Xerox WorkCentre XL2120 User manual

© 5/2001 by Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of copyrighted material and information
now allowed by statutory or judicial law or hereinafter granted, including without limitation material
generated from the software programs that are displayed on the screen such as icons, screen display
looks, etc.
XEROX®, The Document Company®, and the stylized X are registered trademarks of Xerox
Corporation and Xerox Canada Ltd. is a licensee of all the trademarks.
Product names used in this guide may be trademarks or registered trademarks of their respective
companies and hereby acknowledged.
ENERGY STAR is a U.S. registered mark.

User Guide
WorkCentre XL Series
User Guide

FCC Compliance in the USA
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different than that which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not specifically approved by the Xerox Corporation may
void the authority granted by the FCC to operate this equipment.
Shielded cables must be used with this equipment to maintain compliance with FCC regulations.
ENERGY STAR
As an ENERGY STAR® Partner, Xerox Corporation has
determined that this product meets the ENERGY STAR®
guidelines for energy efficiency.
Installed Printer Board
Declaration of conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Model Number:
Contact:
Phone:
Address:
E4Y, FCE, FCD (pre-installed)
Xerox Corporation
1-800-828-6571
800 Phillips Road
Webster, New York 14580
USA
E4Y, FCE, FCD

Information
To get answers for any other questions you might have regarding your WorkCentre, to register your
warranty by phone, or for assistance with the installation of your WorkCentre you may call:
[phone]
Supplies
To order supplies for your WorkCentre, visit your local retailer or their website. If your local retailer
does not stock these items, you may call the Xerox SupplyNet or go to www.xerox.com.
In the United States and Canada:
Xerox SupplyNet toll free at: 1 – 800 – 822 – 2200
Toner Cartridge: 106R482
Drum Cartridge: 13R551
Service
A Customer Service Support Representative will assist you in keeping your WorkCentre operational
and, if required, will arrange for service. Contact our experts at:
• Website – www.xerox.com/support
• Email – T[email protected]rox.com
• Call [phone]
The following information will be needed when you call Xerox:
Machine Type: XL __________________
Machine serial number: ___ ___ ___ and the ___ ___ ___ ___ ___ ___.
(Product Code) (Serial number)
The serial number is located on the back cover of the WorkCentre, to the left of the power cord.
Visit the Xerox Web site at: http://www.xerox.com
PRODUCT CODE : V8Y
RATING : 120 V-60 hz
AW
MANUFACTURED : SSK
1998 APRIL
000000
Product code
Serial Number

Information
How to obtain a French User Guide
Au Canada et aux États-Unis, pour obtenir la version française du présent guide d´utilisation,
procédez comme suit:
• Visitez le site Web – www.xerox.com
• Utilisez le courriel – [e-mail]
• Veuillez composer le [phone]
À l´extérieur des États-Unis et du Canada, veuillez communiquer avec votre représentant Xerox.
It's Illegal
In the USA
It is against US law to copy copyrighted material without permission of the copyright owner unless
the copying falls within the "Fair Use" or library reproduction rights of the copyright law. Further
information on these U.S. provisions may be obtained from the Copyright Office, Library of
Congress, Washington, D.C. 20550, or telephone the Copyright Office at [phone] and ask for
circular 21. Copying of other items may be prohibited. If you have any questions, seek legal advice.
In Canada
In Canada it is against the law to copy copyrighted material without permission of the copyright
owner, unless the copying falls within the private study, research or criticism provision of the
copyright law. Copying of other items may be prohibited. If you have any questions, seek legal
advice.
Product Recycling and Disposal
This product may contain lead, mercury and other materials whose disposal may be regulated due to
environmental considerations. For recycling and disposal information, contact your local authorities. In the
United States, you may also refer to the Electronic Industries Alliance web site: www.eiae.org.
For information on Xerox's worldwide equipment return and recycling programs, visit www.xerox.com
(refer to "About Xerox" section).

i
Table of Contents
Servicing Your WorkCentre............................................................................................................ iv
Ordering Supplies............................................................................................................................ iv
SafetyNotes....................................................................................................................................... 1
Helpful Hints...................................................................................................................................... 3
Getting to KnowYour WorkCentre.................................................................................................. 4
Installation ......................................................................................................................................... 5
Control Panel..................................................................................................................................... 9
Power Reduction / Auto Clear........................................................................................................ 11
Paper Specifications....................................................................................................................... 12
Loading Paper................................................................................................................................. 13
Flashing ..................................................................................................................................... 14
Making Copies on the Document Glass........................................................................................ 15
Making Copies on the Automatic Document Feeder(XL2130f) ................................................. 16
Making Copies on the Automatic Document Feeder(XL2140df) ............................................... 17
Image Quality................................................................................................................................... 19
Copy Contrast.................................................................................................................................. 19
Reduction/Enlargement.................................................................................................................. 20
Copying Oversized Documents.....................................................................................................21
Bypass Tray (XL2120/XL2130f)...................................................................................................... 22
Alternate Paper Tray(XL2140df).................................................................................................... 23
Two-Sided Copying (for all modelsexcept the XL2140df).......................................................... 24

LL
7DEOHRI&RQWHQWV
(QYHORSHV
&XVWRPL]LQJ<RXU:RUN&HQWUH
3URJUDPPDEOH)HDWXUH6HWWLQJV±DQG±
3URJUDPPDEOH)HDWXUH6HWWLQJ
3URJUDPPDEOH)HDWXUHV
:RUN&HQWUH&DUH
&OHDQLQJWKH'RFXPHQW*ODVVDQG&RHU
&OHDQLQJWKH&RURWURQ:LUH
$XWRPDWLF'RFXPHQW)HHGHU LVIHHG
&OHDULQJWKH3DSHU3DWK ±(((((
7RQHU&DUWULGJH5HSODFHPHQW
-'UXP&DUWULGJH5HSODFHPHQW
&RXQWHUDFFHVV
&RSLHVRQ3KRWR&DUWULGJH
7RWDO,PDJHV0RGHRQWKH:RUN&HQWUH
3ULQWHU'ULYHU6RIWZDUH,QVWDOODWLRQ
,(((3DUDOOHO&RQQHFWLRQ
3ULQWHU'ULHU,QVWDOODWLRQIRU:LQGRZV[170H

iii
Table of Contents
WorkCentre Properties (Printer Driver)......................................................................................... 43
Properties Tabs.............................................................................................................................. 44
On-Line Help.................................................................................................................................. 44
?Printer Driver Help.................................................................................................................... 44
Enabling High Speed Printer Communications ........................................................................... 45
Problem Solving.............................................................................................................................. 47
Problem Solving Chart................................................................................................................... 47
Status CodeChart ......................................................................................................................... 49
PrintingSolution Chart................................................................................................................... 50
Technical Data................................................................................................................................. 53

iv

1
Safety Notes
Your WorkCentre and supplies have been designed and tested to meet strict safety requirements.
These include safety agency examination and approval, and compliance to established environmental
standards. Please read the following instructions carefully before operating the WorkCentre and refer
to them as needed to ensure the continued safe operation of your WorkCentre.
Follow all warnings and instructions marked on or supplied with the product.
Symbology: = High Voltage, = Heated Surface, != Warning
= Laser Caution use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Unplug this WorkCentre from the wall outlet before cleaning. Always use materials specifically
designated for this WorkCentre. Use of other materials may result in poor performance and could
create a hazardous situation.
Do not use aerosol cleaners. Follow the instructions in this User Guide for proper cleaning methods.
Never use supplies or cleaning materials for purposes other than what they were intended. Keep all
supplies and materials out of reach of children.
Do not use this WorkCentre near water, wet locations, or outdoors.
Do not place this WorkCentre on an unstable cart, stand, or table. The WorkCentre may fall, causing
personal injury or serious damage to the WorkCentre.
This product is equipped with a 3-wire grounding type plug (e.g., a plug having a third grounding
pin). This plug will fit only into a grounding-type power outlet. This is a safety feature. To avoid risk
of electric shock, contact your electrician to replace the receptacle if you are unable to insert the plug
into the outlet. Never use a grounding adapter plug to connect the WorkCentre to a power source
receptacle that lacks a ground connection terminal.
This WorkCentre should be operated from the type of power source indicated on the marking label.
If you are not sure of the type of power available, consult your local power company.
Do not allow anything to rest on the power cord. Do not locate the WorkCentre where persons will
step on the cord.
The power supply cord is the disconnect device for this equipment. Insure that installation is near
the outlet and is easily accessible.
Your machine is equipped with an energy saving device to conserve power when the machine is not
in use. The machine may be left on continuously.

2
Safety Notes
Slots and Openings in the cabinet and in the back and sides of the WorkCentre are provided for
ventilation. To ensure reliable operation of the WorkCentre and to protect it from overheating, these
openings must not be blocked or covered. The WorkCentre should never be located near or over a
radiator or heat register. This WorkCentre should not be placed in a built-in installation unless proper
ventilation is provided.
Never push objects of any kind into the slots of the WorkCentre as they may touch dangerous voltage
points or short out parts which could result in a fire or electric shock.
Never spill liquid of any kind on the WorkCentre.
Never remove covers or guards that require a tool for removal. There are no casual operator
serviceable areas within these covers.
Never defeat interlock switches. Machines are designed to restrict operator access to unsafe areas.
Covers, guards, and interlock switches are provided to ensure that the machine will not operate with
covers opened.
Use of an extension cord with this WorkCentre is not recommended or authorized.
Avoid direct viewing of the document lights. The lamps are bright and, while not harmful, they may
cause an annoying afterimage. Always keep the document cover closed during operation and
storage.
Avoid exposing the drum cartridge to light for extended periods of time.
Do not touch the green photoreceptor. Scratches or smudges that appear on the photoreceptor will
result in poor copy quality and may shorten the service life.
Do not put your hands into the fuser area, as you may be burned.
Ozone: This product produces ozone during normal operation. The ozone produced is dependent
on copy volume and is heavier than air. Providing the correct environmental parameter, as specified
in the Xerox installation procedures, ensure that concentration levels meet safe limits.
If you need additional safety information concerning the WorkCentre or Xerox supplied materials, you
may call the following toll-free number.
In the United States or Canada: 1 – 800 – 828 – 6571

3
Helpful Hints
Care of your WorkCentre
•Do not place heavy objects on any surface of the WorkCentre.
•Take care not to place liquids on or near the WorkCentre.
•Avoid placing clips or staples on any WorkCentre surface.
Maintenance
•Clean the Document Glass daily and as required.
•Do not apply cleaning liquids or sprays directly to the WorkCentre; apply to the cloth first.
•Store paper in a dry area, on a flat surface, and in a closed cabinet.
•Wrap partially-used reams of paper tightly.
WorkCentre location
For reliable WorkCentre operation and copy quality, Xerox recommends:
•Place your WorkCentre in a well-ventilated room.
•Recommended environment:
– Temperature: 50°to 90°F / 10°to 32°C.
– Humidity: 20% - 60% for up to 90°F / 32°C
20% - 85% for up to 86°F / 30°C
•Place the WorkCentre on a flat, level surface.
•Avoid locations that subject the WorkCentre to:
– Direct sunlight.
– Extreme changes in temperature or humidity.

4
Getting to Know Your WorkCentre
Document Glass
Front Cover
Control Panel
Exit Tray
Paper Tray
Document Cover
Release
Latch Alternate Paper Tray
XL2140df only
Exit Tray
Serial Number
Parallel Port Lift Area
Power Switch
Power Connection
Paper
Guides
Bypass Tray
Paper Guides
Side Cover
Original Exit
A
rea Original Feeder Tray
Original Guides
Automatic Document Feeder
(XL2130f, XL2140df)
Paper Tray 2
XL2140df

5
Installation
As you unpack the WorkCentre, familiarize yourself with its contents. After the WorkCentre is
installed, and the Ready Indicator is lit, the WorkCentre is ready to make copies.
* Note: To ensure reliability of the WorkCentre use the IEEE-1284 compliant parallel cable that is
supplied with the machine. Only cables labeled “IEEE-1284” can be used with your WorkCentre, can
only be supported by this cable.
Drum Cartridge
(installed in the
machine)
Packing Material
Power Cord
Starter Toner Cartridge
(approximately 2000
copies at 5% coverage)
IEEE-1284 Parallel Cable *
User Documentation/
Installation CD

6
Installation(continued)
Follow the steps below to properly set up your Xerox
WorkCentre.
AD
C
E
B
1. Remove the bag from the WorkCentre.
2. Remove the pieces of tape A, B, C, D, and the packing
material E.
XL2140df only
Remove the tape and the packing material supporting the clear
plastic 2-sided tray.
NOTE: To ensure the 2-sided tray is in the correct position,
gently push it in the direction shown by the arrow.
3. Open the Document Cover and remove the packing materials
shown.
NOTE: The XL2130f and XL2140df have a single piece of
packing material.
4. Unscrew and remove the Shipping Screw from the left side of
the WorkCentre. See step 6 for securing the Shipping Screw.
CAUTION: If the Shipping Screw is not removed, the
WorkCentre will malfunction and an L1 status code will be
displayed.
5. Lift and pull open the Paper Tray. Turn and remove the
Paper Tray lock. See step 6 for securing the Paper Tray
Lock.
CAUTION: Paper will misfeed if the Paper Tray lock is not
removed.
XL2140df only
Note: Be sure to remove the Paper Tray Lock from both Paper
Trays.

7
Installation(continued) 6. Secure the Paper Tray Lock and the Shipping Screw in the
locations shown.
•Turn the Paper Tray Lock to secure.
Note: Save the Paper Tray Lock and the shipping screw.
They will be needed if the WorkCentre has to be moved.
7. Load paper into the tray.
•Refer to the Loading Papersection of the User Guide for
additional information.
•Do not fill above the max line.
8. Push the Paper Tray firmly back into the WorkCentre.
XL2140df only
Note: Ensure that the Alternate Paper Tray is lowered.
9. Press the Release Latch to open the Side Cover.
10. Remove the Caution tape from the cover.
11. Remove the two red Fuser Pins, one at a time, by pulling
the string upward.
•Discard the Fuser Pins.
Note: Misfeeds will occur if the Fuser Pins are not
removed.
CAUTION: Ensure that the Side Cover is always open before
opening the Front Cover.
12. Press the Front Cover Release Button, located on the top left
side of the Front Cover, to open.

8
Installation(continued) 13. Remove the Starter Toner Cartridge from the silver bag.
Vigorously shake the cartridge to loosen the toner.
•Thoroughly shaking the cartridge will assure maximum
copies per cartridge.
•Xerox has included a 2000 page yield Starter Toner
Cartridge. Purchased replacement toner cartridges will
yield approximately twice the number of copies at 5%
coverage.
14. Remove the Toner Cartridge Cover.
1
23
15. Slide the Toner Cartridge into the WorkCentre until it locks
into place.
16. Close the Front Cover and the Side Cover.
17. Plug the Power Cord into the WorkCentre and then into a
grounded outlet.
Turn on the Power Switch. In approximately two seconds the
ready indicator will light. Copying is now possible.
Note: Save the carton and packing materials. They should be
used to repack the WorkCentre if it has to be moved or shipped
for servicing.
18. Skip to the Printer Driver Software Installation section in this
User Guide to set up the WorkCentre for printing

9
Control Panel
The control panel has keys and lights that are used to control
and display the conditions of the WorkCentre.
1. 1-Sided/2-Sided Mode (XL2140df only): Use the 2-Sided
copy feature to make one or two-sided copies from one or
two-sided originals. Refer to the Making Copieson the
Automatic DocumentFeeder section for detailed
information.
2. Image Quality Mode: The image quality mode is used to
maximize copy quality.
Auto– for originals with a colored background or mixed text
and graphics.
Text – for originals that contain mainly text.
Photo – for copying photographs.
Toner Save – decreases the overall copy density.
3. Copy Contrast: Press the contrast keys to lighten or
darken copies while in the Text, Photo, or Toner Save
settings. Refer to the Image Qualitysection for detailed
information.
4. Preset Reduction/Enlargement: Press this key to select
any of the preset reductions or enlargements.
•The (customer settable) percentage has been set at
the factoryfor 50%. Refer to Customizing Your
WorkCentre for information about changing this
percentage.
5. Percentage Indicator: The indicator will light when any
reduction or enlargement setting is selected.
6. Variable Percentage: Press the down key to decrease the
percentage. Press the up key to increase the percentage.
Any percentage from 50% to 200% may be selected.
7. %: Press this key to display the reduction/enlargement
percentage selected.
12345
678 111091213141516

10
8. Display Window: Copy quantity, reduction/enlargement
settings, and status codes appear in this area.
9. Quantity Keys: Select up to 100 copies. Press the 1key to
increase the quantity by one. Press the 10 key to increase
the quantity by 10.
•To display the number of copies requested during the copy
run press the 10 key.
•Press the Clear key to clear the selected quantity.
10. WorkCentre Diagram: Helps you locate areas that require
your attention. The indicators will flash in the area requiring
attention. For additional information refer to theProblem
Solving section.
11. Paper Supply Selection (XL2130f/XL2140df): Press to
change the selected paper supply. The selected paper
supply location will be indicated by a green light on the
WorkCentre diagram.
12. ADF Misfeed Indicator: This indicator will light when a
misfeed occurs in the Automatic Document Feeder.
13. On-line/Off-line Key: Press this button to alternate
between On-line and Off-line status. When the light is lit, the
printer is On-line.
14. Ready Indicator: When the light is ON (not flashing), the
WorkCentre is ready to make copies. When the light is
flashing after the Start key is pressed, the WorkCentre is
warming up and the copy cycle will begin automatically.
15. Start: Press this key to begin copying.
•The display will change to 1 and increases by 1 as each
copy is made.
16. Clear/Stop: Press this key to stop the WorkCentre while
making copies or to clear copy quantity. If the key is
pressed twice quickly, all programming will be cleared.
12345
678 111091213141516

11
Power Reduction / Auto Clear
Power Reduction Modes automatically reduce power
consumed by the WorkCentre when the WorkCentre has not
been used for a set period of time. There are two modes of
power reduction; Power Save, and Power Shut-off.
Power Save Mode – The Ready Indicator will flash and the
other indicators will remain on. To copy from the Power Save
mode select the desired features and press Start. The copies
will be made automatically.
Power Shut-Off Mode – When the WorkCentre enters the
power shut-off mode the Ready Indicator will flash and the other
indicators will turn off. To copy from the power shut-off mode,
press the Start button, then, select the desired features and
press Start again. The copies will be made automatically.
Auto Clear – This WorkCentre is enabled at the factory to return
to the Normal Copy Mode approximately one minute after a job
is completed. Unless otherwise programmed, the Normal copy
Mode settings are as follows:
•Copy Quality – Auto
•Copy Lighter/Darker – Normal
•Priority Tray – Tray 1
•Priority Magnification – 100%
•Quantity Selected – 1
Note: Time periods for the Power Shut-Off, Power Save, and
Auto Clear modes can be modified to meet your specific copying
needs. Refer to Customizing Your WorkCentre sectionofthis
User Guide for information about changing these settings.
