Xerox WorkCentre3325 Manual

© 2016 Xerox Corporation. All rights reserved. XEROX® and XEROX and Design®, ColorQube®, and WorkCentre® are trademarks
of Xerox Corporation in the United States and/or other countries.
Technical Support Operations
Page 1 of 3
Purpose
This Bulletin is intended ONLY for the specific security problems identified below. The problems
identified has been rated a criticality level of IMPORTANT. This release includes OpenSSL 1.1.0.
This SPAR release includes fix for:
CVE-2016-2177 -- OpenSSL incorrectly uses pointer arithmetic for heap-buffer boundary checks,
which might allow remote attackers to cause a denial of service.
CVE-2016-2183 - The DES and Triple DES ciphers, as used in the TLS, SSH, and IPSec
protocols and other protocols and products, are vulnerable to a birthday attack against a long-
duration encrypted session, as demonstrated by an HTTPS session using Triple DES in CBC
mode, aka a "Sweet32" attack.
CVE-2015-2808 Bar Mitzvah. The RC4 algorithm, as used in the TLS protocol and SSL protocol,
does not properly combine state data with key data during the initialization phase, which makes it
easier for remote attackers to conduct plaintext-recovery attacks against the initial bytes of a
stream by sniffing network traffic that occasionally relies on keys affected by the Invariance
Weakness, and then using a brute-force approach involving LSB values. RC4 has been disabled
in this release.
Software Release Details
If your software is higher or equal to the versions listed below no action is needed.
Otherwise, please review this bulletin and consider installation of this version.
Model
WorkCentre
3325
Firmware version
51.006.15.000
Link to update
Available here
Save the file to a convenient location on your workstation. Unzip the file if necessary.
Mini Bulletin XRX16AI
WorkCentre 3325
Release SMP5R1 51.006.15.000
Release Date: Nov 30, 2016 Updated: Dec 01, 2016

© 2016 Xerox Corporation. All rights reserved. XEROX® and XEROX and Design®, ColorQube®, and WorkCentre® are trademarks
of Xerox Corporation in the United States and/or other countries.
Technical Support Operations
Page 2 of 3
Installation Instructions:
Manual upgrade using Internet Services
This section provides instructions to upgrade machine software over the network via Xerox
CentreWare Internet Services (CWIS).
Note: If authentication access control is enabled on the device, set the authentication method to No
Authentication before attempting the upgrade.
(Properties > Security Authentication Authentication Authentication Method)
Information Checklist
Before starting the procedure, please ensure that the following items are available and / or the tasks
have been performed:
1. The Software Upgrade file is obtained from the Xerox web site using the links earlier in this
document.
IMPORTANT: It is important to obtain the correct upgrade file for your particular model of
machine.
2. If you are performing the upgrade on a network connected machine, ensure that the machine is
online before continuing. TCP/IP and HTTP protocols must be enabled on the machine so that the
machine web browser can be accessed. Obtain the IP address of the machine you want to
upgrade.
Procedure
1. Open the web browser from your Workstation.
2. Enter the IP Address of the machine in the Address bar and select [Enter].
3. Login by clicking on the Login link at the top of the page and enter the Admin ID and Password.
4. Verify that Firmware Upgrade is enabled:
a. Click on the [Properties] tab.
b. Click on the [Security] link on the left
c. Click on the [System Security] link on the left
d. Click on [Feature Management]
e. Check the Enable checkbox for Firmware Upgrade and click Apply
5. Click on the [Support] tab.
6. Click on [Firmware Upgrade] on the left
7. Click on the [Upgrade Wizard] button on the upper right hand corner
8. Locate and select the software upgrade file obtained earlier. The firmware file will have an
extension .hd.
9. Click [Next]. The firmware will go through a firmware verification step.
10. Click [Next] to start the download process.
Note 1: Please use ASCII characters only in file path.

© 2016 Xerox Corporation. All rights reserved. XEROX® and XEROX and Design®, ColorQube®, and WorkCentre® are trademarks
of Xerox Corporation in the United States and/or other countries.
Technical Support Operations
Page 3 of 3
Note 2: Software Installation will begin several minutes after the software file has been submitted to
the machine. Once Installation has begun all Internet Services from this machine will be lost,
including this Web User Interface.
Once the download is complete, print a Configuration Report to verify the firmware version.
