technology products
and services with features that support accessibility. It is assumed that offerers will provide additional contact
information to facilitate more detailed inquiries.
The first table of the Template provides a summary view of the section 508 Standards. The subsequent tables
provide more detailed views of each subsection. There are three columns in each table. Column one of the
Summary Table describes the subsections of subparts B and C of the Standards. The second column describes
the supporting features of the product or refers you to the corresponding detailed table, "e.g., equivalent
facilitation." The third column contains any additional remarks and explanations regarding the product. In the
subsequent tables, the first column contains the lettered paragraphs of the subsections. The second column
describes the supporting features of the product with regard to that paragraph. The third column contains any
additional remarks and explanations regarding the product.
User Tasks Assessed
For the WorkCentre 7232/7242, general user tasks were assumed to be programming and running jobs, loading
documents, and unloading jobs. According to the Federal Access Board, tasks such as clearing jams, loading
supplies, and adding paper are considered maintenance tasks and are not included in this summary.
Xerox Product Accessories for People with Disabilities
In addition to the award-winning Xerox Copier Assistant, Xerox provides additional accessories for people with
disabilities; for example:
•Braille enablement – Pressure sensitive labels allow Braille to be added to almost any copier control
console.
•Angled console – This kit, which is currently available for a number of models, inclines the copier console,
allowing wheelchair users to view and reach the controls.
•Footswitch – An electrically operated switch models, which is available on many models, can be used to
actuate the "Start Print" button.
For additional information on these and other accessories, contact your Xerox sales representative or call 1-800-
ASK-XEROX (1-800-275-9376).
