Xiaomi Mi 90 Series User manual

Mi 90 Points Smart Metal Suitcase
External side of the suitcase
Extendable handle (four
positions)
Upper handle
TSA lock
Aluminum-
magnesium alloy
Side handle
Internal side of the suitcase
Zipper
Pocket
Separating the inner pocket
The main parameters of the suitcase
Name: Mi 90 Points Smart Metal Suitcase;
Model: LGSR2005RM / Silver, LGGD2005RM / Metal,
LGBU2005RM / Blue;
Size: 497х340х215mm (total size 550х375х215mm);
Capacity: about 31l;
Weight: about 4.4kg;
Standard: Q31 / 0117000530C001-2016;
External material suitcase: 100% aluminum-magnesium alloy;
Internal material suitcase: 100% polyester.
The main parameters of Smart Module
Smart lock: D-901;
Operating temperature: -15С - 55С;
CMIIT ID: 2016DP1367;
Support: Bluetooth 4.0 Android or iOS 7.0 and higher
systems;
Type of wireless connectivity: Bluetooth 4.0;
Power: 1.5V --- 550 mAh.
Note: The lower internal zip pocket intend
only to repair the suitcase, so we recommend
not to open and use it for your own purposes.
Wheels, 360 degree
maneuverability
XIAOMI-MI.COM

Lock/unlock manual
1.Unlocking: Scroll wheels code on the suitcase, set your selected combination, press
the button and the lock is unlocked.
2.Locking: Close the lock and at the same time scroll wheels code in random order.
Lock is locked.
3.Installation password: 0-0-0 - it’s originally set password of the suitcase, so you
need to choose your own combination of three numbers.
3.1. The initial state of the lock (the current password of the suitcase is 0-0-0).
3.2. Use pen or other similar pointed object (as shown on the left picture), on the
opposite side of the lock, to press and hold the installation button (a) until it clicks.
3.3.Rotate the code wheels (b), select the desired combination of three digits (eg 8-8-8)
3.4.If you choose a new combination, press the button (c) and you will hear some
clicking, code switch (a) pops and lock will lock.
4. If you forgot your password, you will not be able to open the suitcase by common
way. So be sure to remember your password.
(Besides the manual lock code lock, is a support function Bluetooth. See the smart lock
user manual).
Code switch (а)
Buttons (wheel) dialing
code (b)
Button (c)
Smart lock manual
1. Install Mi Smart Home APP on your smartphone
To install Mi Smart Home APP on your smartphone, scan QR-code shown on the
right side.
2. Set the battery and turn on Bluetooth on your phone
In the inner part of Mi 90 Points Smart Metal Suitcase (hereinafter referred as a
suitcase), open the battery compartment and insert two AA batteries. The distance
between a smartphone and a suitcase should be no more than 1 meter, check the
stability of the WI-FI signal and turn on Bluetooth on your phone.
XIAOMI-MI.COM

3. Connect the smartphone to the suitcase
Open Mi Smart Home APP, create your Mi account, following the instructions
of the application, then find suitcase in the list of devices. When the display
prompts interface connection confirmation, press and hold the Bluetooth
button, which is located inside the suitcase next to the battery compartment
for 3-5 seconds (shown in the illustration). After doing all the actions in the
application, you will receive a notification about the successful pairing of
devices.
4. Start to use
After pairing the devices, firstly, you must set the password in manual mode
(See the manual unlock\lock instruction). Scroll wheels of code in random
order and make sure that the lock is locked. Unlock the lock using the smart
unlock.
5. Change the batteries
Bundled with a suitcase, you get two AA batteries. If APP notifies you of
insufficient charge, promptly change the batteries.
During normal frequency of exploitation the suitcase you can use the
batteries for 1 year. If for a long time you do not use a suitcase, remove the
batteries. Safety Tips
• Do not carry in a suitcase money and jewelry.
• Do not roll the suitcase up the stairs or steps. This may cause injury to the user or your suitcase
can ip over and go wrong.
• Do not put the suitcase on the problematic and rough surface to prevent it from tipping over, and,
as a result causing an accidents.
• Do not sit on the bag, since it may cause its tipping over and injury the user.
Precautions
• Precautions for the use of retractable suitcase handle
Not recommended to lift the suitcase, holding its retractable handle.
During the movement of suitcase do not press and push the button of the retractable handle.
• Not recommended to leave a suitcase in the rain for a long time.
A suitcase is not completely waterproof. By a sudden splashes of water nothing will happen to him.
But if your bag gets wet, please promptly wipe it with a dry towel to avoid it of getting total wet and of
getting water inside the suitcase.
• Do not put the suitcase near sources of heat.
Warning, if you leave the suitcase near the re, the replace or other heat source, it can lead to
deformation.
• Do not leave the suitcase in areas with a high level of acidity or moisture.
Do not leave the suitcase in areas with a high level of acidity or humidity, since this may cause
damage or breakage of the lock and its metal elements. As a result, the normal use of the suitcase
becomes impossible.
• Keep an eye on the suitcase, if it’s on the top shelf (for luggage).
As a result of the fall of suitcases or other luggage you can get injured, it may break or things
you carry in it may be damaged. So keep an eye on your suitcase, if it is placed on the top shelf,
designed for luggage.
• Do not rely only on the distance unlock of the smart lock.
When connected to the smartphone, the device (smart lock) uses a radio signal. But in some cases
this kind of connection and unlocking the lock is not enough reliable. In the an emergency case you
should not rely only on the distance unlock of the smart lock.
XIAOMI-MI.COM

Warranty:
Warranty servicing is carried out according to the law on «The rights of the consumer
of China» and «Law on product quality of China». During the warranty period you have
the right to repair, replace or return. For repair, replacement or return of goods, you must
present a receipt.
Warranty service includes:
1. Within 7 days of purchase, in case of any problem on «fault list» 90 Points service
center determine the cause of the problem, then you can choose a free replacement of the
product or a refund.
2. Within 8-15 days of purchase, in case of any problem on «fault list» 90 Points service
center determine the problem, then you choose a free replacement of the product or
repair.
3.Within 12 month of purchase, in case of any problem on «fault list» 90 Points service
center determine the problem, then you have free reapeir
Warning:
The conditions, which are not included in warranty service
• Repair of goods by unauthorized organizations or service centers.
• The warranty period has expired.
• Damage arising under force majeure circumstances.
• Damage that do not conform to «List of faults» of hte product service center.
• Damage that arose in connection with the human factor.
Warning:
• Warranty service is impossible if in the result of natural deterioration, incorrect operation
or inuence of the other external factors arose damage to a suitcases (For example, if as
a result of travel by plane or other vehicle arose damage, deformation, fracture, crack the
shell, scratches, corrosion etc.).
• In order to protect your legitimate rights and interests, before you sign in a document
wich conrms receipt of the goods, unpack and check the integrity of the device.
List of faults
Data tables provided according to the provisions SJ / T 11364.
O: toxic and harmful substances in all components of the device are contained in an
amount lower the limit value according to the standard GB / T 26572.
X: presence of toxic and hazardous substances, at least in one of the components of the
device in an amount that exceeds the threshold, according to GB / T 26572
The presence of toxic and hazardous substances
To consult a specialist, please call technical support: 400-807-9090
(Work hours: Mon-Fri 9:00 - 18:00)
Weixin 90Points QQ 90Points
Manufacturer: OOO «Shanghai RunMi Technology»
Address: Floor 5, Building 14, CaoHeJing Park, 518, Shenzhuan Street, Songjiang
District, Shanghai city
Address after-sales service: 3, Huadong Zhen Fenghuang Road, Huadu District,
Guangzhou city, Guangdong Province
