XONTEL XT-12P User manual

XT-12P User Manual

About This Manual
Thank you for choosing XonTel XT-12P door phone. This manual is intended for end users who need to properly configure the door
phone. This manual provides all functions’ configurations of XT-12P. Please visit XonTel forum or consult technical support for any
new information or latest firmware.
Note: Please refer to universal abbreviation form in the end of manual when meet any abbreviation letter.

Content
1. Product Overview...........................................................................................................................................................................8
1.1. Product Description.................................................................................................................................................................8
1.2. Connector Introduction............................................................................................................................................................8
2. Daily Use.......................................................................................................................................................................................10
2.1. Make a Call...........................................................................................................................................................................10
2.2. Receive a Call.......................................................................................................................................................................10
2.3. Unlock...................................................................................................................................................................................11
2.3.1. Unlock by Public Pin Codes.........................................................................................................................................11
2.3.2. Unlock by Private Pin Codes .......................................................................................................................................11
2.3.3. Unlock by RFID Cards.................................................................................................................................................12
2.3.4. Unlock by DTMF Codes...............................................................................................................................................12
3. Basic Features..............................................................................................................................................................................13
3.1. Access the Website Setting ..................................................................................................................................................13
3.1.1. Obtain IPAddress........................................................................................................................................................13
3.1.2. Access the Device Website .........................................................................................................................................13
3.2. Password Modification..........................................................................................................................................................14

3.2.1. Modify the Device Admin Code....................................................................................................................................14
3.2.2. Modify the Web Password...........................................................................................................................................14
3.3. Phone Configuration.............................................................................................................................................................14
3.3.1. Language.....................................................................................................................................................................14
3.3.2. Time...................................................................................................................................................................................15
3.3.3. Network .......................................................................................................................................................................15
3.3.4. Sound..........................................................................................................................................................................16
3.4. Intercom Call.........................................................................................................................................................................18
3.4.1. Direct IP Call................................................................................................................................................................18
3.4.2. SIP Call........................................................................................................................................................................19
3.4.3. SIPAccount.................................................................................................................................................................19
3.4.4. SIP Server 1&2............................................................................................................................................................20
3.4.5. Outbound Proxy Server ...............................................................................................................................................20
3.4.6. Transport Type ........................................................................................................................................................................21
3.4.7. NAT...................................................................................................................................................................................................21
3.4.8. Speed Dial...................................................................................................................................................................22
3.4.9. Auto Answer.................................................................................................................................................................22

3.4.10. Web Call....................................................................................................................................................................23
3.4.11. Dial Plan ....................................................................................................................................................................23
3.5. Security.................................................................................................................................................................................24
3.5.1. Live view......................................................................................................................................................................24
3.5.2. RTSP...........................................................................................................................................................................25
3.5.3. ONVIF..........................................................................................................................................................................27
3.6. Access Control......................................................................................................................................................................28
3.6.1. Unlock via DTMF.........................................................................................................................................................28
3.6.2. Unlock via RFID Card..................................................................................................................................................34
3.6.3. Unlock via Pin Code ....................................................................................................................................................35
3.6.4. Unlock via HTTP command.........................................................................................................................................36
3.6.5. Unlock via Exit Button..................................................................................................................................................37
3.7. Reboot..................................................................................................................................................................................38
3.8. Reset ....................................................................................................................................................................................38
4. Advanced Features......................................................................................................................................................................39
4.1. Phone Configuration.............................................................................................................................................................39
4.1.1. LED..............................................................................................................................................................................39

4.1.2. IR LED.........................................................................................................................................................................40
4.1.3. RFID Card Code Display Related................................................................................................................................41
4.2. Intercom................................................................................................................................................................................42
4.2.1. Call Time Related ........................................................................................................................................................42
4.2.2. SIP Call Related ..........................................................................................................................................................42
4.2.3. Codec..........................................................................................................................................................................43
4.2.4. DTMF...........................................................................................................................................................................45
4.2.5. Encryption....................................................................................................................................................................46
4.2.6. NAT...................................................................................................................................................................................................46
4.2.7. User Agent...................................................................................................................................................................46
4.3. Access Control......................................................................................................................................................................47
4.3.1. Web Relay...................................................................................................................................................................47
4.4. Security.................................................................................................................................................................................48
4.4.1. Anti-alarm ....................................................................................................................................................................48
4.4.2. Motion..........................................................................................................................................................................49
4.4.3. Action...........................................................................................................................................................................50

4.5. Upgrade................................................................................................................................................................................53
4.5.1. Web Upgrade...............................................................................................................................................................53
4.5.2. Autop Upgrade.............................................................................................................................................................53
4.5.3. Backup Config File.......................................................................................................................................................54
4.6. Log........................................................................................................................................................................................55
4.6.1. Call Log .......................................................................................................................................................................55
4.6.2. Door Log......................................................................................................................................................................55
4.6.3. System Log..................................................................................................................................................................56
4.6.4. PCAP...........................................................................................................................................................................57
Contact us.............................................................................................................................................................................58

1. Product Overview
1.1. Product Description
XonTel XT-12P is a SIP-compliant, hands-free and video door
phone. It can be connected with XonTel indoor monitors for remote
access controlling and monitoring. Users can communicate with
visitors via audio and video calls, and unlock the door if they need.
Users can also use RFID cards to unlock the door
1.2. Connector Introduction
Ethernet (POE): Ethernet (POE) connector which it can provide
both power and network connection.
12V/GND: External power supply terminal if POE connector is not
available.
WG_D0/WG_D1: Wigand terminal.
Figure 1.1 Product Description

DOORA/B: Trigger signal input terminal.
RelayA/B (NO/NC/COM): Relay control terminal.
Note: The general door phone interface diagram is only for
reference.

2.Daily Use
2.1. Make a Call
Press the SIP account number or IP address and “Dial key” to make a call.
Management center call: Users can make a speed dial to
management center by pressing “Management center key.”
2.2. Receive a Call
XT-12P will auto answer the incoming call by default. If users
disable auto answer function, they can press “Dial key” to answer
the incoming call.

2.3. Unlock
2.3.1. Unlock by Public Pin Codes
Users can unlock doors by using predefined public pin code. Press
“#,” public pin code, “#” to unlock, and then users will hear “The
door is now opened.” If users press wrong public pin code, the
screen will show “Incorrect Code.” The default public pin code is
33333333. The default public pin code is 8 digits, and it can be
changed to 3 to 8 digits.
2.3.2. Unlock by Private Pin Codes
Users can unlock doors by using predefined private pin code.Press
“#,” private pin code, “#” to unlock, and then users will hear “The
door is now opened.” If users press wrong private pin code, the
screen will show “Incorrect Code.” The default private pin code is 8
digits, and it can be changed to 3 to 8 digits.

2.3.3. Unlock by RFID Cards
Place the predefined user cards in RFID card reader to unlock.
Under normal conditions, XT-12P will announce “The door is now
opened.” If the card has not been registered, XT-12P will show
“Unauthorized.” Both 13.56MHz and 125KHz RFID cards are
supported on XT-12P.
2.3.4. Unlock by DTMF Codes
Users can press the predefined DTMF code from an answer unit to
remotely unlock the door during the call. Users will also hear “The
door is now opened.”

3.Basic Features
3.1. Access the Website Setting
3.1.1. Obtain IP Address
XT-12P use DHCP IP by default. Press “*3258*” to and voice
system will enter IP announcement mode. In IP announcement
mode, the IP address will be announced.
3.1.2. Access the Device Website
Open a web browser, and access the corresponding IP address.
Enter the default user name and password to login. The default
administrator’s user name and password are shown below:
User Name: admin
Password: xontel
Figure 3.2.2 Access the device website

3.2. Password Modification
3.2.1. Modify the Device Admin Code
Go to Intercom –PIN Setting to modify device admin code.
3.2.2. Modify the Web Password
Go to Security - Basic to modify password for webpage.
To modify password for “admin” or “user” account.
Choose the user then click on “ Change Password “
3.3. Phone Configuration
3.3.1. Language
Go to Phone - Time/Lang to select language for webpage.

3.3.2. Time
NTP: To select local time zone for NTP server.
3.3.3. Network
DHCP Mode
In Website, go to Network - Basic.
XT-12P uses DHCP mode by default which will get IP address,
subnet mask, default gateway and DNS server address from
DHCP server automatically.
Static IP Mode
In Website, go to Network - Basic.
If select static IP, users should manually setup IP address, subnet
mask, default gateway and DNS server address. The figure right
shows static IP settings.

3.3.4. Sound
Go to Phone - Voice to configure volume and upload tone file.
Mic Volume: To configure microphone volume.
Volume Level: To configure volume level.
Speaker Volume: To configure speaker volume.
Keypad Volume: To configure Keypad volume.
Tamper Alarm Volume: To configure tamper alarm volume.
Ringback Volume: To configure ringback volume.

Open Door Warning: Disable it, and users will not hear the
prompt voice when the door is opened.
IP Announcement: Configure loop times that user will hear the
voice prompt of intercom IP address after pressing “ *3258* “.
RingBack Upload: Toupload the ring back tone by users
themselves.
Opendoor Succ Tone Upload: Toupload the open door success
tone by users themselves.
Opendoor Failed Tone Upload: Toupload the open door failed
tone by users themselves.

3.4. Intercom Call
3.4.1. Direct IP Call
Go to Phone - Call Feature - Others to enable the direct IP call for
door phones first.
Press the IP address like 192.168.1.100, users need to press
192*168*1*100 and “ Dial Key “ to make IP direct call

3.4.2. SIP Call
SIP calls which use SIP numbers to make or receive calls should be
supported by SIP server. Users need to register accounts and fill
SIP feature parameters before using it.
Go to Account - Basic to configure SIP account and SIP server for
door phones first.
3.4.3. SIP Account
Status: To display register result.
Account Active: Enable this option to start SIP account registration.
Display Label: To configure label name in the intercom.
Display Name: To configure name sent to the other call party for
displaying.
Register Name: To enter extension number which users want and
the number is allocated by SIP server.

User Name: To enter user name of the extension.
Password: To enter password for the extension.
3.4.4. SIP Server 1&2
Server IP 1: To enter SIP server’s IP address or URL.
Server IP 2: To display and configure secondary SIP server
settings. This is for redundancy, if registering to primary SIP server
fails, the phone will go to secondary SIP server for registering.
Registration Period: The registration will expire after registration
period, and the phone will re-register automatically within
registration period.
3.4.5. Outbound Proxy Server
An outbound proxy server is used to receive all initiating request
messages and route them to the designated SIP server.
