Xiaomi Mi Robot Vacuum S10+ User manual

Robot Vacuum S10+ User Manual

1
Safety Information
Read this manual carefully before use, and retain it for future reference.
Usage Restrictions
• This product is for floor cleaning in a home environment only. Do not use it outdoors, on non-floor
surfaces, or in a commercial or industrial setting.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• The appliance is only to be used with the power supply unit provided with the appliance.
• This appliance contains batteries that are only replaceable by skilled persons.
• Children shall not play with this product. Ensure children and pets are kept at a safe distance from the
robot vacuum while it is operating.
• If the power cord is damaged, it must be replaced by a special cord or assembly available from the
manufacturer or its service agent.
• Do not use the robot vacuum in an area suspended above ground level without a protective barrier.
• Do not place the robot vacuum upside down. Do not move the robot vacuum by using its LDS laser sensor

2
cover, cover, or bumper as a handle.
• Do not use the robot vacuum at an ambient temperature above 40°C or below 0°C or on a floor with liquids
or sticky substances.
• Do not install, charge, or use this robot vacuum outdoors, in bathrooms, or near a pool.
• A hazard may occur if the appliance runs over the supply cord.
• Remove fragile or small items from the floor to prevent the robot vacuum from bumping into and
damaging them.
• Keep the cleaning tool out of reach of children.
• Do not place children, pets, or any item on top of the robot vacuum regardless of whether it is stationary
or moving.
• Keep hair, fingers, and other body parts away from the suction opening of the robot vacuum.
• Do not use the robot vacuum to clean any burning substances.
• Do not vacuum up hard or sharp objects.
• The plug must be removed from the socket-outlet before cleaning or maintaining the appliance.
• Do not wipe the robot vacuum or charging dock with a wet cloth or rinse them with any liquid. After
cleaning washable parts, fully dry the parts before reinstalling and using them.

3
• Make sure the robot vacuum is turned off when being transported and kept in its original packaging if
possible.
• Please use this product in accordance with the instructions in the user manual. Users are responsible for
any loss or damage arising from improper use of this product.
Batteries and Charging
WARNINGS:
• Do not use any third-party battery, power cord, or charging dock. The robot vacuum can only be used with
the model CDZ2101 charging dock.
• No action needed from users to shift the charging dock between 50 Hz and 60 Hz, and the product can
adapt itself for both 50 Hz and 60 Hz.
• Do not dismantle, repair, or modify the battery or charging dock on your own.
• Do not place the charging dock near a heat source.
• Do not use a wet cloth or wet hands to wipe or clean the dock's charging contacts.
• If the robot vacuum will not be used for an extended period, fully charge it, then turn it off and store in a
cool, dry place. Recharge the robot vacuum at least once every 3 months to avoid over-discharging the
battery.
• The lithium-ion battery pack contains substances that are hazardous to the environment. Before
disposing of the robot vacuum, please first remove the battery pack, then discard, or recycle it in

4
accordance with local laws and regulations of the country or region it is used in.
• When removing the batteries from the product, it is better to use up the batteries and make sure your
product is disconnected from power.
1). Uninstall the screw on the bottom, then remove the cover.
2). Unplug the battery connector, then remove the batteries. Do not damage the battery case to avoid any
risk of injuries.
3). Return the batteries to a professional recycling organization.
Laser Safety Information
• This product's laser radar meets the IEC 60825-1:2014 Standard for Class I laser product safety and does
not produce laser radiation hazardous to the human body.
Hereby, Dreame (Tianjin) Information Technology Co., Ltd. declares that the radio equipment type B105 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address:
http://www.mi.com/global/service/support/declaration.html
For detailed e-manual, please go to www.mi.com/global/service/userguide
EU Declaration of Conformity

5
Product Overview
Accessories
Other Accessories
Pre-installed Accessories
Note: Illustrations of product, accessories, and user
interface in the user manual are for reference purposes
only. Actual product and functions may vary due to product
enhancements.
Brush Brush Cover Dust Compartment Water Tank
Side Brush Cleaning Tool Power Cord
Charging DockMop Pad × 2
(Pre-installed)
Mop Pad Holder × 2
Robot Vacuum

6
Robot Vacuum
Note: When the robot vacuum is cleaning or returning to the dock to charge, press any
button to pause it.
Indicator
•White: Cleaning/Cleanup completed/Fully charged
•Blinking white: Returning to dock to charge/Updating firmware/
Repositioning/Awaiting connection/Connecting to Wi-Fi
•Breathing white: Charging
•Blinking orange: Error
•Orange: Wi-Fi is not connected
Press to send robot vacuum back to charging dock
Enable/Disable child lock function: Press and hold for 3 seconds
Power/Clean Button
Dock Button
Power on/off: Press and hold for 3 seconds
Clean: Press to start cleaning after the robot vacuum is powered on

7
Robot Vacuum and Sensors
Omnidirectional Wheel
Charging Contacts
LDS Laser Sensor Cover
LDS Laser Sensor
Bumper
Line Laser Sensor
Cover
Side Brush
Brush
Main Wheel Brush Cover Clip
Cliff Sensor
Main Wheel
Mop Pad Holder
Mounting Hole
Brush Cover
Wi-Fi Indicator
•On: Wi-Fi connected
•Off: Wi-Fi is not connected
•Blinking: Awaiting connection/Connecting
Dust Compartment
Reset Button
Press and hold for 3 seconds to restore factory settings
Water Tank
Air Outlet/Speaker

8
Charging Dock
Dust Compartment
Signaling Area
Charging Contacts
Power Port
Filter ClipDust Compartment Cover
Dust Compartment Cover Clip
Dust Compartment Clip
Filter
Water Tank
Water Tank Plug
Water Filling Opening
Water Tank Release Button
Mop Assembly
Mop Pad Attachment Area
Mop Pad Holder Mop Pad

9
Connect to An Electrical OutletRemove Protective Coverings
How to Install
Before using the robot vacuum, remove the protective strips from both sides.
Install the Side Brush
Install the side brush onto the clip on the bottom of the robot vacuum.
Side Brush Clip
Place the charging dock near an electrical outlet in an area with a good Wi-Fi
signal. Then connect the charging dock to power.
Place the Robot Vacuum
Place the robot vacuum onto the charging dock, and the robot vacuum will
automatically turn on and start charging. After 10 minutes of being fully
charged, the indicator will go out. Fully charge the robot vacuum when using it
for the first time.
Note: Make sure the charging contacts on the robot vacuum and the dock are fully aligned.
Note: Do not place any items within the range of 0.5 m at either side or within 1.5 m in front of the
charging dock.
＞1.5 m
＞0.5 m
＞0.5 m
