XINDAK D2 User manual

D/A Convertor
D2
INSTRUCTIONS
®

It means that used electrical and electronic products should not be mixed with general household waste There is a separate collection.
system for these products.
A Information on Disposal for Users private household. ( ).
1. In the European Union
Attention If You want to dispose of this equipment please do not use the ordinary dust bin: , .
Used electrical and electronic equipment must be treated separately and In accordance with legislation that requires proper treatment,
recovery and recycling of used electrical and electronic equipment.
Following the implementation by member states private household within the EU states may return their used electrical and electronic,
equipment to designated collection facilities free of charge In some countries your local retailer may also take back your local*. *
authority for further details.
If you used electrical or electronic equipment has batteries or accumulators please dispose of these separately beforehand according,
to local requirements.
By disposing of this product you will help ensure that waste undergoes the necessary treatment recovery and recycling and thus,
prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste
handling.
2. In the other Countries outside EU
If you wish to discard this product please contact your local authorities and ask for the cor,rect method of disposal.
For Switzerland Used electrical or electronic equipment can be returned free of charge to dealer even if you don’t purchase a new: ,
product Further collection facilities are listed on the homepage of www swico ch or www sens ch. . . . . .
B Information on Disposal of Business Users.
1. In the European Union
If the product is used for business and you want to discard it:
2. In the other Countries outside the EU
If you wish to discard of this product please contact your local authorities and ask for the cor,rect method of disposal.
Attention: Your product is marked with this symbol.
Please contact local dealer who will inform you about the take-back of the product. You might be charged for the costs arising from
take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

Important Safety Instruction
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to presence of uninsulated “Dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
Dangerous Voltage
The exclamation point within an equilateral triangle is intended to alert the
user to presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Important Instructions
!
Chapter 1
1
!
CAUTION

Chapter 2 Notice
2.1 Before Use
Unpack this product and keep all packing materials for future transport or service, locate and remove all accessory
items from the accessory box within the controller shipping carton.
Accessories Included:
Please read all instructions and precautions carefully and completely before operating this product.
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Always keep this unit out of the reach of children.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus ( including amplifiers) that
produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
10. Unplug this apparatus during lightning storms or when unused for a long time.
11. Always disconnect your entire system from the AC mains before connecting or disconnecting any cable, or when cleaning any
component.
12. This product must be terminated with a three conductor AC mains power cord which includes an earth ground connection, to
prevent shock hazard, all three connections must always be used.
13. AC extension cords are not recommended for use with this product.
14. Never use flammable or combustible chemicals for cleaning audio components.
15. Never operate this product with any cover removed.
16. Never pour or spill liquids directly onto this unit.
17. Never block air flow through ventilation slots or heat sinks.
18.Never by pass any fuse.
19. Never replace any fuse with a value or type other than those specified.
20. Never attempt to repair this product, if a problem occurs, contact your dealer.
21. Never expose this product to extremely high or low temperatures.
22. Never operate this product in an explosive atmosphere.
1. AC power cord × 1 2. Remote controller 3. Users’ manual (This manual)
2.2 Check Accessory
2

AAA Batteries
Install Batteries
Before using the remote controller for the first time, you need install
the new battery in the remote controller.
1. Use the tool to remove the rear cover of the remote control unit.
3. Reinstall the rear cover of the remote control unit.
1. Do not use new and old batteries simultaneously.
2. Batteries with similar shapes may have different rated voltage,
be sure to use the correct batteries.
3. Remove batteries from the remote control unit if it will not be used
for a long period of time.
Process
Battery Replacement
2. Install the 2 batteries (AAA) polarity.
1. Use the tool remove the rear cover of the remote control unit.
2. Take out the old batteries from remote control unit.
. Install the 2 batteries (AAA) polarity.
4. Reinstall the rear cover of the remote control unit.
Caution
If you use the remote control unit to control the D10:
1.The remote control range is approximately 5 meters.
2.Pointing the remote control on an angle to the receiver, will
shorten the useful distance of the remote control.
with correct +/-
3 with correct +/-
Using Remote Controller
Install Batteries
Battery Reclaim
Please send the waste batteries to local battery
reclaim center. DO NOT discard the waste
batteries discretionarily, in order to avoid
environment pollution.
3
coax ia l
BAL.
BNC
Volum e
Introduction
Chapter 3
3.1 Remote Controller
Coa xi al
BAL.
BNC
Volume
Signal input selection buttons

4
Power on/off button IR sensor
for remote
control
Signal
indicator
Input
selector
Input
indicator
Introduction
Chapter 3
3.2 Front Panel
Mains
input
BNC
input
AES/EBU
input
Coaxial
input
Audio
outputs
3.3 Rear Panel

Specification
System:
Power specifications
Power consumption
Frequency range
Dynamic range
Harmonic distortion+Noise(THD+N)
Signal-to-Noise Ratio
Digital coaxial input
Digital coaxial input impedance
Output voltage
Net weight
Dimensions(WΧHΧD)
Specification and design subject to change without notice for improvements.
NOTE
Interchannel Crosstalk
Chapter 4
5
Stereo audio digital to analog converter
Specified on rear panel decal
max. 11W
20Hz-20KHz, 0.5dB
125dB
-100dB
-110dB
-130dB
0.5Vp-p
75Ω
2V(RMS,0dB)
7Kg
330mmx101mmx317mm
( )With A-Weighted
4.1 Specifications

No.126, Section 2, East 1 Round Chengdu, Sichuan, China P.C. 610051
You can find your nearest authorized distributor and more product information on our website:
www.xindak.com
Print in China
