User Guide 1
Safety
Safety Introduction
Notices and Safety
Please read the following instructions carefully before operating the machine and refer to them as
needed to ensure the continued safe operation of your machine.
Your Xerox®product and supplies have been designed and tested to meet strict safety
requirements. These include safety agency evaluation and certification, and compliance with
electromagnetic regulations and established environmental standards.
WARNING:
The safety and environment testing and performance of this product have been verified using
Xerox®materials only. Unauthorized alterations, which may include the addition of new
functions or connection of external devices, may impact the product certification. Please
contact your Xerox representative for more information.
Operational Safety Information
Your Xerox®equipment and supplies have been designed and tested to meet strict safety
requirements. These include safety agency examination, approval, and compliance with
established environmental standards.
To ensure the continued safe operation of your Xerox®equipment, follow these safety guidelines
at all times:
Do these:
• Always follow all warnings and instructions that are marked on or supplied with the
equipment.
• Always use materials specifically designated for this product, the use of other materials may
result in poor performance and create a hazardous situation. Do not use aerosol cleaners,
they may be explosive and flammable under certain conditions.
• Always exercise care when moving or relocating equipment.
• Always locate the machine on a solid support surface that has adequate strength to support
the weight of the machine.
• Always locate the machine in an area that has adequate ventilation and room for servicing.
Note: Your Xerox®machine is equipped with an energy saving device to conserve power when the
machine is not in use. The machine may be left on continuously.

Xerox®Duplex Travel Scanner Safety
2User Guide
Do not do these:
• Never attempt any maintenance function that is not specifically described in this
documentation.
• Never remove covers or guards that are fastened with screws. There are no operator
serviceable areas within these covers.
• Never locate the machine near a radiator or any other heat source.
• Never override or “cheat” any of the electrical or mechanical interlock devices.
Caution: This device is not intended for use in the direct field of view at visual display
workplaces
To avoid incommoding reflections at visual display workplaces this device must not be placed in
the direct field of view.
Emergency Power Off
If any of the following conditions occur, turn off the scanner (if applicable) and disconnect the
USB cable from the scanner and the computer.
• The equipment emits unusual odors or makes unusual noises.
• Liquid is spilled into the machine.
• The machine is exposed to water.
• Any part of the machine is damaged.
Maintenance Information
1. Any operator product maintenance procedures will be described in the user documentation
supplied with the product.
2. Do not carry out any maintenance on this product which is not described in the customer
documentation.
3. Do not use aerosol cleaners. The use of cleaners that are not approved may cause poor
performance of the equipment, and could cause a dangerous condition.
4. Use supplies and cleaning materials only as directed in this manual.
5. Do not remove covers or guards that are fastened with screws. There are no parts behind
these covers that you can maintain or service.
6. Do not perform any maintenance procedures unless you have been trained to do them by an
authorized local dealer or unless a procedure is specifically described in the user manuals.

Safety Xerox®Duplex Travel Scanner
User Guide 3
Product Safety Certification
This product is certified by the following Agency using the Safety standards listed:
Environmental Health and Safety
Contacts
Contact Information
For more information on Environment, Health, and Safety in relation to this Xerox®product and
supplies, please contact the following customer help lines:
Standard
UL60950-1 (USA)
CSA 22.2 No. 60950-1 (Canada)
IEC 60950-1
USA & Canada: 1-800-828-6571
Europe: [phone]

Xerox®Duplex Travel Scanner Safety
4User Guide

User Guide 5
Welcome
What’s in the Box
Before proceeding, check the contents of the box. If items are missing or damaged, contact the
dealer where you purchased the scanner.
Xerox® Duplex Travel Scanner Carrying Bag Micro USB Cable
Calibration Page Installation Disc(s) Cleaning Cloth
Quick Install Guide Carrier Sheet Technical Support Card
Warranty Card

Xerox®Duplex Travel Scanner Welcome
6User Guide
System Requirements
• Pentium 4 PC or equivalent processor
• A DVD-ROM drive capable of reading Dual Layer DVDs.
• An available Universal Serial Bus (USB) port
•Microsoft
®Windows®operating system:
– 32-bit Windows XP (Service Pack 3)
– 32-bit or 64-bit Windows Vista (Service Pack 2)
– 32-bit or 64-bit Windows 7 (Service Pack 1)
– 32-bit or 64-bit Windows 8 / 8.1
– 32-bit or 64-bit Windows 10
• Minimum of 2 gigabyte (GB) of internal memory (RAM)
• Minimum available hard disk space:
– 350 MB for the scanner driver
– 750 MB for Visioneer OneTouch
– 1 to 2 GB for each additional application
Please refer page 17 for a list of the applications provided with your scanner.
• Monitor (recommended settings):
– Color quality of 16-bit or 32-bit
– Resolution set to at least 800 x 600 pixels
Refer to your Windows documentation for instructions on setting the color quality and
resolution for the monitor.
Documentation
The following printed documentation is provided in the box:
•Installation guide—abbreviated scanner setup and installation instructions.
•Technical support card—contact information for technical support and customer service,
and a brief overview of our standard product warranty.
The following soft-copy documentation is available on the installation disc:
•Scanner user guide—instructions for scanner setup, installation, operation, maintenance,
safety, and warranty.
•OneTouch scanning guide—instructions for configuring and scanning using OneTouch.
•TWAIN scanning guide—instructions for accessing and scanning using the TWAIN
interface.

Welcome Xerox®Duplex Travel Scanner
User Guide 7
•Nuance PaperPort user’s guide—contains detailed information using the application and
managing your scanned documents.
•Nuance OmniPage user’s guide—contains detailed instructions on using the software,
including information on using Optical Character Recognition to create editable text files
from the scanned documents.
•Nuance Power PDF help—contains detailed information on using the application to create
and modify PDF files. This guide is a software help file which can be accessed from within the
Power PDF application.
The Xerox®Duplex Travel Scanner
Features
1. Safety lock slot—slot for installing a Kensington® style safety lock. (May not be available for
all models).
2. Universal Serial Bus (USB) port—connects the scanner to the computer.
3. Paper feed—place an item face up in paper feed for scanning.
– Scanner lid—can be pulled away from the scanner body to open the scanner for
cleaning.
– Paper sensor—the sensor in the paper feed slot. Detects when an item has been inserted
in the scanner.
– Alignment strip—alignment marks for common paper sizes for the paper guide.
4. Multi-Function Button / Status light—controls the scanner and indicates the scanner
status. The button behavior is described below. Please refer to “Status Light Troubleshooting”
on page 40 for information about the status light conditions.
– Short button press (2 seconds or less)
• Turns the scanner on when the power is off.
• Cancels the scan when a scan is in progress.
• Starts scanning when AutoLaunch™ is not enabled.
– Long button press (3 seconds or more)
• Opens the OneTouch Properties window to configure the settings for the button and
AutoLaunch™.
1
2
3
4

Xerox®Duplex Travel Scanner Welcome
8User Guide

User Guide 9
Unpack the Scanner
1. Remove the blue plastic strip from around the scanner.
2. Remove the clear plastic film from the top of the scanner.
3. Place your thumbs on either side of the paper feed slot, underneath the lid of the scanner.
Hold the scanner sides firmly and pull the scanner lid up to release it from the body of the
scanner.
Use both hands to open the scanner, the lid is held down with locking arms on both sides of
the paper feed slot. If you open only one side, you may damage the scanner lid.
4. Remove the foam strip(s) from inside the scanner.

Xerox®Duplex Travel Scanner Unpack the Scanner
10 User Guide
5. Gently close the scanner lid. Press down on both sides of the lid until you hear a click as the
arms lock the scanner lid in place.
Safety Lock
Your scanner may have a slot for installing a Kensington® style safety lock. This slot can be
identified by the lock icon. It is to the left of the USB port on the scanner. When following the
instructions in this document, make sure you connect the USB cable into the USB port which is
identified by the USB symbol.
A lock is not provided with the scanner and this document does not contain instructions on
purchasing and installing a safety lock. If you choose to use a safety lock, please carefully read the
installation instructions provided with the lock. More information about Kensington® locks can be
found at www.kensington.com.
Use this slot to install a
safety lock. Do not
attempt to insert any
other type of object.
Use this slot to connect the provided micro USB
cable to the scanner. Do not use any other type
of USB cable. Do not attempt to install a safety
lock in this port.

User Guide 11
Installation
Please make sure of the following before you begin installation:
• If you are prompted to reboot during installation, please select "No". Finish installing the rest
of the software, then close all open windows and reboot your computer.
• The information in this guide may cover software not provided with the scanner you
purchased. Please disregard any information about the software not applicable to your
scanner.
• If your computer has AntiVirus or AntiSpyware software running, you may encounter alerts or
messages during installation asking you to allow the installation to proceed. Although the
messages will differ based on the software your computer is running, in each case you should
allow the installation to proceed if that option is available. Alternatively, you can turn off the
AntiVirus or AntiSpyware software before installing your scanner, but if you do, make sure to
turn it back on again when installation is finished.
• If you already have a scanner connected to your computer, it is recommended that you
remove that scanner’s driver program prior to installing your Xerox®scanner. You can remove
these programs from the Windows Control Panel. Please refer to the user manual provided
with your other scanner hardware for instructions about removing the driver and software for
that unit.
• If your computer is running Windows Vista or later, you may see the Windows User Account
Control screen asking you to confirm system changes. Click the Yes button to allow the
installation to proceed.

Xerox®Duplex Travel Scanner Installation
12 User Guide
Install the Software and Connect the
Scanner
1. Start Microsoft Windows and make sure that no other applications are running.
2. Insert the installation disc into your computer’s DVD-ROM drive.
The disc automatically starts.
3. The Select Language window opens. Click the drop-down menu arrow and select the
language to use. Click OK.
The disc’s Main menu window opens.
Note: If the disc does not start, check the following:
– Make sure the disc drive’s door is completely shut.
– Make sure the disc was inserted in the drive in the proper direction (label side up).
To la u n c h t he disc ma n u a l l y :
– Open the Windows options for your computer’s disc drives.
– Double-click the icon for your DVD-ROM drive.
– The Installation menu for the disc should now open.
If the menu does not open:
• From the list of files on the disc, double-click the file named setup.exe.

Installation Xerox®Duplex Travel Scanner
User Guide 13
4. On the Main menu, select Install software.
5. Make sure the boxes for Scanner Driver and Visioneer OneTouch are selected, as well as any
other applications you want to install.
Note: The software provided with your scanner may differ slightly from the list shown in the
window.
6. Click Install now.

Xerox®Duplex Travel Scanner Installation
14 User Guide
Installing the Scanner Driver
The scanner driver installation will start first.
1. The Welcome screen for the scanner driver Setup Wizard opens. Click Next.
2. On the Xerox License Agreement window, read the license agreement. If you accept the
terms, select I Agree then click Next.
If you choose not to accept the license agreement, click Cancel. Click Close on the
Installation Interrupted window.
3. The software will now be installed.
4. Stop when you see the “Complete the installation by connecting your hardware” window. Do
not click OK yet. Leave the window open and proceed to the next section.
Note: If you do not see this on-screen diagram for connecting the scanner, stop and follow the
instructions below.

Installation Xerox®Duplex Travel Scanner
User Guide 15
Connect the USB Cable
The scanner does not have an external power supply. It draws its power directly from the
computer through the USB cable. If you use a USB hub with your computer, the hub must have its
own power supply. The scanner is ready to scan as soon as its software is finished loading onto
your computer.
1. Remove any tape from the USB cable.
2. Plug the USB cable into the USB port on the scanner then into a USB port on the computer.
Check your computer’s manual for USB port locations.
If the plug does not attach easily, make sure that you are plugging it in correctly. Do not force
the plug into either connection.
The status light comes on and flashes indicating that the scanner is receiving power.
Your computer recognizes that a scanner has been plugged into the USB port and
automatically loads the appropriate software to run the scanner.
3. When you’re certain that the software has completely loaded, return to the “Complete the
installation by connecting your hardware” window.
