Xiaomi Mi Robot STYTJ02YM User manual

Mi Robot Vacuum-Mop Cleaner
Model : STYTJ02YM
User Manual
Represented by https://fr.aliexpress.com/item/4000095616285.html
Please read this manual carefully before use and keep it properly. The adapter supplied with this product can only be used
at an altitude below 2000m.

Product Introduction.
............................................................................................................................................
1-3
Installation Instructions ........................................................................................................................................
4-5
Operation Instructions. ........................................................................................................................................
6-7
Routine Maintenance.........................................................................................................................
8-9
Basic Parameters
..................................................................................................................................................
10
Troubleshooting
....................................................................................................................................................
11
Common Problems ...............................................................................................................................................
12
Restrictions on Use.
.............................................................................................................................................
13
Warranty Certificate ..............................................................................................................................................
14

Product Introduction
1
Robot
Intelligent recharging
Short press it to start intelligent recharging
Startup and shutdown/global cleaning
Short press it to start/suspend cleaning
Long press it for 3s to start up or shut down the robot
Blue light remains on: Working normally
Yellow light blinks slowly: Returning for recharging / low battery
Yellow light breathes: Charging
Blue light blinks slowly: Entering the network configuration mode
Blue light breathes: Starting up / Upgrading firmware
Red light blinks fast: Abnormal state
Network configuration
In power-on state, press and hold and
simultaneously for 3s to enter network configuration.
Cover opening
Tip: The dustbin can be removed by opening the top
cover from here.

Product Introduction
2
Robot and Sensor
Laser radar
Top cover
Button
Infrared receivingsensor
Collision sensor
Universal wheel
Charging electrode
Battery
Side brush
Boundary sensor
Cover for middle motor
Rolling brush
Left wheel
Right wheel

Product Introduction
Water Tank Charging Dock
Water inlet
Water tank
Water tank clip
Signal
transmitting area
Charging
electrode
Charging indicator
Charging electrode
Cable slot
Dustbin component Duster component
Dustbin
HEPA
Duster
Duster bracket
Sticking
Filter mesh Clip
3
