WorkCentre® C2424 Copier-Printer
Copyright © 2005 Xerox Corporation. All Rights Reserved.
7-1
This chapter includes:
■"Automatic Diagnostic Tools" on page 7-2
■"Paper Jams" on page 7-4
■"Output Quality Problems" on page 7-26
■"Maintenance" on page 7-31
■"Moving and Repacking the System" on page 7-51
■"Web Links" on page 7-57
Troubleshooting

Automatic Diagnostic Tools
WorkCentre® C2424 Copier-Printer
7-2
Automatic Diagnostic Tools
Xerox provides several automatic diagnostic tools to help you produce and maintain print
quality.
This section includes:
■"Control Panel Help Button" on page 7-2
■"PhaserSMART Technical Support" on page 7-2
■"PrintingScout" on page 7-3
Control Panel Help Button
Your system’s control panel provides you with information and troubleshooting help. When an
error or warning condition occurs, the control panel displays a message informing you of the
problem. In many cases, the control panel also displays an animated graphic showing the
location of the problem, such as the location of a paper jam.
To view information about how to fix the problem, press the control panel’s Help button,
which is labeled with a “?” symbol. You can press the Help button at any time to get additional
information about the message or menu displayed on the control panel.
PhaserSMART Technical Support
PhaserSMART Technical Support is an automated, Internet-based support system. Use your
default web browser to send diagnostic information from your printer to our web site for
analysis. PhaserSMART Technical Support examines the information, diagnoses the problem,
and proposes a solution. If the problem is not resolved with the solution, PhaserSMART
Technical Support assists you in opening a Service Request with Xerox Customer Support.
To access PhaserSMART Technical Support:
1. Open your browser and go to www.phaserSMART.com.
2. Enter your system’s IP address in the browser window.
3. Follow the instructions on the screen.
2424-15
7
Enter
Back

Automatic Diagnostic Tools
WorkCentre® C2424 Copier-Printer
7-3
PrintingScout
PrintingScout is a tool that is installed with your Windows printer driver. It automatically
checks the printer status when you send a print job. If the printer is unable to print your job,
PrintingScout automatically displays a message on your computer screen to let you know that
the printer needs attention. The message also explains how to fix the problem.
Note
PrintingScout is available from the Windows printer driver for printer connected to the
network via TCP/IP.

Paper Jams
WorkCentre® C2424 Copier-Printer
7-4
Paper Jams
This section includes:
■"Jam at the Exit Cover" on page 7-4
■"Jam at the Exit Path" on page 7-9
■"Jam at the Front Cover" on page 7-12
■"Jam at Tray 2, 3, or 4" on page 7-18
■"Jam at the Document Feeder" on page 7-22
Note
For safety information, go to Getting Started/User Safety on the
User Documentation CD-ROM.
Jam at the Exit Cover
Follow these steps to clear the jam.
1. Lift the control panel.
Videos are available with instructions for clearing paper jams. Videos are located
on the User Documentation CD-ROM and at www.xerox.com/office/
c2424support.
2424-189

Paper Jams
WorkCentre® C2424 Copier-Printer
7-5
2. Remove paper from the output tray.
3. Open the exit cover.
2424-01
8
2424-019

Paper Jams
WorkCentre® C2424 Copier-Printer
7-6
4. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper are
removed.
5. If you did not find paper in Steps 1–4, lift up the green paper guides.
6. Remove jammed paper.
2424-020
2424-044
2424-021

Paper Jams
WorkCentre® C2424 Copier-Printer
7-7
7. Close the exit cover.
8. Close the control panel.
2424-022
2424-01
6

Paper Jams
WorkCentre® C2424 Copier-Printer
7-8
9. If you did not find paper in Steps 1–8, follow these steps.
a. Pull up the latch on the front of the system to open the front cover.
b. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper
are removed.
2424-023
2424-025

Paper Jams
WorkCentre® C2424 Copier-Printer
7-9
c. Close the front cover.
For additional information, go to www.phaserSMART.com.
Jam at the Exit Path
Follow these steps to clear the jam.
1. Lift the control panel.
2424-026
2424-189

Paper Jams
WorkCentre® C2424 Copier-Printer
7-10
2. Remove paper from the output tray.
3. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper are
removed.
2424-01
8
2424-05
3

Paper Jams
WorkCentre® C2424 Copier-Printer
7-11
4. Close the control panel.
5. Adjust the output tray for short or long media.
For additional information, go to www.phaserSMART.com.
For media shorter than 190 mm (7.5 in.), flip up the
paper stop.
For media longer than 297 mm (11.7 in.),
extend the output tray.
2424-01
6
2424-18
6
2424-056

Paper Jams
WorkCentre® C2424 Copier-Printer
7-12
Jam at the Front Cover
Follow these steps to clear the jam.
1. Pull up the latch on the front of the system to open the front cover.
2. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper are
removed.
2424-023
2424-025

Paper Jams
WorkCentre® C2424 Copier-Printer
7-13
3. Close the front cover.
4. If you did not find paper in Step 2, follow these steps.
a. Lift the control panel.
2424-026
2424-189

Paper Jams
WorkCentre® C2424 Copier-Printer
7-14
b. Remove paper from the output tray.
c. Open the exit cover.
2424-01
8
2424-019

Paper Jams
WorkCentre® C2424 Copier-Printer
7-15
d. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper
are removed.
e. Lift up the green paper guides.
f. Remove jammed paper.
2424-020
2424-044
2424-021

Paper Jams
WorkCentre® C2424 Copier-Printer
7-16
g. Close the exit cover.
h. Close the control panel.
2424-022
2424-01
6

Paper Jams
WorkCentre® C2424 Copier-Printer
7-17
5. If you did not find jammed paper in the previous steps, follow these steps.
a. Pull Tray 2 completely out of the system and remove the jammed paper.
b. Pull the jammed paper slowly out of the system. Verify that any torn pieces of paper
are removed.
c. Replace all trays and push each one completely to the back of the system.
Note
Use only the approved paper type, weight, and size for the tray. Custom size paper can
be used in Tray 1 only.
For additional information, go to www.phaserSMART.com.
2424-043
2424-028

Paper Jams
WorkCentre® C2424 Copier-Printer
7-18
Jam at Tray 2, 3, or 4
Follow these steps to clear the jam for the tray specified on the control panel.
1. Pull the tray specified on the control panel completely out of the system.
2. Remove the top sheet from the tray.
3. Verify that the paper is loaded correctly in the tray. Adjust the length and side paper
guides.
a. Press the sides of the length guide and slide the guide until the arrow on the guide
matches the appropriate paper size and clicks into place.
2424-043
2424-027

Paper Jams
WorkCentre® C2424 Copier-Printer
7-19
b. Slide the side guides until the arrows on the guides match the appropriate paper size
and the guides click into place.
Note
When the paper guides are adjusted correctly, there may be a small space between the
paper and the guides.
4. Remove jammed paper inside the system tray slot. Verify that any torn pieces of paper are
removed.
2424-003
2424-028

Paper Jams
WorkCentre® C2424 Copier-Printer
7-20
5. Insert the tray into the tray slot and push it completely to the back of the system.
6. If you did not find jammed paper in Step 4, follow these steps.
a. Pull up the latch on the front of the system to open the front cover.
2424-004
2424-023
