Xinje TH465-M User manual

THseries Touch Screen
User’s manual
Xinje Automation Co.,Ltd

Preface
Thank you for buying TH series touch screen made by Xinje Electronic Co., Ltd, this manual
should be read and understood before doing relative operation.
nThis manual will guide readers in the correct operating and maintaining TH series touch
screen. Also, this manual refers to the application situations, operations, transportation,
storage, set up, installation, maintaining and so on.
nThis manual mainly contains three parts: hardware, software, application.
下面的内容只针对 TP 系列产品。
Please read this manual very carefully before operationand please do the correct operations
while paying close attention to all the safty points.The following contents only used for TP
series touch screen.
ØHardware Part: contain the characteristics, specifications, dimensions, installations and
communication connecting of TH series.
ØSoftware Part: introduce how to use the edit software.
ØApplication Part: illustrate the examples, make users to know TH better.
This manual is fit for following personnel:
ØEnd Users
ØEngineers
ØTechnicians
Please read the safety notes carefully before using the products.
Purpose
Personnel
Contact us
If you have any questions, please contact us use the following methods:
Tel: [phone]-221
Fax: [phone]
Address: 4th Floor, Building 7, Original Industrial Park, No.100 Dicui Road,
Wuxi, Jiangsu province, China

Safety caution
Please read the manual carefully before using. Make sure your operation is correct and safety. The
following contents are only aimed at TH series products.
Please keep the manual properly, put in the location easy to get and read, hand the manual to the
end users.
lPlease do not bundle power line with communication cable or let them too close,
keep at least 10cm.
lPlease do not install module or change the wire. Otherwise it may cause
malfunction, error action, damage or fire.
lPlease shut off the power when there is abnormal smell or voice in TH products.
(The short sound made by buzzer after power on is normal)
lDo not strike the touch panel with a hard or sharp object, or press on the touch
panel with too much force or with pen, screw, since it may damage the touch panel
and cause damage.
lPlease tighten the screws when install the products to prevent from falling off.
lPlease transport, store, set up, install and maintain the products correctly, otherwise
the touch panel may be damaged.
lConfirm the rated voltage of TH and connect correct before power on.
lPlease do not touch the terminals after power on to avoid electric shock.
lPlease do not open the cover board.
lPlease cut off all the power when installing or disassembling the products, or it
may cause error action and malfunction.
lPlease use TH touch screen in suitable environment conditions according to
instructions, otherwise it may cause accident.
lPlease do not use the products where there is high frequency radiate, high magnetic
field or other interferences.
DANGERS
NOTICE

Catalog
Preface...............................................................................................................................................3
Safety caution....................................................................................................................................4
1. Summarize ................................................................................................................................7
1.1 Performance characteristics ..........................................................................................7
1.2 Work flow............................................................................................................................8
2. General specification.....................................................................................................................9
2.1 TH465-M ..........................................................................................................................10
2.2 TH765-M ..........................................................................................................................11
2.3 TH865-M ..........................................................................................................................12
2.4 THA61-M..........................................................................................................................13
3. Hardware.....................................................................................................................................14
3.1 Hardware structure............................................................................................................14
3.2 Dimension.........................................................................................................................15
3.3 Installation and using environment...................................................................................17
4. Interface and switch ......................................................................................................................1
4.1 Introduction.........................................................................................................................1
4.2 DIP switch...........................................................................................................................1
4.3 COM1 port..........................................................................................................................1
4.4 COM2 port..........................................................................................................................4
4.5 USB-A port .........................................................................................................................5
4.6 USB-B port .........................................................................................................................6
5. TouchWin software .......................................................................................................................7
5.1 Preparation..........................................................................................................................7
5.2 The construction of Touchwin.............................................................................................8
5.2.1 Screen.......................................................................................................................8
5.2.2 Project bar ................................................................................................................8
5.2.3 Menu ......................................................................................................................10
5.3 Tool bar .............................................................................................................................16
6. Make a simple project.................................................................................................................19
6.1 Build a new project ...........................................................................................................19
6.2 Make a simple project.......................................................................................................20
6.3 simulate offline .................................................................................................................22
6.4 Simulate online .................................................................................................................23
6.5 Download the project........................................................................................................24
7. Application..................................................................................................................................25
7.1 Adjust the touch area.........................................................................................................25
7.2 Photo application...............................................................................................................27
7.3 Debug and download ........................................................................................................30
7.4 Data backup.......................................................................................................................31
7.4.1 Data export.............................................................................................................31
7.4.2 Import the CSV data...............................................................................................41
8. TH series touch screen interior objects .......................................................................................49

1. Summarize
Xinje new touch screen TH series are based on TP series products. It not only has the language,
characters editing, data display, monitor and alarm functions but also has 65536 true color LCD
which can bring you brand-new vision enjoyment. It has the advantage of large capability for data
duplication and friendly user interface. It provides perfect humanized solution for industrial
system, make it easy to control the system.
The function compare between TP and TH:
Function compare
Series
Colors Font
setting
3D
library
Adjust
the touch
area
Animation Password
Two ports
communication
independently
USB data
download
USB data
duplication
TP 256 √〇〇√√√〇〇
TH 65536 √√√√√√√√
1.1 Performance characteristics
lVarious models: product size from 4.7’’to 10.4’’.
lRich colors: 65536 TFT true color, support BMP, JPG format, display more lively.
lAdjust function for touch screen.
lSupport multinational language: simple/traditional Chinese, English, Japanese, Korean.
Define the font as you like, support underline, italic, bold, shadow and other art words.
lLarge picture library, with preloading mode, no delay for screen motion.
lSwitch control, dynamic monitor and display data, bar map, real time trend map, time trend
map, XY trend map, discrete/continue column map, real time alarm, history alarm record…
lUser-defined data collection and saving function
lSet user’s authority, 9 levels password protection
lSimulate online/offline, upload/download data, configuration function
lUSB port inside, connect flash disk to realize data duplication function, speed 480Mbps
lSpecial USB-B port for data download, make the data transfer faster
lUser-defined animation track design
Display
Control

lTwo ports communication independently, can connect two different devices at the same time
lDrive the panel printer directly, economical and flexible
lSupport free format communication, user edits the driver program
1.2 Work flow
The work flow of using TH:
NOTICE
Communication
Edit your project
Connect PC and TH, power on
Download project in TH
Connect TH with other devices
Realize communication and data transmission
Do simulate offline
Simulate the TH
action in the
software.
Do simulate online
Connect the PC with
TH, simulate the action
in your PC
Install edit software TouchWin
Please use TouchWin V2.C and laterversion to edit yourTH project.

2. General specification
This chapter will introduce the specification of TH series touch screen.
TH series touch screen contains TH465-M, TH765-M, TH856-M and THA61-M.
Series Types
TH TH465-M
TH765-M TH865-M THA61-M

2.1 TH465-M
Item TH465-M
Input voltage DC20-DC28V
Consumption current 130mA
Momentary power off
allowance
Less than 10ms
Withstand voltage AC1000V-10mA 1 minute ( signal and time )
Electrical
Insulated impedance DC500V- about 10MΩ ( signal and time )
COM1 Support RS-232/RS-485
COM2 Support RS-232/RS422/RS485
USB1 USB-A ( accord with USB2.0 )
USB2 USB-A ( accord with USB2.0 )
Interface
USB3 USB-B ( accord with USB2.0 )
Operation temperature 0－50℃
Reserve temperature -20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation 10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air No corrosive gas
Environment
Protection construction IP65
Type 65536 true colors
Screen size 4.3 inch
Use life More than 50000 hours, 24 hours running when surrounding
temperature is 25 ℃
Resolution 480*272
Contrast Non-adjustable
Character Chinese, English, Korean, Japanese…
Character size Any size and font
Screen
specification
Touch panel 4-wire resistance mode
Memory Screen 8MB
Cooling method Natural air cooling
Exterior dimension 150.0*100.0*41.0mm
Construction
Mounting dimension 144.0*94.0mm

2.2 TH765-M
Item TH765-M
Input voltage DC20-DC28V
Consumption current 250mA
Momentary power off
allowance
Less than 10ms
Withstand voltage AC1000V-10mA 1 minute ( signal and time )
Electrical
Insulated impedance DC500V- about 10MΩ ( signal and time )
COM1 Support RS-232/RS-485
COM2 Support RS-232/RS422/RS485
USB1 USB-A ( accord with USB2.0 )
USB2 USB-A ( accord with USB2.0 )
Interface
USB3 USB-B ( accord with USB2.0 )
Operation temperature 0－50℃
Reserve temperature -20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation 10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air No corrosive gas
Environment
Protection construction IP65
Type 65536 true colors
Screen size 7 inch
Use life More than 50000 hours, 24 hours running when surrounding
temperature is 25 ℃
Resolution 800*448
Contrast Non-adjustable
Character Chinese, English, Korean, Japanese…
Character size Any size and font
Screen
specification
Touch panel 4-wire resistance mode
Memory Screen 128MB
Cooling method Natural air cooling
Exterior dimension 205.0*151.5*48.9mm
Construction
Mounting dimension 192.0*138.5mm

2.3 TH865-M
Item TH865-M
Input voltage DC20-DC28V
Consumption current 260mA
Momentary power off
allowance
Less than 10ms
Withstand voltage AC1000V-10mA 1 minute ( signal and time )
Electrical
Insulated impedance DC500V- about 10MΩ ( signal and time )
COM1 Support RS-232/RS-485
COM2 Support RS-232/RS422/RS485
USB1 USB-A ( accord with USB2.0 )
USB2 USB-A ( accord with USB2.0 )
Interface
USB3 USB-B ( accord with USB2.0 )
Operation temperature 0－50℃
Reserve temperature -20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation 10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air No corrosive gas
Environment
Protection construction IP65
Type 65536 true colors
Screen size 8 inch
Use life More than 50000 hours, 24 hours running when surrounding
temperature is 25 ℃
Resolution 800*600
Contrast Non-adjustable
Character Chinese, English, Korean, Japanese…
Character size Any size and font
Screen
specification
Touch panel 4-wire resistance mode
Memory Screen 128MB
Cooling method Natural air cooling
Exterior dimension 224.4*170.8*45.5mm
Construction
Mounting dimension 211.4*157.8mm

2.4 THA61-M
Item THA61-M
Input voltage DC20-DC28V
Consumption current 630mA
Momentary power off
allowance
Less than 10ms
Withstand voltage AC1000V-10mA 1 minute ( signal and time )
Electrical
Insulated impedance DC500V- about 10MΩ ( signal and time )
COM1 Support RS-232/RS-485
COM2 Support RS-232/RS422/RS485
USB1 USB-A ( accord with USB2.0 )
USB2 USB-A ( accord with USB2.0 )
Interface
USB3 USB-B ( accord with USB2.0 )
Operation temperature 0－50℃
Reserve temperature -20-60℃
Environment
temperature
20-85% ( no condensation )
Withstand oscillation 10-25Hz ( X, Y, Z each direction 30 minutes 2G )
Anti-jamming Voltage noise: 1000Vp-p, pulse 1us, 1 minute
Surrounding air No corrosive gas
Environment
Protection construction IP65
Type 65536 true colors
Screen size 10.4 inch
Use life More than 50000 hours, 24 hours running when surrounding
temperature is 25 ℃
Resolution 640*480
Contrast Non-adjustable
Character Chinese, English, Korean, Japanese…
Character size Any size and font
Screen
specification
Touch panel 4-wire resistance mode
Memory Screen 128MB
Cooling method Natural air cooling
Exterior dimension 311.0*234.0*48.0mm
Construction
Mounting dimension 302.0*225.0mm

3. Hardware
3.1 Hardware structure
The hardware structure of TH series touch screen includes front and back side. Take TH465-M as
an example to explain the structure.
Touch area
Power LED
USB-A port
Label
Power Plug DIP switch COM1 port
COM2 port
USB-A port
USB-B port

3.2 Dimension
(1) TH465-M exterior dimension:150.0mm×100.0mm×41.0mm, mounting dimension:
144.0mm×94.0mm.
(2) TH765-M exterior dimension:205.0mm×151.5mm×48.9mm, mounting dimension:
192.0mm×138.5mm.
144.0
94.0
24V0VFG
12 34
92.0
142.0
41.0 150.0
100.0
COM1 COM2
138.5
192.0
48.9
12.0
136.5
190.0
1 23 4
24V0VFG
1234
COM1 COM2
205.0
151.5

(3) TH865-M exterior dimension: 224.4mm×170.8mm×45.5mm, mounting dimension:
211.4mm×157.8mm.
(4) THA61-M exterior dimension: 311.0mm×234.0mm×48.0mm, mounting dimension:
302.0mm×225.0mm.
211.4
157.8
1234
1234
Download PLC
24V0VFG
224.4
170.8
38.0
45.5
155.8
209.4
302.0
225.0
+24V0V FG
311.0
234.0
48.0
223.0
43.1 300.0
1234
+24V0V FG
COM1 COM2

3.3 Installation and using environment
(1) Install requirements:
TH has four ferric mounting racks when out of factory, there are two square holes on the up, down
side of TH, use mounting rack to fix the TH with control cabinet.
In order to avoid TH temperature too high after long time working, please keep 10cm space on the
up/down and 5cm on the left/right side of the TH when installing.
(2) Install steps
Step1 Refer to the dimension in the former chapter to open a rectangle mounting hole in the
control cabinet
Step2 Add airproof circles in the airproof slot when installing
Step3 Insert the bottom of TH into the mounting hole of control cabinet
Step4 Insert the install rack into the fix hole of TH then tighten the screw
Step5 Connect TH and PLC with communication cable
NOTICE
(3) Environment
Please use TH series touch screen indoor.
Do not use TH in below environment:
Inflammable gas, steam, dust, fast vary temperature, high humidity ( it may cause moisture inside
TH).
Fixed bracket
Install panel
The communication cable can be offered by the supplier or made by user according to the
connection map, input +24V DC power to start working

(4) Power supply requirements:
TH series touch screen use DC +24V power supply only. The permitted voltage range is 20V~28V.
The connection is as below:
Besides, if connect high voltage or AC power supply with TH, the TH may be damaged and cause
electric shock to human body.
NOTE: if use the DC +24V output of PLC to drive the TH, make sure the PLC has enough current
to drive the TH.
(5) Maintenance and cleaning
lPlease do not open the back cover by yourself.
lPlease do not analyze or change TH by yourself
lPlease cut off all the power supply while observing the TH.
lPlease do not touch terminals after power on, otherwise it may cause electric shock.
lDo not hot plug the cable or pull the cable when communicating, it may destroy the cable.
lPlease periodic check installation and screws to avoid falling off.
lPlease use TH series touch screen in the certain conditions according to instructions.
lKeep the cleanness of touch area, in order to keep touch sensitivity.
lPlease use clean cloths with little detergent or alcohol to clean the screen.
lNeutral detergent, without acid, alkali is recommended.
lKeep the TH away from thrill or strong corrosive gas
lNever use spray detergent.
lAvoid damage to the screen, please do not touch the screen too hard while wiping.
+24V0 V
+DC-
Caution
Maintenance
Clean
Caution

lPlease dispose the TH as industry waste.
Disposal
Caution

4. Interface and switch
4.1 Introduction
TH series touch screen has 1 group of DIP switch and 5 communication ports.
1: DIPswitch 4: USB-A port1
2: COM1 port 5: USB-A port2
3:COM2 port 6: USB-B port3
4.2 DIPswitch
TH has one group of DIP switch at the back side; they can set the function of COM1 port.
Switch
Switch1 Switch2 Switch3 Switch4 Function
ON OFF
OFF
OFF
Undefined
OFF
ON OFF
OFF
Forced download mode of COM1
OFF
OFF
ON OFF
Adjust mode of touch area
State
OFF
OFF
OFF
ON Interior check mode ( not recommend to use)
4.3 COM1 port
TH series touch screen COM1 port has these functions:
ØCommunication function: connect with PLC, printer, frequency inverter, used as communication port.
ØDownload function: connect with PC, used to download data and screens.
1 2 34
5
6
