XEROX 1186 HARDWARE INSTALLATION
3102465
June 1987, .
.-
Lyric Rel~ase
--:-he' information in this document is subject to change
witho.Y:t notice and should not be construed as a
commitment by Xerox Corporation. While every effort has
been
made to ensure the accuracy of this document. Xerox
Corporation assumes no responsibility for any errors that
may appear.
Copyright © 1987 by Xerox Corporation.
All rights reserved.
"Copyright protection claimed includes all forms and
matters of copyrightable material and information now
allowed by statutory or judicial law or hereinafter granted,
including, without limitation, material generated from the
software programs which are displayed on the screen, such
as icons, screen display looks, etc."
IBM and IBM
PC are registered trademarks of International
Business Machines.
This manual
is set in Modern font, with text written and
formatted on Xerox Artificial Intelligence workstations,
using Xerox laser
printers to produce text masters.

PREFACE
Overview of the Manual
The 1186 Hardware Installation provides
information to aid you in installing the 1186
Artificial Intelligence workstation.
A form for documentation comments is included at
the end of this manual.
Organization of the Manual and How to Use It
This manual is divided into chapters, with most
chapters focusing on a parti.cular aspect
of
hardware installation. The manual is organized in
sequential order,
with preliminary tasks presented
first,
followed by subsequent tasks. .
All readers should carefully read Chapter 1,
Hardware Installation Overview, for background
and general
information. Continue by reading each
chapter in order:
• Chapter 2, Installing Standard and Optional
Components.
• Chapter 3, System Configuration Utility.
• Chapter 4, NewSystem Checkout.
In addition, several appendices are included to
provide a convenient location for frequently used
material (Appendix A, Hardware
Configuration)
and specific tasks not generally part of the
installation (Appendix B, Rigid Disk Drive
Installation and Appendix C, Control Store
Upgrade).
-------------------------------------------------------
}\t.KU}\ I j 60 nAKLJWAKt: 11\1) lALLA IIUI\i, L Y KIL Kt.Lt.A)t
III

Table of Contents
1. HARDWARE INSTALLATION OVERVIEW 1
Installation Scenario 2
Software Installation 2
2.
INSTALLING STANDARD AND
OPTIONAL COMPONENTS 5
Standard S~stem Comeonents 5
Electrical Reguirements 6
.safet~ Reguirements 6
Uneacking Standard Comeonents 8
Processor Unit
8
D.isplay 9
Ke~board
10
Oetical Pointer (Mouse) 11
Positioning Standard Comeonents 12
Installing Standard and Oetional Comeonents 13
Connecting the Optical Pointer (Mouse)
to the Ke~board 13
Connecting the Ke~board to the Disela~
15
Mesa Processor Board Uegrade Kit 16
Uneacking the Control Store Uegrade Kit 16
Installing the Control Store Uegrade Kit 17
"~. -' - , "U_' .• ',.'.,_TJ."'...,-Tt!......-,..'T.,.~'!'I! 'fT' 'fI"i' '. '"e1''''~l''fII!'IIt,I!''' • -" " "" ''''''.q' "~'"
",-.i \. V /"....... . I V V l j r-\. I \ ~ • w r'''\. \ _ I. '''..J , r--\ "- _.t" \ l , ~ f t I _ ," _ • _ _ _ ..... _

TABLE OF CONTENTS
VI
Remove MPB and Determine
IC Chips are to be Installed
Install Chips
Reinstall the MPB
Installing a Memory Expansion Board (MEB)
Recording
the Presence of an MEB
?ersonal
Computer Emulation (PCE) Board
Unpacking the PCE Board
Installing a PCE Board in a New System
Recordi ng the Presence of a
PCE Board
Upgrading an Existing System with a
PCE Board
Install the PCE Board
Set Hardware Configuration
Enable PCE
Run PCE Diagnostics
Connecting the Cables to the Processor Unit
Opening the Processsor Unit's Rear Cov
Floppy Disk Drive
Unpacking the Floppy Disk Drive
Installing the Floppy Disk Drive
Recording
the Presence of a
Floppy Disk Drive
Closing the Processor Unit's Rear Cover
Securing the Cables
Powering Up the System
System Configuration Utility and Diagnostics
XEROX 1186 HARDWARE INSTALLATION, LYRIC F

TABLE OF CONTENTS
3.
SYSTEM CONFIGURATION UTILITY
41
Checking Your S~stem Configuration
42
Keyboard
42
Rigid Disk 42
Memor~ Size
43
Ethernet Network Connection 44
PCE Board 45
Automatic Diagnostics 45
Running
the S~stem Configuration Utilit~
45
Install the S~stem Configuration Utilit~
45
Installation from Floppy Disks 46
Installation from the Network
46
Login
47
Show the Current Configuration 48
Set Configuration
48
Record
Your Configuration on
the Processor
51
4. NEW SYSTEM CHECKOUT 53
Runni ng New System Checkout from a Floppy Disk 54
Running New System Checkout from the Network 55
Installing the Rigid Disk Confidence Test from
Floppy Disks 56
Installing the Rigid Disk Confidence Test from
the Network 57
Running the Rigid Disk Confidence Test 57
At:.r\uA I 160 HAKUVvAKc 11\1') 1 ALLA IIUN. L Y KIL KtLtA')t VII

LIST OF ILLUSTRATIONS
2-22
Connecti ng Cable to Processor 34
2-23
Discarding the Shieeing Disk 35
2-24 Cable
Retention Bar Secured 37
2-25
Poweri ng On Processor 38
2-26
Brightness Control Knob
39
3-1
Circuit Board Slots on the Processor Unit
44
x XEROX 1186 HARDWARE INSTALLATION, LYRIC RELEASE

1. HARDWARE INSTALLATION
OVERVIEW
The 1186 Artificial Intelligence workstation is
functional when both the hardware and software
have been installed.
This chapter provides an overview of the hardware
installation procedures for the 1186 Artificial
Intelligence workstation. It also provides a
flowchart of the hardware installation scenario
with references to detailed installation instructions.
A Hardware Checklist,
which you will use in the
following chapters to record specific information
for hardware installation, is located in Appendix A,
Hardware Configuration,
for ease of reference. The
specific instructions
for filling in the Hardware
Checklist appear in the following chapters.
Atr(UX.1 H~o MAf<.UVIIAr\t II~~ lALLA 11UI\I. L'f r(1(. KCLtA=>c

1. HARDWARE INSTALLATION OVERVIEW
Installation Scenario
Hardware installation consists of installing and
configuring various standard and optional
components, and running system diagnostics.
Figure
1-1 on the following page, illustrates the
hardware installation scenario.
The left side of the flowchart presents the three
basic installation tasks, with references to relevant
documentation.
The right side of the flowchart presents the specific
steps of each basic task. The specific instructions for
completing each step are provided in the remaining
chapters of this installation guide. The chapters are
as follows:
• Chapter 2, Installing Standard and Optional
Components
• Chapter
3, System Configuration Utility
• Chapter 4, New System Checkout
Software Installation
2
The 1186 Artificial Intelligence workstation has
been preinstalled
with Xerox Lisp.
Software can be reinstalled on the 1186 after
hardware is installed, the configuration is defined,
and system checkout is completed.
See the 1186 User's Guide for detailed procedures
on software installation.
XEROX 1186 HARDWARE INSTALLATION, LYRIC RELEASE

1. HARDWARE INSTALLATION OVERVIEW
GENERAL INSTALLATION
TASKS
INSTALL SYSTEM
COMPONENTS
7186 Hardware
Installation Manual
Chapter2, Installing
Standard and Optional
Components
CONFIGURE SYSTEM
COMPONENTS
1186 Hardware·
Installation Manual
Chapter
3, System
Configuration
Utility
I
Y
RUN NEW SYSTEM
CHECKOUT
,..----
,
I
I
I
I
I
,
I
-----1
I
I
I
I
I
I
I
I
,
I
L ___ _
~----
I
I
I
I
I
I
,
I
I
-----~
~
I
I
I
I
,
I
I
I
I
,
L ___ _
r-----
I
I
1186 Hardware
Installation Manual
Chapter4, New
System Checkout
I------J
I
I
I
L ____ _
SPECIFIC INSTALLATION
STEPS
Unpack standard
system components
..
Unpack optional system
components
t
Installstandard and
optional components
i
Power on 1186system
+
Check system
configuration
+
Installsystem
configuration
utility
+
Logon and display
current configuration
"'
Change configuration
and recordchanges
Run new system
checkout +
Run rigid disk
confidence test
Figure 1-1. Hardware Installation Scenario
",', '''''~:': : "";' ," 11§,~-,,·,,- ..:.- ~ +. .,.---... 't ... ' ... ~ t.j"v".%?"-""~,,
A C. 1'\ V" i I 00 n 1-'1. (\ U vII r\ r.;;. .... ..; . .-,. ........ -, . ' .... ' '. - . .,. - . .;.. - _ .. '0 -' -

1. HARDWARE INSTALLATION OVERVIEW
(This page intentionally blank)
4 XEROX 1186HARDWARE INSTALLATION, LYRIC
RELEASE

2.
INSTALLING STANDARD AND
OPTIONAL COMPONENTS
Standard System Components
The 1186consists of six basic system components:
• A processor unit
• Adisplay
• A keyboard
• An optical pointer
• A floppydisk drive
• A memory expansion board
Each component is individually packaged. In
addition, several optional system components are
available:
• A Personal Computer Emulation (PCE) board
• An Ethernet transceiver
• A drop cable
• A rigid disk drive (See Appendix S, Rigid Disk
Drive Installation.)
The following is a list of what is contained in each
box
of standard and optional components.
• Processor unit box:
-Processor
unit
-Powercord
-Screwdriver (packaged
with power cord)
-Hardware unpacking instructions (located
on
top of thestyrofoam packing)
• Display box:
-Display
Display powercord
-Display signal cable
-Keyboard cable (attached to the display)
• Floppy disk drive box:
-FIOppr disk drive
Signa cable
-Set
of four clips
~=-".,<t~ A"'i , __
X.~RUX. -II hn nAKUII'VAr-tt. \I\J:"l1 ~L.LJo\ j lUI'll. ~ • ;\i~ ;;:::.:;,.::

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
• Memory expansion box:
- Memory expansion printed wiring board
• Software documentation
• Installation kit:
-1186Hardware Installation Manual
-Software
-Keyboard
Optical Pointer(Mouse)
-Mouse pads
-8K Control Store Upgrade Kit
• Personal computer option:
- PCE board
If you did not receive the six basic components, any
optional components you ordered, the
accompanying documentation, or the software, call
your Xerox marketing representative.
Electrical Requirements
Voltage requirementsare as follows:
• 115V United States/Canada
• 230V Europe
Safety Requirements
6
Your Xerox 1186 Artificial Intelligence workstation
has been designed and tested to meet strict safety
requirements. These include safety agency (UL and
CSA) examination and approval, as well as
compliance to established environmental and
safety standards. Follow these
recommendations
for the continued safe operation and performance
of your computer.
• Always connect the computer to a properly
grounded power source receptacle.
XEROX 1186HARDWARE INSTALLATION, LYRIC RELEASE

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
WARNING
Improper connection of the computer ground
conductorcan result in risk of electrical shock.
• Never use a grounded adapter plug to connect
the computer to a power source receptacle that
lacks a ground connectionterminal.
• Never attempt any maintenance functions that
are not specifically called for in this installation
guide.
• Never remove any covers or guards that are
fastened
with screws, except as explicitly
instructed to do so in this installation guide. If
you are instructed to remove any covers or
guards that are fastened ,with screws, always
follow the instructions exactly as they are
presented.
• Never override or "cheat" electrical or
mechanical interlock devices.
• Always exercise care in moving or relocating the
workstation. Refer to this installation guide for
correct procedures for lifting and moving the
workstation.
• Never move a workstation when the processor is
powered up.
• Never operate the workstation if you notice
unusual noises
or odors. Disconnect the power
cord from the power source receptacle and call
your Xerox service representative to correct the
problem.

L.. IN) I ALLINU ) I ANUAKLJ AND OPTIONAL COMPONENTS
unpacking Standard Components
Processor Unit
The following procedures for unpacking the basic
components should be
performed sequentially.
1. Unpack the box labeled Xerox 1186 Processor
Unit by tearing the perforations marked on the
box and lifting the top portion of the box off.
Fold down the styrofoam packing insert at the
front of the processor unit (Figure 2-1).
Figure2-1. Front View of Processor
2. Face the front of the processor unit (look for the
Xerox label), and grip the processor by placing
your hand in
the groove located under the front
cover of the processor.
3. Carefully slide the processor unit halfway off
the styrofoam.
4. Tilt the processor unit until the bottom of it
touchesthe floor.
8 XEROX
1186 HARDWARE INSTALLATION, LYRIC RELEASE

Display
2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
S. Hold the processor unit at an angle that allows
the packing materials to be pulled away and
out from under the processor.
6. Discard the packing materials and then set the
processor unit upright.
1. Unpack the box labeled Xerox Display (Figure
2-2) by opening the box and then placing it on
its side,
so that the display is resting on the
styrofoam packing.
Figure2-2. DisplayBox
2. Grasp the styrofoam packing and slide out the
display.
3. Discard the packing.
~ .-~' -~ ""':""'" ,. ~"'-tj,'~ ~ <'Ii,....-"""" *• .,~.~, .. ~ ..... ~.'* .. "~ .. -- ""'~""'~·.""F
"'~ _",\,-, Ai. 0", .--,i.r-\.-\..., 'I II I""\f'\ __ ,i".,J • r-. .... -r-" J • '..." .-\i, _ . ,';,. j ...... "lI1. __ .!...: .• ,"; ~
•

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
Keyboard
1. Unpack the keyboard and keyboard cable from
the box labeled Xerox 1186 Installation Kit
(Figure 2-3).
KEYBOARD
Figure 2-3. Contents of Installation Kit
2. Remove the plastic wrapping and styrofoam
packing
from the keyboard.
~~ ____________________________________ ~: ____ q_~~card .!h~.Q~cki_~_g_: _______________ ~ _______________________ -------
10
4. Record the type of keyboard on the Hardware
Checklist
in Appendix A, Hardware
Configuration. Keyboard types are
defined as
follows:
• AI keyboard has 28 special function keys.
• US keyboard has 10 keys on the bottom row
between the left and right shift keys.
• European keyboard has 11 keys between the
left and right shift keys.
• Japanese keyboard has Kanji (Japanese)
characters on the keycaps.
XEROX 1186HARDWARE INSTALLATION, LYRIC RELEASE

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
Optical Pointer (Mouse)
1. Unpack the mouse and mouse pads (both the
optical paper and mechanical plastic pads) from
the box labeled Xerox
1186 Installation Kit
(Figure
2-4).
Figure 2-4. Contents of Optical PointerBox
.
2. Remove the plastic wrapping from the mouse.
3. Discard the packing.
., "

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
positioning Standard Components
u
12
1. Place the display, keyboard, optical pointer, and
mouse pads, on a tabletop,
as shown in Figure
2-5.
Jj]
"
Figure 2-5. Positioning System Components
2. Place the processor unit adjacent to the table,
within 8 feet of agrounded wall outlet.
Note: Keep all system components, (standard and
optional) accessible until all connections are
complete.
XEROX 1186 HARDWARE INSTALLATION, LYRIC RELEASE

2. INSTALLING STANDARD AND OPTIONAL COMPONENTS
Installing Standard and Optional Components
The following procedures for installing the
standard and optional components shou-Id be
performed sequentially.
Connecting the Optical Pointer(Mouse) to the Keyboard
1. Connect the cable that is attached to the optical
pointer to the connector located at the rear
center
of the keyboard (Figure 2-6). The grooves
of the connector must be facing down.
Note: When properly connected,
the mouse
connector fits securely and
is flush with
the rear of the keyboard.
MOUSE
CONNECTOR
' ••• i ••••• cx::J
11111111111
GILtlllllr:1
I ! I 1 II I I I 1I
m
~1 11 I I I I 111 I ~ g
Figure 2-6. Connecting OpticalPointerto Keyboard
2. Determine on which side of the keyboard the
mouse will be placed for ease of use. location
of the mouse is generally correlated with a
person being I
eft- or right-handed. For
example, a right-handed person generally
prefers the mouse placed on the right side.
Xt:ROX. 'I '\86 rlARDWARE INSTALLATION. LY RIC. RtLtA)t:
