Xerox FS-C8008DN User manual

FS-C8008N
FS-C8008DN
Operation Guide
Color Laser Printer
FS-C8008N
FS-C8008N

Cautions
• To prevent the printer from tipping over, the optional CA-31B caster kit must be installed when the printer is installed
with more than one paper feeder or a duplex unit. For detailed information on the CA-31B caster kit, see page A-11.
• Do not block the cooling air in and out vents and the exhaust duct against walls or with other objects. If the flow of
cooling air is blocked, heat will be built up in the printer, and there will be a risk of fire.
Note
Moisture condensation inside the printer can cause blurred printing. When a heavily blured printing occurred, turn printer
power off while the power cable is plugged to power. Then, open the front cover, draw the paper transfer unit fully out, and
draw the primary transfer unit out. Allow approximately 2 hours before use.

i
Please read the Operation Guide before using the printer. Keep it close to the printer for
easy reference.
The sections of this guide and parts of the printer marked with symbols are safety warnings meant to protect the user,
other individuals and surrounding objects, and ensure correct and safe usage of the printer. The symbols and their
meaningsare indicated below.
WARNING:Indicates that serious injury or even death may result from insufficient attention to or incorrect
compliance with the related points.
CAUTION: Indicates that personal injury or mechanical damage may result from insufficient attention to or
incorrect compliance with the related points.
Symbols
The symbol indicates that the related section includes safety warnings. Specific points of attention are indicated
inside the symbol.
....................[General warning]
....................[Warning of danger of electrical shock]
....................[Warning of high temperature]
The symbolindicatesthattherelatedsectionincludesinformationonprohibitedactions.Specificsoftheprohibited
action are indicated inside the symbol.
....................[Warning of prohibited action]
....................[Disassembly prohibited]
The symbolindicates thattherelated sectionincludesinformationonactions whichmustbe performed.Specifics
of the required action are indicated inside the symbol.
....................[Alert of required action]
....................[Remove the power plug from the outlet]
....................[Always connect the printer to an outlet with a ground connection]
Please contact your service representative to order a replacement if the safety warnings in the guide are illegible or if
the guide itself is missing. (fee required)

ii
Caution
NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION.
Notice on Software
SOFTWAREUSEDWITHTHISPRINTERMUSTSUPPORTTHEPRINTER'SEMULATIONMODE.Theprinter
is factory-set to emulate the PCL. The emulation mode can be changed by following the procedures described in
Chapter3.
Notice
The information in this guide is subject to change without notification. Additional pages may be inserted in future
editions. The user is asked to excuse any technical inaccuracies or typographical errors in the present edition.
No responsibility is assumed if accidents occur while the user is following the instructions in this guide. No responsi-
bility is assumed for defects in the printer's firmware (contents of its read-only memory).
This guide, any copyrightable subject matter sold or provided with or in connection with the sale of the page printer,
are protected by copyright. All rights are reserved. Copying or other reproduction of all or part of this guide, any
copyrightablesubject matterwithoutthe priorwritten consentof KyoceraMitaCorporation isprohibited.Any copies
madeofallorpartof thisguide,anycopyrightablesubjectmustcontainthesamecopyrightnoticeasthematerialfrom
which the copying is done.
Regarding Tradenames
PRESCRIBE is a registered trademark of Kyocera Corporation. KPDL is trademark of Kyocera Corporation.
Diablo 630 is a product of Xerox Corporation. IBM Proprinter X24E is a productof International Business Machines
Corporation. Epson LQ-850 is a product of Seiko Epson Corporation.
Hewlett-Packard, PCL, and PJL are registered trademarks of Hewlett-Packard Company. Centronics is a trade name
of Centronics Data Computer Inc. PostScript is a registered trademark of Adobe Systems Incorporated. Macintosh is
a registered trademark of Apple Computer, Inc. Microsoft, Windows, and Windows NT are registered trademarks of
Microsoft Corporation. PowerPC and Microdrive are trademarks of International Business Machines Corporation.
CompactFlashisatrademarkofSanDiskCorporation.ENERGY STARis aU.S.registeredmark.Allotherbrandand
product names are registered trademarks or trademarks of their respective companies.
This Kyocera Mita page printer uses PeerlessPrintXL to provide the HP LaserJet compatible PCL 6 language emula-
tion. PeerlessPrintXL is a trademarkof The Peerless Group, Redondo Beach, CA 90278, U.S.A.
This product was developed using the Tornado™ Real Time Operating System and Tools from Wind River Systems.
This product contains UFST™ and MicroType® from Agfa Monotype Corporation.

iii
IBM PROGRAM LICENSE AGREEMENT
THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS ("PRO-
GRAMS") WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION ("IBM"). THIS
DOCUMENT DEFINES THE TERMS AND CONDITIONS UNDER WHICH THE SOFTWARE IS BEING
LICENSED TO YOU BY IBM. IF YOU DO NOT AGREE WITH THE TERMS AND CONDITIONS OF THIS
LICENSE,THENWITHIN14DAYSAFTERYOURACQUISITIONOFTHEDEVICEYOUMAYRETURNTHE
DEVICE FOR A FULL REFUND. IF YOU DO NOT SO RETURN THE DEVICE WITHIN THE 14 DAYS, THEN
YOU WILL BE ASSUMED TO HAVE AGREED TO THESE TERMS AND CONDITIONS.
The Programs are licensed not sold. IBM, or the applicable IBM country organization, grants you a license for the
ProgramsonlyinthecountrywhereyouacquiredthePrograms.Youobtainnorightsotherthanthosegrantedyouunder
this license.
The term "Programs" means the original and all whole or partial copies of it, including modified copies or portions
mergedinto otherprograms.IBMretains title tothePrograms. IBM owns, or haslicensedfrom the owner,copyrights
in the Programs.
1. License
Underthis license,you may usethe Programsonly withthedevice onwhichthey areinstalled andtransfer possession
of the Programs and the device to another party.
If you transfer the Programs, you must transfer a copyof this license and any other documentation to the other party.
Your license is then terminated. The other party agrees to these terms and conditions by its first use of the Program.
You may not:
1) use, copy, modify, merge, or transfer copies of the Program except as provided in this license;
2) reverse assemble or reverse compile the Program; or
3) sublicense, rent, lease, or assign the Program.
2. Limited Warranty
The Programs are provided "AS IS."
THERE ARE NO OTHER WARRANTIES COVERING THE PROGRAMS (OR CONDITIONS), EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
Some jurisdictions do not allow the exclusion of implied warranties, so the above exclusion may not apply to you.
3. Limitation of Remedies
IBM's entire liability under this license is the following;
1) Forany claim (includingfundamentalbreach), in anyform, related in any waytothislicense, IBM's liability will
be for actual damages only and will be limited to the greater of:
a) the equivalent of U.S. $25,000 in your local currency; or
b) IBM's then generally available license fee for the Program
ThislimitationwillnotapplytoclaimsforbodilyinjuryordamagestorealortangiblepersonalpropertyforwhichIBM
is legally liable.
IBM will not be liable for any lost profits, lost savings, or any incidental damages or other economic consequential
damages,evenifIBM,oritsauthorized supplier,has beenadvised ofthe possibilityof suchdamages. IBM willnot be
liable for any damages claimed by you based on any third party claim. This limitation of remediesalso applies to any
developer of Programs supplied toIBM. IBM's and the developer's limitations of remedies are not cumulative. Such
developer is an intended beneficiary of this Section. Some jurisdictions do not allow these limitations or exclusions,
so they may not applyto you.
4. General
You may terminate your license at any time. IBM may terminate your license if you fail to comply with the terms and
conditions of this license. In either event, you must destroy all your copies of the Program. You are responsible for
paymentofanytaxes,includingpersonalpropertytaxes,resultingfromthislicense.Neitherpartymaybringanaction,
regardlessofform,morethantwoyearsafterthecauseofactionarose.IfyouacquiredtheProgramintheUnitedStates,
this license is governed by the laws of the State of New York. If you acquired the Program in Canada, this license is
governedbythelawsoftheProvinceofOntario.Otherwise,thislicenseisgovernedbythelawsofthecountryinwhich
you acquired the Program.
Typeface Trademark Acknowledgement
All resident fonts in this printer are licensed from Agfa Corporation.
Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG. ITC Avant Garde Gothic, ITC
Bookman, ITC ZapfChanceryand ITC Zapf Dingbats are registered trademarks of International Typeface Corpora-
tion.

iv
Agfa Monotype License Agreement
1) "Software" shall mean the digitally encoded, machine readable, scalable outline data as encoded in a special
format as well as the UFST Software.
2) You agree to accept a non-exclusive license to use the Software to reproduce and display weights, styles and
versions of letters, numerals, characters and symbols ("Typefaces") solely for your own customary business or
personal purposesat the address stated on the registration card you return to Agfa Japan. Under the terms of this
License Agreement, you have the right to use the Fonts on up to three printers. If you need to have access to the
fontson more thanthree printers, youneed to acquireamulti-user license agreement whichcanbe obtained from
AgfaJapan. AgfaJapanretainsallrights,titleandinterest totheSoftwareandTypefacesand norightsare granted
to you other than a License to use the Software on the terms expressly set forth in this Agreement.
3) To protectproprietaryrightsof AgfaJapan, youagreeto maintaintheSoftware andotherproprietaryinformation
concerningthe Typefaces instrictconfidence andto establish reasonableprocedures regulating accessto and use
of the Software and Typefaces.
4) You agree not to duplicate or copy the Software or Typefaces, except that you may make one backup copy. You
agree that any such copy shall contain the same proprietary notices as those appearing on the original.
5) ThisLicenseshallcontinueuntilthelastuseoftheSoftwareandTypefaces,unlesssoonerterminated.ThisLicense
may be terminated by Agfa Japan if you fail to comply with the terms of this License and such failure is not
remedied within thirty (30) days after notice from Agfa Japan. When this License expires or is terminated, you
shall either return to Agfa Japan or destroy all copies of the Software and Typefaces and documentation as
requested.
6) You agree that you will not modify, alter, disassemble, decrypt, reverse engineer or decompile the Software.
7) Agfa Japan warrants that for ninety (90) days after delivery, the Software will perform in accordance with Agfa
Japan-published specifications, and the diskette will be free from defects in material and workmanship. Agfa
Japan does not warrant that the Software is free from all bugs, errors and omissions.
THE PARTIES AGREE THAT ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY, ARE
EXCLUDED.
8) YourexclusiveremedyandthesoleliabilityofAgfaJapaninconnectionwiththeSoftwareandTypefacesisrepair
or replacement of defective parts, upon their return to Agfa Japan.
IN NO EVENT WILL AGFA JAPAN BE LIABLE FOR LOST PROFITS, LOST DATA, OR ANY OTHER
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES CAUSED BY ABUSE OR MIS-
APPLICATION OF THE SOFTWARE AND TYPEFACES.
9) New York, U.S.A. law governs this Agreement.
10) You shallnot sublicense,sell, lease,or otherwisetransferthe Softwareand/or Typefaceswithout theprior written
consent of Agfa Japan.
11) Use, duplication or disclosure by the Government is subject to restrictions as set forth in the Rights in Technical
Data and Computer Software clause at FAR 252-227-7013, subdivision (b)(3)(ii) or subparagraph (c)(1)(ii), as
appropriate.Further use,duplicationor disclosureissubjecttorestrictionsapplicabletorestricted rightssoftware
as set forth in FAR 52.227-19 (c)(2).
12) YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT, AND AGREE
TO BE BOUND BY ITS TERMS AND CONDITIONS. NEITHER PARTYSHALL BE BOUND BY ANY
STATEMENT OR REPRESENTATION NOT CONTAINED IN THIS AGREEMENT. NO CHANGE IN THIS
AGREEMENTISEFFECTIVEUNLESSWRITTENANDSIGNEDBYPROPERLYAUTHORIZEDREPRE-
SENTATIVES OF EACH PARTY. BY OPENING THIS DISKETTE PACKAGE, YOU AGREE TO ACCEPT
THE TERMS AND CONDITIONS OF THIS AGREEMENT.

v
FCC statement (for users in the United States)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including inter-
ference that may cause undesired operation.
Note:
Thisequipment has beentestedand foundto comply withthelimits for aClass B digitaldevice, pursuant to Part15 of
theFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is not
guaranteethat interferencewill notoccurin aparticular installation.If thisequipment doesnot causeharmful interfer-
ence toradioortelevision reception, which can be determined by turning the equipment offandon,the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that used for the receiver.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved bythe manufacturer for compliance couldvoid the user's authority
to operate the equipment. Shielded circular cables should be used for interfacing with the computer.
Cautions to the user:
• Any modifications without prior permission of Kyocera may cause harmful interference.
• If any modifications or changes are made to this equipment without prior permission of Kyocera, Kyocera as the
manufacturer does not guarantee the compliance with the FCC Rules.
• The use of equipment that does not comply with the FCC Rules is prohibited.

vi
Important Notes for Interface connectors
Be sure to power off the printer before connecting or disconnecting an interface cable. For protection against static
electricitydischargetotheprinter'sinternalelectronicsthroughtheinterfaceconnector(s),coveranyinterfaceconnec-
tor that is not in use with the protective cap supplied.
Use shielded interface cables.
Safety information
Laser safety:
This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS)
Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968. This means
that the printer does not produce hazardous laser radiation. Because radiation emitted inside the printer is completely
confinedwithinthe protectivehousingsand externalcovers,the laserbeamcannot escapefrom theprinter duringany
phase of user operation.
Laser notice:
This printer is certified in the United States to conform to the requirements of DHHS 21 CFR Subchapter for Class I
(1) laser products, and is certified elsewhere as a Class I laser product conformingto the requirements of IEC 825-1.
Cautions:
• Laser radiation will open. DO NOT STARE INTO THE BEAM OR VIEW THE BEAM DIRECTLY WITH
OPTICAL INSTRUMENTS.
• Use of controls or adjustments or performance of procedures other than those specified herein may result in haz-
ardousradiation exposure.
Cautionary Labels
Inside
For Europe, Asia,
and other countries
For U.S.A. and Canada
The printer bears any of the following labels.

vii
U.S. CDRH regulations
The Center of Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented
regulationsforlaser productsonAugust 2,1976.Theseregulationsapply to laserproductsmanufactured onandafter
August 1, 1976. Compliance is mandatory for products marketed in the United States. A label indicating compliance
with the CDRH regulations must be attached to laser products marketed in the United States.
Ozone concentration
Theprintersgenerateozonegas(O3)whichmayconcentrateintheplaceofinstallationandcauseanunpleasantsmell.
To minimize the concentration of ozone gas to less than 0.1 ppm, we recommend you not to install the printer in a
confined area where ventilation is blocked.

viii
Declaration of Conformity for U.S.A.
Model name: Color Laser Printer FS-C8008N
Trade name: Kyocera Mita
Responsible party: Kyocera Mita America, Inc.
Address: 225 Sand Road PO Box 40008 Fairfield, New Jersey 07004-0008, U.S.A.
Telephone: [phone]
Fax: [phone]
Contact person for technical matter: Ryozo Kojima
Phone: [phone]
Manufacturer: Kyocera Mita Corporation Tamaki Plant
Manufacturer’s address: 704-19, Nojino, Tamaki-cho, Watarai-gun, Mie-ken 519-0497, Japan
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including inter-
ference that may cause undesired operation.
Themanufactureranditsmerchandisingcompaniesretainthefollowingtechnicaldocumentationinanticipationofthe
inspection that may be conducted by the authorities concerned.
User’s instruction that conforms to the applicable specifications.
Technical drawings.
Descriptions of the procedures that guarantee the conformity.
Other technical information.
Kyocera Mita America Inc.
CE Marking Directive
According to Council Directive 89/336/EEC and 73/23/EEC
Manufacturer: Kyocera Mita Corporation Tamaki Plant
Manufacturer’s address: 704-19, Nojino, Tamaki-cho, Watarai-gun, Mie-ken 519-0497, Japan
Declares that the product
Product name: Color Laser Printer
Model number: FS-C8008N
(as tested with enhancement optional units; Duplex unit PD-800, Paper Feeder PF-30A, Document
Finisher DF-31 etc.)
Conforms to the following product specifications:
EN 55 022: 1998 Class B
EN 61 000-3-2: 1995
EN 61 000-3-3: 1995
EN 55 024: 1998
EN 60 950: 1992+A1+A2+A3+A4+A11
EN 60 825-1: 1994+A11
Themanufactureranditsmerchandisingcompaniesretainthefollowingtechnicaldocumentationinanticipationofthe
inspection that may be conducted by the authorities concerned.
User’s instruction that conforms to the applicable specifications.
Technical drawings.
Descriptions of procedures that guarantee conformity.
Other technical information.

ix
Declaration of Conformity for Australia
Manufacturer: Kyocera Mita Corporation Tamaki Plant
Manufacturer’s address: 704-19, Nojino, Tamaki-cho, Watarai-gun, Mie-ken 519-0497, Japan
declares that the product
Product name: Color Laser Printer
Model name: FS-C8008N
Descriptionofdevices:This PagePrinterModelFS-C8008Nisthe31ppm(monochrome)/8ppm(color),A4sizeand
utilized plane paper; laser; dry toner; etc. The printer can be equipped with several enhancement optional units as a
paper feeder as PF-30A, a duplex unit as PD-800, a mailbox/sorter as SO-30, IB-21E, etc.
conforms to the following product specifications:
AS/NZS 3548: 1995 (EN 55 022: 1998 Class B)
IEC60950 (EN 60 950: 1992+A1+A2+A3+A4+A11)
IEC60825-1 (EN 60 825-1: 1994+A11)
Themanufactureranditsmerchandisingcompaniesretainthefollowingtechnicaldocumentationinanticipationofthe
inspection that may be conducted by the authorities concerned.
User’s instruction that conforms to the applicable specifications
Technical drawings
Descriptions of procedures that guarantee conformity
Other technical information
The manufacturer has been employed with ISO9001 scheme. JQA and BS have attested the manufacturer.
Kyocera Mita Australia Pty., Ltd.
6-10 Talavera Road, North Ryde, NSW 2113, Australia
Telephone: [phone]
Fax: [phone]
Canadian Department of Communications compliance statement
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformité aux normes du ministere des Communications du Canada
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada.
ISO 7779
Maschinenlärminformationsverordnung3.GSGV,18.01.1991:DerhöchsteSchalldruckpegelbeträgt 70dB(A) oder
weniger gemäß ISO 7779.
Disclaimer
Kyocera Mita will not be liable to customers or any other person or entity for any loss or damage caused or alleged to
be caused directly or indirectly by equipment sold or furnished by us, including but not limited to, any interruption of
service, loss of business oranticipatory profits, or consequential damages resulting from the use or operation of the
equipment or software.

x
ENERGY STAR®
Asan ENERGY STAR Partner, we have determined that this product meets the ENERGY STAR
guidelines for energy efficiency.
The basic objective of the ENERGY STAR Program is to reduce environmental pollution by
encouraging the manufacture and sale of equipment that uses energy more efficiently.
This printer is equipped with a sleep timer function that conforms with the standards of the ENERGY STAR Program.
Thisfunctionmakesitpossibletoreducetheamountofelectricalpowerconsumedbytheprinter.Formaximumpower
savings, turn off the printer’s power supply when not using the printer for extended periods of time.
For details on the sleep timer function and printer power consumption, refer to this manual.
Initial settings of the sleep timer function and power saved using the sleep timer function:
( ): ENERGY STAR program guideline
Group for Energy Efficient Appliances (GEEA)
The goal of GEEA is efficient use of energy. This product has a high-efficiency profile
and meets the criteria for receiving the GEEA-Label.
( ): GEEA criteria
Initial sleep mode setting Power consumption in
sleep mode
FS-C8008N 30 minutes (30 minutes) 22 W (35 W) [for U.S.A. and Canada]
26 W (35 W) [For Europe, Asia, and
other countries]
Initial sleep mode setting Power Consumption
Power off Sleep mode
30 min. (30 min.) 1 W (1 W) 26 W (30 W)

xi
Installation Precautions
Environment
CAUTION
• Avoidplacingtheprinteronorinlocationswhichareunstableornotlevel.Suchlocationsmay
cause the printer to fall down or fall over. This type of situation presents a danger of personal
injury or damage to the printer. .......................................................................................
• Avoid locations with humidity or dust and dirt. If dust or dirt becomes attached to the power
plug, clean the plug to avoid the danger of fire or electrical shock. ......................................
• Avoid locations near radiators, heaters, or other heat sources, or locations near flammable
items, to avoid the danger of fire. ....................................................................................
• To keep the printer cool and facilitate changing of parts and maintenance, allow access space
as shown below. Leave adequate space, especially around the side cover, to allow air to be
properly ventilated out of the printer. ...............................................................................
• Alwaysuse thecasterstopperstostabilizetheprinter once it is in placeto keep it from moving
and/or falling over and causing injury. .............................................................................
Other Precautions
• Adverse environmental conditions may affect the safe operation and performance of the
printer. Install in an air-conditioned room (recommended room temperature: around 20 °C,
humidity: around 65 % RH) and avoid the following locations when selecting a site for the
printer.
• Avoid locations near a window or with exposure to direct sunlight.
• Avoid locations with vibrations.
• Avoid locations with drastic temperature fluctuations.
• Avoid locations with direct exposure to hot or cold air.
• Avoid poorly ventilated locations.
• If the floor is delicate against casters, when this product is moved after installation, the floor
material may be damaged.
Left: 50 cm
(19-11/16 inches)

xii
Power Supply/Grounding the Printer
WARNING
• DO NOT use a power supply with a voltage other than that specified. Avoid multiple connec-
tions in the same outlet. These types of situations present a danger of fire or electrical shock...
• Plugthepowercordsecurelyintotheoutlet.Ifmetallicobjectscomeincontactwiththeprongs
on the plug, it may cause a fire or electric shock. ...............................................................
• Always connect the printer to an outlet with a ground connection to avoid the danger of fire or
electrical shock in case of anelectric short. If an earth connection isnot possible, contact your
service representative. ...................................................................................................
Other Precautions
• Connect the power plug to the closest outlet possible to the printer.
Handling of Plastic Bags
WARNING
• Keep the plastic bags that are used with the printer away from children. The plastic may cling
to their nose and mouth causing suffocation. ............................................................................

xiii
Precautions for Use
Cautions when Using the Printer
WARNING
• DONOTplacemetallicobjectsorcontainerswithwater(flower vases,flowerpots,cups,etc.)
onornear the printer. This type of situation presents a danger of fire orelectrical shock should
they fall inside. .............................................................................................................
• DONOTremoveanyofthecoversfromtheprinterasthereisadangerofelectricalshockfrom
high voltage parts inside the printer. ................................................................................
• DO NOT damage, break or attempt to repair the power cord. DO NOT place heavy objects on
the cord, pull it, bend it unnecessarily or cause any other type of damage.These types of situa-
tions present a danger of fire or electrical shock. ...............................................................
• NEVER attempt to repair or disassemble the printer or its parts as there is a danger of fire,
electricalshockordamagetothelaser.Ifthelaserbeamescapes,thereis a dangerofitcausing
blindness. ....................................................................................................................
• If the printer becomes excessively hot, smoke appears from the printer, there is an odd smell,
or any other abnormal situation occurs, there is a danger of fire or electrical shock. Turn the
power switch OFF ({) immediately, remove the power plug from the outlet and contact your
service representative. ...................................................................................................
• If anything harmful (paper clips, water, other fluids, etc.) falls into the printer, turn the power
switchOFF({)immediately.Next,removethepowerplugfromtheoutlettoavoidthedanger
of fire or electrical shock. Then contact your service representative. ...................................
• DO NOT remove or connect the power plug with wet hands, as there is a danger of electrical
shock. .........................................................................................................................
• ALWAYS contact your service representative for maintenance or repair of internal parts. ......
CAUTION
• DONOTpullthepowercord whenremovingitfromtheoutlet. If the powercordispulled,the
wiresmay becomebrokenandthereisadangeroffireorelectrical shock.(ALWAYSgraspthe
power plug when removing the power cord from the outlet.) ..............................................
• ALWAYSremovethepowerplugfromtheoutletwhenmovingtheprinter.Ifthepowercordis
damaged, there is a danger of fire or electrical shock. ........................................................
• If the printer will not beused for a short period of time (overnight, etc.), turn the powerswitch
OFF({).Ifitwillnotbeusedforanextendedperiodoftime(vacations,etc.),removethepower
plug from the outlet for safety purposes during the time the printer is not in use. ...................
• Forsafetypurposes.ALWAYSremovethepower plugfromtheoutletwhenperformingclean-
ing operations. .............................................................................................................
• If dust accumulates within the printer, there is a danger of fire or other trouble. It is therefore
recommendedthatyouconsultwithyourservicerepresentativeinregardtocleaningofinternal
parts. This is particularly effectiveif accomplished prior to seasons of high humidity. Consult
withyourservicerepresentativeinregardtothecostofcleaningtheinternalpartsoftheprinter.

xiv
Other Precautions
• DO NOT place heavy objects on the printer or cause other damage to the printer.
• DO NOT open the front cover, turn off the main switch, or pull out the power plug during
printing.
• During printing, some ozone is released, but the amount does not cause any ill effect to one's
health.If,however,theprinterisusedoveralongperiodoftimeina poorlyventilatedroom or
when printing an extremely large number of copies, the smell may become unpleasant. To
maintain the appropriate environmentfor print work, it is suggested thatthe room be properly
ventilated.
• DO NOT touch electrical parts, such as connectors or printed circuit boards. They could be
damaged by static electricity.
• DO NOT attempt to perform any operations not explained in this handbook.
• CAUTION:Useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespec-
ified herein may result in hazardous radiation exposure.
• Iftheprinterwillnotbeusedforanextendedperiodoftime,removethepaperfromthecassette,
return it to its original package and reseal it.
Cautions for Toner Handling
CAUTION
• Do not incinerate toner and toner containers. Dangerous sparks may cause burn. ..................
• Never open the toner container........................................................................................
• Makesure not to inhale the toner,and not to rub your eyes or touch your mouth with thehands
stained with the toner. And make sure not to stick to your skin. ................................................
• For the disposal of old toner container, consult your dealer. Or dispose of the toner or toner
containers in accordance with Federal, State and Local rules and regulations. ......................
• Keep away the toner container. .......................................................................................

xv
For More Information...
Item Description
Installation Guide
(paper manual) Describes procedures from printer setup to printing a test page.
Quick Reference Guide
(paper manual) Describes common information about the printer such as load- ing paper, understanding messages, etc. This guide can be
retained in the plastic pocket at the printer.
The following documents are stored in the CD-ROM as PDF documents.
Operation Guide (this manual) Guides youthrough topics concerningtheoperations andmain-
tenance of the printer.
KX Printer Drivers Operation Guide Describes how to install and set the printer driver.
PRESCRIBE Commands Technical
Reference PRESCRIBE is the native language of the Kyocera Mita printers. This Technical Reference contains the information
about how the printing is performed using the PRESCRIBE
commands as well as the font and emulation description. Also
includedis a list of permanentparametersandtheirexplanation
needed when customizing your printer.
PRESCRIBE Commands Command
Reference Gives a detailed explanation of the PRESCRIBE command syntax and parameters with the aid of print examples.

xvi
Guide to the Operation Guide
This Operation Guide has the following chapters:
Chapter 1 Introduction
This chapter explains printer features and the names of parts.
Chapter 2 Handling Paper
This chapter explains the types of paper that can be used with the printer.
Chapter 3 Using the Operator Panel
This chapter explains the message display, indicators and keys on the operator panel, and
how to make various settings from the operator panel.
Chapter 4 Troubleshooting
This chapter explains how to handle printer problems that may occur, such as paper jams.
Chapter 5 Maintenance
This chapter explains how to replace the toner container and how to care for your printer.
Appendix A Options
This appendix introduces the available options to be used with the printer.
Appendix B Computer Interface
This appendix explains the pin assignment and specifications for the printer’s parallel
interface, USB interface, and serial interface.
Appendix C Technical Specifications
This appendix lists the printer’s specifications.

Contents
xviii
Contents
Chapter 1 Introduction
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
1.1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
1.1.2 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
1.1.3 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-3
1.1.4 Networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.2 Parts and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
1.2.1 Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5
1.2.2 Internal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-7
1.2.3 Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-9
Chapter 2 Handling Paper
2.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.1.1 Available paper types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.1.2 Paper specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2.1.3 Minimum and Maximum Paper Sizes . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.1.4 Recommended Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.2 Selecting the Right Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
2.2.1 Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
2.2.2 Paper properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5
2.2.3 Other properties of paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
2.3 Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
2.3.1 Loading Paper into the Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
2.3.2 Loading Paper into the MP (Multi-Purpose) Tray . . . . . . . . . . . . . . . 2-10
2.4 Special Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
2.4.1 Selecting the Special Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-11
Chapter 3 Using the Operator Panel
3.1 Understanding the Operator Panel . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.1 Message Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
3.1.2 Indicators in Message Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3
3.1.3 Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6
3.2 Using the Menu Selection System . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.2.1 Menu Selection System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8
3.2.2 Menu System Road Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10
3.3 Menu Map and Status Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15
3.3.1 Printing a Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
3.3.2 Printing a Status Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17
3.4 e-MPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20
3.4.1 Using Quick Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-21
3.4.2 Using Proof-and-Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-23
3.4.3 Printing a Private Print/Job Retention . . . . . . . . . . . . . . . . . . . . . . . .3-24
3.4.4 Retrieving Jobs from Virtual Mailbox (VMB) . . . . . . . . . . . . . . . . . . .3-28
3.4.5 Changing e-MPS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-30
3.5 Changing the Interface Parameters . . . . . . . . . . . . . . . . . . . . . . . 3-34
3.5.1 Changing Parallel Interface Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .3-34
3.5.2 Changing Serial Interface Parameters . . . . . . . . . . . . . . . . . . . . . . . 3-35
3.5.3 Changing Network Interface Parameters . . . . . . . . . . . . . . . . . . . . .3-37
3.5.4 Resolving IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-39
3.6 Making Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-42
3.6.1 Default Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-42
3.6.2 KC-GL Pen Width and Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-43

Contents
xix
3.6.3 Alternative Emulation for KPDL Emulation . . . . . . . . . . . . . . . . . . . . 3-44
3.6.4 Printing KPDL Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
3.6.5 Default Font . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
3.7 Pagination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
3.7.1 Number of Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-53
3.7.2 Print Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-54
3.7.3 Page Protect Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-55
3.7.4 Linefeed (LF) Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-56
3.7.5 Carriage-Return (CR) Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-57
3.8 Setting Print Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
3.8.1 Tone Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
3.8.2 Gloss Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-59
3.9 Operating the Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
3.9.1 Using the Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
3.9.2 Using the Option Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-67
3.9.3 Using the RAM Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-67
3.10 Paper Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-69
3.10.1 MP Tray Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-69
3.10.2 Setting MP Tray Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-70
3.10.3 Setting the MP Tray Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-72
3.10.4 Setting the Cassette Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-73
3.10.5 Selecting the Paper Feed Source . . . . . . . . . . . . . . . . . . . . . . . . . . 3-74
3.10.6 Duplex Printing (FS-C8008DN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-75
3.10.7 Overriding Difference between A4 and Letter . . . . . . . . . . . . . . . . . 3-77
3.10.8 Creating Custom Paper Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-78
3.10.9 Resetting the Custom Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . 3-80
3.10.10 Selecting the Output Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-81
3.10.11 Selecting the Option Sorter Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 3-82
3.11 Selecting Monochrome or Color Printing . . . . . . . . . . . . . . . . . . 3-85
3.12 Reading Life Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-86
3.12.1 Displaying the Total Printed Pages . . . . . . . . . . . . . . . . . . . . . . . . . 3-86
3.12.2 Resetting the Toner Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-87
3.13 Other Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-88
3.13.1 Selecting the Message Language . . . . . . . . . . . . . . . . . . . . . . . . . . 3-88
3.13.2 Automatic Form Feed Timeout Setting . . . . . . . . . . . . . . . . . . . . . . . 3-89
3.13.3 Setting the Sleep Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-90
3.13.4 Received Data Dump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
3.13.5 Printer Resetting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-93
3.13.6 Resource Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-94
3.13.7 Alarm (Buzzer) Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-95
3.13.8 Auto Continue Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-96
3.13.9 Setting the Auto Continue Recovery Time . . . . . . . . . . . . . . . . . . . . 3-97
3.13.10 Duplex Printing Error Detection Setting . . . . . . . . . . . . . . . . . . . . . . 3-98
3.13.11 Printing the Service Status Page . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-99
3.13.12 Color Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-100
Chapter 4 Troubleshooting
4.1 General Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.1.1 Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.2 Print Quality Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
4.3 Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
4.4 Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.4.1 Possible Paper Jam Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
4.4.2 General considerations for clearing jams . . . . . . . . . . . . . . . . . . . . . 4-13
4.4.3 Paper Jam — Right Cover # . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
4.4.4 Paper Jam — Cassette # . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
4.4.5 Paper Jam — MP Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
