XPR Access B100PAD-M User guide

www.xprgroup.com 1
Biometric Keypad Reader
EN
INSTALLER MANUAL
B100PAD- M
v. c2

www.xprgroup.com 2
1. DESCRIPTION
2. SPECIFICATIONS
3. MOUNTING
4. WIRING
5. CONNECTING BIOMETRIC READERS TO EWS CONTROLLER
5.1 CONNECTING BIOMETRIC READERS IN SAME RS485 LINE WITH THE EWS CONTROLLERS
5.2 CONNECTING BIOMETRIC READERS WHEN ALL THE CONTROLLERS HAVE TCPIP COMMUNICATION
5.3 RS485 TUNING
6. CONNECTING BIOMETRIC READERS TO 3RD PARTY CONTROLLER
6.1 CONVERTERS PIN DESCRIPTION
7. ENROLLMENT
8. CONFIGURING THE BIOMETRIC READERS IN PROS SOFTWARE
8.1 ADDING BIOMETRIC READER
8.2 ENROLLING FINGERPRINTS FROM A READER
8.3 ENROLLING FINGERPRINTS FROM DESKTOP READER
8.4 DELETING FINGERPRINTS
8.5 UPLOADING THE FINGERPRINTS TO THE BIOMETRIC READERS
8.6 FIRMWARE UPDATE
8.7 SEND CONFIGURATION
8.8 ADVANCED SETTINGS
8.9 ENTRY MODE
8.9.1 Access Code or Finger
8.9.2 Access Code and Finger
8.9.3 Finger Only
9. CONFIGURING THE BIOMETRIC READERS IN BIOMANAGER
9.1 ADD PORTAL
9.2 ADD READER
9.3 EDIT READER
9.4 DELETE READER
9.5 ADD USER
9.6 DELETING FINGERPRINTS
9.7 UPLOADING THE FINGERPRINTS TO THE BIOMETRIC READERS
9.8 CUSTOM WIEGAND
10. WIEGAND PROTOCOL DESCRIPTION
11. SAFETY PRECAUTIONS
3
3
4
4
5
5
6
6
7
7
7
8
8
9
10
11
11
12
12
12
13
13
13
13
14
14
14
15
15
16
17
17
18
19
20
CONTENS

www.xprgroup.com 3
1. DESCRIPTION
2. SPECIFICATIONS
Fingerprint capacity up to 100 ingerprints
Technology Biometry and Keypad
Use Outdoors
Authentication Finger, PIN Code, Finger or/and PIN Code
Fingerprints per user 110 ingerprints
PIN Code Length 1- 8 Digits
Interface Wiegand 8 to 128 bits; Default: Wiegand 26bit
Protocol programming By PROS CS software (EWS system) and BIOMANAGER (all access control systems)
Cable distance 50m
Fingerprint Sensor Type Swipe Capacitive
1:1000 identiication time 970 msec, including feature extraction time
Fingerprint enrolment On the reader or from the USB desktop reader
Panel Connection Cable, 1m
Green and Red LED Externally Controlled
Orange LED Idle mode
Buzzer ON/OFF Yes
Backlight ON/OFF Yes, by software settings
Tamper Yes
Consumption Max. 150mA
IP Rating 65
Power supply 914V DC
Operating Temperature -20°C to +50°C
Dimensions (mm) 100 x 94 x 30
Housing Moulded Aluminium
Storage/Operating Humidity 5% to 93% RH without condensation
B100PADM is a Wiegand biometric reader for outdoors access control applications. It oers storage up to 100 ingerprints,
programmable Wiegand Output (8 to 128 bits) and selectable PIN Code length.
Coniguration of the readers and ingerprint enrollment is done through PC Software.
Connection between the biometric readers is RS485 and it is used for ingerprint transfer and coniguration.
When used with third party controllers, the connection between the Biometric readers and the PC is done through a converter
(CNV200RS485 to USB or CNV1000RS485 to TCP/IP). Only one converter is needed per system (one converter for 1, 2, 3...30, 31
Biometric readers)
The tamper switch output can trigger the alarm system, if an attempt is made to open or remove the unit from the wall.
The sensor incorporates dedicated sensing hardware to facilitate the detection of “spooing” attacks based on fake ingers. This
data is embedded into the image data stream, and is processed on the processor. The system is capable of detecting and defeating
well-known fake inger mechanisms, such as molded “gummy” ingers.
The coating on the surface of the TouchChip sensor provides protection from scratching and abrasion due to normal contact
with ingertips and any incidental contact with ingernails.

www.xprgroup.com 4
3. MOUNTING
If the biometric reader is installed and used outdoor, the reader MUST be itted with MCDMINI cover available in our accessories
in order to protect the sensor from direct rainfall. The operating temperature of the product is between -15ºC - + 50ºC. If the reader
is installed in an environment where the temperature can drop below -10ºC or/and if the sensor could only be exposed to direct
sunlight, it is strongly recommended to install the reader inside a third party sealed wall mount box (itted with additional heater if
very low temperature) to keep a constant sensor level performance. XPR™ cannot guarantee the functionality of the product if
measures and advice before are not followed.
It is also strongly recommended to use double technology biometric readers when use outdoor to oer irst higher security but also
the possibility to use dierent readers depending on users.
4. WIRING
Red
Black
Pink
Violet
Orange
Green
White
Yellow
Gray
Blue
RS485
LED Red -
LED Green -
WIEGAND
12V DC
914V DC
GND ground
ARS485 A
BRS485 B
LR- Red LED -
LG- Green LED -
D1 Data 1
D0 Data 0
Tamper Tamper Switch(NO)
Tamper Tamper Switch(NO)
TricolorLED (Red, Green, Orange)
5mm 4 (3 x 30mm)
1 (M3 x 6mm)

www.xprgroup.com 5
50m. max
pink
violet
green
orange
black
red
white
yellow
A
B
LG
LR
+12V
LGD1
D0
D1
5. CONNECTING BIOMETRIC READERS TO EWS C ONTROLLER
5.1 CONNECTING BIOMETRIC READERS IN SAME RS485 LINE WITH THE EWS CONTROLLERS
- The Biometric readers can be connected to virtually any controller that conforms to Wiegand format standards (standard Wiegand
26bit or self-deined Wiegand).
- The lines D0 and D1 are the Wiegand lines and the Wiegand Number is sent through them.
- The RS485 line (A, B) is used for ingerprint transfer and reader settings.
- The Biometric readers must be powered from the controller.
- If you use dierent power supply for the biometric reader, connect the GND from the both devices to ensure correct transfer of
the wiegand signal
- When you have connected the reader and powered on, the LED should lash in orange light + 2 beeps. This lets you know it’s on
and ready for use.
- Fingerprint enrollment is done from the PC Software. Connection between the Biometric readers and the PC must be established.
• The Biometric readers are connected through RS485 bus. The same RS485 bus that the EWS controllers are connected to.
• Maximum units in one network (EWS + Biometric readers) is 32.
• If there are more than 32 units in one network, please utilize RS 485 HUB to connect.
• The RS485 Line should be conigured in the form of a daisy chain, NOT in a form of a star. If star must be used in some points, keep
the stubs from the RS485 backbone as short as possible. Maximum length of the stub is dependant of the installation (total
number of devices in RS485 line (total cable length, termination, cable type...) so recommendation is to keep stubs shorter than
5 meters, keeping in mind that this can be possible reason for errors in communication with PC software
• The cable must be twisted and shielded with a min. 0.2 mm2 cross section.
• Connect the ground (0V) of each unit in the RS 485 Line using a third wire in the same cable.
• The shield of the communication cable between two devices must be connected to the EARTH from ONE side of the RS 485 Line.
Use the side that has earth connection to the building’s grounding network.
50 ohm 50 ohm
Jumper for
RS485 termination
Jumper for
RS485 termination
TCP/IP gnd gnd
1 km max / 32 Units (EWS + Biometric Readers)
Stub
max. 5m
RS485

www.xprgroup.com 6
5.2 CONNECTING BIOMETRIC READERS WHEN ALL THE CONTROLLERS HAVE TCP/IP COMMUNICATION
50 ohm 50 ohm
Jumper for
RS485 termination
TCP/IP gnd gnd
1 km max / 32 Units (EWS + Biometric Readers)
Stub
max. 5m
RS485
TCP/IP
Switch
50m
max.
50m
max.
50m
max.
•When all the controllers are connected via TCP/IP, then the RS485 network becomes local (from Reader 1 to the Controller then
to the Reader 2).
•Connect the readers directly to the Rs485 terminals in each controller.
•If the distance Reader-Controller is high (50meters) and if the communication with the reader can not be established, then
terminate the RS485 network by closing the jumper in the EWS Controller or as described in chapter 4.
NOTE: This is recommended coniguration when you have multiple biometric readers in the same network.
In this coniguration, NO TERMINATION resistors are required.
When all the controllers have TCP/IP communication the biometric readers are easily wired. When the controllers have RS485
communication, it is diicult to maintain the daisy chain of the RS485 network. Wiring the biometric readers in that formation
is a challenge. See the schematic diagram bellow.
5.3 RS485 TUNING
Rs485 Termination resistors:
- Terminate both ends of the line with 120 Ohm resistor. If end of line is EWS, use built in resistor (120 ohm) by closing
the jumper.
- If the communication is not established and stable, use the external resistors provided in the hardware kit.
When using CAT 5 compatible cable, in most of the cases, termination made with 50 Ohm external resistor or combination
of 50 Ohm external and termination resistor from the EWS (120 Ohm) should be the solution.
RS485 RS485

www.xprgroup.com 7
6. CONNECTING BIOMETRIC READERS TO THIRD PARTY CONTROLLERS
6.1 CONVERTERS PIN DESCRIPTION
7. ENROLLMENT
3rd party controller
-+DO D1 -+DO D1 -+DO D1 -+DO D1
RS485 A CNV200 BIOE
USB Desktop Reader
optional
CNV1000 BIOMANAGER Software
A
BRS485 B
3rd party controller
CNV200
Converter RS485 to USB
Requires installation as USB
serial device (refer to
CNV200 Manual).
CNV1000
Converter RS485 to TCP/IP
Does not require installation. IP
address set through Internet
Browser
Biometric Reader
RS 485 A
RS 485 B
Converter
PIN 1 (RS 485 +)
PIN 2 (RS 485 -)
Follow the below instructions for correct inger swiping
Starting from the irst inger joint, place the selected inger on
the swipe sensor and move it evenly towards oneself in one
steady movement.
Result:
For a valid swipe: Tricolour Status LED turns green + OK
Beep(short + long beep)
For an invalid or misread swipe: Tricolour Status LED turns
red + Error Beep ( 3 short beeps)
• Connect the lines D0, D1, Gnd and +12V to the third party controller.
• Connect the RS485 Line (A, B) to the converter. Connect the converter in the PC.
• Fingerprint enrollment is done from the PC Software. Connection between the Biometric readers and the PC must be established.
• The Biometric readers communicate with each other with a RS485 and with the PC Software through a Converter.
• The RS485 Line should be conigured in the form of a daisy chain, NOT in a form of a star. Keep the stubs from the RS485 backbone
as short as possible (not more than 5 meters)
• Only one converter per installation is needed, not per reader.

www.xprgroup.com 8
8. CONFIGURING THE BIOMETRIC READERS IN PROS CS SOFTWARE
8.1 ADDING BIOMETRIC READER
1. Expand the Door item to view the readers
2. Right click on the reader and select properties (8.1)
3. In the Basic tab, for “Type” of the Reader select “B100PAD”. (8.2)
4. After selecting the type, a third tab will appear “Biometric”. Go to that tab and put the serial number of the Biometric
Reader. (8.3)
Important Note: The serial number of the reader can be found on a sticker inside the reader, on the packaging box and it can
be search from the software (right click on the portal/search devices/readers). (8.4 & 8.5)
To check if the reader is On Line, right click on the reader and select “Check version”. In the Event Window a message should
appear “Device ON Line, Type: B100PAD” (8.6)

www.xprgroup.com 9
8.2 ENROLLING FINGERPRINTS FROM A READER
1. Open the Users Window and create a new user.
Click on “New User”, put a name and ID(card number) and PIN Code. (8.7)
2. Go to the “Biometric” Tab
3. Select the reader(with left click) from which the enrollment will be done. (8.8)
4. Right click on the ingertip and select enroll. (8.9)
5. In the next 25 sec. swipe the inger on the selected reader min. 5 times and the inger tip will turn red. (8.10)
In these 25 sec. the reader will continuously blink in orange.
6. Repeat point 4&5 for each inger that should be enrolled.
7. Click on “Save New” and the ingerprint will be sent automatically to all Biometric Readers where that user has access, i.e. to
all the readers according to the Access Level assign to that user.
Example:
If the user has “Unlimited” Access level then the ingerprints will be sent to all readers, if the user has Access level only for
Reader1 and Reader 3 then the ingerprints will be sent only to those two readers.
Note:
To check if all the ingerprints are sent to the reader, right click on the reader and select “Memory Status”. (8.11)
In the event window a line will appear indicating the number of ingerprints stored in the reader. (8.12)
Note:
If more ingerprints are added for one user, all ingerprints will send the same Wiegand Code to the controller, the one written
in the ield User ID(card Number).

www.xprgroup.com 10
Plug the Swipe Desktop Reader in the PC. If the device is not installed automatically use the drivers located on the web site. It is
installed in the same way as a USB Device. When the desktop reader has been installed it will automatically appear in the Software.
(8.13)
1. Open the Users Window and create a new user.
Click on “New User”, put a name and ID(card number). (8.7)
2. Go to the “Biometric” Tab
3. Select the USB Swipe desktop Reader (with left click).(8.8)
4. Right click on the ingertip and select enroll. (8.9)
5. In the next 25 sec. swipe the inger on the selected reader min. 5 times and the inger tip will turn red. (8.10)
In these 25 sec. the reader will continuously blink in orange.
6. Repeat point 4&5 for each inger that should be enrolled.
7. Click on “Save New” and the ingerprint will be sent automatically to all Biometric Readers where that user has access, i.e. to
all the readers according to the Access Level assign to that user.
Example:
If the user has “Unlimited” Access level then the ingerprints will be sent to all readers, if the user has Access level only for
Reader1 and Reader 3 then the ingerprints will be sent only to those two readers.
Note:
To check if all the ingerprints are sent to the reader, right click on the reader and select “Memory Status”. (8.11)
In the event window a line will appear indicating the number of ingerprints stored in the reader. (8.12)
Note:
If more ingerprints are added for one user, all ingerprints will send the same Wiegand Code to the controller, the one written
in the ield User ID(card Number).).
8.3 ENROLLING FINGERPRINTS FROM DESKTOP READER

www.xprgroup.com 11
8.4 DELETING FINGERPRINTS
8.5 UPLOADING THE FINGERPRINTS TO THE BIOMETRIC READERS
In General, the ingerprints are stored in the Biometric reader and in the Software.
Deleting can be done only in the readers or from both places.
Deleting one user from the biometric reader
Select the User
Click on “Delete User”. The User together with its ingerprints will be deleted from both the software and the
ingerprint readers. (8.14)
Deleting all users from the biometric reader
Right click on the reader and select “Delete all users from reader” (8.15)
Delete one or more ingerprints
Select the User and open the “Biometric” tab
Go to the ingertip that needs to be deleted, right click and select ”Delete” for one inger or “Delete All” for all ingers
of the User.
Click “Save Changes”.
With this procedure the User’s ingerprints are deleted from the software and from the reader. (8.16)
Right click on the biometric reader
Select “Upload all users to reader”
While receiving the ingerprints the reader will blink in orange.
Note: Use this feature when you change or add a reader, if pending tasks are
deleted in the software or if there are doubts that ingerprints in the reader
memory are not synchronized with the software database.
In normal usage, the ingerprints are sent automatically and this feature is
not used.

www.xprgroup.com 12
8.6 FIRMWARE UPDATE
8.7 SEND CONFIGURATION
8.8 ADVANCED SETTINGS
Right-click on the reader and select Firmware update menu (8.18)
On the Firmware update window, click on the Browse button (8.19). The
default location of the irmware iles installed with PROS CS is in the folder
“Firmware”.
Select the irmware ile with a “xhc” extension.
Click on the Upload button
Important: Wait for the update end message. Do not turn o the reader, the
software or any communication device in between during the entire process.
· Right-click on the reader and select the Send
coniguration menu
· See the events panel to check the coniguration low
Note: The biometric reader gets its settings
automatically. This function is used if the reader was o
line while making the changes.
Send This ID for:
Unknown Finger sends the desired Wiegand when
an unknown inger is applied.
Backlight:
Backlight of the device (ON or OFF)
Buzzer:
Buzzer of the device (ON or OFF)
Finger Acceptance Flexibility:
Accepted tolerance. The recommended value is
“Automatic Secure”.
Sensitivity:
Bio-sensor sensitivity, the recommended value is 7,
most sensitive.

www.xprgroup.com 13
8.9 ENTRY MODE
8.9.1 Access Code or Finger
8.9.2 Access Code and Finger
8.9.3 Finger Only
Right click on the biometric reader
Select “Properties” and go to the “Biometric” tab
For Entry Mode select “Access Code or Finger” (8.20)
Note: All the ingers and the Access Code will send the
same wiegand number (8.21)
Right click on the biometric reader
Select “Properties” and go to the “Biometric” tab
For Entry Mode select “Access Code and Finger” (8.21)
Use of the double security mode:
Type the PIN Code (ex. 2279), in the next 8 sec. the
reader will blink in orange waiting for the inger.
Swipe the inger.
Right click on the biometric reader
Select “Properties” and go to the “Biometric” tab
For Entry Mode select “Finger” (8.22)
Note:
In this mode the keypad will become inactive.

www.xprgroup.com 14
Right-click on the portal connected to
the reader and select Add reader
Fill the Reader form
Right-click on reader and select Check Version
Click on Save and the reader icon appears
under the selected portal
9. CONFIGURING THE BIOMETRIC READERS IN BIOMANAGER
9.1 ADD PORTAL
9.2 ADD READER
BIOMANAGER CS is software for ingerprint management of XPR Biometric readers, when used with third party access
controllers.
Main functions:
- Fingerprint Enrollment
It can be done by ANY Biometric reader in the network or by Desktop (USB) Biometric reader.
- Fingerprint Transfer
Finger templates can be sent to any Reader in the Network. Dierent Users can be sent to dierent Biometric readers.
- PIN Codes management and transfer
PIN Code length coniguration (1 to 8 digits) and PIN Code transfer.
- Wiegand Output Coniguration
The Wiegand output of the Biometric reader can be customized bitwise.
Right-click on “Portal” and select “Add Portal”.
If the converter used for the Biometric Readers is RS485 to TCP/IP converter, then create Portal by adding the IP Address of
the converter.(9.1)
If the converter used for the Biometric Readers is RS485 to USB converter, then create Portal by adding the COM port of the
converter.(9.2)

www.xprgroup.com 15
9.3 EDIT READER
9.4 DELETE READER
If reader is online, new line is added on top of the event table
If reader is not online, following line is added on top of the event table
If reader is online, right click on reader and select Upload coniguration
Right-click on the reader and select Properties
Check at event table if coniguration was successful
Check at event table if coniguration was successful
Edit reader properties and click Save button
Right-click on the reader and select Delete reader

www.xprgroup.com 16
9.5 ADD USER
1. Open the Users Window and create a new user.
Click on “New User”, put a name and ID(card number) and Access Code. (8.7)
2. Select the reader(with left click) from which the enrollment will be done. (8.8)
3. Right click on the ingertip and select enroll. (8.9)
4. In the next 25 sec. swipe the inger on the selected reader min. 5 times and the inger tip will turn red. (8.10)
In these 25 sec. the reader will continuously blink in orange.
5. Repeat point 4&5 for each inger that should be enrolled.
6. Click on “Save New” and the ingerprint will be sent automatically to all Biometric Readers where that user has access, i.e. to
all the readers according to the Access Level assign to that user.
Example:
If the user has “Unlimited” Access level then the ingerprints will be sent to all readers, if the user has Access level only for
Reader1 and Reader 3 then the ingerprints will be sent only to those two readers.
Note:
To check if all the ingerprints are sent to the reader, right click on the reader and select “Memory Status”. (8.11)
In the event window a line will appear indicating the number of ingerprints stored in the reader. (8.12)
Note:
If more ingerprints are added for one user, all ingerprints will send the same Wiegand Code to the controller, the one written
in the ield User ID(card Number).

www.xprgroup.com 17
9.6 DELETING FINGERPRINTS
9.7 UPLOADING THE FINGERPRINTS TO THE BIOMETRIC READERS
In General, the ingerprints are stored in the Biometric reader and in the Software.
Deleting can be done only in the readers or from both places.
Deleting one user from the biometric reader
Select the User
Click on “Delete User”. The User together with its ingerprints will be deleted from both the software and the
ingerprint readers. (8.14)
Deleting all users from the biometric reader
Right click on the reader and select “Delete all users from reader” (8.15)
Delete one or more ingerprints
Select the User and open the “Biometric” tab
Go to the ingertip that needs to be deleted, right click and select ”Delete” for one inger or “Delete All” for all ingers
of the User.
Click “Save Changes”.
With this procedure the User’s ingerprints are deleted from the software and from the reader. (8.16)
Right click on the biometric reader
Select “Upload all users to reader”
While receiving the ingerprints the reader will blink in orange.
Note: Use this feature when you change or add a reader, if pending tasks are
deleted in the software or if there are doubts that ingerprints in the reader
memory are not synchronized with the software database.
In normal usage, the ingerprints are sent automatically and this feature is
not used.

www.xprgroup.com 18
9.8 CUSTOM WIEGAND
BIOMANAGER CS has deined Wiegand 26, 30, 34, 40 bit as standard options and other 3 Wiegand settings as user deinable.
To setup custom Wiegand format
Select Wiegand menu from Settings
At Wiegand setup window select one from customs Wiegand
Set Wiegand parameter
Click on Save button
Note:
Wiegand settings are out of scope for common end user. Please ask your installer to set the parameters and do not change it later.
For more information please refer to BIOMANAGER CS User Manual

www.xprgroup.com 19
10. WIEGAND PROTOCOL DESCRIPTION
The data is sent over the lines DATA 0 for the logic “0” and DATA 1 for the logic “1”. Both lines use inverted logic, meaning that a
pulse low on DATA 0 indicates a “0” and a pulse low on DATA 1 indicates a “1”.When the lines are high, no data is being sent. Only 1
of the 2 lines ( DATA 0 / DATA 1 ) can pulse at the same time.
Example: data 0010....
5V
5V
0V
0V
100 us
1 ms
Data bit 0 = approximately 100 us (microseconds)
Data bit 1 = approximately 100 us (microseconds)
Time between two data bits: approximately 1 ms (millisecond). Both data lines (D0 and D1) are high.
Description for the 26 bits Wiegand format
Each data block consists of a irst parity bit P1, a ixed 8 bits header, 16 bits of user code and a 2nd parity bit P2. Such a data block
is shown bellow:
Parity bit (bit 1) + 8 bits header + 16 bits user code = 2 bytes + Parity bit (bit 26)
P1 XXXXXXXX XXXXYYYY YYYYYYYY P2
Example: 170 31527
1 1 0 1 0 1 0 1 0 0 1 1 1 1 0 1 1 0 0 1 0 0 1 1 1 0
Note: Parity bits are calculated as follows:
P1 = even parity calculated over the bits 2 to 13 (X)
P2 = odd parity calculated over the bits 14 to 25 (Y)
Even
Parity
Bit
Even
Parity
Bit
Site Code Site Code

www.xprgroup.com 20
11. SAFETY PRECAUTIONS
Do not install the device in a place subject to direct sun light without protective cover.
Do not install the device and cabling close to a source of strong electro-magnetic ields like radio-transmitting antenna.
Do not place the device near or above heating equipments.
If cleaning, do not spray or splash water or other cleaning liquids but wipe it out with smooth cloth or towel.
Do not let children touch the device without supervision.
Note that if the sensor is cleaned by detergent, benzene or thinner, the surface will be damaged and the ingerprint can’t be
entered.
This product herewith complies with requirements of EMC directive 2014/30/EU. In addition it complies with RoHS2 directive EN50581:2012
